Page 9 Installing Junos OS ..........77 Downloading Software Packages from Juniper Networks ....77 Installing Software on an EX Series Switch with a Single Routing Engine (CLI Procedure) .
Page 76: Part 5 Junos Os For Ex Series Switches System Setup
Table 60: Class-of-Service (CoS) Features ......369 Table 61: High Availability and Resiliency Features ..... . . 369 lxxvi Copyright © 2010, Juniper Networks, Inc.
Page 91: Ex4200 Switches
Component descriptions, site preparation, installation, replacement, and safety and compliance information for EX3200 and EX4200 switches Complete Hardware Guide for EX4500 Switches Component descriptions, site preparation, installation, replacement, and safety and compliance information for EX4500 switches Copyright © 2010, Juniper Networks, Inc.
Page 92 OS for EX Series Switches, Release 10.3: Power Management ® Junos OS for EX Series Switches, Release 10.3: Routing Policy and Packet Filtering ® Junos OS for EX Series Switches, Release 10.3: Software Installation xcii Copyright © 2010, Juniper Networks, Inc.
Page 93: Downloading Software
You can download Junos OS for EX Series switches from the Download Software area http://www.juniper.net/customers/support/ . To download the software, you must have a Juniper Networks user account. For information about obtaining an account, see http://www.juniper.net/entitlement/setupAccountInfo.do Copyright © 2010, Juniper Networks, Inc.
Page 94 IP addresses; configuration ospf area area-id] hierarchy level. hierarchy levels; or labels on routing The console port is labeled CONSOLE platform components. < > (angle brackets) Enclose optional keywords or variables. stub <default-metric metric>; xciv Copyright © 2010, Juniper Networks, Inc.
Page 95: Documentation Feedback
We encourage you to provide feedback, comments, and suggestions so that we can improve the documentation. Send e-mail to with the techpubs-comments@juniper.net following: Document URL or title Page number if applicable Software version Your name and company Copyright © 2010, Juniper Networks, Inc.
Page 96: Requesting Technical Support
7 days a week, 365 days a year. Self-Help Online Tools and Resources For quick and easy problem resolution, Juniper Networks has designed an online self-service portal called the Customer Support Center (CSC) that provides you with the following features: Find CSC offerings: http://www.juniper.net/customers/support/...
Page 97: Junos Os For Ex Series Switches Product Overview
PART 1 Junos OS for EX Series Switches Product Overview Software Overview on page 3 Supported Hardware on page 25 Copyright © 2010, Juniper Networks, Inc.
Page 99: Software Overview
EX Series Switch Software Features Overview The following tables list the Juniper Networks EX Series Ethernet Switches software features and the Juniper Networks Junos operating system (Junos OS) release in which they were introduced: Table 1 on page 4—Access Control Features Table 2 on page 5—Administration Features...
Page 100: Table 1: Access Control Features
Junos OS 10.1R1 9.0R2 10.2R1 9.4R1 Server fail fallback Junos OS Junos OS Junos OS Junos OS 10.1R1 9.3R2 10.2R1 10.2R1 TACACS+ Junos OS Junos OS Junos OS Junos OS 10.1R1 9.0R2 10.2R1 9.4R1 Copyright © 2010, Juniper Networks, Inc.
Page 101: Table 2: Administration Features
EX4500 Switches EX8200 Switches Graceful protocol restart for BGP Not applicable Junos OS 9.0R2 Not applicable Junos OS 9.4R1 Graceful protocol restart for IS-IS Not applicable Junos OS 9.3R2 Not applicable Junos OS 9.4R1 Copyright © 2010, Juniper Networks, Inc.
Page 102 Split and merge Virtual Chassis Not applicable Junos OS 10.0R1 Not applicable Not applicable (EX4200 only) Automatic software update on prospective member switches Front-panel configuration of uplink module ports as Virtual Chassis ports (VCPs) Copyright © 2010, Juniper Networks, Inc.
Page 103: Table 5: Interfaces Features
Junos OS 9.3R2 Not supported Not supported Local DHCP server Not supported Junos OS 9.3R2 Not supported Junos OS 9.4R1 Static addresses Junos OS 10.1R1 Junos OS 9.0R2 Junos OS 10.2R1 Junos OS 9.4R1 Copyright © 2010, Juniper Networks, Inc.
Page 104: Table 7: Ipv6 Features
Junos OS 10.0R1 Not supported Junos OS 10.0R1 (MVRP) Private VLANs (PVLANs) Not supported Junos OS 9.3R2 Not supported Junos OS 10.1R1 Proxy ARP—restricted Junos OS 10.1R1 Junos OS 10.0R1 Junos OS 10.2R1 Junos OS 10.0R1 Copyright © 2010, Juniper Networks, Inc.
Page 105: Table 9: Layer 3 Protocols Features
Junos OS 9.4R1 Table 9: Layer 3 Protocols Features EX3200 and EX4200 Feature EX2200 Switches Switches EX4500 Switches EX8200 Switches Bidirectional Forwarding Detection Not supported Junos OS 9.0R2 Junos OS 10.2R1 Junos OS 9.4R1 (BFD) Copyright © 2010, Juniper Networks, Inc.
Page 106 VRF with IPv4—virtual routing Not supported Junos OS 10.0R1 Not supported Junos OS 10.0R1 instances for multicast traffic VRF with IPv6—virtual routing Not supported Junos OS 10.1R1 Not supported Junos OS 10.1R1 instances for multicast traffic Copyright © 2010, Juniper Networks, Inc.
Page 107 Not supported Junos OS 9.4R1 Junos OS 10.2R1 Junos OS 9.4R1 (MSDP) http://www.juniper.net/techpubs/software/junos/index.html See the Junos OS Multicast Configuration Guide at Multicast VLAN registration (MVR) Not supported Junos OS 9.6R1 Not supported Not supported Copyright © 2010, Juniper Networks, Inc.
Page 108: Table 12: Network Management And Monitoring Features
VLAN on the intermediate switch Real-time performance monitoring Junos OS 10.1R1 Junos OS 9.3R2 Junos OS 10.2R1 Junos OS 10.1R1 (RPM) RMON Junos OS 10.1R1 Junos OS 9.0R2 Junos OS 10.2R1 Junos OS 9.4R1 Copyright © 2010, Juniper Networks, Inc.
Page 109: Table 13: Port Security Features
EX4500 Switches EX8200 Switches Autoinstallation of configuration files Junos OS 10.1R1 Junos OS 9.4R1 Junos OS 10.2R1 Not supported Automatic software download Junos OS 10.1R1 Junos OS 9.6R1 Junos OS 10.2R1 Junos OS 9.6R1 Copyright © 2010, Juniper Networks, Inc.
Page 110: Layer 3 Protocols Supported On Ex Series Switches
See the Junos OS Routing Protocols Configuration Guide at http://www.juniper.net/techpubs/software/junos/ Fully supported. See the Junos OS Routing Protocols Configuration Guide at http://www.juniper.net/techpubs/software/junos/ ICMP Fully supported. See the Junos OS Routing Protocols Configuration Guide at http://www.juniper.net/techpubs/software/junos/ Copyright © 2010, Juniper Networks, Inc.
Page 111: Layer 3 Protocols Not Supported On Ex Series Switches
EX Series Switch Software Features Overview on page 3 Layer 3 Protocols Not Supported on EX Series Switches EX Series switches do not support the Junos OS Layer 3 protocols and features listed in Table 16 on page 16: Copyright © 2010, Juniper Networks, Inc.
Page 112 Policy statements related to NAT OSPF statement demand-circuit label-switched-path and subordinate statements neighbor statement within an OSPF area and subordinate statements within an OSPF area peer-interface statement sham-link statement te-metric PIM SM Not supported on EX2200 switches Copyright © 2010, Juniper Networks, Inc.
Page 113 (On EX Series switches, port mirroring is implemented using the port-mirroring statement.) analyzer and subordinate statements sampling Related Layer 3 Protocols Supported on EX Series Switches on page 14 Documentation EX Series Switch Software Features Overview on page 3 Copyright © 2010, Juniper Networks, Inc.
Page 114: Security Features For Ex Series Switches Overview
OS for EX Series Ethernet Switches, Release 10.3 Security Features for EX Series Switches Overview Juniper Networks Junos operating system (Junos OS) is a network operating system that has been hardened through the separation of control forwarding and services planes, with each function running in protected memory.
Page 115 802.1X for EX Series Switches Overview on page 2531 Documentation Firewall Filters for EX Series Switches Overview on page 3001 Port Security for EX Series Switches Overview on page 2825 Understanding Proxy ARP on EX Series Switches on page 1301 Copyright © 2010, Juniper Networks, Inc.
Page 116: High Availability Features For Ex Series Switches Overview
High availability refers to the hardware and software components that provide redundancy and reliability for packet-based communications. This topic covers the following high availability features of Juniper Networks EX Series Ethernet Switches: VRRP on page 20 Graceful Protocol Restart on page 20...
Page 117 The master Routing Engine, which is in the master of the Virtual Chassis configuration, runs Juniper Networks Junos operating system (Junos OS) in the master role. It receives and transmits routing information, builds and maintains routing tables, communicates with interfaces and Packet Forwarding Engine components of the member switches, and has full control over the Virtual Chassis configuration.
Page 118 Configuration Guide at http://www.juniper.net/techpubs/software/junos/index.html Virtual Chassis Overview on page 921 Understanding Virtual Chassis Components on page 924 Understanding Virtual Chassis Configurations and Link Aggregation on page 932 Understanding VRRP on EX Series Switches on page 1671 Copyright © 2010, Juniper Networks, Inc.
Page 119: Understanding Software Infrastructure And Processes
Chapter 1: Software Overview Understanding Software Infrastructure and Processes Each switch runs the Juniper Networks Junos operating system (Junos OS) for Juniper Networks EX Series Ethernet Switches on its general-purpose processors. Junos OS includes processes for Internet Protocol (IP) routing and for managing interfaces, networks, and the chassis.
Page 120: Table 17: Junos Os Processes
For more information about processes, see the Junos OS Network Operations Guide at Documentation http://www.juniper.net/techpubs/software/junos/index.html For more information about basic system parameters, supported protocols, and software processes, see Junos OS System Basics Configuration Guide at http://www.juniper.net/techpubs/software/junos/index.html Copyright © 2010, Juniper Networks, Inc.
Page 121: Ex4500 Switch Models
Juniper Networks Junos operating system (Junos OS), which provides Layer 2 and Layer 3 switching, routing, and security services. The same Junos OS code base that runs on EX Series switches also runs on all Juniper Networks J Series, M Series, MX Series, and T Series routers.
Page 122: Software
Juniper Networks Junos operating system (Junos OS), which provides Layer 2 and Layer 3 switching, routing, and security services. The same Junos OS code base that runs on EX Series switches also runs on all Juniper Networks J Series, M Series, MX Series, and T Series routers.
Page 123 You can connect individual EX4200 switches together to form one unit and manage the unit as a single chassis, called a Virtual Chassis. You can add more member switches to the Virtual Chassis as needed, up to a total of 10 members. Copyright © 2010, Juniper Networks, Inc.
Page 124 Related EX3200 Switch Models on page 29 Documentation EX4200 Switch Models on page 29 Field-Replaceable Units in EX3200 and EX4200 Switches Site Preparation Checklist for EX3200 and EX4200 Switches Copyright © 2010, Juniper Networks, Inc.
Page 125: Ex3200 Switch Models
EX4200-48P 48 Gigabit Ethernet All 48 ports 930 W EX4200-24F 24 small form-factor pluggable Not applicable 320 W (SFP) transceivers Related EX3200 Switch Models on page 29 Documentation Front Panel of an EX4200 Switch Copyright © 2010, Juniper Networks, Inc.
Page 126: Ex4500 Switches Hardware Overview
The Juniper Networks EX Series Ethernet Switches run Junos OS, which provides Layer 2 and Layer 3 switching, routing, and security services. The same Junos OS code base that runs on EX Series switches also runs on all Juniper Networks J Series, M Series, MX Series, and T Series routers.
Page 127 EX4500 switch. Each uplink module provides four SFP+ ports for connecting to core devices in a data center. You can install SFP or SFP+ transceivers in these ports. Related EX4500 Switch Models on page 32 Documentation Field-Replaceable Units in EX4500 Switches Copyright © 2010, Juniper Networks, Inc.
Page 128: Ex4500 Switch Models
SFP/SFP+ One fan tray (with orange intake label visible) One AC power supply (with orange ejector lever) One power cord One power supply cover panel Two uplink module cover panels One intraconnect module Copyright © 2010, Juniper Networks, Inc.
Page 129 Routing Engines, switch fabric, fan tray, and power supplies. You can manage EX8208 switches using the same interfaces that you use for managing other devices running the Juniper Networks Junos operating system (Junos OS)—the command-line interface (CLI), the J-Web graphical interface, and the Network and Security Manager (NSM).
Page 130: Software
OS for EX Series Ethernet Switches, Release 10.3 Software The Juniper Networks EX Series Ethernet Switches run under the Juniper Networks Junos OS, which provides Layer 2 and Layer 3 switching, routing, and security services. The same Junos OS code base that runs on EX Series switches also runs on all Juniper Networks J Series, M Series, MX Series, and T Series routers.
Page 131: Routing Engines And Switch Fabric
EX8200 Switch. Cooling System The cooling system in an EX8208 switch consists of a hot-removable and hot-insertable fan tray. The fan tray contains 12 fans. The fan tray installs vertically on the left front of Copyright © 2010, Juniper Networks, Inc.
Page 132: Power Supplies
Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 189 EX8216 Switch Hardware Overview The Juniper Networks EX8216 Ethernet Switch is a half-rack, midplane architecture, modular Ethernet switch that is designed for ultra high-density environments such as campus aggregation, data center, or high performance core switching environments.
Page 133: Chassis Physical Specifications, Lcd Panel, And Midplane
Juniper Networks Junos OS, which provides Layer 2 and Layer 3 switching, routing, and security services. The same Junos OS code base that runs on EX Series switches also runs on all Juniper Networks J Series, M Series, MX Series, and T Series routers.
Page 135: Routing Engines And Switch Fabric
System management and system control functions of an EX8216 switch are performed by the Routing Engine (RE) module. An RE module contains a Routing Engine. The RE modules are hot-insertable and hot-removable field-replaceable units (FRUs) that are Copyright © 2010, Juniper Networks, Inc.
Page 136: Cooling System
(FRU) fan trays. Each fan tray contains nine fans. Both fan trays install vertically on the left front of the chassis and provide side-to-side chassis cooling and front-to-side cooling. The top and bottom fan trays are identical and interchangeable. Copyright © 2010, Juniper Networks, Inc.
Page 137: Power Supplies
Field-Replaceable Units in an EX8216 Switch Documentation Slot Numbering for an EX8216 Switch Connecting and Configuring an EX Series Switch (CLI Procedure) on page 187 Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 189 Copyright © 2010, Juniper Networks, Inc.
Page 139: Chapter 3 Complete Software Configuration Statement Hierarchy
PART 2 Complete Software Configuration Statement Hierarchy Complete Software Configuration Statement Hierarchy on page 45 Copyright © 2010, Juniper Networks, Inc.
Page 141: Edit Access] Configuration Statement Hierarchy
[ radius | none ]; accounting-stop-on-access-deny; accounting-stop-on-failure; authentication-order [ authentication-method ]; radius { accounting-server [ server-address ]; authentication-server [ server-address ]; Related Example: Connecting a RADIUS Server for 802.1X to an EX Series Switch on page 2545 Documentation Copyright © 2010, Juniper Networks, Inc.
Page 142: Edit Chassis] Configuration Statement Hierarchy
[edit class-of-service] Configuration Statement Hierarchy class-of-service { classifiers { (dscp | ieee-802.1 | inet-precedence) classifier-name { import (classifier-name | default); forwarding-class class-name { loss-priority loss-priority { code-points [ aliases ] [ 6 bit-patterns ]; Copyright © 2010, Juniper Networks, Inc.
Page 143 { scheduler-name { buffer-size (percent percentage | remainder); drop-profile-map loss-priority loss-priority protocol protocol drop-profile profile-name; priority priority; shaping-rate (rate | percent percentage); transmit-rate (rate | percent percentage | remainder); Copyright © 2010, Juniper Networks, Inc.
Page 144: Edit Ethernet-Switching-Options] Configuration Statement Hierarchy
(vlan-id | vlan-name); egress { interface (all | interface-name); output { interface interface-name; vlan (vlan-id | vlan-name); bpdu-block { disable-timeout timeout; interface (all | [interface-name]); dot1q-tunneling { ether-type (0x8100 | 0x88a8 | 0x9100); Copyright © 2010, Juniper Networks, Inc.
Page 145 { prefix hostname | mac | none; use-interface-description; use-string string; vendor-id [string]; (examine-dhcp | no-examine-dhcp ); (ip-source-guard | no-ip-source-guard); mac-move-limit limit action action; storm-control { action-shutdown; interface (all | interface-name) { Copyright © 2010, Juniper Networks, Inc.
Page 146: Edit Firewall] Configuration Statement Hierarchy
Understanding MAC Notification on EX Series Switches on page 1302 [edit firewall] Configuration Statement Hierarchy firewall { family family-name { filter filter-name { interface-specific; term term-name { from { match-conditions; then { action; action-modifiers; Copyright © 2010, Juniper Networks, Inc.
Page 147: Edit Forwarding-Options] Configuration Statement Hierarchy
{ prefix hostname | mac | none; use-interface-description; use-string string; vendor-id <string>; interface interface-name { dhcp-option82 { circuit-id { prefix hostname; use-interface-description; use-vlan-id; remote-id { prefix hostname | mac | none; use-interface-description; use-string string; Copyright © 2010, Juniper Networks, Inc.
Page 148: Edit Interfaces] Configuration Statement Hierarchy
(traps | no-traps); unit logical-unit-number { description text; disable; family family-name {...} proxy-arp (restricted | unrestricted); (traps | no-traps); vlan-id vlan-id-number; vlan-tagging; fe-fpc/pic/port { description text; disable; Copyright © 2010, Juniper Networks, Inc.
Page 149 {...} proxy-arp (restricted | unrestricted); rpm; (traps | no-traps); vlan-id vlan-id-number; vlan-tagging; interface-range interface-range name { description text; disable; ether-options { 802.3ad aex { lacp { force-up; (auto-negotiation | no-auto-negotiation); (flow-control| no-flow-control); Copyright © 2010, Juniper Networks, Inc.
Page 150 {...} (traps | no-traps); vlan-id vlan-id-number; vlan-tagging; vlan { description text; disable; hold-time up milliseconds down milliseconds; mtu bytes; no-gratuitous-arp-request; traceoptions; (traps | no-traps); unit logical-unit-number { description text; Copyright © 2010, Juniper Networks, Inc.
Page 151 (auto-negotiation | speed); hold-time up milliseconds down milliseconds; mtu bytes; no-gratuitous-arp-request; traceoptions; (traps | no-traps); unit logical-unit-number { description text; disable; family family-name {...} proxy-arp (restricted | unrestricted); rpm; (traps | no-traps); vlan-id vlan-id-number; vlan-tagging; Copyright © 2010, Juniper Networks, Inc.
Page 152: Edit Poe] Configuration Statement Hierarchy
Configuring PoE (CLI Procedure) on page 3315 PoE and EX Series Switches Overview on page 3303 [edit protocols] Configuration Statement Hierarchy protocols { connections { remote-interface-switch connection-name { interface interface-name.unit-number; transmit-lsp label-switched-path; receive-lsp label-switched-path; Copyright © 2010, Juniper Networks, Inc.
Page 153 (detail | disable | receive | send); vlan (vlan-id | vlan-number) { data-forwarding { source { groups group-prefix; receiver { source-vlans vlan-list; install ; disable { interface interface-name immediate-leave; interface interface-name { Copyright © 2010, Juniper Networks, Inc.
Page 154 { what number; country-code code; ca-type { number { ca-value value; mpls { interface ( all | interface-name ); label-switched-path lsp-name to remote-provider-edge-switch; path destination { <address | hostname> <strict | loose> mstp { Copyright © 2010, Juniper Networks, Inc.
Page 155 (all | interface-name) { disable; join-timer milliseconds; leave-timer milliseconds; leaveall-timer milliseconds; registration (forbidden | normal); no-dynamic-vlan; traceoptions { file filename <files number > <size size> <no-stamp | world-readable | no-world-readable>; flag flag; oam { ethernet{ connectivity-fault-management { Copyright © 2010, Juniper Networks, Inc.
Page 156 { link-adjacency-loss; link-event-rate; frame-error count; frame-period count; frame-period-summary count; symbol-period count; interface interface-name { link-discovery (active | passive); pdu-interval interval; event-thresholds threshold-value; remote-loopback; event-thresholds { frame-errorcount; frame-period count; frame-period-summary count; symbol-period count; Copyright © 2010, Juniper Networks, Inc.
Page 157 { ip-address; udp-port port-number; disable; interfaces interface-name { disable; polling-interval seconds; sample-rate number; polling-interval seconds; sample-rate number; source-ip stp { disable; bridge-priority priority; forward-delay seconds; hello-time seconds; interface (all | interface-name) { disable; Copyright © 2010, Juniper Networks, Inc.
Page 158 Example: Configure Automatic VLAN Administration Using GVRP on page 1329 Understanding MAC RADIUS Authentication on EX Series Switches Understanding Server Fail Fallback and 802.1X Authentication on EX Series Switches on page 2536 IGMP Snooping on EX Series Switches Overview on page 2315 Copyright © 2010, Juniper Networks, Inc.
Page 159: Edit Routing-Instances] Configuration Hierarchy
[edit snmp] Configuration Statement Hierarchy snmp { rmon { history index { bucket-size number; interface interface-name; interval seconds; owner owner-name; Related Configuring SNMP (J-Web Procedure) on page 3603 Documentation Junos OS Network Management Configuration Guide at http://www.juniper.net/techpubs/software/junos/index.html Copyright © 2010, Juniper Networks, Inc.
Page 160: Edit Virtual-Chassis] Configuration Statement Hierarchy
[edit vlans] Configuration Statement Hierarchy vlans { vlan-name { description text-description; dot1q-tunneling { customer-vlans (id | native | range); layer2-protocol-tunneling all | protocol-name { drop-threshold number; shutdown-threshold number; filter input filter-name; filter output filter-name; interface interface-name { Copyright © 2010, Juniper Networks, Inc.
Page 161 Example: Setting Up Q-in-Q Tunneling on EX Series Switches on page 1347 Example: Configuring Layer 2 Protocol Tunneling on EX Series Switches on page 1368 Creating a Private VLAN (CLI Procedure) on page 1385 Understanding Q-in-Q Tunneling on EX Series Switches on page 1293 Copyright © 2010, Juniper Networks, Inc.
Page 163: Chapter 4 Software Installation Overview
Registering the Switch, Booting the Switch, Upgrading Software, and Managing Licenses on page 87 Verifying Software Installation on page 95 Troubleshooting Software Installation on page 99 Configuration Statements for Software Installation on page 103 Operational Mode Commands for Software Installation on page 105 Copyright © 2010, Juniper Networks, Inc.
Page 165: Understanding Software Installation On Ex Series Switches
Understanding System Snapshot on EX Series Switches on page 72 Understanding Software Installation on EX Series Switches A Juniper Networks EX Series Ethernet Switch is delivered with Juniper Networks Junos operating system (Junos OS) preinstalled. As new features and software fixes become available, you must upgrade your software to use them.
Page 166: Software Package Security
Chassis or to only a particular member. Installing Software on EX8200 Switches with Redundant Routing Engines To install software on a Juniper Networks EX8200 Ethernet Switch that has two Routing Engines with minimal network disruption, you perform a Junos OS installation on each Routing Engine separately, starting with the backup.
Page 167: Junos Os Package Names
Procedure) on page 79 Junos OS Package Names You upgrade the Juniper Networks Junos operating system (Junos OS) on a Juniper Networks EX Series Ethernet Switch by copying a software package to your switch or another system on your local network, then install the new software package on the switch.
Page 168: Understanding System Snapshot On Ex Series Switches
Understanding Software Installation on EX Series Switches on page 69 Understanding System Snapshot on EX Series Switches You can create copies of the software running a Juniper Networks EX Series Ethernet Switch using the system snapshot feature. The system snapshot feature takes a “snapshot”...
Page 169: Understanding Software Licenses For The Ex Series Switch
Chapter 4: Software Installation Overview Understanding Software Licenses for the EX Series Switch To enable and use some Juniper Networks Junos operating system (Junos OS) features, you must purchase, install, and manage separate software licenses. The presence on the switch of the appropriate software license keys (“passwords”) determines whether you are eligible to configure and use certain features.
Page 170: License Warning Messages
License Key Components for the EX Series Switch When you purchase a license for a Junos OS feature that requires a separate license, you receive a license key. A license key consists of two parts: Copyright © 2010, Juniper Networks, Inc.
Page 171 Managing Licenses for the EX Series Switch (CLI Procedure) on page 91 Documentation Managing Licenses for the EX Series Switch (J-Web Procedure) on page 92 Understanding Software Licenses for the EX Series Switch on page 73 Copyright © 2010, Juniper Networks, Inc.
Page 173: Downloading Software Packages From Juniper Networks
To download software upgrades from Juniper Networks: Using a Web browser, follow the links to the download URL on the Juniper Networks webpage. For EX Series, there are not separate software packages for Canada the U.S. and other locations. Therefore, select Canada and U.S. Version regardless of your location: https://www.juniper.net/support/csc/swdist-domestic/...
Page 174 To install software upgrades on an EX Series switch with a single Routing Engine using the CLI: Download the software package as described in “Downloading Software Packages from Juniper Networks” on page 77. (Optional) Back up the current software configuration to a second storage option. See the Junos OS Installation and Upgrade Guide at http://www.juniper.net/techpubs/software/junos/index.html...
Page 175: Preparing The Switch For The Software Installation
Installing Software on the Default Master Routing Engine on page 82 Returning Routing Control to the Default Master Routing Engine (Optional) on page 83 Preparing the Switch for the Software Installation Perform the following steps before installing the software: Copyright © 2010, Juniper Networks, Inc.
Page 176 Exit out of the CLI configuration mode: [edit] user@switch# exit (Optional) Back up the current software configuration to a second storage option. See the Junos OS Installation and Upgrade Guide at http://www.juniper.net/techpubs/software/junos/index.html for instructions on performing this task. Copyright © 2010, Juniper Networks, Inc.
Page 177: Installing Software On The Backup Routing Engine
Download the software by following the procedures in “Downloading Software Packages from Juniper Networks” on page 77. Copy the software package to the switch. We recommend that you use FTP to copy the file to the /var/tmp directory.
Page 178: Installing Software On The Default Master Routing Engine
[edit] user@switch# activate chassis redundancy graceful-switchover Re-enabling GRES allows any future Routing Engine switchovers to occur without the loss of any network traffic. Enter the command to save the configuration change: commit synchronize [edit] Copyright © 2010, Juniper Networks, Inc.
Page 179: Installing Software On Ex Series Switches (J-Web Procedure)
You can use the J-Web interface to install software upgrades from a server using FTP or HTTP, or by copying the file to the EX Series switch. This topic describes: Installing Software Upgrades from a Server on page 84 Installing Software Upgrades by Uploading Files on page 84 Copyright © 2010, Juniper Networks, Inc.
Page 180: Installing Software Upgrades From A Server
Download the software package as described in “Downloading Software Packages from Juniper Networks” on page 77. Log in to the Juniper Networks authentication system using the username (generally your e-mail address) and password supplied by Juniper Networks representatives. In the J-Web interface, select Maintain>Software>Install Package.
Page 181: Rebooting Or Halting The Ex Series Switch (J-Web Procedure)
If the reboot is scheduled to occur immediately, the switch reboots. You cannot access the J-Web interface until the switch has restarted and the boot sequence is complete. After the reboot is complete, refresh the browser window to display the J-Web interface login page. Copyright © 2010, Juniper Networks, Inc.
