JUNOSe 11.1.x BGP and MPLS Configuration Guide
NOTE: To provide uninterrupted service during an SRP switchover in a scaled
configuration, such as one with 32,000 Martini circuits, set the LDP graceful restart
reconnect time to the maximum 300 seconds and set the LDP graceful restart recovery
timer to the maximum 600 seconds. This requirement is true for all SRP switchovers,
including those in the context of a unified in-service software upgrade.
This chapter describes how to configure different types of layer 2 services over MPLS.
Each procedure uses either the mpls-relay command or the route-interface command
to configure MPLS tunneling.
Related Topics
Configuring Frame Relay Layer 2 Services
To configure Frame Relay layer 2 services over MPLS with the RFC-4619 Frame Relay
pseudowire type:
1.
2.
3.
Configuring Interoperation with Legacy Frame Relay Layer 2 Services
To configure the router to interoperate with a router that uses the legacy Frame Relay
pseudowire type for layer 2 services over MPLS:
1.
530
Configuring Frame Relay Layer 2 Services
Layer 2 Services over MPLS Overview on page 509
For more information about configuring MPLS and the layer 2 interfaces that
support L2VPNs, see Layer 2 Services over MPLS References on page 511
Configure the Frame Relay interface.
host1(config)#interface serial 4/1:1/1
host1(config-if)#encapsulation frame-relay ietf
host1(config-if)#frame-relay intf-type dte
host1(config-if)#frame-relay lmi-type ansi
host1(config-if)#interface serial 4/1:1/1.1
host1(config-subif)#frame-relay interface-dlci 17 ietf
Specify MPLS tunneling by using the appropriate command.
host1(config-if)#mpls-relay 10.10.100.2 45
or
host1(config-if)#route interface tunnel mpls:tunnel6 45
Configure Frame Relay and MPLS on the remote PE router.
Configure the Frame Relay interface.
host1(config)#interface serial 4/1:1/1
host1(config-if)#encapsulation frame-relay ietf
host1(config-if)#frame-relay intf-type dte
host1(config-if)#frame-relay lmi-type ansi
