JUNOSe 11.1.x BGP and MPLS Configuration Guide
Table 29: Incoming L-LSP PHB Determination (continued)

Table 30: Examples of Incoming L-LSP PHB Determination

Table 31: Outgoing L-LSP PHB Determination

304
Classifying Traffic for Differentiated Services
PSC + EXP Field
AFn 001
AFn 010
AFn 011
EF 000
For nonstandard PHBs (any that are not listed in Table 29 on page 303), the
JUNOSe software uses mapping similar to AFn mapping; EXP 001 is mapped
to color green, EXP 010 is mapped to yellow, and EXP 011 is mapped to
red.
Table 30 on page 304 presents three examples that indicate how the PSC and
the EXP field are combined to determine the PHB for traffic on incoming
L-LSPs.
PSC + EXP Field
AF2 010
AF3 010
AF3 011
For outgoing L-LSPs, the EXP is determined by the PHB. Table 31 on page 304
indicates the PHB-to-EXP mapping for outgoing traffic on L-LSPs.
PHB = EXP Field
BE 000
CSn 000
AFn1 001
AFn2 010
AFn3 011
EF 000
= PHB
AFn1
AFn2
AFn3
EF
= PHB
AF22
AF32
AF33