Page 182 If the switch is halted, all software processes stop and you can access the switching platform through the console port only. Reboot the switch by pressing any key on the keyboard. Related Starting the J-Web Interface on page 152 Documentation Copyright © 2010, Juniper Networks, Inc.
Page 183: Managing Licenses
Booting the Switch Booting an EX Series Switch Using a Software Package Stored on a USB Flash Drive on page 88 Creating a Snapshot and Using It to Boot an EX Series Switch on page 89 Copyright © 2010, Juniper Networks, Inc.
Page 184: Flash Drive
Download the Junos OS package that you would like to place onto the EX Series switch from the Internet onto the USB flash drive using your computer or other device. See “Downloading Software Packages from Juniper Networks” on page 77. Remove the USB flash drive from the computer or other device.
Page 185: Creating A Snapshot And Using It To Boot An Ex Series Switch
/config /var the running Juniper Networks Junos OS, the active configuration, and the rescue configuration—and copies all of these files into an alternate (internal, meaning internal flash, or an external, meaning USB flash) memory source. You can then use these snapshots to boot the switch at the next bootup or as a backup boot option.
Page 186: Switch
If you enable automatic software download, the DHCP client EX Series switch compares the software package name in the DHCP server message to the name of the software package that booted the switch. If the software packages are different, the DHCP client Copyright © 2010, Juniper Networks, Inc.
Page 187: Managing Licenses For The Ex Series Switch (Cli Procedure)
Before you begin managing licenses, be sure that you have: Obtained the needed licenses. For information about how to purchase software licenses, contact your Juniper Networks sales representative. Copyright © 2010, Juniper Networks, Inc.
Page 188: Adding New Licenses
Managing Licenses for the EX Series Switch (J-Web Procedure) To enable and use some Junos OS features on an EX Series switch, you must purchase, install, and manage separate software licenses. Each switch requires one license. For a Copyright © 2010, Juniper Networks, Inc.
Page 189: Deleting Licenses
Before you begin managing licenses, be sure that you have: Obtained the needed licenses. For information about how to purchase software licenses, contact your Juniper Networks sales representative. Understand what makes up a license key. For more information, see “License Key Components for the EX Series Switch”...
Page 190: Downloading Licenses
Managing Licenses for the EX Series Switch (CLI Procedure) on page 91 Documentation Monitoring Licenses for the EX Series Switch on page 96 Understanding Software Licenses for the EX Series Switch on page 73 Copyright © 2010, Juniper Networks, Inc.
Page 191: Chapter 7 Verifying Software Installation
The sample output in DHCP options shows that the last DHCP server message to arrive on the DHCP client had a boot server address of and a 192.168.1.165 boot file named . If automatic software jinstall-ex-4200-9.6R1.5-domestic-signed.tgz Copyright © 2010, Juniper Networks, Inc.
Page 192: Verifying That A System Snapshot Was Created On An Ex Series Switch
To enable and use some Junos OS features on the EX Series switch, you must purchase, install, and manage the appropriate software licenses. Each switch requires one license. For a Virtual Chassis deployment, two licenses are recommended for redundancy. Copyright © 2010, Juniper Networks, Inc.
Page 193: Licenses
Licenses needed The appropriate number of licenses is installed. Each switch requires one license. For a Virtual Chassis deployment, two licenses are recommended for redundancy. The expected license is installed. Copyright © 2010, Juniper Networks, Inc.
Page 194: Displaying Installed License Keys
Managing Licenses for the EX Series Switch (CLI Procedure) on page 91 Documentation Managing Licenses for the EX Series Switch (J-Web Procedure) on page 92 Understanding Software Licenses for the EX Series Switch on page 73 Copyright © 2010, Juniper Networks, Inc.
Page 195: Troubleshooting Software Installation
—Use this option to wipe the installation media before installing the software package. If you do not include this option, the system installs the new Junos OS package in a different partition from that of the most recently installed Junos OS package. Copyright © 2010, Juniper Networks, Inc.
Page 196: Rebooting From The Inactive Partition
NOTE: If you have completed the installation of the software image but have not yet rebooted, you can issue the request system software rollback command to return to the original software installation package. Solution Reboot from the inactive partition: user@switch> request system reboot partition alternate Copyright © 2010, Juniper Networks, Inc.
Page 197 Installing Software on an EX Series Switch with a Single Routing Engine (CLI Procedure) Documentation on page 78 Installing Software on EX Series Switches (J-Web Procedure) on page 83 Understanding Software Installation on EX Series Switches on page 69 Copyright © 2010, Juniper Networks, Inc.
Page 199: Configuration Statements For Software Installation
Upgrading Software Using Automatic Software Download on EX Series Switches on Documentation page 90 Configuring the LCD Panel on EX Series Switches (CLI Procedure) on page 192 Configuring Graceful Routing Engine Switchover in a Virtual Chassis Configuration (CLI Procedure) on page 1033 Copyright © 2010, Juniper Networks, Inc.
Page 200: Auto-Image-Upgrade
Upgrading Software Using Automatic Software Download on EX Series Switches on Documentation page 90 Understanding Software Installation on EX Series Switches on page 69 DHCP Services for EX Series Switches Overview on page 547 Copyright © 2010, Juniper Networks, Inc.
Page 202: Request System License Add
106 Output Fields When you enter this command, you are provided feedback on the status of your request. request system license request system license user@host> request system license add terminal Copyright © 2010, Juniper Networks, Inc.
Page 203: Request System License Delete
107 Output Fields When you enter this command, you are provided feedback on the status of your request. request system license request system license user@host> request system license delete G03000002223 delete delete Copyright © 2010, Juniper Networks, Inc.
Page 204: Request System License Save
108 Output Fields When you enter this command, you are provided feedback on the status of your request. request system license request system license user@host> request system license save ftp://user@host/license.conf save save Copyright © 2010, Juniper Networks, Inc.
Page 205: Request System Reboot
—(TX Matrix and TX Matrix Plus routers only) (Optional) On a TX Matrix router, reboot all T640 routers (or line-card chassis) connected to the TX Matrix router. On a TX Matrix Plus router, reboot all T1600 routers (or line-card chassis) connected to the TX Matrix Plus router. Copyright © 2010, Juniper Networks, Inc.
Page 206 For example, if you issue the command from the master Routing Engine, the backup Routing Engine is rebooted. Similarly, if you issue the command from the backup Routing Engine, the master Routing Engine is rebooted. Copyright © 2010, Juniper Networks, Inc.
Page 207: Request System Reboot
Routing Engine (if you have upgraded it) first, and then reboot the master Routing Engine. Required Privilege maintenance Level Related clear system reboot on page 232 Documentation List of Sample Output request system reboot on page 112 request system reboot (at 2300) on page 112 Copyright © 2010, Juniper Networks, Inc.
Page 208 To reboot the system at 1:20 AM, enter the following command. Because 1:20 AM is the next day, you must specify the absolute time. (at 1:20 AM) user@host> request system reboot at 06060120 request system reboot at 120 Reboot the system at 120? [yes,no] (no) yes Copyright © 2010, Juniper Networks, Inc.
Page 209 USB flash drive. The internal option reboots the switch using a software package stored in an internal memory source. —(Optional) Message to display to all system users before rebooting the message “text” software. Copyright © 2010, Juniper Networks, Inc.
Page 210 To reboot the system at 1:20 AM, enter the following command. Because 1:20 AM is the (at 1:20 AM) next day, you must specify the absolute time. user@host> request system reboot at 06060120 request system reboot at 120 Reboot the system at 120? [yes,no] (no) yes Copyright © 2010, Juniper Networks, Inc.
Page 211: Request System Snapshot
Command introduced in Junos OS Release 10.0 for EX Series switches. Description Take a snapshot of the files currently used to run the switch—the complete contents of directories, which include the running Juniper Networks Junos OS, /config /var the active configuration, and the rescue configuration—and copy all of these files into an alternate (internal, meaning internal flash, or an external, meaning USB flash) memory source.
Page 212 When you enter this command, you are provided feedback on the status of your request. request system request system user@switch> request system snapshot media external slice 1 snapshot media snapshot media external slice 1 external slice 1 Copyright © 2010, Juniper Networks, Inc.
Page 213: Request System Software Add
—For a software package or bundle that is to be downloaded and installed from a remote location. Replace protocol with one of the following: Copyright © 2010, Juniper Networks, Inc.
Page 214 (or line-card chassis) that is connected to the TX Matrix Plus router. Replace with a value from through number —(TX Matrix routers only) (Optional) Install a software package or bundle on a Routing Engine on a TX Matrix router (or switch-card chassis). Copyright © 2010, Juniper Networks, Inc.
Page 215 /var/tmp/jroute user@host> request system software add /var/tmp/jcrypto By default, when you issue the command request system software add package-name on a TX Matrix master Routing Engine, all the T640 master Routing Engines that are Copyright © 2010, Juniper Networks, Inc.
Page 216: Request System Software Delete
It will attempt to preserve dumps WARNING: and log files, but this can not be guaranteed. This is the WARNING: pre-installation stage and all the software is loaded when WARNING: you reboot the system. Copyright © 2010, Juniper Networks, Inc.
Page 217 To abort the installation, do not reboot your system, WARNING: instead use the 'request system software delete jinstall' WARNING: command as soon as this operation completes. Saving package file in /var/sw/pkg/jinstall-7.2R1.7-domestic-signed.tgz ... Saving state for rollback ... Copyright © 2010, Juniper Networks, Inc.
Page 218: Request System Software Delete
TX Matrix router. On a TX Matrix Plus router, remove an extension or upgrade package from a specific T1600 router (or line-card chassis) that is connected to the TX Matrix Plus router. Replace number with a value from through Copyright © 2010, Juniper Networks, Inc.
Page 219: Request System Software Rollback
Information for jbase: Comment: JUNOS Base OS Software Suite [7.2R1.7] Information for jcrypto: Comment: JUNOS Crypto Software Suite [7.2R1.7] Information for jdocs: Comment: JUNOS Online Documentation [7.2R1.7] Information for jkernel: Comment: JUNOS Kernel Software Suite [7.2R1.7] Copyright © 2010, Juniper Networks, Inc.
Page 220 Removing package 'jdocs' ... user@host> show system software Information for jbase: Comment: JUNOS Base OS Software Suite [7.2R1.7] Information for jcrypto: Comment: JUNOS Crypto Software Suite [7.2R1.7] Information for jkernel: Comment: JUNOS Kernel Software Suite [7.2R1.7] Copyright © 2010, Juniper Networks, Inc.
Page 221: Request System Software Rollback
Additional Information On the J Series router, you can use this command to roll back to a previous software package when the current upgrade has been successful or has failed. On M Series and Copyright © 2010, Juniper Networks, Inc.
Page 222: Request System Software Validate
467 List of Sample Output request system software rollback on page 127 Output Fields When you enter this command, you are provided feedback on the status of your request. Copyright © 2010, Juniper Networks, Inc.
Page 223 Restarting vrrpd ... WARNING: cli has been replaced by an updated version: CLI release 7.2R1.7 built by builder on 2005-04-22 02:03:44 UTC Restart cli using the new version ? [yes,no] (yes) yes Restarting cli ... user@host Copyright © 2010, Juniper Networks, Inc.
Page 224: Request System Software Validate
If you issue the same command on a TX Matrix Plus backup Routing Engine, all the T1600 backup Routing Engines that are connected to it are upgraded to the same version of software. Copyright © 2010, Juniper Networks, Inc.
Page 225 (Successful Case) on page 130 request system software validate (Failure Case) on page 130 Output Fields When you enter this command, you are provided feedback on the status of your request. Copyright © 2010, Juniper Networks, Inc.
Page 226 (Failure Case) user@host> request system software validate test Pushing bundle to lcc0-re0 Pushing bundle to lcc2-re0 lcc0-re0: gzip: stdin: not in gzip format tar: child returned status 1 ERROR: Not a valid package: /var/tmp/test Copyright © 2010, Juniper Networks, Inc.
Page 227: Show System Autoinstallation Status
Master state: Active Last committed file: None Configuration server of last committed file: 0.0.0.0 Interface: Name: fe-0/0/1 State: None Address acquisition: Protocol: DHCP Client Acquired address: None Protocol: RARP Client Acquired address: None Copyright © 2010, Juniper Networks, Inc.
Page 228: Show System Boot-Messages
Virtual Chassis configuration. Replace member-id with a value from 0 through 9. —(TX Matrix routers only) (Optional) Display boot time messages for the TX Matrix router (or switch-card chassis). Copyright © 2010, Juniper Networks, Inc.
Page 229 Copyright (c) 1992-1998 FreeBSD Inc. boot-messages (TX boot-messages (TX Copyright (c) 1996-2000 Juniper Networks, Inc. Matrix Router) Matrix Router) All rights reserved. Copyright (c) 1982, 1986, 1989, 1991, 1993 The Regents of the University of California.
Page 230 (TX -------------------------------------------------------------------------- Matrix Router) Copyright (c) 1996-2001, Juniper Networks, Inc. All rights reserved. Copyright (c) 1992-2001 The FreeBSD Project. Copyright (c) 1979, 1980, 1983, 1986, 1988, 1989, 1991, 1992, 1993, 1994 The Regents of the University of California. All rights reserved.
Page 231 (TX -------------------------------------------------------------------------- Matrix Plus Router) Copyright (c) 1996-2009, Juniper Networks, Inc. All rights reserved. Copyright (c) 1992-2006 The FreeBSD Project. Copyright (c) 1979, 1980, 1983, 1986, 1988, 1989, 1991, 1992, 1993, 1994 The Regents of the University of California. All rights reserved.
Page 232: Show System License
This is applicable for scalable license-based features such as Subscriber Access ), L2TP ( ), Mobile IP ( ), and so on. scale-subscriber scale-l2tp scale-mobile-ip Copyright © 2010, Juniper Networks, Inc.
Page 233 License identifier: XXXXXXXXXX installed License version: 2 Features: subscriber-accounting - Per Subscriber Radius Accounting permanent subscriber-authentication - Per Subscriber Radius Authentication permanent subscriber-address-assignment - Radius/SRC Address Pool Assignment Copyright © 2010, Juniper Networks, Inc.
Page 234 License usage: usage Licenses Licenses Licenses Expiry Feature name used installed needed subscriber-accounting permanent subscriber-authentication permanent subscriber-address-assignment permanent subscriber-vlan permanent subscriber-ip permanent scale-subscriber permanent scale-l2tp permanent scale-mobile-ip permanent Copyright © 2010, Juniper Networks, Inc.
Page 235: Show System Snapshot
Information for snapshot on external (da1s1) media external media external Creation date: Oct 13 20:23:23 2009 JUNOS version on snapshot: jbase : 10.0I20090726_0011_user jcrypto-ex: 10.0I20090726_0011_user Copyright © 2010, Juniper Networks, Inc.
Page 236 ® Complete Software Guide for Junos OS for EX Series Ethernet Switches, Release 10.3 jdocs-ex: 10.0I20090726_0011_user jkernel-ex: 10.0I20090726_0011_user jroute-ex: 10.0I20090726_0011_user jswitch-ex: 10.0I20090726_0011_user jweb-ex: 10.0I20090726_0011_user jpfe-ex42x: 10.0I20090726_0011_user Copyright © 2010, Juniper Networks, Inc.
Page 237: Chapter 11 User Interfaces Overview
PART 4 User Interfaces User Interfaces Overview on page 143 Using the Configuration Tools on page 151 Operational Mode Commands for User Interfaces on page 153 Copyright © 2010, Juniper Networks, Inc.
Page 239: Cli User Interface Overview
CLI Help and Command Completion on page 143 CLI Command Modes on page 144 CLI Overview Junos operating system (Junos OS) CLI is a Juniper Networks specific command shell that runs on top of a UNIX-based operating system kernel. The CLI provides command help and command completion.
Page 240: Cli Command Modes
> prompt—for example, user@switch> In configuration mode, you can define all properties of the Juniper Networks Junos operating system (Junos OS), including interfaces, VLANs, Virtual Chassis information, routing protocols, user access, and several system hardware properties. To enter configuration mode, enter the command: .
Page 241: J-Web User Interface For Ex Series Switches Overview
The J-Web interface provides CLI tools that allow you to perform all of the tasks that you can perform from the Junos OS command-line interface (CLI), including a CLI Viewer to view the current configuration, a CLI Editor for viewing and modifying the configuration, Copyright © 2010, Juniper Networks, Inc.
Page 242: Table 25: J-Web Interface
Maintain—Manage files and licenses, upgrade software, and reboot the switch. Troubleshoot—Run diagnostic tools to troubleshoot network issues. Main Pane Help (?) icon Displays useful information—such as the definition, format, and valid range of an option—when you move the cursor over the question mark. Copyright © 2010, Juniper Networks, Inc.
Page 243: Understanding J-Web Configuration Tools
CLI. The J-Web interface provides three methods of configuring the switch: Configure menu Point & Click CLI Editor CLI Editor Table 26 on page 148 gives a comparison of the three methods of configuration. Copyright © 2010, Juniper Networks, Inc.
Page 244: Understanding J-Web User Interface Sessions
You establish a J-Web session with the switch through an HTTP-enabled or HTTPS-enabled Web browser. The HTTPS protocol, which uses 128-bit encryption, is available only in domestic versions of the Juniper Networks Junos operating system (Junos Copyright © 2010, Juniper Networks, Inc.
Page 245 To explicitly terminate a J-Web session at any time, click in the top pane. Logout Related J-Web User Interface for EX Series Switches Overview on page 145 Documentation Configuring Management Access for the EX Series Switch (J-Web Procedure) on page 495 Copyright © 2010, Juniper Networks, Inc.
Page 247: Chapter 12 Using The Configuration Tools
. Installing JRE installs Java plug-ins, which once installed, load automatically and transparently to render Java applets. NOTE: The CLI terminal is supported on JRE version 1.4 and later only. To access the CLI terminal, select Troubleshoot >CLI Terminal Copyright © 2010, Juniper Networks, Inc.
Page 248: Starting The J-Web Interface
To explicitly terminate a J-Web session at any time, click Logout in the top pane. Related J-Web User Interface for EX Series Switches Overview on page 145 Documentation Understanding How to Use the J-Web Interface to View System Information Copyright © 2010, Juniper Networks, Inc.
Page 250: Set Cli Complete-On-Space
In the following example, pressing the Spacebar changes the partial command entry complete-on-space complete-on-space from complete-on-space . The example shows how adding the keyword the end of the command disables command completion. user@host> set cli com<Space> user@host>set cli complete-on-space off Disabling complete-on-space Copyright © 2010, Juniper Networks, Inc.
Page 251: Set Cli Directory
155 Output Fields When you enter this command, you are provided feedback on the status of your request. set cli directory set cli directory user@host> set cli directory /var/home/regress Current directory: /var/home/regress Copyright © 2010, Juniper Networks, Inc.
Page 252: Set Cli Idle-Timeout
Output Fields When you enter this command, you are provided feedback on the status of your request. set cli idle-timeout set cli idle-timeout user@host> set cli idle-timeout 60 Idle timeout set to 60 minutes Copyright © 2010, Juniper Networks, Inc.
Page 253: Set Cli Prompt
List of Sample Output set cli prompt on page 157 Output Fields When you enter this command, the new CLI prompt is displayed. set cli prompt set cli prompt user@host> set cli prompt lab1-router> lab1-router> Copyright © 2010, Juniper Networks, Inc.
Page 254: Set Cli Restart-On-Upgrade
158 Output Fields When you enter this command, you are provided feedback on the status of your request. set cli set cli user@host> set cli restart-on-upgrade on Enabling restart-on-upgrade restart-on-upgrade restart-on-upgrade Copyright © 2010, Juniper Networks, Inc.
Page 255: Set Cli Screen-Length
159 Output Fields When you enter this command, you are provided feedback on the status of your request. set cli screen-length set cli screen-length user@host> set cli screen-length 75 Screen length set to 75 Copyright © 2010, Juniper Networks, Inc.
Page 256: Set Cli Screen-Width
160 Output Fields When you enter this command, you are provided feedback on the status of your request. set cli screen-width set cli screen-width user@host> set cli screen-width Screen width set to 132 Copyright © 2010, Juniper Networks, Inc.
Page 257: Set Cli Terminal
163 Documentation List of Sample Output set cli terminal on page 161 Output Fields This command provides no output. set cli terminal set cli terminal user@host> set cli terminal xterm Copyright © 2010, Juniper Networks, Inc.
Page 258: Set Cli Timestamp
Output Fields When you enter this command, you are provided feedback on the status of your request. set cli timestamp set cli timestamp user@host> set cli timestamp format '%m-%d-%T' '04-21-17:39:13' CLI timestamp set to: '%m-%d-%T' Copyright © 2010, Juniper Networks, Inc.
Page 259: Show Cli
CLI idle-timeout disabled CLI restart-on-upgrade set to on CLI screen-length set to 47 CLI screen-width set to 132 CLI terminal is 'vt100' CLI is operating in enhanced mode CLI timestamp disabled CLI working directory is '/var/home/regress' Copyright © 2010, Juniper Networks, Inc.
Page 260: Show Cli Authorization
Reserved for field (debugging) support. firewall Can view firewall configuration information. firewall-control Can modify firewall configuration information. floppy Can read from and write to removable media. flow-tap Can view flow-tap configuration information. flow-tap-control Can configure flow-tap configuration information. Copyright © 2010, Juniper Networks, Inc.
Page 261 Can view all configuration information (not including secrets). view-configuration show cli authorization show cli authorization user@host> show cli authorization Current user: 'remote' login: 'user' class '' Permissions: admin -- Can view user accounts Copyright © 2010, Juniper Networks, Inc.
Page 262 Can view all configuration (not including secrets) flow-tap -- Can view flow-tap configuration flow-tap-control-- Can configure flow-tap service Individual command authorization: Allow regular expression: none Deny regular expression: none Allow configuration regular expression: none Deny configuration regular expression: none Copyright © 2010, Juniper Networks, Inc.
Page 263: Show Cli Directory
Table 29: show cli directory Output Fields Field Name Field Description Pathname of the current working directory. Current directory show cli directory show cli directory user@host> show cli directory Current directory: /var/home/regress Copyright © 2010, Juniper Networks, Inc.
Page 264: Show Cli History
Time at which the command was entered. timestamp Command that was entered. command-syntax show cli history show cli history user@host> show cli history 11:14:14 -- show arp 11:22:10 -- show cli authorization 11:27:12 -- show cli history Copyright © 2010, Juniper Networks, Inc.
Page 265: Start Shell
Output Fields When you enter this command, you are provided feedback on the status of your request. start shell csh start shell csh user@host> start shell csh exit username@hostname% start shell sh exit user@host> Copyright © 2010, Juniper Networks, Inc.
Page 267: Chapter 14 System Setup Overview
Junos OS for EX Series Switches System Setup System Setup Overview on page 173 Initial Configuration on page 187 Configuration Statements for System Setup on page 197 Operational Mode Commands for System Setup on page 229 Copyright © 2010, Juniper Networks, Inc.
Page 269: Junos Os—Overview
EX Series Switch Software Features Overview The following tables list the Juniper Networks EX Series Ethernet Switches software features and the Juniper Networks Junos operating system (Junos OS) release in which they were introduced: Table 1 on page 4—Access Control Features Table 2 on page 5—Administration Features...
Page 270: Table 31: Access Control Features
Junos OS 10.1R1 9.0R2 10.2R1 9.4R1 Server fail fallback Junos OS Junos OS Junos OS Junos OS 10.1R1 9.3R2 10.2R1 10.2R1 TACACS+ Junos OS Junos OS Junos OS Junos OS 10.1R1 9.0R2 10.2R1 9.4R1 Copyright © 2010, Juniper Networks, Inc.
Page 271: Table 32: Administration Features
EX4500 Switches EX8200 Switches Graceful protocol restart for BGP Not applicable Junos OS 9.0R2 Not applicable Junos OS 9.4R1 Graceful protocol restart for IS-IS Not applicable Junos OS 9.3R2 Not applicable Junos OS 9.4R1 Copyright © 2010, Juniper Networks, Inc.
Page 272 Split and merge Virtual Chassis Not applicable Junos OS 10.0R1 Not applicable Not applicable (EX4200 only) Automatic software update on prospective member switches Front-panel configuration of uplink module ports as Virtual Chassis ports (VCPs) Copyright © 2010, Juniper Networks, Inc.
Page 273: Table 35: Interfaces Features
Junos OS 9.3R2 Not supported Not supported Local DHCP server Not supported Junos OS 9.3R2 Not supported Junos OS 9.4R1 Static addresses Junos OS 10.1R1 Junos OS 9.0R2 Junos OS 10.2R1 Junos OS 9.4R1 Copyright © 2010, Juniper Networks, Inc.
Page 274: Table 37: Ipv6 Features
Junos OS 10.0R1 Not supported Junos OS 10.0R1 (MVRP) Private VLANs (PVLANs) Not supported Junos OS 9.3R2 Not supported Junos OS 10.1R1 Proxy ARP—restricted Junos OS 10.1R1 Junos OS 10.0R1 Junos OS 10.2R1 Junos OS 10.0R1 Copyright © 2010, Juniper Networks, Inc.
Page 275: Table 39: Layer 3 Protocols Features
Junos OS 9.4R1 Table 39: Layer 3 Protocols Features EX3200 and EX4200 Feature EX2200 Switches Switches EX4500 Switches EX8200 Switches Bidirectional Forwarding Detection Not supported Junos OS 9.0R2 Junos OS 10.2R1 Junos OS 9.4R1 (BFD) Copyright © 2010, Juniper Networks, Inc.
Page 276 VRF with IPv4—virtual routing Not supported Junos OS 10.0R1 Not supported Junos OS 10.0R1 instances for multicast traffic VRF with IPv6—virtual routing Not supported Junos OS 10.1R1 Not supported Junos OS 10.1R1 instances for multicast traffic Copyright © 2010, Juniper Networks, Inc.
Page 277 Not supported Junos OS 9.4R1 Junos OS 10.2R1 Junos OS 9.4R1 (MSDP) http://www.juniper.net/techpubs/software/junos/index.html See the Junos OS Multicast Configuration Guide at Multicast VLAN registration (MVR) Not supported Junos OS 9.6R1 Not supported Not supported Copyright © 2010, Juniper Networks, Inc.
Page 278: Table 42: Network Management And Monitoring Features
VLAN on the intermediate switch Real-time performance monitoring Junos OS 10.1R1 Junos OS 9.3R2 Junos OS 10.2R1 Junos OS 10.1R1 (RPM) RMON Junos OS 10.1R1 Junos OS 9.0R2 Junos OS 10.2R1 Junos OS 9.4R1 Copyright © 2010, Juniper Networks, Inc.
Page 279: Table 43: Port Security Features
EX4500 Switches EX8200 Switches Autoinstallation of configuration files Junos OS 10.1R1 Junos OS 9.4R1 Junos OS 10.2R1 Not supported Automatic software download Junos OS 10.1R1 Junos OS 9.6R1 Junos OS 10.2R1 Junos OS 9.6R1 Copyright © 2010, Juniper Networks, Inc.
Page 280: Routing Engine And Packet Forwarding Engine
EX8216 Switch Hardware Overview on page 36 Understanding Software Infrastructure and Processes Each switch runs the Juniper Networks Junos operating system (Junos OS) for Juniper Networks EX Series Ethernet Switches on its general-purpose processors. Junos OS includes processes for Internet Protocol (IP) routing and for managing interfaces, networks, and the chassis.
Page 281: Table 45: Junos Os Processes
Defines how routing protocols operate on the switch. The overall performance of the process switch is largely determined by the effectiveness of the forwarding process. Interface Configures and monitors network interfaces by defining physical characteristics such process as link encapsulation, hold times, and keepalive timers. Copyright © 2010, Juniper Networks, Inc.
