JUNOSe 11.1.x BGP and MPLS Configuration Guide

Table 59: show mpls rsvp hello instance Output Fields

364
Monitoring RSVP-TE Hello Adjacency Instances
Field Name Field Description
Peer Address Address of the peer in the RSVP-TE hello adjacency
Interface Specifier and status of each interface
any Identifies an RSVP-TE node hello peer
Interval Interval at which hellos are sent to the neighbor, in milliseconds
Miss Limit Number of hello messages from the neighbor that can be missed
before the adjacency is considered to be down
State State of the adjacency with the neighbor:
AdjLost Adjacency has been lost. Hellos were received from the peer but
have timed out. The peer is known to be capable of graceful restart,
so the router is waiting for hellos to resume from the peer. The
router is actively sending hellos to the peer.
The router declares the peer to be dead if it does not receive hellos
from the peer during the peer's advertised recovery period.
The router declares the peer to be gracefully restarting if hellos are
seen from the peer and its sequence number has changed.
The router declares the peer to be up if hellos are seen from the
peer and its sequence number has not changed.
Dead Hellos were received from the peer but have timed out. The router
is not in graceful restart helper mode. The router changes the local
hello sequence number and does not send hellos to the peer. The
router transitions to Down if new control traffic needs to be sent
to the peer or if the peer starts sending control traffic.
Down No hellos have been received from the peer. The router is actively
sending hellos to the peer.
GR Graceful restart in progress. The hello sequence number from the
peer changed. The router is in graceful restart helper mode and
actively sending hellos to the peer.
Up Hellos were received from the peer. The router is actively sending
hellos to the peer.
Neighbor IP address of remote hello adjacency peer
Local Address IP address of the local hello adjacency peer
Restart Time Graceful restart time, in milliseconds
Recovery Time Graceful restart recovery time, in milliseconds
