JUNOSe 11.1.x BGP and MPLS Configuration Guide
Table 105 on page 676 lists the show ip bgp l2vpn command output fields
Meaning

Table 105: show ip bgp l2vpn Output Fields

676
Monitoring BGP-Related Settings for VPWS L2VPNs
Route Distinguisher (RD) is 100:23
Original Route Distinguisher (RD) is 100:23
MPLS in-label is none
MPLS in-label block size is 0
MPLS out-label is 106
MPLS out-label block size is 10
Next hop IP address is 2.2.2.2 (metric 3)
Multi-exit discriminator is not present
Local preference is 100
Weight is 0
Origin is IGP
AS path is empty
Extended communities RT:100:3 Layer2:atm-vcc-cell:use-cw,use-seq,:mtu=0
Status Vector 0x7fc0
Field Name Field Description
Local BGP identifier IP address of the local PE router
local AS Autonomous system number
Local-RIB version Version number of the local routing information base
FIB version Version number of the forwarding information base
Status codes Status codes for the route, listed before the Prefix:
Prefix Route prefix in the format siteID:blockOffset
Peer IP address of the peer from which the route was learned
Next-hop (or Next hop IP IP address of the next router that is used when a packet is
address) forwarded to the destination network
MED Multiexit discriminator for the route
LocPrf Local preference for the route
Weight Weight of the route
Origin Origin of the route
AS Path AS path through which this route has been advertised
> best route
* invalid route
s suppressed route
d dampened route
r rejected route
a auto-summarized
m multihomed backup route