Page 282 For more information about processes, see the Junos OS Network Operations Guide at Documentation http://www.juniper.net/techpubs/software/junos/index.html For more information about basic system parameters, supported protocols, and software processes, see Junos OS System Basics Configuration Guide at http://www.juniper.net/techpubs/software/junos/index.html Copyright © 2010, Juniper Networks, Inc.
Page 283: Chapter 15 Initial Configuration
427. Before you begin connecting and configuring an EX Series switch through the console using the CLI: Set the following parameter values in the console server or PC: Baud Rate—9600 Flow Control—None Data—8 Parity—None Copyright © 2010, Juniper Networks, Inc.
Page 284 VLAN name, VLAN ID, management IP address, and default gateway. Select the ports that must be part of this VLAN. . Specify the IP address and gateway of the Configure out-of-band management management interface. Use this IP address to connect to the switch. Copyright © 2010, Juniper Networks, Inc.
Page 285: Connecting And Configuring An Ex Series Switch (J-Web Procedure)
EX2200 switch—The LEDs on the network ports on the front panel blink when the switch is in the initial setup mode. EX3200, EX4200, EX4500, or EX8200 switch—The LCD displays a count-down timer when the switch is in initial setup mode. Copyright © 2010, Juniper Networks, Inc.
Page 286 On the J-Web login page, type root as the username, leave the password field blank, and click Login. On the Introduction page, click Next. On the Basic Settings page, modify the hostname, the root password, and date and time settings: Copyright © 2010, Juniper Networks, Inc.
Page 287 If you use the J-Web interface to continue configuring the switch, the Web session is redirected to the new management IP address. If the connection cannot be made, the J-Web interface displays instructions for starting a J-Web session. Copyright © 2010, Juniper Networks, Inc.
Page 288: Configuring The Lcd Panel On Ex Series Switches (Cli Procedure)
NOTE: On some platforms you must specify an FPC slot number in these commands. See the lcd-menu statement for details. To disable a menu: Copyright © 2010, Juniper Networks, Inc.
Page 289: Configuring A Custom Display Message
To disable the display of the custom message: user@switch> clear chassis display message You can view the custom message by issuing the command show chassis lcd Related LCD Panel in EX3200 and EX4200 Switches Documentation LCD Panel in an EX8200 Switch Copyright © 2010, Juniper Networks, Inc.
Page 290: Configuring Date And Time For The Ex Series Switch (J-Web Procedure)
Configuring System Identity for an EX Series Switch (J-Web Procedure) To configure identification details for an EX series switch: Select > > . The System Identity page Configure System Properties System Identity displays configuration details. Copyright © 2010, Juniper Networks, Inc.
Page 291: Table 47: Set Up Configuration Summary
Specifies the domains to be searched. To add a domain, click To edit a domain click Edit. To delete a domain, click Delete. Related Configuring Date and Time for the EX Series Switch (J-Web Procedure) on page 194 Documentation Copyright © 2010, Juniper Networks, Inc.
Page 293: Chapter 16 Configuration Statements For System Setup
Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software ARP Learning and Aging Options for Mapping IPv4 Documentation Network Addresses to MAC Addresses Junos OS Network Interfaces Configuration Guide Copyright © 2010, Juniper Networks, Inc.
Page 294: Authentication-Key
Level system-control—To add this statement to the configuration. Related Configuring NTP Authentication Keys Documentation broadcast on page 201 peer on page 222 server on page 225 trusted-key on page 228 Copyright © 2010, Juniper Networks, Inc.
Page 295: Auxiliary
Default: The terminal type is unknown, and the user is prompted for the terminal type. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software to Set Console and Auxiliary Port Properties Documentation Copyright © 2010, Juniper Networks, Inc.
Page 296: Boot-Server (Ntp)
—Address of an NTP server. You must specify an address, not a hostname. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Synchronizing and Coordinating Time Distribution Using NTP Documentation Copyright © 2010, Juniper Networks, Inc.
Page 297: Broadcast
Range: 1 through 4 Default: 4 Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the NTP Time Server and Time Services Documentation Copyright © 2010, Juniper Networks, Inc.
Page 298: Broadcast-Client
Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the Router or Switch to Listen for Broadcast Messages Using NTP Documentation Copyright © 2010, Juniper Networks, Inc.
Page 299: Console (Physical Port)
Default: The terminal type is unknown, and the user is prompted for the terminal type. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software to Set Console and Auxiliary Port Properties Documentation Copyright © 2010, Juniper Networks, Inc.
Page 300: Default-Address-Selection
Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software to Select a Fixed Source Address for Locally Generated Documentation TCP/IP Packets Junos OS Network Interfaces Configuration Guide Copyright © 2010, Juniper Networks, Inc.
Page 301: Domain-Name (Router)
Path MTU discovery is enabled. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software for Path MTU Discovery on Outgoing GRE Tunnel Documentation Connections Copyright © 2010, Juniper Networks, Inc.
Page 302: Host-Name
Range: 0 through 4294967295 pps Default: 1000 Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Configuring the JUNOS Software ICMPv4 Rate Limit for ICMPv4 Routing Engine Documentation Messages Copyright © 2010, Juniper Networks, Inc.
Page 303: Icmpv6-Rate-Limit
Range: 0 through 4294967295 pps Default: 1000 Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Configuring the JUNOS Software ICMPv6 Rate Limit for ICMPv6 Routing Engine Documentation Messages Copyright © 2010, Juniper Networks, Inc.
Page 304: Inet6-Backup-Router
Default: All hosts (default route) are reachable through the backup router. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring a Backup Router Documentation Copyright © 2010, Juniper Networks, Inc.
Page 305: Internet-Options
Configuring the JUNOS Software to Ignore ICMP Source Quench Messages Configuring the JUNOS Software to Enable the Router or Switch to Drop Packets with the SYN and FIN Bits Set Configuring the JUNOS Software to Disable TCP RFC 1323 Extensions Copyright © 2010, Juniper Networks, Inc.
Page 306: Ipip-Path-Mtu-Discovery
The default value is 3. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software for IPv6 Duplicate Address Detection Attempts Documentation Copyright © 2010, Juniper Networks, Inc.
Page 307: Ipv6-Path-Mtu-Discovery
—IPv6 path MTU discovery timeout. Default: 10 minutes Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software for IPv6 Path MTU Discovery Documentation Copyright © 2010, Juniper Networks, Inc.
Page 308: Ipv6-Reject-Zero-Hop-Limit
Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software for Acceptance of IPv6 Packets with a Zero Hop Limit Documentation Copyright © 2010, Juniper Networks, Inc.
Page 309: Lcd-Menu
Related Configuring the LCD Panel on EX Series Switches (CLI Procedure) on page 192 Documentation LCD Panel in EX3200 and EX4200 Switches LCD Panel in EX4500 Switches LCD Panel in an EX8200 Switch Copyright © 2010, Juniper Networks, Inc.
Page 310: Location
—First six digits of the phone number (area code and exchange). npa-nxx number postal-code postal-code —Postal code. —Rack number. rack number vcoord vertical-coordinate —Bellcore Vertical Coordinate. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Copyright © 2010, Juniper Networks, Inc.
Page 312: Menu-Item
—(EX8200 switches only) Status of the power ''status-menu psu-status1-menu'' supplies in slots P0 and P1 ''status-menu psu-status2-menu'' —(EX8200 switches only) Status of the power supplies in slots P2–P5 —Status of the fan and the temperature ''status-menu environ-status'' Copyright © 2010, Juniper Networks, Inc.
Page 313: Multicast-Client
Default: 224.0.1.1 Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the Router or Switch to Listen for Multicast Messages Using NTP Documentation Copyright © 2010, Juniper Networks, Inc.
Page 314: No-Multicast-Echo
Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software to Disable the Reporting of IP Address and Documentation Timestamps in Ping Responses Copyright © 2010, Juniper Networks, Inc.
Page 315: No-Ping-Time-Stamp
Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software to Disable Protocol Redirect Messages on the Router Documentation or Switch Junos Network Interfaces Configuration Guide Copyright © 2010, Juniper Networks, Inc.
Page 316: No-Tcp-Rfc1323-Paws
(PAWS) number extension. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software to Disable the TCP RFC 1323 PAWS Extension Documentation Copyright © 2010, Juniper Networks, Inc.
Page 317: Path-Mtu-Discovery
Path MTU discovery is enabled. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software for Path MTU Discovery on Outgoing TCP Connections Documentation Copyright © 2010, Juniper Networks, Inc.
Page 318: Peer
—(Optional) Specify the NTP version number to be used in outgoing NTP version value packets. Range: through Default: Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the NTP Time Server and Time Services Documentation Copyright © 2010, Juniper Networks, Inc.
Page 319: Ports
The remaining statements are explained separately. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software to Set Console and Auxiliary Port Properties Documentation Copyright © 2010, Juniper Networks, Inc.
Page 320: Processes
Default: seconds (rounded up to 291 seconds by the Junos kernel) Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Disabling JUNOS Software Processes Documentation Copyright © 2010, Juniper Networks, Inc.
Page 321: Server (Ntp)
Level admin-control—To add this statement to the configuration. Related Configuring the JUNOS Software to Enable the Router or Switch to Drop Packets with Documentation the SYN and FIN Bits Set Copyright © 2010, Juniper Networks, Inc.
Page 322: Traceoptions (Sbc Configuration Process)
Syntax: to specify KB, to specify MB, or to specify GB. Range: 10 KB through 1 GB Default: 128 KB —(Optional) Enable unrestricted file access. world-readable Copyright © 2010, Juniper Networks, Inc.
Page 323 Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related See “Troubleshooting the IMSG” in the Junos Multiplay Solutions Guide Documentation System Management Configuration Statements Copyright © 2010, Juniper Networks, Inc.
Page 324: Trusted-Key
Level system-control—To add this statement to the configuration. Related Configuring NTP Authentication Keys Documentation authentication-key on page 198 broadcast on page 201 peer on page 222 server on page 225 Copyright © 2010, Juniper Networks, Inc.
Page 326: Clear Chassis Display Message
Documentation set chassis display message on page 271 show chassis craft-interface List of Sample Output clear chassis display message on page 231 Output Fields See show chassis craft-interface for an explanation of output fields. Copyright © 2010, Juniper Networks, Inc.
Page 327 Red alarm: LED off, relay off Yellow alarm: LED off, relay off Host OK LED: Host fail LED: Off FPCs ------------------------------- Green ..LCD screen: +--------------------+ |host |Up: 0+17:05:47 |Temperature OK +--------------------+ Copyright © 2010, Juniper Networks, Inc.
Page 329 List of Sample Output clear system reboot on page 234 clear system reboot (TX Matrix Router) on page 234 Output Fields When you enter this command, you are provided feedback on the status of your request. Copyright © 2010, Juniper Networks, Inc.
Page 330 Sat Dec 12 19:37:34 1998 [process id 17855] Terminating... clear system reboot user@host> clear system reboot scc-re0: (TX Matrix Router) -------------------------------------------------------------------------- No shutdown/reboot scheduled. lcc0-re0: -------------------------------------------------------------------------- No shutdown/reboot scheduled. lcc2-re0: -------------------------------------------------------------------------- No shutdown/reboot scheduled. Copyright © 2010, Juniper Networks, Inc.
Page 331: Configure
235 Output Fields When you enter this command, you are placed in configuration mode and the system prompt changes from hostname> hostname# configure configure user@host> configure Entering configuration mode [edit] user@host# Copyright © 2010, Juniper Networks, Inc.
Page 332 Executing an Op Script from a Remote Site in the Junos Configuration and Operations Automation Guide checksum file checksum md5 on page 452 file checksum sha-256 on page 454 file checksum sha1 on page 453 List of Sample Output op on page 237 Copyright © 2010, Juniper Networks, Inc.
Page 333 When you enter this command, you are provided feedback on the status of your request. user@host> op script1 interface ge-0/2/0.0 protocol inet op url user@host> op url https://www.juniper.net/fa/2009-04-01.01.slax key md5 8de24d09e1d90b2581bb937d2a5ad590 interface ge-0/2/0.0 protocol inet Copyright © 2010, Juniper Networks, Inc.
Page 334: Request Chassis Pic
T640 router by using the option (the recommended lcc number method), replace slot-number with a value from 0 through 7. Otherwise, replace with a value from 0 through 31. slot-number Copyright © 2010, Juniper Networks, Inc.
Page 335 When you enter this command, you are provided feedback on the status of your request. request chassis pic request chassis pic user@host> request chassis pic pic-slot 0 online fpc-slot 0 FPC 0, PIC 0 is already online Copyright © 2010, Juniper Networks, Inc.
Page 336: Request Chassis Routing-Engine Master
TX Matrix router) or T1600 routers (in a routing matrix based on a TX Matrix Plus router) might become logically disconnected from the TX Matrix router and cause data loss. For more information, see the TX Matrix Router Hardware Guide or the Junos High Availability Configuration Guide. Copyright © 2010, Juniper Networks, Inc.
Page 337 Because both Routing Engines are always running, the transition from one to the other as the master Routing Engine is immediate. However, the changeover interrupts communication to the System and Switch Board (SSB). The SSB takes several seconds Copyright © 2010, Juniper Networks, Inc.
Page 338 Complete. The other Routing Engine becomes the master. Switch mastership back to the local Routing Engine: user@host> request chassis routing-engine master switch warning: Traffic will be interrupted while the PFE is re-initialized Toggle mastership between routing engines ? [yes,no] (no) yes Copyright © 2010, Juniper Networks, Inc.
Page 340: Request System Halt
—(TX Matrix and TX Matrix Plus routers only) (Optional) Halt all chassis. all-chassis all-lcc —(TX Matrix and TX Matrix Plus routers only) (Optional) On a TX Matrix router, halt all T640 routers (or line-card chassis) connected to the TX Matrix router. On a Copyright © 2010, Juniper Networks, Inc.
Page 341 Routing Engine is halted. Similarly, if you issue the command from the backup Routing Engine, the master Routing Engine is halted. —(TX Matrix routers only) (Optional) Halt the TX Matrix router (or switch-card chassis). Copyright © 2010, Juniper Networks, Inc.
Page 342 (in 2 Hours) on page 247 request system halt (Immediately) on page 247 request system halt (at 1:20 AM) on page 247 Output Fields When you enter this command, you are provided feedback on the status of your request. Copyright © 2010, Juniper Networks, Inc.
Page 343 To stop the system at 1:20 AM, enter the following command. Because 1:20 AM is the (at 1:20 AM) next day, you must specify the absolute time. user@host> request system halt at yymmdd120 request system halt at 120 Halt the system at 120? [yes,no] (no) yes Copyright © 2010, Juniper Networks, Inc.
Page 344: Request System Logout
Output Fields When you enter this command, you are provided feedback on the status of your request. request system logout request system logout user@host> request system logout user tammy all Connection closed by foreign host. Copyright © 2010, Juniper Networks, Inc.
Page 345: Request System Power-Off
—(Optional) (TX Matrix and TX Matrix Plus router only) Power off all Routing Engines in the chassis. —(Optional) (TX Matrix and TX Matrix Plus router only) On a TX Matrix router, all-lcc power off all T640 routers (or line-card chassis) connected to the TX Matrix router. Copyright © 2010, Juniper Networks, Inc.
Page 346 For example, if you issue the command from the master Routing Engine, the backup Routing Engine is halted. Similarly, if you issue the command from the backup Routing Engine, the master Routing Engine is halted. Copyright © 2010, Juniper Networks, Inc.
Page 347 Power Off the system ? [yes,no] (no) yes *** FINAL System shutdown message from remote@nutmeg *** System going down IMMEDIATELY This router will be powered off in 30 minutes. Please save your data and log out Copyright © 2010, Juniper Networks, Inc.
Page 349: Request System Reboot
—(TX Matrix and TX Matrix Plus routers only) (Optional) On a TX Matrix router, reboot all T640 routers (or line-card chassis) connected to the TX Matrix router. On a TX Matrix Plus router, reboot all T1600 routers (or line-card chassis) connected to the TX Matrix Plus router. Copyright © 2010, Juniper Networks, Inc.
Page 350 For example, if you issue the command from the master Routing Engine, the backup Routing Engine is rebooted. Similarly, if you issue the command from the backup Routing Engine, the master Routing Engine is rebooted. Copyright © 2010, Juniper Networks, Inc.
Page 351: Request System Reboot
Routing Engine (if you have upgraded it) first, and then reboot the master Routing Engine. Required Privilege maintenance Level Related clear system reboot on page 232 Documentation List of Sample Output request system reboot on page 256 request system reboot (at 2300) on page 256 Copyright © 2010, Juniper Networks, Inc.
Page 352 To reboot the system at 1:20 AM, enter the following command. Because 1:20 AM is the next day, you must specify the absolute time. (at 1:20 AM) user@host> request system reboot at 06060120 request system reboot at 120 Reboot the system at 120? [yes,no] (no) yes Copyright © 2010, Juniper Networks, Inc.
Page 353 USB flash drive. The internal option reboots the switch using a software package stored in an internal memory source. —(Optional) Message to display to all system users before rebooting the message “text” software. Copyright © 2010, Juniper Networks, Inc.
Page 354 To reboot the system at 1:20 AM, enter the following command. Because 1:20 AM is the (at 1:20 AM) next day, you must specify the absolute time. user@host> request system reboot at 06060120 request system reboot at 120 Reboot the system at 120? [yes,no] (no) yes Copyright © 2010, Juniper Networks, Inc.
Page 355: Request System Scripts Convert
/var/db/scripts/op/script1.slax destination /var/db/scripts/op convert slax-to-xslt convert slax-to-xslt conversion complete request system scripts user@host> request system scripts convert xslt-to-slax source /var/db/scripts/commit/script1.xsl destination /var/db/scripts/commit convert xslt-to-slax conversion complete Copyright © 2010, Juniper Networks, Inc.
Page 356: Request System Scripts Refresh-From Commit
260 request system scripts request system scripts user@switch> request system scripts refresh-from commit file config.txt url http://host1.juniper.net refresh-from commit refresh-from commit user@switch> file config.txt url file config.txt url http://host1.juniper.net http://host1.juniper.net Copyright © 2010, Juniper Networks, Inc.
Page 357: Request System Scripts Refresh-From Event
261 request system scripts request system scripts user@switch> request system scripts refresh-from event file config.txt url http://host1.juniper.net refresh-from event file refresh-from event file user@switch> config.txt url config.txt url http://host1.juniper.net http://host1.juniper.net Copyright © 2010, Juniper Networks, Inc.
Page 358: Request System Scripts Refresh-From Op
262 request system scripts request system scripts user@switch> request system scripts refresh-from op file config.txt url http://host1.juniper.net user@switch> refresh-from op file refresh-from op file config.txt url config.txt url http://host1.juniper.net http://host1.juniper.net Copyright © 2010, Juniper Networks, Inc.
Page 359: Request System Storage Cleanup
List of files to delete: Size Date Name 11.4K Mar 8 15:00 /var/log/messages.1.gz 7245B Feb 5 15:00 /var/log/messages.3.gz 11.8K Feb 22 13:00 /var/log/messages.2.gz 3926B Mar 16 13:57 /var/log/messages.0.gz 3962B Feb 22 12:47 /var/log/sampled.1.gz 4146B Mar 8 12:20 /var/log/sampled.0.gz Copyright © 2010, Juniper Networks, Inc.
Page 360 4708B Dec 21 11:39 /var/log/sampled.2.gz 7068B Jan 16 18:00 /var/log/messages.4.gz 13.7K Dec 27 22:00 /var/log/messages.5.gz 890B Feb 22 17:22 /var/tmp/sampled.pkts 65.8M Oct 26 09:10 /var/sw/pkg/jinstall-7.4R1.7-export-signed.tgz 63.1M Oct 26 09:13 /var/sw/pkg/jbundle-7.4R1.7.tgz Delete these files ? [yes,no] (yes) Copyright © 2010, Juniper Networks, Inc.
Page 361: Restart
| pgm | ppp | pppoe | remote-operations | routing <logical-system logical-system-name> | sampling | service-deployment | snmp | usb-control | web-management> <gracefully | immediately | soft> Release Information Command introduced before Junos OS Release 7.4. Copyright © 2010, Juniper Networks, Inc.
Page 362 —(EX Series switch only) (Optional) Restart the autoinstallation process. —(Optional) Restart the chassis management process. chassis-control class-of-service —(Optional) Restart the class-of-service (CoS) process, which controls the router's or switch’s CoS configuration. —(EX Series switch only) (Optional) Restart the database replication database-replication process. Copyright © 2010, Juniper Networks, Inc.
Page 363 —(Optional) Restart the interface process, which controls the router's or switch’s physical interface devices and logical interfaces. —(Optional) Restart the IPsec key management process. ipsec-key-management —(J Series router only) (Optional) Restart the ISDN signaling process, which isdn-signaling initiates ISDN connections. Copyright © 2010, Juniper Networks, Inc.
Page 364 —(Optional) Restart the logging process for some PICs. With this process, also known as fsad (the file system access daemon), PICs send special logging information to the Routing Engine for archiving on the hard disk. Copyright © 2010, Juniper Networks, Inc.
Page 365 Omitting this option results in a graceful restart of the software process. —(J Series router only) (Optional) Restart the USB control process. usb-control vrrp —(EX Series switch only) (Optional) Restart the Virtual Router Redundancy Protocol process. Copyright © 2010, Juniper Networks, Inc.
Page 366 270 Output Fields When you enter this command, you are provided feedback on the status of your request. restart interfaces restart interfaces user@host> restart interfaces interfaces process terminated interfaces process restarted Copyright © 2010, Juniper Networks, Inc.
Page 367: Set Chassis Display Message
—(Optional) Display a text message on the craft interface display or LCD panel display permanently. —(TX Matrix routers only) Display the text message on the craft interface display of the TX Matrix router (or switch-card chassis). Copyright © 2010, Juniper Networks, Inc.
Page 368 Red alarm: LED off, relay off Yellow alarm: LED off, relay off Host OK LED: Host fail LED: Off FPCs ------------------------------- Green ..LCD screen: +--------------------+ |host |Up: 0+17:05:47 Copyright © 2010, Juniper Networks, Inc.
Page 370: Set Date
When you enter this command, you are provided feedback on the status of your request. set date set date user@host> set date ntp 21 Apr 17:22:02 ntpdate[3867]: step time server 172.17.27.46 offset 8.759252 sec Copyright © 2010, Juniper Networks, Inc.
Page 371: Show Chassis Firmware
Matrix router (or switch-card chassis). sfc number —(TX Matrix Plus router only) (Optional) Display version levels for the firmware on the TX Matrix Plus router (or switch-fabric chassis). Replace with number Required Privilege view Level Copyright © 2010, Juniper Networks, Inc.
Page 372: Table 48: Show Chassis Firmware Output Fields
Juniper ROM Monitor Version 2.0i49Copyrig Version 2.0i1 by root on Thu Jul 23 00:59 show chassis firmware user@host> show chassis firmware FPC 2 Juniper ROM Monitor Version 8.0b29 (M120 Router) Version 8.2B1 by builder on 2006-10-18 16:2 Copyright © 2010, Juniper Networks, Inc.
Page 373 FreeBSD/PowerPC U-Boot bootstrap loader 2.2 FPC 3 U-Boot U-Boot 1.1.6 (Dec 4 2009 - 13:17:34) 3.1.0 loader FreeBSD/PowerPC U-Boot bootstrap loader 2.2 FPC 5 U-Boot U-Boot 1.1.6 (Mar 25 2009 - 06:13:12) 2.4.0 Copyright © 2010, Juniper Networks, Inc.
Page 374 Version 9.6-20090507.0 by builder on 2009-0 lcc0-re1: -------------------------------------------------------------------------- Part Type Version FPC 4 Juniper ROM Monitor Version 9.0b2 Version 9.6-20090507.0 by builder on 2009-0 FPC 6 Juniper ROM Monitor Version 9.0b2 Version 9.6-20090507.0 by builder on 2009-0 Copyright © 2010, Juniper Networks, Inc.
Page 375 Version 9.6-20090507.0 by builder on 2009-0 SPMB 1 Juniper ROM Monitor Version 9.5b1 Version 9.6-20090507.0 by builder on 2009-0 show chassis firmware user@host> show chassis firmware lcc 0 lcc0-re1: lcc (TX Matrix Plus -------------------------------------------------------------------------- Router) Part Type Version Copyright © 2010, Juniper Networks, Inc.
Page 376 Global FPC 28 Global FPC 29 Global FPC 31 SPMB 0 Juniper ROM Monitor Version 9.5b1 Version 9.6-20090507.0 by builder on 2009-0 SPMB 1 Juniper ROM Monitor Version 9.5b1 Version 9.6-20090507.0 by builder on 2009-0 Copyright © 2010, Juniper Networks, Inc.
Page 377: Show Chassis Lcd
LCD panel for the specified Virtual Chassis member. Required Privilege view Level Related LCD Panel in EX3200 and EX4200 Switches Documentation LCD Panel in EX4500 Switches Copyright © 2010, Juniper Networks, Inc.
Page 378: Table 49: Show Chassis Lcd Output Fields
NOTE: EX4500 and EX8200 switches do not have the POE port parameter. —Administrative —Speed —Duplex —Power over Ethernet fpcx On EX3200 and EX4500 switches, always . On EX4200 switches, member ID of the Virtual Chassis member whose LCD menu is displayed. Copyright © 2010, Juniper Networks, Inc.
Page 379 LCD screen: 01:RE switch2 LED:SPD ALARM 01 LEDs status: Alarms LED: Yellow System LED: Green Master LED: Green Interface LED(ADM/SPD/DPX/POE) ------------------------------------- ge-1/0/0 ge-1/0/1 ge-1/0/2 ge-1/0/3 ge-1/0/4 ge-1/0/5 ge-1/0/6 ge-1/0/7 ge-1/0/8 ge-1/0/9 ge-1/0/10 ge-1/0/11 ge-1/0/12 ge-1/0/13 Copyright © 2010, Juniper Networks, Inc.
Page 382 (EX8200) (EX8200) status-menu sf-status1-menu status-menu sf-status2-menu status-menu psu-status1-menu status-menu psu-status2-menu status-menu environ-menu status-menu show-version Copyright © 2010, Juniper Networks, Inc.
Page 383 Chapter 17: Operational Mode Commands for System Setup maintenance-menu maintenance-menu halt-menu maintenance-menu system-reboot maintenance-menu rescue-config maintenance-menu factory-default Copyright © 2010, Juniper Networks, Inc.
Page 384: Show Configuration
—Configuration groups. groups interfaces —Interface configuration. —JSRC partition configuration. jsrc jsrc-partition —JSRC partition configuration. —Logical system configuration. logical-systems —(EX Series switch only) Power over Ethernet configuration. —Routing policy option configuration. policy-options protocols —Routing protocol configuration. Copyright © 2010, Juniper Networks, Inc.
Page 385 ## Last commit: 2006-10-31 14:13:00 PST by alant version "8.2I0 [builder]"; ## last changed: 2006-10-31 14:05:53 PST system { host-name nestor; domain-name east.net; backup-router 192.1.1.254; time-zone America/Los_Angeles; default-address-selection; name-server { 192.154.169.254; 192.154.169.249; 192.154.169.176; services { telnet; tacplus-server { 1.2.3.4 { secret /* SECRET-DATA */; Copyright © 2010, Juniper Networks, Inc.
Page 386 { export "direct routes"; policy-options { policy-statement "direct routes" { from protocol direct; then accept; show configuration user@host> show configuration policy-options policy-options { policy-options policy-statement "direct routes" { from protocol direct; then accept; Copyright © 2010, Juniper Networks, Inc.
Page 387: Show Host
Required Privilege view Level List of Sample Output show host on page 291 show host show host user@host> show host snark snark.boojum.net has address 192.168.1.254 user@host> show host 192.168.1.254 Name: snark.boojum.net Address: 192.168.1.254 Aliases: Copyright © 2010, Juniper Networks, Inc.
Page 388: Show Ntp Associations
Polling interval, in seconds. poll Reachability register, in octal. reach Current estimated delay of the peer, in milliseconds. delay Current estimated offset of the peer, in milliseconds. offset disp Current estimated dispersion of the peer, in milliseconds. Copyright © 2010, Juniper Networks, Inc.
Page 389 —Selected for synchronization, but the packets-per-second (pps) signal is in use. show ntp associations show ntp associations user@host> show ntp associations remote refid st t when poll reach delay offset disp ============================================================================== *wolfe-gw.junipe tick.ucla.edu 1.86 0.319 0.08 Copyright © 2010, Juniper Networks, Inc.
Page 390: Show Ntp Status
4.1.0-a Fri Jun 24 06:40:56 GMT 2005 (1)", processor="i386", system="JUNOS7.4-20050624.0", leap=00, stratum=2, precision=-28, rootdelay=6.849, rootdispersion=10.615, peer=38788, refid=ntp-server.company-a.net, reftime=c66705d9.06ee0f3c Fri, Jun 24 2005 15:21:13.027, poll=6, clock=c6670602.cf6db940 Fri, Jun 24 2005 15:21:54.810, state=4, offset=0.205, frequency=75.911, jitter=0.396, stability=0.005 Copyright © 2010, Juniper Networks, Inc.
Page 391: Show System Firmware
Routing Engine 0 RE BIOS show system firmware user@host> show system firmware compatibility Part Type Tag Current Available Action compatibility version version FPC 0 ROM Monitor 0 6.4.10 None Routing Engine 0 RE BIOS None Copyright © 2010, Juniper Networks, Inc.
Page 392: Show System Reboot
TX Matrix router. On a TX Matrix Plus router, display halt or reboot request information for a specific T1600 router that is connected to the TX Matrix Plus router. Replace number with a value from through Copyright © 2010, Juniper Networks, Inc.
Page 393 (TX Matrix Plus Router) on page 298 show system reboot show system reboot user@host> show system reboot reboot requested by root at Wed Feb 10 17:40:46 1999 [process id 17885] Copyright © 2010, Juniper Networks, Inc.
Page 394 (TX Matrix -------------------------------------------------------------------------- Router) No shutdown/reboot scheduled. lcc2-re0: -------------------------------------------------------------------------- No shutdown/reboot scheduled. show system reboot user@host> show system sfc 0 No shutdown/reboot scheduled. sfc (TX Matrix Plus Router) Copyright © 2010, Juniper Networks, Inc.
Page 395: Show System Snapshot
Information for snapshot on external (da1s1) media external media external Creation date: Oct 13 20:23:23 2009 JUNOS version on snapshot: jbase : 10.0I20090726_0011_user jcrypto-ex: 10.0I20090726_0011_user Copyright © 2010, Juniper Networks, Inc.
Page 396 ® Complete Software Guide for Junos OS for EX Series Ethernet Switches, Release 10.3 jdocs-ex: 10.0I20090726_0011_user jkernel-ex: 10.0I20090726_0011_user jroute-ex: 10.0I20090726_0011_user jswitch-ex: 10.0I20090726_0011_user jweb-ex: 10.0I20090726_0011_user jpfe-ex42x: 10.0I20090726_0011_user Copyright © 2010, Juniper Networks, Inc.
Page 397: Show System Software
—(TX Matrix and TX Matrix Plus routers only) (Optional) On a TX Matrix router, display system software information for a specific T640 router that is connected to the TX Matrix router. On a TX Matrix Plus router, display system software information Copyright © 2010, Juniper Networks, Inc.
Page 398 JUNOS Online Documentation [7.2R1.7] Information for jkernel: Comment: JUNOS Kernel Software Suite [7.2R1.7] Information for jpfe: Comment: JUNOS Packet Forwarding Engine Support (M20/M40) [7.2R1.7] Information for jroute: Comment: JUNOS Routing Software Suite [7.2R1.7] Information for junos: Copyright © 2010, Juniper Networks, Inc.
Page 399 Information for jpfe-common: Comment: JUNOS Packet Forwarding Engine Support (M/T Common) [9.6-20090515.0] Information for jroute:Comment: JUNOS Routing Software Suite [9.6-20090515.0] Information for jservices-aacl: Comment: JUNOS Services AACL Container package [9.6-20090515.0] Information for jservices-appid: Comment: Copyright © 2010, Juniper Networks, Inc.
Page 400 JUNOS Base OS boot [9.6-20090515.0] lcc0-re0: -------------------------------------------------------------------------- Information for jbase: Comment: JUNOS Base OS Software Suite [9.6-20090515.0] Information for jcrypto: Comment: JUNOS Crypto Software Suite [9.6-20090515.0] Information for jdocs: Comment: JUNOS Online Documentation [9.6-20090515.0] Copyright © 2010, Juniper Networks, Inc.
Page 401 Information for jservices-appid: Comment: JUNOS AppId Services [9.6-20090515.0] Information for jservices-bgf: Comment: JUNOS Border Gateway Function package [9.6-20090515.0] Information for jservices-idp: Comment: JUNOS IDP Services [9.6-20090515.0] Information for jservices-llpdf: Comment: JUNOS Services LL-PDF Container package [9.6-20090515.0] Copyright © 2010, Juniper Networks, Inc.
Page 402 JUNOS Voice Services Container package [9.6-20090515.0] Information for junos: Comment: JUNOS Base OS boot [9.6-20090515.0] lcc1-re0: -------------------------------------------------------------------------- Information for jbase: Comment: JUNOS Base OS Software Suite [9.6-20090515.0] Information for jcrypto: Comment: JUNOS Crypto Software Suite [9.6-20090515.0] Copyright © 2010, Juniper Networks, Inc.
Page 403: Show System Storage
T1600 router that is connected to the TX Matrix Plus router. Replace number with a value from through —(EX4200 switches only) (Optional) Display system storage statistics for the local local Virtual Chassis member. Copyright © 2010, Juniper Networks, Inc.
Page 404: Table 52: Show System Storage Output Fields
Directory in which the file system is mounted. Mounted on show system storage show system storage user@host> show system storage Filesystem Size Used Avail Capacity Mounted on /dev/ad0s1a devfs 100% /dev/ /dev/vn0 100% /packages/mnt/jbase /dev/vn1 100% /packages/mnt/jkernel-7.2R1.7 /dev/vn2 100% Copyright © 2010, Juniper Networks, Inc.
Page 405 /packages/mnt/jpfe-T-9.6-20090519.0 /dev/md3 4.1M 4.1M 100% /packages/mnt/jdocs-9.6-20090519.0 /dev/md4 100% /packages/mnt/jroute-9.6-20090519.0 /dev/md5 100% /packages/mnt/jcrypto-9.6-20090519.0 /dev/md6 100% /packages/mnt/jpfe-common-9.6-20090519.0 /dev/md7 2.0G 10.0K 1.8G /tmp /dev/md8 2.0G 540K 1.8G /mfs /dev/ad0s1e 383M 352M /config procfs 4.0K 4.0K 100% /proc Copyright © 2010, Juniper Networks, Inc.
Page 406 /dev/ad1s1f 3.7G /var lcc3-re0: -------------------------------------------------------------------------- Filesystem Size Used Avail Capacity Mounted on /dev/ad0s1a 3.4G 178M 2.9G devfs 1.0K 1.0K 100% /dev devfs 1.0K 1.0K 100% /dev/ /dev/md0 100% /packages/mnt/jbase /dev/md1 216M 216M 100% /packages/mnt/jkernel-9.6-20090519.0 Copyright © 2010, Juniper Networks, Inc.
Page 407 4.1M 100% /packages/mnt/jdocs-9.6-20090519.0 /dev/md4 100% /packages/mnt/jroute-9.6-20090519.0 /dev/md5 100% /packages/mnt/jcrypto-9.6-20090519.0 /dev/md6 100% /packages/mnt/jpfe-common-9.6-20090519.0 /dev/md7 2.0G 10.0K 1.8G /tmp /dev/md8 2.0G 540K 1.8G /mfs /dev/ad0s1e 383M 352M /config procfs 4.0K 4.0K 100% /proc /dev/ad1s1f 3.5G /var Copyright © 2010, Juniper Networks, Inc.
Page 408: Show System Switchover
—(TX Matrix and TX Matrix Plus routers only) (Optional) On a TX Matrix router, all-lcc display graceful Routing Engine switchover information for all T640 routers (or line-card chassis) connected to the TX Matrix router. On a TX Matrix Plus router, Copyright © 2010, Juniper Networks, Inc.
Page 409: Table 53: Show System Switchover Output Fields
Configuration State of the configuration database: database —Configuration database has synchronized. Ready —Configuration database is synchronizing. Displayed when there are updates within Synchronizing the last 5 seconds. —Configuration database synchronize process failed. Synchronize failed Copyright © 2010, Juniper Networks, Inc.
Page 410 —An error occurred when the state was replicated from the primary Routing Engine. Replication error Inspect /var/log/ksyncd for possible causes, or notify Juniper Networks customer support. Routing Engine peer state: Peer state —Peer completed switchover transition. Steady State —Peer in switchover transition.
Page 411: Show System Uptime
Virtual Chassis member. member member-id —(EX4200 switches only) (Optional) Show time since the system rebooted and processes started on the specified member of the Virtual Chassis configuration. Replace with a value from 0 through 9. member-id Copyright © 2010, Juniper Networks, Inc.
Page 412: Table 54: Show System Uptime Output Fields
1998-10-13 19:45:47 UTC System booted: 1998-10-12 20:51:41 UTC (22:54:06 ago) Protocols started: 1998-10-13 19:33:45 UTC (00:12:02 ago) Last configured: 1998-10-13 19:33:45 UTC (00:12:02 ago) by abc 12:45PM up 22:54, 2 users, load averages: 0.07, 0.02, 0.01 Copyright © 2010, Juniper Networks, Inc.
Page 413 Current time: 2009-05-25 00:24:30 PDT System booted: 2009-05-24 06:39:44 PDT (17:44:46 ago) error: the routing subsystem is not running Last configured: 2009-05-24 06:40:08 PDT (17:44:22 ago) by root 12:24AM up 17:45, 0 users, load averages: 0.00, 0.00, 0.00 Copyright © 2010, Juniper Networks, Inc.
Page 414: Show System Users
—(TX Matrix routers only) (Optional) Show users currently logged in to the TX Matrix router (or switch-card chassis). sfc number —(TX Matrix Plus routers only) (Optional) Show users currently logged in to the TX Matrix Plus router (or switch-fabric chassis). Replace with number Copyright © 2010, Juniper Networks, Inc.
Page 415: Table 55: Show System Users Output Fields
2:26, 2 users, load averages: 0.07, 0.02, 0.01 USER TTY FROM LOGIN@ IDLE WHAT root Fri05PM 4days -csh (csh) blue p0 level5.company.net 7:30PM - cli show system users lcc user@host> show system users lcc 2 no-resolve no-resolve (TX Matrix lcc2-re0: Copyright © 2010, Juniper Networks, Inc.
Page 416 28 mins, 0 users, load averages: 0.07, 0.04, 0.03 lcc2-re0: -------------------------------------------------------------------------- 1:42AM up 27 mins, 0 users, load averages: 0.07, 0.06, 0.02 lcc3-re0: -------------------------------------------------------------------------- 1:42AM up 28 mins, 0 users, load averages: 0.05, 0.04, 0.04 Copyright © 2010, Juniper Networks, Inc.
Page 417: Show System Virtual-Memory
Virtual Chassis member. —(EX4200 switches only) (Optional) Display kernel dynamic memory member member-id usage information for the specified member of the Virtual Chassis configuration. Replace with a value from 0 through 9. member-id Copyright © 2010, Juniper Networks, Inc.
Page 418 | display xml on page 332 Output Fields Table 56 on page 323 lists the output fields for the command. show system virtual-memory Output fields are listed in the approximate order in which they appear. Copyright © 2010, Juniper Networks, Inc.
Page 419: Table 56: Show System Virtual-Memory Output Fields
Number of times requests were blocked for kernel map. Kern Limit Memory block sizes this type is using. Size(s) Memory Totals In Use Total kernel dynamic memory in use (bytes, rounded up). Total kernel dynamic memory free (bytes, rounded up). Free Copyright © 2010, Juniper Networks, Inc.
Page 420 MD disk, rman, ATA generic, bus, sysctl, ippool, pfestat, ifstate, pfe_ipc, mkey, rtable, ifmaddr, ipfw, rnode atkbddev, dirrem, mkdir, diradd, freefile, freefrag, indirdep, bmsafemap, newblk, temp, devbuf, COS, vnodes, cluster_save buffer, pcb, soname, proc-args, sigio, kld, Gzip trees, taskqueue, SWAP, Copyright © 2010, Juniper Networks, Inc.
Page 421 6K127753K freefile 4K127753K freeblks 8K127753K freefrag 1K127753K allocindir 25K127753K 1518 indirdep 17K127753K 32,16K allocdirect 10K127753K bmsafemap 1K127753K newblk 1K127753K 2279 32,256 inodedep 128K 175K127753K 2367 128,128K pagedep 33K127753K 64,32K temp 1239 96K127753K 8364 16,32,64K Copyright © 2010, Juniper Networks, Inc.
Page 422 1K127753K 130262 16,32,64 uidinfo 1K127753K 32,128 cred 3K127753K 3450 subproc 10K127753K 7882 32,64,256 proc 1K127753K session 2K127753K pgrp 1K127753K ippool 1K127753K pfestat 1K127753K 47349 16,32,64,512 1K127753K 64,128 1K127753K itable32 4K127753K itable16 26K127753K 128,256 Copyright © 2010, Juniper Networks, Inc.
Page 423 380 vnode pager pageins 395 vnode pager pages paged in 122 vnode pager pageouts 1476 vnode pager pages paged out 0 page daemon wakeups 0 pages examined by the page daemon 101 pages reactivated Copyright © 2010, Juniper Networks, Inc.
Page 424 COS, vnodes, Memory statistics by type Type Kern Type InUse MemUse HighUse Limit Requests Limit Limit Size(s) isadev 1K166400K atkbddev 1K166400K uc_devlist 3K166400K 16,2K ..Memory Totals: In Use Free Requests 6091K 1554K 2897122 Copyright © 2010, Juniper Networks, Inc.
Page 425 6220 32,64,128,256,131072 gencfg 1486 424K 2614 16,32,64,256,512,16384,32768,65536 32,64,128,256,512,1024,2048,8192,16384,32768,65536,131072 rtsmsg 131072 module 64,128 mtx_pool 64,128 DEVFS3 DEVFS1 2048 pgrp 8600 session 2829 proc 16384 subproc 572K 24689 2048,131072 cred 619244 plimit 21311 2048 uidinfo 32,512 Copyright © 2010, Juniper Networks, Inc.
Page 426 - 19035108 16,32,64,128,512,1024,2048,8192,16384,32768,65536,131072 ifstate 710270 42176K 9583703 16,32,64,128,256,512,1024,2048,8192,16384,32768 idxbucket itable16 5045 1245K 1825178 1024,4096 itable32 itable64 16384 64,16384 pfestat 1682 32,64,128,256,131072 gencfg 1486 424K 2812 16,32,64,256,512,16384,32768,65536 32768,131072 rtsmsg 131072 module 64,128 mtx_pool 64,128 Copyright © 2010, Juniper Networks, Inc.
Page 427 16,32,64,128,256,4096,32768 vnodemarker 2497 16384 pfs_nodes pfs_vncache GEOM 1068 16,32,64,128,256,512,2048,16384,32768,131072 syncache 16,32,64,128,256,512,2048,16384,32768,131072 tlv_stat 16,32,64,128,256,512,2048,16384,32768,131072 NFS daemon 16,32,64,128,256,512,2048,16384,32768,131072 p1003.1b MD disk 65536 ata_generic 16,16384,32768 ISOFS mount ISOFS node 1439 135K 1453 CAM SIM CAM XPT 16,64,16384 Copyright © 2010, Juniper Networks, Inc.
Page 428 | display xml <rpc-reply xmlns:junos="http://xml.juniper.net/junos/10.2R1/junos"> virtual-memory | <system-virtual-memory-information> display xml <vmstat-memstat-malloc> <memstat-name>CAM dev queue</memstat-name> <inuse>1</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>1</memstat-req> <memstat-size>64</memstat-size> <memstat-name>entropy</memstat-name> <inuse>1024</inuse> <memuse>64</memuse> <high-use>-</high-use> <memstat-req>1024</memstat-req> <memstat-size>64</memstat-size> <memstat-name>linker</memstat-name> <inuse>481</inuse> <memuse>1871</memuse> <high-use>-</high-use> <memstat-req>1145</memstat-req> <memstat-size>16,32,64,4096,32768,131072</memstat-size> <memstat-name>lockf</memstat-name> Copyright © 2010, Juniper Networks, Inc.
Page 429 <memstat-name>in6ifmulti</memstat-name> <inuse>1</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>1</memstat-req> <memstat-size>64</memstat-size> <memstat-name>in6grentry</memstat-name> <inuse>1</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>1</memstat-req> <memstat-size>64</memstat-size> <memstat-name>iflogical</memstat-name> <inuse>13</inuse> <memuse>3</memuse> <high-use>-</high-use> <memstat-req>13</memstat-req> <memstat-size>64,2048</memstat-size> <memstat-name>iffamily</memstat-name> <inuse>28</inuse> <memuse>4</memuse> <high-use>-</high-use> <memstat-req>28</memstat-req> <memstat-size>32,1024,2048</memstat-size> <memstat-name>rtnexthop</memstat-name> <inuse>127</inuse> <memuse>18</memuse> <high-use>-</high-use> <memstat-req>129</memstat-req> <memstat-size>32,256,512,1024,2048,4096</memstat-size> <memstat-name>metrics</memstat-name> <inuse>3</inuse> <memuse>1</memuse> <high-use>-</high-use> Copyright © 2010, Juniper Networks, Inc.
Page 430 <memstat-name>ifdevice</memstat-name> <inuse>4</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>4</memstat-req> <memstat-size>16</memstat-size> <memstat-name>ifstat</memstat-name> <inuse>40</inuse> <memuse>22</memuse> <high-use>-</high-use> <memstat-req>40</memstat-req> <memstat-size>512,16384,32768</memstat-size> <memstat-name>ipfw</memstat-name> <inuse>42</inuse> <memuse>23</memuse> <high-use>-</high-use> <memstat-req>91</memstat-req> <memstat-size>16,32,64,128,256,512,1024,16384,32768,65536,131072</memstat-size> <memstat-name>ifmaddr</memstat-name> <inuse>103</inuse> <memuse>3</memuse> <high-use>-</high-use> <memstat-req>103</memstat-req> <memstat-size>16,32</memstat-size> <memstat-name>rtable</memstat-name> <inuse>129</inuse> <memuse>14</memuse> <high-use>-</high-use> <memstat-req>139</memstat-req> <memstat-size>16,32,64,128,1024,16384</memstat-size> <memstat-name>sysctl</memstat-name> <inuse>0</inuse> <memuse>0</memuse> <high-use>-</high-use> Copyright © 2010, Juniper Networks, Inc.
Page 431 <memstat-req>655</memstat-req> <memstat-size>16,32,64,128,256,1024,2048,4096,16384,32768</memstat-size> <memstat-name>itable16</memstat-name> <inuse>276</inuse> <memuse>52</memuse> <high-use>-</high-use> <memstat-req>294</memstat-req> <memstat-size>1024,4096</memstat-size> <memstat-name>itable32</memstat-name> <inuse>160</inuse> <memuse>10</memuse> <high-use>-</high-use> <memstat-req>160</memstat-req> <memstat-size>64</memstat-size> <memstat-name>itable64</memstat-name> <inuse>2</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>2</memstat-req> <memstat-size>128</memstat-size> <memstat-name>lr</memstat-name> <inuse>1</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>1</memstat-req> <memstat-size>16384</memstat-size> <memstat-name>pic</memstat-name> <inuse>5</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>5</memstat-req> <memstat-size>64,512</memstat-size> <memstat-name>pfestat</memstat-name> <inuse>0</inuse> Copyright © 2010, Juniper Networks, Inc.
Page 432 <memstat-req>2</memstat-req> <memstat-size>131072</memstat-size> <memstat-name>module</memstat-name> <inuse>249</inuse> <memuse>16</memuse> <high-use>-</high-use> <memstat-req>249</memstat-req> <memstat-size>64,128</memstat-size> <memstat-name>mtx_pool</memstat-name> <inuse>1</inuse> <memuse>8</memuse> <high-use>-</high-use> <memstat-req>1</memstat-req> <memstat-size>64,128</memstat-size> <memstat-name>DEVFS3</memstat-name> <inuse>109</inuse> <memuse>12</memuse> <high-use>-</high-use> <memstat-req>117</memstat-req> <memstat-size>256</memstat-size> <memstat-name>DEVFS1</memstat-name> <inuse>102</inuse> <memuse>23</memuse> <high-use>-</high-use> <memstat-req>109</memstat-req> <memstat-size>2048</memstat-size> <memstat-name>pgrp</memstat-name> <inuse>12</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>21</memstat-req> <memstat-size>64</memstat-size> <memstat-name>session</memstat-name> <inuse>8</inuse> Copyright © 2010, Juniper Networks, Inc.
Page 433 <memstat-size>2048</memstat-size> <memstat-name>uidinfo</memstat-name> <inuse>3</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>6</memstat-req> <memstat-size>32,512</memstat-size> <memstat-name>sysctloid</memstat-name> <inuse>1117</inuse> <memuse>34</memuse> <high-use>-</high-use> <memstat-req>1117</memstat-req> <memstat-size>16,32,64</memstat-size> <memstat-name>sysctltmp</memstat-name> <inuse>0</inuse> <memuse>0</memuse> <high-use>-</high-use> <memstat-req>743</memstat-req> <memstat-size>16,32,64,1024</memstat-size> <memstat-name>umtx</memstat-name> <inuse>144</inuse> <memuse>9</memuse> <high-use>-</high-use> <memstat-req>144</memstat-req> <memstat-size>64</memstat-size> <memstat-name>SWAP</memstat-name> <inuse>2</inuse> <memuse>209</memuse> <high-use>-</high-use> <memstat-req>2</memstat-req> <memstat-size>64</memstat-size> <memstat-name>bus</memstat-name> <inuse>496</inuse> <memuse>55</memuse> Copyright © 2010, Juniper Networks, Inc.
Page 434 <memstat-name>DEVFS</memstat-name> <inuse>8</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>9</memstat-req> <memstat-size>16,64</memstat-size> <memstat-name>rman</memstat-name> <inuse>71</inuse> <memuse>5</memuse> <high-use>-</high-use> <memstat-req>433</memstat-req> <memstat-size>16,32,64</memstat-size> <memstat-name>sbuf</memstat-name> <inuse>0</inuse> <memuse>0</memuse> <high-use>-</high-use> <memstat-req>522</memstat-req> <memstat-size>16,32,32768,131072</memstat-size> <memstat-name>NULLFS hash</memstat-name> <inuse>1</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>1</memstat-req> <memstat-size>64</memstat-size> <memstat-name>taskqueue</memstat-name> <inuse>5</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>5</memstat-req> <memstat-size>64</memstat-size> <memstat-name>turnstiles</memstat-name> <inuse>145</inuse> <memuse>10</memuse> Copyright © 2010, Juniper Networks, Inc.
Page 435 <memstat-name>sem</memstat-name> <inuse>4</inuse> <memuse>7</memuse> <high-use>-</high-use> <memstat-req>4</memstat-req> <memstat-size>16384,32768,131072</memstat-size> <memstat-name>shm</memstat-name> <inuse>9</inuse> <memuse>20</memuse> <high-use>-</high-use> <memstat-req>14</memstat-req> <memstat-size>32768</memstat-size> <memstat-name>ttys</memstat-name> <inuse>321</inuse> <memuse>61</memuse> <high-use>-</high-use> <memstat-req>528</memstat-req> <memstat-size>512,32768</memstat-size> <memstat-name>ptys</memstat-name> <inuse>1</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>1</memstat-req> <memstat-size>128</memstat-size> <memstat-name>mbuf_tag</memstat-name> <inuse>0</inuse> <memuse>0</memuse> <high-use>-</high-use> <memstat-req>23383</memstat-req> <memstat-size>16</memstat-size> <memstat-name>soname</memstat-name> <inuse>115</inuse> <memuse>12</memuse> <high-use>-</high-use> Copyright © 2010, Juniper Networks, Inc.
Page 436 <memstat-name>VFS hash</memstat-name> <inuse>1</inuse> <memuse>128</memuse> <high-use>-</high-use> <memstat-req>1</memstat-req> <memstat-size>32,64</memstat-size> <memstat-name>vnodes</memstat-name> <inuse>1</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>1</memstat-req> <memstat-size>512</memstat-size> <memstat-name>mount</memstat-name> <inuse>290</inuse> <memuse>23</memuse> <high-use>-</high-use> <memstat-req>535</memstat-req> <memstat-size>16,32,64,128,256,4096,32768</memstat-size> <memstat-name>vnodemarker</memstat-name> <inuse>0</inuse> <memuse>0</memuse> <high-use>-</high-use> <memstat-req>498</memstat-req> <memstat-size>16384</memstat-size> <memstat-name>pfs_nodes</memstat-name> <inuse>25</inuse> <memuse>3</memuse> <high-use>-</high-use> <memstat-req>25</memstat-req> <memstat-size>128</memstat-size> <memstat-name>pfs_vncache</memstat-name> <inuse>27</inuse> <memuse>1</memuse> <high-use>-</high-use> Copyright © 2010, Juniper Networks, Inc.
Page 437 <memstat-name>NFS daemon</memstat-name> <inuse>1</inuse> <memuse>8</memuse> <high-use>-</high-use> <memstat-req>1</memstat-req> <memstat-size>16,32,64,128,256,512,2048,16384,32768,131072</memstat-size> <memstat-name>p1003.1b</memstat-name> <inuse>1</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>1</memstat-req> <memstat-size>16</memstat-size> <memstat-name>MD disk</memstat-name> <inuse>10</inuse> <memuse>20</memuse> <high-use>-</high-use> <memstat-req>10</memstat-req> <memstat-size>65536</memstat-size> <memstat-name>ata_generic</memstat-name> <inuse>1</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>6</memstat-req> <memstat-size>16,16384,32768</memstat-size> <memstat-name>ISOFS mount</memstat-name> <inuse>8</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>15</memstat-req> <memstat-size>512</memstat-size> <memstat-name>ISOFS node</memstat-name> Copyright © 2010, Juniper Networks, Inc.
Page 438 <memstat-req>1</memstat-req> <memstat-size>256</memstat-size> <memstat-name>pagedep</memstat-name> <inuse>1</inuse> <memuse>32</memuse> <high-use>-</high-use> <memstat-req>106</memstat-req> <memstat-size>64</memstat-size> <memstat-name>inodedep</memstat-name> <inuse>1</inuse> <memuse>128</memuse> <high-use>-</high-use> <memstat-req>464</memstat-req> <memstat-size>256</memstat-size> <memstat-name>newblk</memstat-name> <inuse>1</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>336</memstat-req> <memstat-size>64,4096</memstat-size> <memstat-name>bmsafemap</memstat-name> <inuse>0</inuse> <memuse>0</memuse> <high-use>-</high-use> <memstat-req>63</memstat-req> <memstat-size>64</memstat-size> <memstat-name>allocdirect</memstat-name> <inuse>0</inuse> <memuse>0</memuse> <high-use>-</high-use> <memstat-req>320</memstat-req> <memstat-size>128</memstat-size> <memstat-name>indirdep</memstat-name> <inuse>0</inuse> Copyright © 2010, Juniper Networks, Inc.
Page 439 <memstat-name>diradd</memstat-name> <inuse>0</inuse> <memuse>0</memuse> <high-use>-</high-use> <memstat-req>465</memstat-req> <memstat-size>64</memstat-size> <memstat-name>mkdir</memstat-name> <inuse>0</inuse> <memuse>0</memuse> <high-use>-</high-use> <memstat-req>136</memstat-req> <memstat-size>32</memstat-size> <memstat-name>dirrem</memstat-name> <inuse>0</inuse> <memuse>0</memuse> <high-use>-</high-use> <memstat-req>168</memstat-req> <memstat-size>32</memstat-size> <memstat-name>newdirblk</memstat-name> <inuse>0</inuse> <memuse>0</memuse> <high-use>-</high-use> <memstat-req>1</memstat-req> <memstat-size>32</memstat-size> <memstat-name>savedino</memstat-name> <inuse>0</inuse> <memuse>0</memuse> <high-use>-</high-use> <memstat-req>157</memstat-req> <memstat-size>512</memstat-size> <memstat-name>UFS mount</memstat-name> <inuse>15</inuse> <memuse>36</memuse> Copyright © 2010, Juniper Networks, Inc.
Page 440 <memstat-name>VM pgdata</memstat-name> <inuse>2</inuse> <memuse>65</memuse> <high-use>-</high-use> <memstat-req>2</memstat-req> <memstat-size>64</memstat-size> <memstat-name>sigio</memstat-name> <inuse>1</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>20</memstat-req> <memstat-size>32</memstat-size> <memstat-name>kenv</memstat-name> <inuse>24</inuse> <memuse>5</memuse> <high-use>-</high-use> <memstat-req>27</memstat-req> <memstat-size>16,32,64,131072</memstat-size> <memstat-name>atkbddev</memstat-name> <inuse>2</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>2</memstat-req> <memstat-size>32</memstat-size> <memstat-name>kqueue</memstat-name> <inuse>15</inuse> <memuse>9</memuse> <high-use>-</high-use> <memstat-req>19</memstat-req> <memstat-size>1024,4096,32768</memstat-size> <memstat-name>proc-args</memstat-name> <inuse>57</inuse> <memuse>3</memuse> <high-use>-</high-use> Copyright © 2010, Juniper Networks, Inc.
Page 441 <memuse>4</memuse> <high-use>-</high-use> <memstat-req>1</memstat-req> <memstat-size>131072</memstat-size> <memstat-name>nexusdev</memstat-name> <inuse>2</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>2</memstat-req> <memstat-size>16</memstat-size> <memstat-name>CAM queue</memstat-name> <inuse>3</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>3</memstat-req> <memstat-size>16</memstat-size> <memstat-name>$PIR</memstat-name> <inuse>4</inuse> <memuse>1</memuse> <high-use>-</high-use> <memstat-req>4</memstat-req> <memstat-size>32</memstat-size> <memstat-name>KTRACE</memstat-name> <inuse>100</inuse> <memuse>10</memuse> <high-use>-</high-use> <memstat-req>100</memstat-req> <memstat-size>128</memstat-size> <memstat-name>kbdmux</memstat-name> <inuse>5</inuse> <memuse>9</memuse> <high-use>-</high-use> <memstat-req>5</memstat-req> Copyright © 2010, Juniper Networks, Inc.
Page 442 <zone-req>5</zone-req> <zone-name>16 Bucket:</zone-name> <zone-size>76</zone-size> <count-limit>0</count-limit> <used>30</used> <free>20</free> <zone-req>30</zone-req> <zone-name>32 Bucket:</zone-name> <zone-size>140</zone-size> <count-limit>0</count-limit> <used>33</used> <free>23</free> <zone-req>33</zone-req> <zone-name>64 Bucket:</zone-name> <zone-size>268</zone-size> <count-limit>0</count-limit> <used>33</used> <free>9</free> <zone-req>33</zone-req> <zone-name>128 Bucket:</zone-name> <zone-size>524</zone-size> <count-limit>0</count-limit> <used>49</used> <free>0</free> <zone-req>49</zone-req> <zone-name>VM OBJECT:</zone-name> <zone-size>128</zone-size> <count-limit>0</count-limit> <used>2111</used> Copyright © 2010, Juniper Networks, Inc.
Page 443 <zone-size>72</zone-size> <count-limit>0</count-limit> <used>0</used> <free>0</free> <zone-req>0</zone-req> <zone-name>mt_zone:</zone-name> <zone-size>64</zone-size> <count-limit>0</count-limit> <used>238</used> <free>57</free> <zone-req>238</zone-req> <zone-name>16:</zone-name> <zone-size>16</zone-size> <count-limit>0</count-limit> <used>2114</used> <free>119</free> <zone-req>80515</zone-req> <zone-name>32:</zone-name> <zone-size>32</zone-size> <count-limit>0</count-limit> <used>1335</used> <free>134</free> <zone-req>10259</zone-req> <zone-name>64:</zone-name> <zone-size>64</zone-size> <count-limit>0</count-limit> <used>3529</used> <free>129</free> <zone-req>29110</zone-req> <zone-name>96:</zone-name> <zone-size>96</zone-size> <count-limit>0</count-limit> <used>2062</used> <free>58</free> Copyright © 2010, Juniper Networks, Inc.
Page 444 <count-limit>0</count-limit> <used>204</used> <free>36</free> <zone-req>1225</zone-req> <zone-name>288:</zone-name> <zone-size>288</zone-size> <count-limit>0</count-limit> <used>2</used> <free>24</free> <zone-req>10</zone-req> <zone-name>512:</zone-name> <zone-size>512</zone-size> <count-limit>0</count-limit> <used>49</used> <free>7</free> <zone-req>911</zone-req> <zone-name>1024:</zone-name> <zone-size>1024</zone-size> <count-limit>0</count-limit> <used>213</used> <free>11</free> <zone-req>1076</zone-req> <zone-name>2048:</zone-name> <zone-size>2048</zone-size> <count-limit>0</count-limit> <used>199</used> <free>113</free> <zone-req>640</zone-req> <zone-name>4096:</zone-name> <zone-size>4096</zone-size> <count-limit>0</count-limit> <used>144</used> <free>7</free> <zone-req>2249</zone-req> Copyright © 2010, Juniper Networks, Inc.
Page 445 <used>127</used> <free>73</free> <zone-req>131</zone-req> <zone-name>UPCALL:</zone-name> <zone-size>44</zone-size> <count-limit>0</count-limit> <used>0</used> <free>0</free> <zone-req>0</zone-req> <zone-name>SLEEPQUEUE:</zone-name> <zone-size>32</zone-size> <count-limit>0</count-limit> <used>145</used> <free>194</free> <zone-req>145</zone-req> <zone-name>VMSPACE:</zone-name> <zone-size>268</zone-size> <count-limit>0</count-limit> <used>57</used> <free>13</free> <zone-req>1335</zone-req> <zone-name>mbuf_packet:</zone-name> <zone-size>256</zone-size> <count-limit>180000</count-limit> <used>256</used> <free>128</free> <zone-req>49791</zone-req> <zone-name>mbuf:</zone-name> <zone-size>256</zone-size> <count-limit>180000</count-limit> <used>50</used> <free>466</free> <zone-req>105183</zone-req> <zone-name>mbuf_cluster:</zone-name> Copyright © 2010, Juniper Networks, Inc.
Page 446 <free>0</free> <zone-req>0</zone-req> <zone-name>g_bio:</zone-name> <zone-size>132</zone-size> <count-limit>0</count-limit> <used>0</used> <free>174</free> <zone-req>69750</zone-req> <zone-name>ata_request:</zone-name> <zone-size>200</zone-size> <count-limit>0</count-limit> <used>0</used> <free>57</free> <zone-req>5030</zone-req> <zone-name>ata_composite:</zone-name> <zone-size>192</zone-size> <count-limit>0</count-limit> <used>0</used> <free>0</free> <zone-req>0</zone-req> <zone-name>GENCFG:</zone-name> <zone-size>72</zone-size> <count-limit>1000004</count-limit> <used>57</used> <free>102</free> <zone-req>57</zone-req> <zone-name>VNODE:</zone-name> <zone-size>292</zone-size> <count-limit>0</count-limit> <used>2718</used> <free>25</free> <zone-req>2922</zone-req> <zone-name>VNODEPOLL:</zone-name> <zone-size>72</zone-size> Copyright © 2010, Juniper Networks, Inc.
Page 447 <zone-req>0</zone-req> <zone-name>NFSNODE:</zone-name> <zone-size>460</zone-size> <count-limit>0</count-limit> <used>0</used> <free>0</free> <zone-req>0</zone-req> <zone-name>PIPE:</zone-name> <zone-size>404</zone-size> <count-limit>0</count-limit> <used>27</used> <free>9</free> <zone-req>717</zone-req> <zone-name>KNOTE:</zone-name> <zone-size>72</zone-size> <count-limit>0</count-limit> <used>42</used> <free>64</free> <zone-req>3311</zone-req> <zone-name>socket:</zone-name> <zone-size>412</zone-size> <count-limit>25191</count-limit> <used>343</used> <free>8</free> <zone-req>2524</zone-req> <zone-name>unpcb:</zone-name> <zone-size>140</zone-size> <count-limit>25200</count-limit> <used>170</used> <free>26</free> <zone-req>2157</zone-req> <zone-name>ipq:</zone-name> <zone-size>52</zone-size> <count-limit>216</count-limit> Copyright © 2010, Juniper Networks, Inc.
Page 448 <zone-size>128</zone-size> <count-limit>15360</count-limit> <used>0</used> <free>60</free> <zone-req>55</zone-req> <zone-name>tcpreass:</zone-name> <zone-size>20</zone-size> <count-limit>1690</count-limit> <used>0</used> <free>0</free> <zone-req>0</zone-req> <zone-name>sackhole:</zone-name> <zone-size>20</zone-size> <count-limit>0</count-limit> <used>0</used> <free>0</free> <zone-req>0</zone-req> <zone-name>ripcb:</zone-name> <zone-size>232</zone-size> <count-limit>25194</count-limit> <used>5</used> <free>29</free> <zone-req>5</zone-req> <zone-name>SWAPMETA:</zone-name> <zone-size>276</zone-size> <count-limit>94948</count-limit> <used>0</used> <free>0</free> <zone-req>0</zone-req> <zone-name>FFS inode:</zone-name> <zone-size>132</zone-size> <count-limit>0</count-limit> <used>1146</used> Copyright © 2010, Juniper Networks, Inc.
Page 449 <swap-pagedin>0</swap-pagedin> <swap-pageouts>0</swap-pageouts> <swap-pagedout>0</swap-pagedout> <vnode-pageins>23094</vnode-pageins> <vnode-pagedin>23119</vnode-pagedin> <vnode-pageouts>226</vnode-pageouts> <vnode-pagedout>3143</vnode-pagedout> <page-daemon-wakeup>0</page-daemon-wakeup> <page-daemon-examined-pages>0</page-daemon-examined-pages> <pages-reactivated>8821</pages-reactivated> <copy-on-write-faults>48364</copy-on-write-faults> <copy-on-write-optimized-faults>31</copy-on-write-optimized-faults> <zero-fill-pages-zeroed>74665</zero-fill-pages-zeroed> <zero-fill-pages-prezeroed>70061</zero-fill-pages-prezeroed> <transit-blocking-page-faults>85</transit-blocking-page-faults> <total-vm-faults>191824</total-vm-faults> <pages-affected-by-kernel-thrd-creat>0</pages-affected-by-kernel-thrd-creat> <pages-affected-by-fork>95343</pages-affected-by-fork> <pages-affected-by-vfork>3526</pages-affected-by-vfork> <pages-affected-by-rfork>0</pages-affected-by-rfork> <pages-freed>221502</pages-freed> <pages-freed-by-deamon>0</pages-freed-by-deamon> <pages-freed-by-exiting-proc>75630</pages-freed-by-exiting-proc> <pages-active>45826</pages-active> <pages-inactive>13227</pages-inactive> <pages-in-vm-cache>49278</pages-in-vm-cache> <pages-wired-down>10640</pages-wired-down> <pages-free>70706</pages-free> <bytes-per-page>4096</bytes-per-page> <swap-pages-used>0</swap-pages-used> <peak-swap-pages-used>0</peak-swap-pages-used> <total-name-lookups>214496</total-name-lookups> <positive-cache-hits>92</positive-cache-hits> <negative-cache-hits>5</negative-cache-hits> Copyright © 2010, Juniper Networks, Inc.
Page 450 <intr-rate>0</intr-rate> <intr-name>irq8: rtc </intr-name> <intr-cnt>159164</intr-cnt> <intr-rate>127</intr-rate> <intr-name>irq9: cbb1 fxp0 </intr-name> <intr-cnt>28490</intr-cnt> <intr-rate>22</intr-rate> <intr-name>irq10: fxp1 </intr-name> <intr-cnt>20593</intr-cnt> <intr-rate>16</intr-rate> <intr-name>irq14: ata0 </intr-name> <intr-cnt>5031</intr-cnt> <intr-rate>4</intr-rate> <intr-name>Total</intr-name> <intr-cnt>1457873</intr-cnt> <intr-rate>1171</intr-rate> </vmstat-intr> <vm-kernel-state> <vm-kmem-map-free>248524800</vm-kmem-map-free> </vm-kernel-state> </system-virtual-memory-information> <cli> <banner></banner> </cli> </rpc-reply> Copyright © 2010, Juniper Networks, Inc.
Page 451: Table 57: Show Task Replication Output Fields
RE mode: Master Routing Engine) Routing Engine) Protocol Synchronization Status OSPF NotStarted Complete IS-IS NotStarted Complete show task replication user@host> show task replication Stateful Replication: Enabled (Issued on the Backup RE mode: Master Routing Engine) Copyright © 2010, Juniper Networks, Inc.
Page 452: Show Version
T1600 router that is connected to the TX Matrix Plus router. Replace with a value from through number local —(EX4200 switches only) (Optional) Display standard information about the hostname and version of the software running on the local Virtual Chassis member. Copyright © 2010, Juniper Networks, Inc.
Page 453 TX Matrix Plus router) backup Routing Engines that are connected to Required Privilege view Level List of Sample Output show version on page 358 show version (TX Matrix Plus Router) on page 358 Copyright © 2010, Juniper Networks, Inc.
Page 454 1024 1024 16,32,64,128,256,1024,2048 linker 6216K 1166 16,32,64,4096,32768,131072 USBdev 16,128,2048,16384 lockf 64872 devbuf 21086 15337K 21661 16,32,64,128,256,512,1024,2048,4096,16384,32768,65536,131072 temp 1249 149K 9479 16,32,64,128,256,512,2048,4096,16384,32768,65536,131072 ip6ndp in6ifmulti in6grentry iftable 16,64,4096 iflogical 64,2048 iffamily 32,1024,2048 rtnexthop 16,32,64,256,512,1024,2048,4096,8192,16384 metrics inifmulti Copyright © 2010, Juniper Networks, Inc.
Page 455 SWAP 277K 126K 3263 16,32,64,128,32768 bus-sc 1623 16,32,64,512,1024,4096,16384,65536,131072 DEVFS 16,64 devstat 16,131072 eventhandler 32,128 kobj 186K 65536 rman 16,32,64 sbuf 1112 16,32,32768,131072 NULLFS hash taskqueue turnstiles Unitno 16,64 ioctlops 477380 16,32,64,128,16384,65536,131072 49032 16,64,128,256,512,1024,2048,131072 32768,131072 Copyright © 2010, Juniper Networks, Inc.
Page 456 ISOFS mount VM pgdata ISOFS node 1405 132K 1419 CAM SIM atkbddev Gzip trees 470292 32,64,128,1024,8192,32768,65536,131072 CAM XPT 16,64,16384 isadev CAM periph I/O APIC 32768 ad_driver legacydrv memdesc 131072 MP Table nexusdev ata_dma cdev Copyright © 2010, Juniper Networks, Inc.
Page 457 192, VNODE: 292, 4128, 4583 VNODEPOLL: S VFS Cache: 3890, 9271 L VFS Cache: 291, NAMEI: 1024, 341732 NFSMOUNT: 480, NFSNODE: 460, PIPE: 404, 1825 KNOTE: 15004 socket: 412, 30006, 352, 4683 ipq: 288, Copyright © 2010, Juniper Networks, Inc.
Page 458 0 peak swap pages used 1295493 total name lookups cache hits (93% pos + 5% neg) system 0% per-directory deletions 0%, falsehits 0%, toolong 0% interrupt total rate irq4: sio0 5131 irq16: uhci0 uhci* 164201 Copyright © 2010, Juniper Networks, Inc.
Page 459 Chapter 17: Operational Mode Commands for System Setup irq17: uhci1 uhci* 386684 cpu0: timer 8131301 2017 Total 8687317 2155 vm.kmem_map_free: 618377216 Copyright © 2010, Juniper Networks, Inc.
Page 461: Junos Os For Ex Series Switches Power Management
Power Management Overview on page 367 Initial Configuration on page 383 Verifying Power Management on page 385 Configuration Statements for Power Management on page 387 Operational Mode Commands for Power Management on page 391 Copyright © 2010, Juniper Networks, Inc.
Page 463: Power Management Overview
EX Series Switch Software Features Overview The following tables list the Juniper Networks EX Series Ethernet Switches software features and the Juniper Networks Junos operating system (Junos OS) release in which they were introduced: Table 1 on page 4—Access Control Features Table 2 on page 5—Administration Features...
Page 464: Table 58: Access Control Features
Junos OS 10.1R1 9.0R2 10.2R1 9.4R1 Server fail fallback Junos OS Junos OS Junos OS Junos OS 10.1R1 9.3R2 10.2R1 10.2R1 TACACS+ Junos OS Junos OS Junos OS Junos OS 10.1R1 9.0R2 10.2R1 9.4R1 Copyright © 2010, Juniper Networks, Inc.
Page 465: Table 59: Administration Features
EX4500 Switches EX8200 Switches Graceful protocol restart for BGP Not applicable Junos OS 9.0R2 Not applicable Junos OS 9.4R1 Graceful protocol restart for IS-IS Not applicable Junos OS 9.3R2 Not applicable Junos OS 9.4R1 Copyright © 2010, Juniper Networks, Inc.
Page 466 Split and merge Virtual Chassis Not applicable Junos OS 10.0R1 Not applicable Not applicable (EX4200 only) Automatic software update on prospective member switches Front-panel configuration of uplink module ports as Virtual Chassis ports (VCPs) Copyright © 2010, Juniper Networks, Inc.
Page 467: Table 62: Interfaces Features
Junos OS 9.3R2 Not supported Not supported Local DHCP server Not supported Junos OS 9.3R2 Not supported Junos OS 9.4R1 Static addresses Junos OS 10.1R1 Junos OS 9.0R2 Junos OS 10.2R1 Junos OS 9.4R1 Copyright © 2010, Juniper Networks, Inc.
Page 468: Table 64: Ipv6 Features
Junos OS 10.0R1 Not supported Junos OS 10.0R1 (MVRP) Private VLANs (PVLANs) Not supported Junos OS 9.3R2 Not supported Junos OS 10.1R1 Proxy ARP—restricted Junos OS 10.1R1 Junos OS 10.0R1 Junos OS 10.2R1 Junos OS 10.0R1 Copyright © 2010, Juniper Networks, Inc.
Page 469: Table 66: Layer 3 Protocols Features
Junos OS 9.4R1 Table 66: Layer 3 Protocols Features EX3200 and EX4200 Feature EX2200 Switches Switches EX4500 Switches EX8200 Switches Bidirectional Forwarding Detection Not supported Junos OS 9.0R2 Junos OS 10.2R1 Junos OS 9.4R1 (BFD) Copyright © 2010, Juniper Networks, Inc.
Page 470 VRF with IPv4—virtual routing Not supported Junos OS 10.0R1 Not supported Junos OS 10.0R1 instances for multicast traffic VRF with IPv6—virtual routing Not supported Junos OS 10.1R1 Not supported Junos OS 10.1R1 instances for multicast traffic Copyright © 2010, Juniper Networks, Inc.
Page 471 Not supported Junos OS 9.4R1 Junos OS 10.2R1 Junos OS 9.4R1 (MSDP) http://www.juniper.net/techpubs/software/junos/index.html See the Junos OS Multicast Configuration Guide at Multicast VLAN registration (MVR) Not supported Junos OS 9.6R1 Not supported Not supported Copyright © 2010, Juniper Networks, Inc.
Page 472: Table 69: Network Management And Monitoring Features
VLAN on the intermediate switch Real-time performance monitoring Junos OS 10.1R1 Junos OS 9.3R2 Junos OS 10.2R1 Junos OS 10.1R1 (RPM) RMON Junos OS 10.1R1 Junos OS 9.0R2 Junos OS 10.2R1 Junos OS 9.4R1 Copyright © 2010, Juniper Networks, Inc.
Page 473: Table 70: Port Security Features
EX4500 Switches EX8200 Switches Autoinstallation of configuration files Junos OS 10.1R1 Junos OS 9.4R1 Junos OS 10.2R1 Not supported Automatic software download Junos OS 10.1R1 Junos OS 9.6R1 Junos OS 10.2R1 Junos OS 9.6R1 Copyright © 2010, Juniper Networks, Inc.
Page 474: Power Supply Redundancy
Understanding Power Management on EX Series Switches on page 378 Understanding Power Management on EX Series Switches The power management feature for Juniper Networks EX8200 Ethernet Switches helps ensure that normal operation of the system is not disrupted because of insufficient power to the switch.
Page 475 Restarting a line card, however, does not affect the power allocated to it. Thus when power is insufficient, restarting a line card does not change its operating status or the operating status of other line cards. Copyright © 2010, Juniper Networks, Inc.
Page 476 By default, power management in EX8200 switches is configured to manage the power supplies for N+1 redundancy, in which one power supply is held in reserve for backup if one of the other power supplies is removed or fails. Copyright © 2010, Juniper Networks, Inc.
Page 477 For example, if you have an N+N configuration with three online 2000 W power supplies, power management allocates 2000 W to redundant power. If you bring a fourth 2000 W power supply online, power Copyright © 2010, Juniper Networks, Inc.
Page 478 Understanding Alarm Types and Severity Levels on EX Series Switches on page 637 Documentation Configuring the Power Priority of Line Cards (CLI Procedure) on page 384 Configuring Power Supply Redundancy (CLI Procedure) on page 383 Verifying Power Configuration and Use on page 385 Copyright © 2010, Juniper Networks, Inc.
Page 479: Initial Configuration
60 percent in an N+N configuration from 80 percent in an N+1 configuration. Because the maximum fan speed is reduced, it is possible that a line card that overheats would be shut down sooner in an N+N configuration than in an N+1 configuration. Copyright © 2010, Juniper Networks, Inc.
Page 480: Configuring The Power Priority Of Line Cards (Cli Procedure)
6 power-budget-priority 0 Related Configuring Power Supply Redundancy (CLI Procedure) on page 383 Documentation Verifying Power Configuration and Use on page 385 Understanding Power Management on EX Series Switches on page 378 Copyright © 2010, Juniper Networks, Inc.
Page 481: Verifying Power Management
450 W. However, it does have enough power for an additional 48-port SFP line card, which requires only 330 W. The 8-port SFP+ line card in slot 6 has a higher power priority than the 48-port SFP line card line card in slot 5. Copyright © 2010, Juniper Networks, Inc.
Page 482 Related Configuring Power Supply Redundancy (CLI Procedure) on page 383 Documentation Configuring the Power Priority of Line Cards (CLI Procedure) on page 384 Copyright © 2010, Juniper Networks, Inc.
Page 484 Related Setting the Mode on an SFP+ Uplink Module (CLI Procedure) on page 1156 Documentation Configuring the Power Priority of Line Cards (CLI Procedure) on page 384 Copyright © 2010, Juniper Networks, Inc.
Page 485: N-Plus-N
Range: 0 through 15 for an EX8216 switch Required Privilege interface—To view this statement in the configuration. Level interface-control—To add this statement to the configuration. Related Configuring the Power Priority of Line Cards (CLI Procedure) on page 384 Documentation Copyright © 2010, Juniper Networks, Inc.
Page 486: Redundancy (Power Management)
N+1 power supply redundancy is configured by default. Required Privilege interface—To view this statement in the configuration. Level interface-control—To add this statement to the configuration. Related Configuring Power Supply Redundancy (CLI Procedure) on page 383 Documentation Copyright © 2010, Juniper Networks, Inc.
Page 488: Show Chassis Power-Budget-Statistics
Because the amount budgeted is based on maximum power requirements, the real power consumption of the switch is likely to be less than this figure. Copyright © 2010, Juniper Networks, Inc.
Page 489 6000 W Power Redundancy Configuration Power Reserved for the Chassis 1600 W (EX8200-8XS ) 450 W Priority: 7 Actual Power Used 2050 W Power Available (Redundant case) 1950 W Total Power Available 3950 W Copyright © 2010, Juniper Networks, Inc.
Page 491: Chapter 23 Configuration Management Overview
Configuration Management Overview on page 397 Managing Junos OS Configuration on page 417 Verifying Configuration on page 435 Configuration Statements for Configuration Management on page 437 Operational Mode Commands for Configuration Management on page 447 Copyright © 2010, Juniper Networks, Inc.
Page 493: Configuration Files—Overview
For more information, see “Configuration Files Terms” on page 398. Juniper Networks Junos operating system (Junos OS) saves the 50 most recently committed configuration files on the switch so that you can return to a previous configuration.
Page 494: Configuration Files Terms
Managing Configuration Files Through the Configuration History (J-Web Procedure) on page 424 Reverting to the Rescue Configuration for the EX Series Switch on page 429 Understanding Configuration Files for EX Series Switches on page 397 Copyright © 2010, Juniper Networks, Inc.
Page 495: Understanding Automatic Refreshing Of Scripts On Ex Series Switches
Autoinstallation takes place automatically when you connect an Ethernet port on a new switch to the network and power on the switch. You can also explicitly enable autoinstallation on Juniper Networks EX Series Ethernet Switches in your network to implement autoinstallation when they are powered on. To configure autointallation, you specify a configuration server, an autoinstallation interface, and a protocol for IP address acquisition.
Page 496: Autoinstallation Configuration Files And Ip Addresses
If the DHCP server provides the server’s hostname, a DNS server must be available on the network to resolve the name to an IP address. The IP address of an intermediate device if the configuration server is on a different LAN segment from the new switch. Copyright © 2010, Juniper Networks, Inc.
Page 497: Ex Series Switches Default Configuration
EX2200 switch configures Ethernet switching and storm control on all interfaces, configures Power over Ethernet (PoE) on all interfaces of models that provide PoE, and enables the LLDP, LLDP-MED, and RSTP protocols and IGMP snooping. Copyright © 2010, Juniper Networks, Inc.
Page 498 { interface all; rstp; poe { interface all; interfaces { ge-0/0/0 { unit 0 { family ethernet-switching; ge-0/0/1 { unit 0 { family ethernet-switching; ge-0/0/2 { unit 0 { family ethernet-switching; ge-0/0/3 { Copyright © 2010, Juniper Networks, Inc.
Page 499 { unit 0 { family ethernet-switching; ge-0/0/11 { unit 0 { family ethernet-switching; ge-0/0/12 { unit 0 { family ethernet-switching; ge-0/0/13 { unit 0 { family ethernet-switching; ge-0/0/14 { unit 0 { Copyright © 2010, Juniper Networks, Inc.
Page 500 { unit 0 { family ethernet-switching; ge-0/0/22 { unit 0 { family ethernet-switching; ge-0/0/23 { unit 0 { family ethernet-switching; ge-0/1/0 { unit 0 { family ethernet-switching; ge-0/1/1 { unit 0 { family ethernet-switching; Copyright © 2010, Juniper Networks, Inc.
Page 501: Ex3200 And Ex4200 Default Configuration
See “Reverting to the Default Factory Configuration for the EX Series Switch” on page 427. The following factory default configuration file is for an EX3200 or EX4200 switch with 24 ports (for models that have more ports, this default configuration file has more interfaces): Copyright © 2010, Juniper Networks, Inc.
Page 502 { unit 0 { family ethernet-switching; ge-0/0/1 { unit 0 { family ethernet-switching; ge-0/0/2 { unit 0 { family ethernet-switching; ge-0/0/3 { unit 0 { family ethernet-switching; ge-0/0/4 { unit 0 { family ethernet-switching; Copyright © 2010, Juniper Networks, Inc.
Page 503 0 { family ethernet-switching; ge-0/0/12 { unit 0 { family ethernet-switching; ge-0/0/13 { unit 0 { family ethernet-switching; ge-0/0/14 { unit 0 { family ethernet-switching; ge-0/0/15 { unit 0 { family ethernet-switching; ge-0/0/16 { Copyright © 2010, Juniper Networks, Inc.
Page 504 { unit 0 { family ethernet-switching; xe-0/1/0 { unit 0 { family ethernet-switching; xe-0/1/1 { unit 0 { family ethernet-switching; ge-0/1/0 { unit 0 { family ethernet-switching; ge-0/1/1 { unit 0 { Copyright © 2010, Juniper Networks, Inc.
Page 505: Ex4500 Default Configuration
The default configuration file sets values for system parameters such as , configures syslog commit Ethernet switching on all interfaces, enables IGMP snooping, and enables the LLDP and RSTP protocols. Copyright © 2010, Juniper Networks, Inc.
Page 506 { factory-settings { reset-chassis-lcd-menu; reset-virtual-chassis-configuration; interfaces { xe-0/0/0 { unit 0 { family ethernet-switching; xe-0/0/1 { unit 0 { family ethernet-switching; xe-0/0/2 { unit 0 { family ethernet-switching; xe-0/0/3 { unit 0 { Copyright © 2010, Juniper Networks, Inc.
Page 507 { unit 0 { family ethernet-switching; xe-0/0/11 { unit 0 { family ethernet-switching; xe-0/0/12 { unit 0 { family ethernet-switching; xe-0/0/13 { unit 0 { family ethernet-switching; xe-0/0/14 { unit 0 { family ethernet-switching; Copyright © 2010, Juniper Networks, Inc.
Page 508 { unit 0 { family ethernet-switching; xe-0/0/22 { unit 0 { family ethernet-switching; xe-0/0/23 { unit 0 { family ethernet-switching; xe-0/0/24 { unit 0 { family ethernet-switching; xe-0/0/25 { unit 0 { family ethernet-switching; Copyright © 2010, Juniper Networks, Inc.
Page 509 { unit 0 { family ethernet-switching; xe-0/0/33 { unit 0 { family ethernet-switching; xe-0/0/34 { unit 0 { family ethernet-switching; xe-0/0/35 { unit 0 { family ethernet-switching; xe-0/0/36 { unit 0 { family ethernet-switching; Copyright © 2010, Juniper Networks, Inc.
Page 510 { unit 0 { family ethernet-switching; xe-0/2/0 { unit 0 { family ethernet-switching; xe-0/2/1 { unit 0 { family ethernet-switching; xe-0/2/2 { unit 0 { family ethernet-switching; xe-0/2/3 { unit 0 { family ethernet-switching; Copyright © 2010, Juniper Networks, Inc.
Page 511: Ex8200 Switch Default Configuration
Switch” on page 427. This topic shows the factory default configuration file of an EX8200 switch: system { arp { aging-timer 5 syslog { user * { any emergency; file messages { any notice; authorization info; Copyright © 2010, Juniper Networks, Inc.
Page 512 Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 189 Understanding Configuration Files for EX Series Switches on page 397 EX8208 Switch Hardware Overview on page 33 EX8216 Switch Hardware Overview on page 36 Copyright © 2010, Juniper Networks, Inc.
Page 513: Managing Junos Os Configuration
Using the CLI Editor in the J-Web Interface to Edit Configuration Text Use the CLI Editor to edit configuration if you know the Junos OS CLI or prefer a command interface. To edit the entire configuration in text format: Copyright © 2010, Juniper Networks, Inc.
Page 514: Text
(toggle). Table 75: J-Web Edit Point & Click Configuration Links Link Function Add new entry Displays fields and lists for a statement identifier, allowing you to add a new identifier to a statement. Copyright © 2010, Juniper Networks, Inc.
Page 515: Table 76: J-Web Edit Point & Click Configuration Icons
Updates the display with any changes to the configuration made by other users. Commit Verifies edits and applies them to the current configuration file running on the switch. Discard Removes edits applied to or deletes existing statements or identifiers from the candidate configuration. Copyright © 2010, Juniper Networks, Inc.
Page 516 Choose an action. See Table 78 on page 421 for details on the actions. Configure the commit options by selecting . See Table 79 on page 421 for Preference details on preference options. Copyright © 2010, Juniper Networks, Inc.
Page 517: Managing Junos Os Configuration
J-Web User Interface for EX Series Switches Overview on page 145 Documentation EX Series Switch Software Features Overview on page 3 Managing Junos OS Configuration Uploading a Configuration File (CLI Procedure) on page 422 Uploading a Configuration File (J-Web Procedure) on page 423 Copyright © 2010, Juniper Networks, Inc.
Page 518: Uploading A Configuration File (Cli Procedure)
Press Ctrl+A to select all the text in the configuration file. Press Ctrl+C to copy the contents of the configuration text file to the Clipboard. Copyright © 2010, Juniper Networks, Inc.
Page 519: Uploading A Configuration File (J-Web Procedure)
Specify the name of the file to upload using one of the following methods: Type the absolute path and filename in the File to Upload box. Click to navigate to the file. Browse Click Upload and Commit to upload and commit the configuration. Copyright © 2010, Juniper Networks, Inc.
Page 520: Displaying Configuration History
—A Junos XML protocol client performed the operation. Commit operations performed by users junoscript through the J-Web interface are identified in this way. —An SNMP request started the operation. snmp other —Another method was used to commit the configuration. Comment Comment. Copyright © 2010, Juniper Networks, Inc.
Page 521: Displaying Users Editing The Configuration
Select the check boxes to the left of the two configuration versions you want to compare. Click Compare The main pane displays the differences between the two configuration files at each hierarchy level as follows: Copyright © 2010, Juniper Networks, Inc.
Page 522: Downloading A Configuration File With The J-Web Interface
You can return to a previously committed configuration file if you need to revert to a previous configuration. The EX Series switch saves the last 50 committed configurations, including the rollback number, date, time, and name of the user who issued the commit configuration command. Copyright © 2010, Juniper Networks, Inc.
Page 523: Reverting To The Default Factory Configuration For The Ex Series Switch
Switch” on page 429. The default factory configuration contains the basic configuration settings. This is the first configuration of the switch and it is loaded when the switch is first installed and powered on. Copyright © 2010, Juniper Networks, Inc.
Page 524: Panel
Reverting to the Default Factory Configuration by Using the Load Factory Default Command load factory default command is a standard Junos OS configuration command. This configuration command replaces the current active configuration with the default factory configuration. Copyright © 2010, Juniper Networks, Inc.
Page 525: Reverting To The Rescue Configuration For The Ex Series Switch
You can also revert to the default factory configuration, as described in “Reverting to the Default Factory Configuration for the EX Series Switch” on page 427. Before you begin to revert to the rescue configuration: Ensure that you have physical access to the switch. Copyright © 2010, Juniper Networks, Inc.
Page 526: Setting Or Deleting The Rescue Configuration (Cli Procedure)
IP address (accessible from the network) for the management port. To set the current active configuration as the rescue configuration: user@switch> request system configuration rescue save To delete an existing rescue configuration: user@switch> request system configuration rescue delete Copyright © 2010, Juniper Networks, Inc.
Page 527: Setting Or Deleting The Rescue Configuration (J-Web Procedure)
Delete rescue configuration Related Setting or Deleting the Rescue Configuration (CLI Procedure) on page 430 Documentation Reverting to the Rescue Configuration for the EX Series Switch on page 429 Configuration Files Terms on page 398 Copyright © 2010, Juniper Networks, Inc.
Page 528: Configuring Autoinstallation Of Configuration Files (Cli Procedure)
Configure the DHCP server to provide a filename to each new switch. hostname.conf Each switch uses its hostname.conf filename to request a configuration file from Copyright © 2010, Juniper Networks, Inc.
Page 529 Verifying Autoinstallation Status on an EX Series Switch on page 435 Documentation Understanding Autoinstallation of Configuration Files on EX Series Switches on page 399 DHCP Services for EX Series Switches Overview on page 547 Copyright © 2010, Juniper Networks, Inc.
Page 531: Verifying Configuration
The output shows the settings configured for autoinstallation. Verify that the values displayed are correct for the switch when it is deployed on the network. Related Configuring Autoinstallation of Configuration Files (CLI Procedure) on page 432 Documentation Copyright © 2010, Juniper Networks, Inc.
Page 533: Configuration Statements For Configuration Management
Level admin-control—To add this statement to the configuration. Related Using JUNOS Software to Configure a Router or Switch to Transfer Its Configuration Documentation to an Archive Site Copyright © 2010, Juniper Networks, Inc.
Page 534: Archive-Sites (Configuration File)
Related Using JUNOS Software to Configure a Router or Switch to Transfer Its Configuration Documentation to an Archive Site configuration on page 441 transfer-on-commit on page 445 Copyright © 2010, Juniper Networks, Inc.
Page 535: Autoinstallation
Related Upgrading Software Using Automatic Software Download on EX Series Switches on Documentation page 90 J Series Services Router Basic LAN and WAN Access Configuration Guide configuration-servers on page 442 idle-timeout on page 519 Copyright © 2010, Juniper Networks, Inc.
Page 536: Commit Synchronize
Logging of accounting events is supported only for events and operations on a master Routing Engine. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring Multiple Routing Engines to Synchronize Committed Configurations Documentation Automatically Copyright © 2010, Juniper Networks, Inc.
Page 537: Configuration
Related Using JUNOS Software to Configure a Router or Switch to Transfer Its Configuration Documentation to an Archive Site archive on page 668 transfer-interval on page 444 transfer-on-commit on page 445 Copyright © 2010, Juniper Networks, Inc.
Page 538: Configuration-Servers
Related Upgrading Software Using Automatic Software Download on EX Series Switches on Documentation page 90 Getting Started Guide for your router model autoinstallation on page 439 idle-timeout on page 519 Copyright © 2010, Juniper Networks, Inc.
Page 539: Interfaces
Related Upgrading Software Using Automatic Software Download on EX Series Switches on Documentation page 90 J Series Services Router Basic LAN and WAN Access Configuration Guide autoinstallation on page 439 Copyright © 2010, Juniper Networks, Inc.
Page 540: Transfer-Interval (Configuration)
Related Using JUNOS Software to Configure a Router or Switch to Transfer Its Configuration Documentation to an Archive Site archive on page 668 configuration on page 441 transfer-on-commit on page 445 Copyright © 2010, Juniper Networks, Inc.
Page 541: Transfer-On-Commit
Related Using JUNOS Software to Configure a Router or Switch to Transfer Its Configuration Documentation to an Archive Site archive on page 668 configuration on page 441 transfer-interval on page 444 Copyright © 2010, Juniper Networks, Inc.
Page 544: Clear Log
1 root wheel 26450 Jun 23 18:47 /var/log/sampled total 1 user@host> clear log lcc0-re0:sampled lcc0-re0: -------------------------------------------------------------------------- user@host> file list lcc0-re0:/var/log/sampled detail lcc0-re0: -------------------------------------------------------------------------- -rw-r----- 1 root wheel 57 Sep 15 03:44 /var/log/sampled total 1 Copyright © 2010, Juniper Networks, Inc.
Page 545: Clear System Commit
Pending commit cleared. clear system commit user@host> clear system commit No commit scheduled. (None Pending) clear system commit user@host> clear system commit error: Permission denied (User Does Not Have Required Privilege Level) Copyright © 2010, Juniper Networks, Inc.
Page 546: File Archive
The following sample command archives one message file in the local directory File) as the single file in the same directory: /var/log/messages messages-archive.tar user@host> file archive source /var/log/messages destination /var/log/messages-archive.tar /usr/bin/tar: Removing leading / from absolute path names in the archive. user@host Copyright © 2010, Juniper Networks, Inc.
Page 547 The following sample command archives and compresses all message files in the local (with Compression) directory as the single file in the same directory: /var/log/messages messages-archive.tgz user@host> file archive compress source /var/log/messages* destination /var/log/messages-archive.tgz /usr/bin/tar: Removing leading / from absolute path names in the archive. user@host> Copyright © 2010, Juniper Networks, Inc.
Page 548: File Checksum Sha1
452 Output Fields When you enter this command, you are provided feedback on the status of your request. file checksum md5 file checksum md5 user@host> file checksum md5 jbundle-5.3R2.4-export-signed.tgz MD5 (jbundle-5.3R2.4-export-signed.tgz) = 2a3b69e43f9bd4893729cc16f505a0f5 Copyright © 2010, Juniper Networks, Inc.
Page 549 453 Output Fields When you enter this command, you are provided feedback on the status of your request. file checksum sha1 file checksum sha1 user@host> file checksum sha1 /var/db/scripts/opscript.slax SHA1 (/var/db/scripts/commitscript.slax) = ba9e47120c7ce55cff29afd73eacd370e162c676 Copyright © 2010, Juniper Networks, Inc.
Page 550 454 Output Fields When you enter this command, you are provided feedback on the status of your request. file checksum sha-256 file checksum sha-256 user@host> file checksum sha-256 /var/db/scripts/commitscript.slax SHA256 (/var/db/scripts/commitscript.slax) = 94c2b061fb55399e15babd2529453815601a602b5c98e5c12ed929c9d343dd71 Copyright © 2010, Juniper Networks, Inc.
Page 551: File Compare
456 file compare files unified on page 456 file compare files unified ignore-white-space on page 457 Output Fields When you enter this command, you are provided feedback on the status of your request. Copyright © 2010, Juniper Networks, Inc.
Page 552 +++ /tmp/two Wed Dec 3 09:13:14 2003 @@ -97,8 +97,9 @@ user bill { full-name "Bill Smith"; class foo; # 'foo' is not defined full-name "Bill Smith"; uid 1089; class super-user; authentication { encrypted-passwordSECRET; Copyright © 2010, Juniper Networks, Inc.
Page 553 +++ /tmp/two Wed Dec 3 09:13:14 2003 ignore-white-space @@ -99,7 +99,7 @@ user bill { full-name "Bill Smith"; uid 1089; class foo; # 'foo' is not defined class super-user; authentication { encrypted-password <SECRET>; # SECRET-DATA Copyright © 2010, Juniper Networks, Inc.
Page 554: File Copy
The following sample command copies a text file from Routing Engine 1 on the the TX Matrix Plus switch-fabric chassis sfc0 to Routing Engine 1 on the line-card chassis lcc0 Router to a T1600 user@host> file copy sfc0-re1:/tmp/sample.txt lcc0-re1:/var/tmp Router Connected to the TX Matrix Plus Router) Copyright © 2010, Juniper Networks, Inc.
Page 555: File Delete
/var/tmp/snmpd.core user@host> file list /var/tmp dcd.core rpd.core file delete user@host> file list lcc0-re0:/var/tmp dcd.core (Routing Matrix) rpd.core snmpd.core user@host> file delete lcc0-re0:/var/tmp/snmpd.core user@host> file list /var/tmp dcd.core rpd.core Copyright © 2010, Juniper Networks, Inc.
Page 556: File List
(Routing Matrix) on page 461 Output Fields When you enter this command, you are provided feedback on the status of your request. file list file list user@host> file list /var/tmp dcd.core rpd.core snmpd.core Copyright © 2010, Juniper Networks, Inc.
Page 557 Chapter 27: Operational Mode Commands for Configuration Management file list (Routing user@host> file list lcc0-re0:var/tmp lcc0-re0: Matrix) -------------------------------------------------------------------------- /var/tmp/: .gdbinit .pccardd Test/ chassisd* chassisd.nathan* check_time* cores/ diagTestPrep* diagtest* diagtest.regress* do_switchovers* dump_test* err.manoj.log esw_clearstats* esw_counter* esw_debug* esw_debug_ge* esw_filt_test* esw_filter_tnp_addr* esw_getstats* esw_phy* esw_stats* Copyright © 2010, Juniper Networks, Inc.
Page 558: File Rename
, renames one of the files, and then displays the list of files again to reveal the newly named file. user@host> file list /var/tmp dcd.core rpd.core snmpd.core user@host> file rename /var/tmp/dcd.core /var/tmp/dcd.core.990413 user@host> file list /var/tmp dcd.core.990413 rpd.core snmpd.core Copyright © 2010, Juniper Networks, Inc.
Page 559 -------------------------------------------------------------------------- /var/tmp: .pccardd sartre.conf snmpd syslogd.core-tarball.0.tgz user@host> file rename lcc0-re0:/var/tmp/snmpd /var/tmp/snmpd.rr user@host> file list lcc0-re1:/var/tmp lcc0-re1: -------------------------------------------------------------------------- /var/tmp: .pccardd sartre.conf snmpd.rr syslogd.core-tarball.0.tgz Copyright © 2010, Juniper Networks, Inc.
Page 560: File Show
# hex dump of a block of memory # usage: dump address length define dump p $arg0, $arg1 set $ch = $arg0 set $j = 0 set $n = $arg1 while ($j < $n) Copyright © 2010, Juniper Networks, Inc.
Page 561 Chapter 27: Operational Mode Commands for Configuration Management #printf "%x %x ",&$ch[$j],$ch[$j] printf "%x ",$ch[$j] set $j = $j + 1 if (!($j % 16)) printf "\n" Copyright © 2010, Juniper Networks, Inc.
Page 562: Request System Configuration Rescue Delete
List of Sample Output request system configuration rescue delete on page 466 Output Fields This command produces no output. request system request system user@host> request system configuration rescue delete configuration rescue configuration rescue delete delete Copyright © 2010, Juniper Networks, Inc.
Page 563: Request System Configuration Rescue Save
List of Sample Output request system configuration rescue save on page 467 Output Fields This command produces no output. request system request system user@host> request system configuration rescue save configuration rescue configuration rescue save save Copyright © 2010, Juniper Networks, Inc.
Page 564: Request System Scripts Refresh-From Commit
468 request system scripts request system scripts user@switch> request system scripts refresh-from commit file config.txt url http://host1.juniper.net refresh-from commit refresh-from commit user@switch> file config.txt url file config.txt url http://host1.juniper.net http://host1.juniper.net Copyright © 2010, Juniper Networks, Inc.
Page 565: Request System Scripts Refresh-From Event
469 request system scripts request system scripts user@switch> request system scripts refresh-from event file config.txt url http://host1.juniper.net refresh-from event file refresh-from event file user@switch> config.txt url config.txt url http://host1.juniper.net http://host1.juniper.net Copyright © 2010, Juniper Networks, Inc.
Page 566: Request System Scripts Refresh-From Op
470 request system scripts request system scripts user@switch> request system scripts refresh-from op file config.txt url http://host1.juniper.net user@switch> refresh-from op file refresh-from op file config.txt url config.txt url http://host1.juniper.net http://host1.juniper.net Copyright © 2010, Juniper Networks, Inc.
Page 567: Show System Commit
—A button on the router or switch was pressed to commit a rescue configuration for recovery. button —A configuration obtained through autoinstallation was committed. autoinstall —A method other than those identified was used to perform the commit operation. other Copyright © 2010, Juniper Networks, Inc.
Page 568 (At the Next Reboot) show system commit user@host> show system commit 0 2005-01-05 15:00:37 PST by root via cli commit confirmed, rollback in 3mins (Rollback Pending) Copyright © 2010, Juniper Networks, Inc.
Page 569: Show System Configuration Archival
This command has no options. Required Privilege maintenance Level List of Sample Output show system configuration archival on page 473 show system show system user@host> show system configuration archival configuration archival configuration archival /var/transfer/config/: total 8 Copyright © 2010, Juniper Networks, Inc.
Page 570: Show System Configuration Rescue
[ customer.net ]; backup-router 192.168.124.254; name-server { 172.17.28.11; 172.17.28.101; 172.17.28.100; 172.17.28.10; login { user regress { uid 928; class ; shell csh; authentication { encrypted-password "$1$kPU..$w.4FGRAGanJ8U4Yq6sbj7."; ## SECRET-DATA services { ftp; rlogin; rsh; telnet; ..Copyright © 2010, Juniper Networks, Inc.
Page 571: Show System Rollback
{ input mf_plp; address 14.1.1.1/30; ge-1/2/1 { unit 0 { family inet { filter { input mf_plp; address 13.1.1.1/30; ge-1/3/0 { unit 0 { family inet { filter { input mf_plp; address 12.1.1.1/30; Copyright © 2010, Juniper Networks, Inc.
Page 573: Test Configuration
{ host-name bluesky; paris-23; login; terminal:3:(8) syntax error: paris [edit system] 'paris-23;' syntax error terminal:4:(11) statement must contain additional statements: ; [edit system login] 'login ;' statement must contain additional statements configuration syntax failed Copyright © 2010, Juniper Networks, Inc.
Page 575: Chapter 28 User And Access Management On Ex Series Switches Overview
User Access Management Configuration on page 495 Monitoring Users on page 501 Troubleshooting User Access Management on page 505 Configuration Statements for User and Access Management on page 509 Operational Mode Commands for User and Access Management on page 535 Copyright © 2010, Juniper Networks, Inc.
Page 577: Ex Series Switch Software Features Overview
EX Series Switch Software Features Overview The following tables list the Juniper Networks EX Series Ethernet Switches software features and the Juniper Networks Junos operating system (Junos OS) release in which they were introduced: Table 1 on page 4—Access Control Features Table 2 on page 5—Administration Features...
Page 578: Table 84: Access Control Features
Junos OS 10.1R1 9.0R2 10.2R1 9.4R1 Server fail fallback Junos OS Junos OS Junos OS Junos OS 10.1R1 9.3R2 10.2R1 10.2R1 TACACS+ Junos OS Junos OS Junos OS Junos OS 10.1R1 9.0R2 10.2R1 9.4R1 Copyright © 2010, Juniper Networks, Inc.
Page 579: Table 85: Administration Features
EX4500 Switches EX8200 Switches Graceful protocol restart for BGP Not applicable Junos OS 9.0R2 Not applicable Junos OS 9.4R1 Graceful protocol restart for IS-IS Not applicable Junos OS 9.3R2 Not applicable Junos OS 9.4R1 Copyright © 2010, Juniper Networks, Inc.
Page 580 Split and merge Virtual Chassis Not applicable Junos OS 10.0R1 Not applicable Not applicable (EX4200 only) Automatic software update on prospective member switches Front-panel configuration of uplink module ports as Virtual Chassis ports (VCPs) Copyright © 2010, Juniper Networks, Inc.
Page 581: Table 88: Interfaces Features
Junos OS 9.3R2 Not supported Not supported Local DHCP server Not supported Junos OS 9.3R2 Not supported Junos OS 9.4R1 Static addresses Junos OS 10.1R1 Junos OS 9.0R2 Junos OS 10.2R1 Junos OS 9.4R1 Copyright © 2010, Juniper Networks, Inc.
Page 582: Table 90: Ipv6 Features
Junos OS 10.0R1 Not supported Junos OS 10.0R1 (MVRP) Private VLANs (PVLANs) Not supported Junos OS 9.3R2 Not supported Junos OS 10.1R1 Proxy ARP—restricted Junos OS 10.1R1 Junos OS 10.0R1 Junos OS 10.2R1 Junos OS 10.0R1 Copyright © 2010, Juniper Networks, Inc.
Page 583: Table 92: Layer 3 Protocols Features
Junos OS 9.4R1 Table 92: Layer 3 Protocols Features EX3200 and EX4200 Feature EX2200 Switches Switches EX4500 Switches EX8200 Switches Bidirectional Forwarding Detection Not supported Junos OS 9.0R2 Junos OS 10.2R1 Junos OS 9.4R1 (BFD) Copyright © 2010, Juniper Networks, Inc.
Page 584 VRF with IPv4—virtual routing Not supported Junos OS 10.0R1 Not supported Junos OS 10.0R1 instances for multicast traffic VRF with IPv6—virtual routing Not supported Junos OS 10.1R1 Not supported Junos OS 10.1R1 instances for multicast traffic Copyright © 2010, Juniper Networks, Inc.
Page 585 Not supported Junos OS 9.4R1 Junos OS 10.2R1 Junos OS 9.4R1 (MSDP) http://www.juniper.net/techpubs/software/junos/index.html See the Junos OS Multicast Configuration Guide at Multicast VLAN registration (MVR) Not supported Junos OS 9.6R1 Not supported Not supported Copyright © 2010, Juniper Networks, Inc.
Page 586: Table 95: Network Management And Monitoring Features
VLAN on the intermediate switch Real-time performance monitoring Junos OS 10.1R1 Junos OS 9.3R2 Junos OS 10.2R1 Junos OS 10.1R1 (RPM) RMON Junos OS 10.1R1 Junos OS 9.0R2 Junos OS 10.2R1 Junos OS 9.4R1 Copyright © 2010, Juniper Networks, Inc.
Page 587: Table 96: Port Security Features
EX4500 Switches EX8200 Switches Autoinstallation of configuration files Junos OS 10.1R1 Junos OS 9.4R1 Junos OS 10.2R1 Not supported Automatic software download Junos OS 10.1R1 Junos OS 9.6R1 Junos OS 10.2R1 Junos OS 9.6R1 Copyright © 2010, Juniper Networks, Inc.
Page 588: Routing Engine And Packet Forwarding Engine
EX8216 Switch Hardware Overview on page 36 Understanding Software Infrastructure and Processes Each switch runs the Juniper Networks Junos operating system (Junos OS) for Juniper Networks EX Series Ethernet Switches on its general-purpose processors. Junos OS includes processes for Internet Protocol (IP) routing and for managing interfaces, networks, and the chassis.
Page 589: Table 98: Junos Os Processes
Defines how routing protocols operate on the switch. The overall performance of the process switch is largely determined by the effectiveness of the forwarding process. Interface Configures and monitors network interfaces by defining physical characteristics such process as link encapsulation, hold times, and keepalive timers. Copyright © 2010, Juniper Networks, Inc.
Page 590 For more information about processes, see the Junos OS Network Operations Guide at Documentation http://www.juniper.net/techpubs/software/junos/index.html For more information about basic system parameters, supported protocols, and software processes, see Junos OS System Basics Configuration Guide at http://www.juniper.net/techpubs/software/junos/index.html Copyright © 2010, Juniper Networks, Inc.
Page 591: Chapter 29 User Access Management Configuration
For SSL Junos XML management protocol access—To use this option, you must have a Junos XML management protocol client such as Junos Scope. For information about how to log into Junos Scope, see the Junos Scope Software User Guide. Copyright © 2010, Juniper Networks, Inc.
Page 592: Table 99: Secure Management Access Configuration Summary
Enables clear text access to the Junos To enable clear text access, select the Enable Junos management protocol XML management protocol XML scripting XML management protocol over Clear Text check box. over Clear Text API. Copyright © 2010, Juniper Networks, Inc.
Page 593 4. Open the certificate file and copy its contents. 5. Paste the generated certificate and RSA private key in the Certificate box. To edit a certificate, select it and click Edit To delete a certificate, select it and click Delete. Copyright © 2010, Juniper Networks, Inc.
Page 594: Generating Ssl Certificates To Be Used For Secure Web Access
[edit] user@switch# set security certificates local my-signed-cert load-key-file my-certificate.pem Related Configuring Management Access for the EX Series Switch (J-Web Procedure) on Documentation page 495 Security Features for EX Series Switches Overview on page 18 Copyright © 2010, Juniper Networks, Inc.
Page 595 You must have the required access permission on the switch in order to change your password. Related Managing Users (J-Web Procedure) on page 501 Documentation For more about configuring user access, see the Junos OS Access Privilege Configuration Guide at http://www.juniper.net/techpubs/software/junos/index.html Copyright © 2010, Juniper Networks, Inc.
Page 597: Chapter 30 Monitoring Users
Table 101 on page 503. Edit—Select this option to modify the authentication server details. Enter details as described in Table 101 on page 503. Delete—Select this option to delete an authentication server from the list. Copyright © 2010, Juniper Networks, Inc.
Page 598: Table 100: User Management Configuration Page Summary
The password must be at least 6 characters long. It can include alphabetic, numeric, and special characters, but not control characters. It must contain at least one change of case or character class. Copyright © 2010, Juniper Networks, Inc.
Page 599: Table 101: Add An Authentication Server
Specifies the time interval to wait before the Type the interval in seconds. connection to the server is closed. Related Configuring Management Access for the EX Series Switch (J-Web Procedure) on Documentation page 495 Copyright © 2010, Juniper Networks, Inc.
Page 601: Chapter 31 Troubleshooting User Access Management
Insert one end of the Ethernet cable into the serial port on the management device and connect the other end to the console port on the back of the switch. See Figure 8 on page 505 Figure 8: Connecting to the Console Port on the EX Series Switch Copyright © 2010, Juniper Networks, Inc.
Page 602 At the second prompt, reenter the new root password. If you are finished configuring the network, commit the configuration. root@switch# commit commit complete Exit configuration mode in the CLI. root@switch# exit Exit operational mode in the CLI. Copyright © 2010, Juniper Networks, Inc.
Page 603 Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 189 For information about configuring an encrypted root password, configuring SSH keys to authenticate root logins, and configuring special requirements for plain-text passwords, see the Junos OS System Basics Configuration Guide at http://www.juniper.net/techpubs/software/junos/index.html Copyright © 2010, Juniper Networks, Inc.
Page 605: Chapter 32 Configuration Statements For User And Access Management
Level admin-control—To add this statement to the configuration. Related Specifying Access Privileges for JUNOS Software Operational Mode Commands Documentation deny-commands on page 516 user on page 534 Copyright © 2010, Juniper Networks, Inc.
Page 606: Allow-Configuration
Related Specifying Access Privileges for JUNOS Software Configuration Mode Commands Documentation Regular Expressions for Allowing and Denying JUNOS Software Configuration Mode Commands deny-commands on page 516 user on page 534 Copyright © 2010, Juniper Networks, Inc.
Page 607: Announcement
Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration Related Configuring the JUNOS Software to Display a System Login Announcement Documentation message on page 522 Copyright © 2010, Juniper Networks, Inc.
Page 608: Authentication (Login)
You can specify one or more public keys for each user. Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Configuring JUNOS Software User Accounts Documentation root-authentication on page 528 Copyright © 2010, Juniper Networks, Inc.
Page 609: Authentication-Order
Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software Authentication Order for RADIUS, TACACS+, and Documentation Local Password Authentication authentication on page 512 Copyright © 2010, Juniper Networks, Inc.
Page 610: Change-Type
—One of the classes defined at the hierarchy level. class-name [edit system login class] Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Configuring JUNOS Software User Accounts Documentation Copyright © 2010, Juniper Networks, Inc.
Page 611: Class (Defining Login Classes)
The remaining statements are explained separately. Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Defining JUNOS Software Login Classes Documentation user on page 534 Copyright © 2010, Juniper Networks, Inc.
Page 612: Deny-Commands
Level admin-control—To add this statement to the configuration. Related Specifying Access Privileges for JUNOS Software Operational Mode Commands Documentation allow-commands on page 509 user on page 534 Copyright © 2010, Juniper Networks, Inc.
Page 613: Deny-Configuration
Level admin-control—To add this statement to the configuration. Related Specifying Access Privileges for JUNOS Software Operational Mode Commands Documentation allow-configuration on page 510 user on page 534 Copyright © 2010, Juniper Networks, Inc.
Page 614: Format
—Full name of the user. If the name contains spaces, enclose it in quotation complete-name marks. Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Configuring JUNOS Software User Accounts Documentation Copyright © 2010, Juniper Networks, Inc.
Page 615: Idle-Timeout
Range: 0 through 100,000 minutes Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Configuring the Timeout Value for Idle Login Sessions Documentation user on page 534 Copyright © 2010, Juniper Networks, Inc.
Page 616: Login
Configure user access to the router or switch. Options The remaining statements are explained separately. Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Defining JUNOS Software Login Classes Documentation Copyright © 2010, Juniper Networks, Inc.
Page 617: Login-Alarms
Statement introduced in Junos OS Release 9.0 for EX Series switches. Description Enable CLI tips at login. Default Disabled. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring CLI Tips Documentation Copyright © 2010, Juniper Networks, Inc.
Page 618: Maximum-Length
Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration Related Configuring the JUNOS Software to Display a System Login Message Documentation announcement on page 511 Copyright © 2010, Juniper Networks, Inc.
Page 619: Minimum-Changes
—The minimum number of character sets (or character set changes) required for the password. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Special Requirements for JUNOS Software Plain-Text Passwords Documentation change-type on page 514 Copyright © 2010, Juniper Networks, Inc.
Page 620: Minimum-Length
Range: 6 to 20 characters Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Special Requirements for JUNOS Software Plain-Text Passwords Documentation maximum-length on page 522 Copyright © 2010, Juniper Networks, Inc.
Page 621: Password (Login)
—Privilege type. For a list of permission flag types, see JUNOS Software permissions Access Privilege Levels Overview. Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Configuring Access Privilege Levels Documentation user on page 534 Copyright © 2010, Juniper Networks, Inc.
Page 622: Radius-Options
—IP address of the network access server (NAS) that requests user authentication. —Protocol MS-CHAPv2, used for password authentication and password mschap-v2 changing. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring RADIUS Authentication Documentation Copyright © 2010, Juniper Networks, Inc.
Page 623: Retry-Options
Range: 20 through 60 Default: 20 —Maximum number of times a user is allowed to attempt tries-before-disconnect number to enter a password to log in through SSH or Telnet. Range: 1 through 10 Default: 10 Copyright © 2010, Juniper Networks, Inc.
Page 624: Root-Authentication
SSH version 2) public key. You can specify one or more public keys. Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Configuring the Root Password Documentation authentication on page 512 Copyright © 2010, Juniper Networks, Inc.
Page 625: Root-Login
Level admin-control—To add this statement to the configuration. Related Configuring SSH Service for Remote Access to the Router or Switch Documentation Configuring SSH Service for Remote Access to the Router or Switch Copyright © 2010, Juniper Networks, Inc.
Page 626: Tacplus-Options
Level system-control—To add this statement to the configuration. Related Configuring TACACS+ Authentication Documentation Configuring TACACS+ System Accounting JUNOS Software Authentication Order for RADIUS, TACACS+, and Password Authentication Copyright © 2010, Juniper Networks, Inc.
Page 627: Tacplus-Server
—Address of the TACACS+ authentication server. server-address The remaining statements are explained separately. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring TACACS+ Authentication Documentation Copyright © 2010, Juniper Networks, Inc.
Page 628: Traceoptions (Address-Assignment Pool)
You can include the following flags: —All address-assignment events address-assignment —All tracing operations —Configuration events configuration framework —Authentication framework events —LDAP authentication events ldap local-authentication —Local authentication events Copyright © 2010, Juniper Networks, Inc.
Page 629 —Number associated with the login account. This value must be unique on the uid-value router or switch. Range: through 64000 Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Configuring JUNOS Software User Accounts Documentation Copyright © 2010, Juniper Networks, Inc.
Page 630: User (Access)
The remaining statements are explained separately. Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Configuring JUNOS Software User Accounts Documentation class on page 514 Copyright © 2010, Juniper Networks, Inc.
Page 632: Request Message
When you enter this command, you are provided feedback on the status of your request. request message request message user@host> request message message "Maintenance window in 10 minutes" user maria Message from user@host on ttyp0 at 20:27 ... message message Maintenance window in 10 minutes Copyright © 2010, Juniper Networks, Inc.
Page 633: Show Subscribers
—(Optional) Display subscribers whose routing instance matches the specified routing instance. —(Optional) Display subscribers whose subscriber state matches the subscriber-state specified subscriber state (ACTIVE, CONFIGURED, INIT, TERMINATED, or TERMINATING). Copyright © 2010, Juniper Networks, Inc.
Page 634 Table 102: show subscribers Output Fields Field Name Field Description Name of subscriber. User Name Subscriber client type (DHCP, VLAN, PPP, PPPOE, or L2TP). Type IP Address Subscriber IPv4 address. IP Netmask Subscriber IP netmask. Copyright © 2010, Juniper Networks, Inc.
Page 635 Service session profile name. Name assigned to the IPv4 input filter (client or service session). IPv4 Input Filter Name Name assigned to the IPv4 output filter (client or service session). IPv4 Output Filter Name Copyright © 2010, Juniper Networks, Inc.
Page 636 Dynamic Profile Name: dhcp-demux-prof MAC Address: 00:10:95:00:00:98 State: Active Radius Accounting ID: jnpr :2304 Login Time: 2009-08-25 14:43:52 PDT Service Sessions: 2 show subscribers user@host> show subscribers detail Type: DHCP detail (IPv6) IPv6 Address: 1080:0:0:0:8:800:200C:417A Copyright © 2010, Juniper Networks, Inc.
Page 637 Dynamic Profile Name: svlan-prof State: Active Stacked VLAN Id: 0x8100.101 VLAN Id: 0x8100.100 Login Time: 2009-03-27 11:57:19 PDT show subscribers user@host> show subscribers stacked-vlan-id 101 vlan-id 100 detail Type: VLAN stacked-vlan-id vlan-id Interface: ge-1/2/0.1073741824 Copyright © 2010, Juniper Networks, Inc.
Page 638 Interface type: Dynamic Dynamic Profile Name: dhcp-demux-prof State: Active Radius Accounting ID: jnpr :2 Agent Circuit ID: abc Remote Circuit ID: xyz Login Time: 2010-03-31 14:27:19 PDT Service Sessions: 1 IPv6 Input Filter Name: demux0-inet6-in Copyright © 2010, Juniper Networks, Inc.
Page 639 TOTAL show subscribers terse user@host> show subscribers summary terse Interface IP Address/VLAN ID User Name LS:RI ge-1/3/0.1073741824 default:default demux0.1073741824 100.0.0.10 WHOLESALER-CLIENT default:default demux0.1073741825 101.0.0.3 RETAILER1-CLIENT test1:retailer1 demux0.1073741826 102.0.0.3 RETAILER2-CLIENT test1:retailer2 Copyright © 2010, Juniper Networks, Inc.
Page 641: Junos Os For Ex Series Switches System Services
System Services Overview on page 547 System Services Configuration on page 549 Monitoring System Services on page 553 Configuration Statements for System Services on page 557 Operational Mode Commands for System Services on page 613 Copyright © 2010, Juniper Networks, Inc.
Page 643: Dhcp Overview
DHCP, through the use of the automatic software download feature, can also be used to install software packages on Juniper Networks EX Series Ethernet Switches. Users can define a path to a software package on the DHCP server, and then the DHCP server communicates this path to EX Series switches acting as DHCP clients as part of the DHCP message exchange process.
Page 644: Dhcp/Bootp Relay For Ex Series Switches Overview
Monitoring DHCP Services on page 553 DHCP/BOOTP Relay for EX Series Switches Overview You can configure the Juniper Networks EX Series Ethernet Switch to act as a Dynamic Host Configuration Protocol (DHCP) or Bootstrap Protocol (BOOTP) relay agent. This means that a locally attached host can issue a DHCP or BOOTP request as a broadcast message.
Page 645: Chapter 35 System Services Configuration
To commit all changes to the active configuration, select > . See Using the Commit Options Commit Commit Options to Commit Configuration Changes for details about all commit options. Copyright © 2010, Juniper Networks, Inc.
Page 646: Table 103: Dhcp Server Configuration Pages Summary
To add a DNS server, type an IP address next in the specified order—from top to bottom. to the Add button, and click Add. To remove a DNS server, select the IP address in the DNS Name Servers box, and click Delete. Copyright © 2010, Juniper Networks, Inc.
Page 647 The name must be unique to the client within the subnet on which the client resides. Related DHCP Services for EX Series Switches Overview on page 547 Documentation Monitoring DHCP Services on page 553 Copyright © 2010, Juniper Networks, Inc.
Page 648: Configuring A Dhcp Sip Server (Cli Procedure)
For example, to configure a name: [edit system services dhcp] user@switch set sip-server abc.example.com Related DHCP Services for EX Series Switches Overview on page 547 Documentation Junos OS System Basics Configuration Guide at http://www.juniper.net/techpubs/software/junos/index.html Copyright © 2010, Juniper Networks, Inc.
Page 649: Chapter 36 Monitoring System Services
Meaning Table 104 on page 553 summarizes the output fields in DHCP displays in the J-Web interface. Table 104: Summary of DHCP Output Fields Field Values Additional Information Global tab Copyright © 2010, Juniper Networks, Inc.
Page 650 Lowest address in the IP address pool. Address High Highest address in the IP address pool. Address Excluded Addresses excluded from the address pool. Addresses Clients tab Interface Name of the logical interface. Name Copyright © 2010, Juniper Networks, Inc.
Page 651 DHCP Statistics Relay Statistics tab Packet Displays the number of packet counters. Counters Dropped Graphically displays the number of dropped packet Packet counters. Counters Statistics tab Copyright © 2010, Juniper Networks, Inc.
Page 652 Number of BOOTREPLY, DHCPACK, DHCPOFFER, sent and DHCPNAK messages sent from the DHCP server to DHCP clients. Related Configuring DHCP Services (J-Web Procedure) on page 549 Documentation DHCP Services for EX Series Switches Overview on page 547 Copyright © 2010, Juniper Networks, Inc.
Page 653: Chapter 37 Configuration Statements For System Services
Related Configuring the Router, Switch, or Interface to Act as a DHCP Server on J Series Services Documentation Routers and EX Series Ethernet Switches boot-server on page 558 Copyright © 2010, Juniper Networks, Inc.
Page 654: Boot-Server (Dhcp)
Related Configuring the Router, Switch, or Interface to Act as a DHCP Server on J Series Services Documentation Routers and EX Series Ethernet Switches boot-file on page 557 Copyright © 2010, Juniper Networks, Inc.
Page 655: Bootp
Configuring Routers, Switches, and Interfaces as DHCP and BOOTP Relay Agents Documentation Setting Up DHCP Option 82 with the Switch as a Relay Agent Between Clients and DHCP Server (CLI Procedure) on page 2926 Copyright © 2010, Juniper Networks, Inc.
Page 656: Ca-Name
NOTE: We recommend that you limit your cache size to 4 MB. Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration Related Configuring Digital Certificates for an ES PIC Documentation Copyright © 2010, Juniper Networks, Inc.
Page 657: Cache-Timeout-Negative
CAUTION: Configuring a large negative cache value can lead to a denial-of-service attack. Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration Related Configuring Digital Certificates for an ES PIC Documentation Copyright © 2010, Juniper Networks, Inc.
Page 658: Certificates
Configure the digital certificates for IPsec. The remaining statements are explained separately. Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Configuring Digital Certificates for an ES PIC Documentation Copyright © 2010, Juniper Networks, Inc.
Page 659: Certification-Authority
Level system-control—To add this statement to the configuration. Related Configuring the Router, Switch, or Interface to Act as a DHCP Server on J Series Services Documentation Routers and EX Series Ethernet Switches Copyright © 2010, Juniper Networks, Inc.
Page 660: Connection-Limit
Configuring Finger Service for Remote Access to the Router Configuring FTP Service for Remote Access to the Router or Switch Configuring SSH Service for Remote Access to the Router or Switch Configuring Telnet Service for Remote Access to a Router Copyright © 2010, Juniper Networks, Inc.
Page 661: Crl (Encryption Interface)
Related Configuring the Router, Switch, or Interface to Act as a DHCP Server on J Series Services Documentation Routers and EX Series Ethernet Switches maximum-lease-time on page 582 Copyright © 2010, Juniper Networks, Inc.
Page 662: Description
Level interface-control—To add this statement to the configuration. Related Configuring DNS and TFTP Packet Forwarding Documentation Configuring Routers, Switches, and Interfaces as DHCP and BOOTP Relay Agents Copyright © 2010, Juniper Networks, Inc.
Page 663: Dhcp
DHCP server. A DHCP server can allocate network addresses and deliver configuration information to client hosts on a TCP/IP network. The remaining statements are explained separately. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Copyright © 2010, Juniper Networks, Inc.
Page 664: Domain
Enable DNS request packet forwarding. The remaining statements are explained separately. Required Privilege interface—To view this statement in the configuration. Level interface-control—To add this statement to the configuration. Related Configuring DNS and TFTP Packet Forwarding Documentation Copyright © 2010, Juniper Networks, Inc.
Page 665: Domain-Name (Dhcp)
Configuring the Domains to Search When a Router or Switch Is Included in Multiple Documentation Domains Configuring the Router, Switch, or Interface to Act as a DHCP Server on J Series Services Routers and EX Series Ethernet Switches Copyright © 2010, Juniper Networks, Inc.
Page 666: Encoding
—Number of enrollment retries. attempts Range: through Default: Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Configuring Digital Certificates for an ES PIC Documentation Copyright © 2010, Juniper Networks, Inc.
Page 667: Enrollment-Url
—File from which to read the digital certificate. certificate-filename Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Configuring Digital Certificates for an ES PIC Documentation Copyright © 2010, Juniper Networks, Inc.
Page 668 The remaining statements are explained separately. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring FTP Service for Remote Access to the Router or Switch Documentation Copyright © 2010, Juniper Networks, Inc.
Page 669: Helpers
{ description text-description; interface interface-name { broadcast; description text-description; no-listen; server address <logical-system logical-system-name> <routing-instance routing-instance-name>; server address <logical-system logical-system-name> <routing-instance routing-instance-name>; tftp { description text-description; interface interface-name { broadcast; description text-description; no-listen; Copyright © 2010, Juniper Networks, Inc.
Page 670: Http
Level interface-control—To add this statement to the configuration. Related Configuring DNS and TFTP Packet Forwarding Documentation Configuring Routers, Switches, and Interfaces as DHCP and BOOTP Relay Agents Copyright © 2010, Juniper Networks, Inc.
Page 671: Https
Related Configuring Management Access for the EX Series Switch (J-Web Procedure) on Documentation page 495 J-Web Interface User Guide https on page 576 port on page 590 web-management on page 611 Copyright © 2010, Juniper Networks, Inc.
Page 672 Related Configuring Management Access for the EX Series Switch (J-Web Procedure) on Documentation page 495 J-Web Interface User Guide http on page 575 port on page 590 web-management on page 611 Copyright © 2010, Juniper Networks, Inc.
Page 673: Interface (Bootp)
Configuring Routers, Switches, and Interfaces as DHCP and BOOTP Relay Agents Documentation Setting Up DHCP Option 82 with the Switch as a Relay Agent Between Clients and DHCP Server (CLI Procedure) on page 2926 Copyright © 2010, Juniper Networks, Inc.
Page 674: Interface (Dns And Tftp Packet Forwarding Or Relay Agent)
Options url-name —Name of the LDAP URL. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring Digital Certificates for an ES PIC Documentation Copyright © 2010, Juniper Networks, Inc.
Page 675: Load-Key-File
The file is a URL containing one or more SSH keys. Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Configuring the Root Password Documentation Configuring JUNOS Software User Accounts Copyright © 2010, Juniper Networks, Inc.
Page 676: Local
URL to the certificate file location (for instance, on the computer where the Junos XML protocol client application runs) Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Importing SSL Certificates for JUNOScript Support Documentation Copyright © 2010, Juniper Networks, Inc.
Page 677: Local-Certificate
Range: 64 through 4,294,967,295 peer certificates Default: 1024 peer certificates Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring Digital Certificates for an ES PIC Documentation Copyright © 2010, Juniper Networks, Inc.
Page 678: Maximum-Hop-Count
Related Configuring the Router, Switch, or Interface to Act as a DHCP Server on J Series Services Documentation Routers and EX Series Ethernet Switches default-lease-time on page 565 Copyright © 2010, Juniper Networks, Inc.
Page 679: Minimum-Wait-Time
Configuring a DNS Name Server for Resolving a Hostname into Addresses Documentation Configuring the Router, Switch, or Interface to Act as a DHCP Server on J Series Services Routers and EX Series Ethernet Switches Copyright © 2010, Juniper Networks, Inc.
Page 680: No-Listen
Level interface-control—To add this statement to the configuration. Related Configuring DNS and TFTP Packet Forwarding Documentation Configuring Routers, Switches, and Interfaces as DHCP and BOOTP Relay Agents Copyright © 2010, Juniper Networks, Inc.
Page 681: Outbound-Ssh
To configure the keepalive message, you must set both the attributes. timeout retry reconnect-strategy —(Optional) Specify the method the router or switch uses to reestablish a disconnected outbound SSH connection. Two methods are available: Copyright © 2010, Juniper Networks, Inc.
Page 682 1 to the maximum value (specified by the default value or the options value set here). Once the maximum value is reached, the numbering sequence is restarted at 1, overwriting the older file. Copyright © 2010, Juniper Networks, Inc.
Page 683 —(Optional) Disable remote tracing. Required Privilege interface—To view this statement in the configuration. Level interface-control—To add this statement to the configuration. Related Configuring Outbound SSH Service Documentation System Management Configuration Statements Copyright © 2010, Juniper Networks, Inc.
Page 684: Path-Length
Range: 2 through 15 certificates Default: 15 certificates Required Privilege admin—To view this statement in the configuration. Level admin-control—To add this statement to the configuration. Related Configuring Digital Certificates for an ES PIC Documentation Copyright © 2010, Juniper Networks, Inc.
Page 685: Pool
Level system-control—To add this statement to the configuration. Related Configuring the Router, Switch, or Interface to Act as a DHCP Server on J Series Services Documentation Routers and EX Series Ethernet Switches Copyright © 2010, Juniper Networks, Inc.
Page 686: Port (Src Server)
—(Optional) The TCP port number for the SRC server. port-number Default: 3333 Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software to Work with SRC Software Documentation Copyright © 2010, Juniper Networks, Inc.
Page 687: Protocol-Version
Range: through Default: Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring clear-text or SSL Service for JUNOScript Client Applications Documentation Copyright © 2010, Juniper Networks, Inc.
Page 688: Server (Dhcp And Bootp Relay Agent)
DHCP or BOOTP relay agent. Required Privilege interface—To view this statement in the configuration. Level interface-control—To add this statement to the configuration. Related Configuring Routers, Switches, and Interfaces as DHCP and BOOTP Relay Agents Documentation Copyright © 2010, Juniper Networks, Inc.
Page 689: Server (Dns And Tftp Service)
DNS server or TFTP server. Required Privilege interface—To view this statement in the configuration. Level interface-control—To add this statement to the configuration. Related Configuring DNS and TFTP Packet Forwarding Documentation Copyright © 2010, Juniper Networks, Inc.
Page 690: Server-Identifier
Level system-control—To add this statement to the configuration. Related Configuring the Router, Switch, or Interface to Act as a DHCP Server on J Series Services Documentation Routers and EX Series Ethernet Switches Copyright © 2010, Juniper Networks, Inc.
Page 691: Servers
The remaining statements are explained separately. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software to Work with SRC Software Documentation Copyright © 2010, Juniper Networks, Inc.
Page 692: Services
{ interfaces [ interface-names ]; local-certificate name; port port; session { idle-timeout [ minutes ]; session-limit [ session-limit ]; xnm-clear-text { <connection-limit limit>; <rate-limit limit>; xnm-ssl { <connection-limit limit>; <local-certificate name> <rate-limit limit>; Copyright © 2010, Juniper Networks, Inc.
Page 693: Session
Configuring clear-text or SSL Service for JUNOScript Client Applications Documentation Configuring the Router, Switch, or Interface to Act as a DHCP Server on J Series Services Routers and EX Series Ethernet Switches Configuring the JUNOS Software to Work with SRC Software Copyright © 2010, Juniper Networks, Inc.
Page 694 —Configure the maximum number of simultaneous J-Web session-limit session-limit user login sessions. Range: through 1024 Default: Unlimited Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related J-Web Interface User Guide Documentation Copyright © 2010, Juniper Networks, Inc.
Page 695: Sip-Server
The source address restricts traffic within the out-of-band network. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring the JUNOS Software to Work with SRC Software Documentation Copyright © 2010, Juniper Networks, Inc.
Page 696: Source-Address-Giaddr
IP address for relayed DHCP packets. Required Privilege interface—To view this statement in the configuration. Level interface-control—To add this statement to the configuration. Related DHCP/BOOTP Relay for EX Series Switches Overview on page 548 Documentation Copyright © 2010, Juniper Networks, Inc.
Page 697 The remaining statements are explained separately. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring SSH Service for Remote Access to the Router or Switch Documentation Copyright © 2010, Juniper Networks, Inc.
Page 698: Static-Binding
Level system-control—To add this statement to the configuration. Related Configuring the Router, Switch, or Interface to Act as a DHCP Server on J Series Services Documentation Routers and EX Series Ethernet Switches Copyright © 2010, Juniper Networks, Inc.
Page 699: Telnet
Enable TFTP request packet forwarding. The remaining statements are explained separately. Required Privilege interface—To view this statement in the configuration. Level interface-control—To add this statement to the configuration. Related Configuring DNS and TFTP Packet Forwarding Documentation Copyright © 2010, Juniper Networks, Inc.
Page 700: Traceoptions
Then the oldest trace file is overwritten. Default: 1024 KB —Trace operation to perform. To specify more than one trace operation, include flag multiple statements. flag —Trace all security events. —Trace database events. database —Trace general events. general Copyright © 2010, Juniper Networks, Inc.
Page 701 —Trace policy manager processing. policy-manager routing-socket —Trace routing socket messages. timer —Trace internal timer events. Required Privilege admin—To view the configuration. Level admin-control—To add this statement to the configuration. Related Configuring Tracing Operations for Security Services Documentation Copyright © 2010, Juniper Networks, Inc.
Page 702: Traceoptions (Dhcp Server)
—Trace user-detected conflicts for IP addresses conflict event —Trace important events —Trace interface database operations ifdb — Trace I/O operations —Trace lease operations lease main —Trace main loop operations — Trace miscellaneous operations misc packet —Trace DHCP packets Copyright © 2010, Juniper Networks, Inc.
Page 703 —Trace address pool operations pool protocol —Trace protocol operations —Trace routing socket operations rtsock scope —Trace scope operations —Trace DHCP signal operations signal —All tracing operations trace —Trace user interface operations —(Optional) Disable unrestricted file access. no-world-readable Copyright © 2010, Juniper Networks, Inc.
Page 704 —(Optional) Enable unrestricted file access. world-readable Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Configuring Tracing Operations for DHCP Processes Documentation System Management Configuration Statements Copyright © 2010, Juniper Networks, Inc.
Page 705: Traceoptions (Dns And Tftp Packet Forwarding)
—Trace BOOTP or DHCP services events bootp —Trace configuration events config —Trace DNS service events domain ifdb —Trace interface database operations —Trace I/O operations main —Trace main loop events —Trace arbitrary protocol events port Copyright © 2010, Juniper Networks, Inc.
Page 706 Default: 128 KB world-readable —(Optional) Enable unrestricted file access. Required Privilege interface—To view this statement in the configuration. Level interface-control—To add this statement to the configuration. Related Tracing BOOTP, DNS, and TFTP Forwarding Operations Documentation Copyright © 2010, Juniper Networks, Inc.
Page 707: Web-Management
Level system-control—To add this statement to the configuration. Related Table 99 on page 496 Documentation J-Web Interface User Guide http on page 575 https on page 576 port on page 590 Copyright © 2010, Juniper Networks, Inc.
Page 708: Wins-Server
Level system-control—To add this statement to the configuration. Related Configuring the Router, Switch, or Interface to Act as a DHCP Server on J Series Services Documentation Routers and EX Series Ethernet Switches Copyright © 2010, Juniper Networks, Inc.
Page 710: Clear System Services Dhcp Binding
614 Output Fields When you enter this command, you are provided feedback on the status of your request. clear system services clear system services user@host> clear system services dhcp binding dhcp binding dhcp binding Copyright © 2010, Juniper Networks, Inc.
Page 711: Clear System Services Dhcp Conflict
615 Output Fields When you enter this command, you are provided feedback on the status of your request. clear system services clear system services user@host> clear system services dhcp conflict dhcp conflict dhcp conflict Copyright © 2010, Juniper Networks, Inc.
Page 712: Clear System Services Dhcp Statistics
616 Output Fields When you enter this command, you are provided feedback on the status of your request. clear system services clear system services user@host> clear system services dhcp statistics dhcp statistics dhcp statistics Copyright © 2010, Juniper Networks, Inc.
Page 713: Request Ipsec Switch
617 Output Fields When you enter this command, you are provided feedback on the status of your request. request ipsec switch request ipsec switch user@host> request ipsec switch security-associations sa-private Copyright © 2010, Juniper Networks, Inc.
Page 714: Request Security Certificate (Signed)
10.50.1.4 Encoding: binary Certificate enrollment has started. To view the status of your enrollment, check the key management process (kmd) log file at /var/log/kmd. <-------------- Copyright © 2010, Juniper Networks, Inc.
Page 715: Request Security Key-Pair
619 Output Fields When you enter this command, you are provided feedback on the status of your request. request security request security user@host> request security key-pair security-key-file key-pair key-pair Copyright © 2010, Juniper Networks, Inc.
Page 716: Request Security Certificate (Unsigned)
CA name: juniper.net CA file: verisign Encoding: binary Certificate enrollment has started. To view the status of your enrollment, check the key management process (kmd) log file at /var/log/kmd. <-------------- Copyright © 2010, Juniper Networks, Inc.
Page 717: Show System Services Dhcp Binding
Time the lease expires or for leases that do not expire. All levels Lease Expires at never option only) Time the client obtained the lease from the DHCP server. Lease Obtained at address detail Copyright © 2010, Juniper Networks, Inc.
Page 718 2004-05-03 13:01:42 PDT State active DHCP options: Name: name-server, Value: { 6.6.6.6, 6.6.6.7 } Name: domain-name, Value: mydomain.tld Code: 19, Type: flag, Value: off Code: 40, Type: string, Value: domain.tld Code: 32, Type: ip-address, Value: 3.3.3.33 Copyright © 2010, Juniper Networks, Inc.
Page 719: Show System Services Dhcp Conflict
Detection time Detection method Address 2004-08-03 19:04:00 PDT 3.3.3.5 2004-08-04 04:23:12 PDT Ping 4.4.4.8 2004-08-05 21:06:44 PDT Client 3.3.3.10 Copyright © 2010, Juniper Networks, Inc.
Page 720: Show System Services Dhcp Global
Maximum time a client can retain an IP address lease on the server. Maximum lease time User-defined options created for the DHCP server. If no options DHCP options have been defined, this field is blank. Copyright © 2010, Juniper Networks, Inc.
Page 721 Maximum lease time infinite DHCP options: Name: name-server, Value: { 6.6.6.6, 6.6.6.7 } Name: domain-name, Value: mydomain.tld Code: 19, Type: flag, Value: off Code: 40, Type: string, Value: domain.tld Code: 32, Type: ip-address, Value: 3.3.3.33 Copyright © 2010, Juniper Networks, Inc.
Page 722: Show System Services Dhcp Pool
IP addresses in the pool. assigned Number of assigned IP addresses in the pool that are active. Active detail Number of assigned IP addresses in the pool that are excluded. Excluded detail Copyright © 2010, Juniper Networks, Inc.
Page 723 Name: name-server, Value: { 6.6.6.6, 6.6.6.7 } Name: domain-name, Value: mydomain.tld Name: router, Value: { 3.3.3.1 } Name: server-identifier, Value: 3.3.3.1 Code: 19, Type: flag, Value: off Code: 40, Type: string, Value: domain.tld Code: 32, Type: ip-address, Value: 3.3.3.333.3.3.254 3.3.3.1 Copyright © 2010, Juniper Networks, Inc.
Page 724: Show System Services Dhcp Statistics
Total number of packets dropped and number of packets dropped because of: Packets dropped Invalid hardware address Invalid opcode Invalid server address No available address No interface match No routing instance match No valid local addresses Packet too short Read error Send error Copyright © 2010, Juniper Networks, Inc.
Page 725 No available addresses No interface match No routing instance match No valid local address Packet too short Read error Send error Messages received: BOOTREQUEST DHCPDECLINE DHCPDISCOVER DHCPINFORM DHCPRELEASE DHCPREQUEST Messages sent: BOOTREPLY DHCPACK DHCPOFFER DHCPNAK Copyright © 2010, Juniper Networks, Inc.
Page 726: Show System Services Service-Deployment
Connected to 192.4.4.4 port 10288 since 2004-05-03 11:04:34 PDT Keepalive settings: service-deployment service-deployment Interval 15 seconds Keepalives sent: 750 Notifications sent: 0 Last update from peer: 00:00:06 ago Copyright © 2010, Juniper Networks, Inc.
Page 727 —(Optional) Name of a particular logical system for logical-system logical-system-name the SSH attempt. routing-instance routing-instance-name —(Optional) Name of the routing instance for the SSH attempt. —(Optional) Source address of the SSH connection. source address Copyright © 2010, Juniper Networks, Inc.
Page 728 Host key not found from the list of known hosts. Are you sure you want to continue connecting (yes/no)? yes Host ?cree' added to the list of known hosts. boojun@cree's password: Last login: Sun Jun 21 10:43:42 1998 from junos-router % ... Copyright © 2010, Juniper Networks, Inc.
Page 729: Telnet
—(Optional) Name of a particular logical system for the telnet attempt. —(Optional) Do not attempt to determine the hostname that corresponds to no-resolve the IP address. port port-number —(Optional) Port number or service name on the remote system. Copyright © 2010, Juniper Networks, Inc.
Page 730 634 Output Fields When you enter this command, you are provided feedback on the status of your request. telnet telnet user@host> telnet 192.154.1.254 Trying 192.154.169.254... Connected to level5.company.net. Escape character is '^]'. ttypa login: Copyright © 2010, Juniper Networks, Inc.
Page 731: Chapter 39 System Monitoring Overview
Junos OS for EX Series Switches System Monitoring System Monitoring Overview on page 637 Administering and Monitoring System Functions on page 649 Configuration Statements for System Monitoring on page 667 Operational Mode Commands for System Monitoring on page 721 Copyright © 2010, Juniper Networks, Inc.
Page 733: Understanding Alarm Types And Severity Levels On Ex Series Switches
System alarms indicate a missing rescue configuration. System alarms are preset and cannot be modified, although you can configure them to appear automatically in the J-Web interface display or CLI display. Alarm Severity Levels Copyright © 2010, Juniper Networks, Inc.
Page 734: Dashboard For Ex Series Switches
Complete Software Guide for Junos OS for EX Series Ethernet Switches, Release 10.3 Alarms on an Juniper Networks EX Series Ethernet Switches have two severity levels: Major (red)—Indicates a critical situation on the switch that has resulted from one of the following conditions.
Page 735: Health Status Panel
Inventory is always 1 FPC. FPC is a legacy term for a slot in a large Juniper Networks chassis; here, it simply refers to the single switch. For an EX4200 switch configured as a Virtual Chassis, the value in is displayed as 1–10 Inventory FPC, with the number corresponding to the number of member switches.
Page 736: Capacity Utilization Panel
5 major alarms, then details for all 5 major alarms are displayed. If there are 4 major alarms and 3 minor alarms, then details of the 4 major alarms and 1 minor alarm are displayed. Major alarms are displayed in red and minor alarms are displayed in yellow. Copyright © 2010, Juniper Networks, Inc.
Page 737: Chassis Viewer
(You might do this for initial switch configuration.) USB port Indicates the USB port for the switch. NOTE: We recommend you use USB flash drives purchased from Juniper Networks for your EX Series switch. Fan tray Hover the mouse pointer over the fan tray icon to display Name, Status, and Description information.
Page 738 (You might do this for initial switch configuration.) USB port Indicates the USB port for the switch. NOTE: We recommend you use USB flash drives purchased from Juniper Networks for your EX Series switch. Fan tray Hover the mouse pointer over the fan tray icon to display Name, Status, and Description information.
Page 739: Table 116: Chassis Viewer For Ex4500 Switches
Field Description USB port Indicates the USB port for the switch. NOTE: We recommend you use USB flash drives purchased from Juniper Networks for your EX Series switch. Management ( ) port The management port is used to connect the switch to a management device for out-of-band management.
Page 740: Table 117: Chassis Viewer For Ex8208 Switches
You can view status for the following ports on the SRE module: USB port—Indicates the USB port for the switch. NOTE: We recommend you use USB flash drives purchased from Juniper Networks for your EX Series switch. Auxiliary port—This port is not enabled on the switch. It is reserved for future use.
Page 741 LCD panel configured for the LEDs on the ports. Hover the mouse pointer over the icon to view the current character display. Rear View The EX8208 switch does not have any components on the rear of the chassis. Copyright © 2010, Juniper Networks, Inc.
Page 742: Table 118: Chassis Viewer For Ex8216 Switches
You can view status for the following ports on the RE module: USB port—Indicates the USB port for the switch. NOTE: We recommend you use USB flash drives purchased from Juniper Networks for your EX Series switch. Auxiliary port—This port is not enabled on the switch. It is reserved for future use.
Page 743 Chapter 39: System Monitoring Overview EX4500 Switches Hardware Overview on page 30 EX8208 Switch Hardware Overview on page 33 EX8216 Switch Hardware Overview on page 36 Copyright © 2010, Juniper Networks, Inc.
Page 745: Monitoring System Log Messages
Lists the names of all the system log files that you configure. Select to include Include archived files By default, a log file, , is included in the directory. messages /var/log/ archived files in the search. Copyright © 2010, Juniper Networks, Inc.
Page 746 25 events, with severity levels highlighted in different colors. After you specify the filters, Event Summary displays the events matching the specified filters. Click the First, Next, Prev, and Last links to navigate through messages. Copyright © 2010, Juniper Networks, Inc.
Page 747: Checking Active Alarms With The J-Web Interface
Displays the time at which the message was logged. Related Checking Active Alarms with the J-Web Interface on page 652 Documentation Understanding Alarm Types and Severity Levels on EX Series Switches on page 637 Copyright © 2010, Juniper Networks, Inc.
Page 748: Monitoring Chassis Alarms For An Ex8200 Switch
Understanding Alarm Types and Severity Levels on EX Series Switches on page 637 Monitoring Chassis Alarms for an EX8200 Switch Purpose This document provides information on chassis alarm conditions, and how you should respond when a certain chassis alarm is seen on your switch. Copyright © 2010, Juniper Networks, Inc.
Page 749: Table 122: Chassis Alarms For Ex8200 Switches
Temperature alarms If removing and functioning properly. will follow. reinserting the fan tray does not resolve the problem, reboot the switch. Copyright © 2010, Juniper Networks, Inc.
Page 750 Ensure airflow through To monitor temperature: increased. the switch is user@switch> show chassis unobstructed. environment To monitor temperature thresholds: user@switch> show chassis temperature-thresholds Copyright © 2010, Juniper Networks, Inc.
Page 751 Routing Engine (RE), The RE, SRE, or SF The RE, SRE, or SF Switch Fabric and module has failed. module must be Routing Engine (SRE), replaced. or Switch Fabric (SF) module Copyright © 2010, Juniper Networks, Inc.
Page 752: Monitoring Switch Control Traffic
Specifies the number of packets to be captured. Values From the list, select the number of packets range from . Default is . Packet capture stops to be captured—for example, 10. 1000 capturing packets after this number is reached. Copyright © 2010, Juniper Networks, Inc.
Page 753 Type the number of bytes you want to capture packet. If a packet header exceeds this size, the display is for each packet header—for example, truncated for the packet header. The default value is 96 bytes. Copyright © 2010, Juniper Networks, Inc.
Page 754: Monitoring System Properties
Export software is for use outside of the U.S. and Version whether the software is for domestic or export use. Canada. Hostname The name of switch. IP Address The IP address of the switch. Copyright © 2010, Juniper Networks, Inc.
Page 755 System from which the user has logged in. A hyphen indicates that the user is logged in through the console. Login Time Time when the user logged in. This is the field in command LOGIN@ show system users output. Copyright © 2010, Juniper Networks, Inc.
Page 756: Monitoring Chassis Information
Table 125: Summary of the Key Output Fields for Chassis Information Field Values Routing Engine Details Select the Master tab to view details about the master Routing Engine or select Backup to view details about the backup Routing Engine. Copyright © 2010, Juniper Networks, Inc.
Page 757 FPC. Name/Value Displays the temperature details of the sensors present in the selected FPC. Resource Select the tab to view the resource details of the selected FPC. Resource Copyright © 2010, Juniper Networks, Inc.
Page 758: Monitoring System Process Information
The display includes the total CPU load and total memory utilization. Table 126: Summary of System Process Information Output Fields Field Values Additional Information Identifier of the process. Name Owner of the process. State Current state of the process. Copyright © 2010, Juniper Networks, Inc.
Page 759: Managing Log, Temporary, And Crash Files On The Switch (J-Web Procedure)
Clean Up Files files and identifies files that can be safely deleted. The J-Web interface displays the files that you can delete and the amount of space that will be freed on the file system. Copyright © 2010, Juniper Networks, Inc.
Page 760: Downloading Files
Clean Up Files tool described in Cleaning Up Files. This tool determines which files can be safely deleted from the file system. To delete files with the J-Web interface: Select Maintain>Files In the Download and Delete Files section, click one: Copyright © 2010, Juniper Networks, Inc.
Page 761 Click one of the following buttons on the confirmation page: To delete the files and return to the Files page, click To cancel your entries and return to the list of files in the directory, click Cancel Copyright © 2010, Juniper Networks, Inc.
Page 764: Archive (All System Log Files)
Junos permission. maintenance Default: no-world-readable Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Specifying Log File Size, Number, and Archiving Properties Documentation Copyright © 2010, Juniper Networks, Inc.
Page 765: Archive-Sites
—Name of the argument. argument-name —Value of the argument. argument-value Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Executing Event Scripts in an Event Policy Documentation Copyright © 2010, Juniper Networks, Inc.
Page 766: Attributes-Match
The statements are explained separately. Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Using Correlated Events to Trigger an Event Policy Documentation within on page 719 Copyright © 2010, Juniper Networks, Inc.
Page 767: Commands
Level maintenance-control—To add this statement to the configuration. Related Configuring an Event Policy to Execute Operational Mode Commands Documentation Representing the Correlating Event in an Event Policy Copyright © 2010, Juniper Networks, Inc.
Page 768: Console (System Logging)
JUNOS System Logging Facilities and Message Severity Levels. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Directing System Log Messages to the Console Documentation Junos OS System Log Messages Reference Copyright © 2010, Juniper Networks, Inc.
Page 769: Destination
Level maintenance-control—To add this statement to the configuration. Related Configuring an Event Policy to Execute Operational Mode Commands Documentation Executing Event Scripts in an Event Policy destinations on page 674 Copyright © 2010, Juniper Networks, Inc.
Page 770: Destinations
—Name of a destination. The remaining statements are explained separately. Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Defining Destinations for File Archiving by Event Policies Documentation Copyright © 2010, Juniper Networks, Inc.
Page 771: Equals
—Attribute of one event. event1.attribute-name event2.attribute-name —Attribute of another event. Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Using Correlated Events to Trigger an Event Policy Documentation Copyright © 2010, Juniper Networks, Inc.
Page 772: Event-Options
[ events ]; within seconds not events [ events ]; then { event-script filename { arguments { argument-name argument-value; output-filename filename; destination destination-name { retry-count count retry-interval seconds; transfer-delay seconds; Copyright © 2010, Juniper Networks, Inc.
Page 773 Statement introduced in Junos OS Release 9.0 for EX Series switches. Description Configure event policies. The statements are explained separately. Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related [Unresolved xref] Documentation Copyright © 2010, Juniper Networks, Inc.
Page 774: Events (Correlating Events With Each Other)
[ events ] by Junos OS processes. Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Using Correlated Events to Trigger an Event Policy Documentation Copyright © 2010, Juniper Networks, Inc.
Page 775: Event-Script
For Junos OS event scripts, configure scripting mechanisms. The statements are explained separately. Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Implementing Event Scripts Documentation Copyright © 2010, Juniper Networks, Inc.
Page 776: Event-Script
The statements are explained separately. Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Executing Event Scripts in an Event Policy Documentation Copyright © 2010, Juniper Networks, Inc.
Page 777: Execute-Commands
The statements are explained separately. Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Configuring an Event Policy to Execute Operational Mode Commands Documentation Copyright © 2010, Juniper Networks, Inc.
Page 778: Explicit-Priority
Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Changing the Alternative Facility Name for Remote System Log Messages Documentation Junos System Log Messages Reference Copyright © 2010, Juniper Networks, Inc.
Page 779: File
Stylesheet Language Alternative Syntax (SLAX) file containing an event script. The statements are explained separately. Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Enabling an Event Script Documentation Copyright © 2010, Juniper Networks, Inc.
Page 780: File (System Logging)
The remaining statements are explained separately. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Directing System Log Messages to a Log File Documentation Junos System Log Messages Reference Copyright © 2010, Juniper Networks, Inc.
Page 781: Files
Level system-control—To add this statement to the configuration. Related Specifying Log File Size, Number, and Archiving Properties Documentation Junos System Log Messages Reference size on page 698 Copyright © 2010, Juniper Networks, Inc.
Page 782: Generate-Event
—Name of an internally generated event. event-name The statements are explained separately. Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Generating Internal Events to Trigger Event Policies Documentation Copyright © 2010, Juniper Networks, Inc.
Page 783: Host
—Severity of the messages that belong to the facility specified by the paired severity facility name. Messages with severities the specified level and higher are logged. For a list of the severities, see JUNOS System Logging Facilities and Message Severity Levels. Copyright © 2010, Juniper Networks, Inc.
Page 784: Ignore
Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Configuring Event Policies to Ignore an Event Documentation Copyright © 2010, Juniper Networks, Inc.
Page 785: Interface (Accounting Or Sampling)
—Text string to include in each message. Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Adding a Text String to System Log Messages Documentation Junos System Log Messages Reference Copyright © 2010, Juniper Networks, Inc.
Page 786: Match
[ events ] by Junos OS processes. Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Using Correlated Events to Trigger an Event Policy Documentation Copyright © 2010, Juniper Networks, Inc.
Page 787: Output-Filename
Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Configuring an Event Policy to Execute Operational Mode Commands Documentation Executing Event Scripts in an Event Policy Copyright © 2010, Juniper Networks, Inc.
Page 788: Output-Format
Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Configuring an Event Policy to Execute Operational Mode Commands Documentation Executing Event Scripts in an Event Policy Copyright © 2010, Juniper Networks, Inc.
Page 789: Policy
{ retry-count count retry-interval seconds; transfer-delay seconds; output-filename filename; output-format (text | xml); user-name username; ignore; raise-trap; upload filename (filename | committed) destination destination-name { retry-count count retry-interval seconds; transfer-delay seconds; user-name username; Copyright © 2010, Juniper Networks, Inc.
Page 790: Raise-Trap
(NMS) of significant events. Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Configuring Event Policies to Raise SNMP Traps Documentation Copyright © 2010, Juniper Networks, Inc.
Page 791: Refresh
Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Updating an Event Script from an Alternate Location Documentation refresh on page 695 source on page 699 Copyright © 2010, Juniper Networks, Inc.
Page 792: Remote-Execution
—User’s login name for the remote host. Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Using RPCs and Operational Mode Commands in Event Scripts Documentation Copyright © 2010, Juniper Networks, Inc.
Page 793: Retry-Count
—Length of time to wait between retries. Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Configuring an Event Policy to Retry the File Upload Action Documentation Copyright © 2010, Juniper Networks, Inc.
Page 794: Size
Level system-control—To add this statement to the configuration. Related Specifying Log File Size, Number, and Archiving Properties Documentation Junos System Log Messages Reference files on page 685 Copyright © 2010, Juniper Networks, Inc.
Page 795: Source
Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related refresh on page 695 Documentation refresh-from on page 695 Specifying a Master Source for an Event Script Copyright © 2010, Juniper Networks, Inc.
Page 796: Structured-Data
Level system-control—To add this statement to the configuration. Related Logging Messages in Structured-Data Format Documentation Junos System Log Messages Reference explicit-priority on page 682 time-format on page 704 Copyright © 2010, Juniper Networks, Inc.
Page 797: Syslog
Statement introduced in Junos OS Release 9.0 for EX Series switches. Description Configure the types of system log messages to log to files, a remote destination, user terminals, or the system console. The remaining statements are explained separately. Copyright © 2010, Juniper Networks, Inc.
Page 798 OS for EX Series Ethernet Switches, Release 10.3 Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related JUNOS Software System Log Configuration Overview Documentation Junos System Log Messages Reference Copyright © 2010, Juniper Networks, Inc.
Page 799: Then
Level maintenance-control—To add this statement to the configuration. Related Configuring an Event Policy to Upload Files Documentation Configuring an Event Policy to Execute Operational Mode Commands Executing Event Scripts in an Event Policy Copyright © 2010, Juniper Networks, Inc.
Page 800: Time-Format
Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Including the Year or Millisecond in Timestamps Documentation Junos System Log Messages Reference structured-data on page 700 Copyright © 2010, Juniper Networks, Inc.
Page 801: Time-Interval
—Time of day at which to generate an event. Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Generating Internal Events to Trigger Event Policies Documentation Copyright © 2010, Juniper Networks, Inc.
Page 802: Time-Zone
America/Halifax, America/Havana, America/Indiana/Knox, America/Indiana/Marengo, America/Indiana/Vevay, America/Indianapolis, America/Inuvik, America/Iqaluit, America/Jamaica, America/Jujuy, America/Juneau, America/La_Paz, America/Lima, America/Los_Angeles, America/Louisville, America/Maceio, America/Managua, America/Manaus, America/Martinique, America/Mazatlan, America/Mendoza, America/Menominee, America/Mexico_City, America/Miquelon, America/Montevideo, America/Montreal, America/Montserrat, America/Nassau, America/New_York, America/Nipigon, America/Nome, America/Noronha, America/Panama, America/Pangnirtung, America/Paramaribo, America/Phoenix, America/Port-au-Prince, Copyright © 2010, Juniper Networks, Inc.
Page 803 Pacific/Midway, Pacific/Nauru, Pacific/Niue, Pacific/Norfolk, Pacific/Noumea, Pacific/Pago_Pago, Pacific/Palau, Pacific/Pitcairn, Pacific/Ponape, Pacific/Port_Moresby, Pacific/Rarotonga, Pacific/Saipan, Pacific/Tahiti, Pacific/Tarawa, Pacific/Tongatapu, Pacific/Truk, Pacific/Wake, Pacific/Wallis, Pacific/Yap Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Copyright © 2010, Juniper Networks, Inc.
Page 804 ® Complete Software Guide for Junos OS for EX Series Ethernet Switches, Release 10.3 Related Modifying the Default Time Zone for a Router or Switch Running JUNOS Software Documentation System Management Configuration Statements Copyright © 2010, Juniper Networks, Inc.
Page 805: Traceoptions
—Log event script input data —Generate data for offline development offline output —Log event script output data —Log event script RPCs —Log the XSLT library xslt no-world-readable —Restrict file access to owner. This is the default. Copyright © 2010, Juniper Networks, Inc.
Page 806 Range: 10 KB through 1 GB Default: 128 KB —Enable unrestricted file access. world-readable Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Tracing Event Script Processing Documentation Copyright © 2010, Juniper Networks, Inc.
Page 807: Traceoptions
—Log communication with processes that are generating events server timer-events —Log internally generated events match regular-expression —(Optional) Refine the output to include lines that contain the regular expression. —Restrict file access to owner. This is the default. no-world-readable Copyright © 2010, Juniper Networks, Inc.
Page 808 Range: 10 KB through 1 GB Default: 128 KB —(Optional) Enable unrestricted file access. world-readable Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Tracing Event Policy Processing Documentation Copyright © 2010, Juniper Networks, Inc.
Page 809: Traceoptions (Commit And Op Scripts)
—Log script input data input —Generate data for offline development offline —Log script output data output —Log script RPCs —Log the XSLT library xslt —Restrict file access to owner. This is the default. no-world-readable Copyright © 2010, Juniper Networks, Inc.
Page 810 Default: 128 KB —Enable unrestricted file access. world-readable Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Tracing Commit Script Processing Documentation Tracing Op Script Processing Copyright © 2010, Juniper Networks, Inc.
Page 811: Transfer-Delay
Level maintenance-control—To add this statement to the configuration. Related Defining Destinations for File Archiving by Event Policies Documentation Configuring the Delay Before Files Are Uploaded by an Event Policy Copyright © 2010, Juniper Networks, Inc.
Page 812: Trigger
Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Triggering an Event Policy Based on Event Count Documentation Copyright © 2010, Juniper Networks, Inc.
Page 813: Upload
The remaining statements are explained separately. Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related destinations on page 674 Documentation Configuring an Event Policy to Upload Files Copyright © 2010, Juniper Networks, Inc.
Page 814: User (System Logging)
Level system-control—To add this statement to the configuration. Related Directing System Log Messages to a User Terminal. Documentation JUNOS System Logging Facilities and Message Severity Levels Junos System Log Messages Reference Copyright © 2010, Juniper Networks, Inc.
Page 815: User-Name
—Interval between events. seconds Range: 60 through 604,800 seconds Required Privilege maintenance—To view this statement in the configuration. Level maintenance-control—To add this statement to the configuration. Related Using Correlated Events to Trigger an Event Policy Documentation Copyright © 2010, Juniper Networks, Inc.
Page 816: World-Readable
Default no-world-readable Required Privilege system—To view this statement in the configuration. Level system-control—To add this statement to the configuration. Related Specifying Log File Size, Number, and Archiving Properties Documentation Junos System Log Messages Reference Copyright © 2010, Juniper Networks, Inc.
Page 818: Clear Log
1 root wheel 26450 Jun 23 18:47 /var/log/sampled total 1 user@host> clear log lcc0-re0:sampled lcc0-re0: -------------------------------------------------------------------------- user@host> file list lcc0-re0:/var/log/sampled detail lcc0-re0: -------------------------------------------------------------------------- -rw-r----- 1 root wheel 57 Sep 15 03:44 /var/log/sampled total 1 Copyright © 2010, Juniper Networks, Inc.
Page 819: File Archive
The following sample command archives one message file in the local directory File) as the single file in the same directory: /var/log/messages messages-archive.tar user@host> file archive source /var/log/messages destination /var/log/messages-archive.tar /usr/bin/tar: Removing leading / from absolute path names in the archive. user@host Copyright © 2010, Juniper Networks, Inc.
Page 820 The following sample command archives and compresses all message files in the local (with Compression) directory as the single file in the same directory: /var/log/messages messages-archive.tgz user@host> file archive compress source /var/log/messages* destination /var/log/messages-archive.tgz /usr/bin/tar: Removing leading / from absolute path names in the archive. user@host> Copyright © 2010, Juniper Networks, Inc.
Page 821: File Checksum Sha1
725 Output Fields When you enter this command, you are provided feedback on the status of your request. file checksum md5 file checksum md5 user@host> file checksum md5 jbundle-5.3R2.4-export-signed.tgz MD5 (jbundle-5.3R2.4-export-signed.tgz) = 2a3b69e43f9bd4893729cc16f505a0f5 Copyright © 2010, Juniper Networks, Inc.
Page 822 726 Output Fields When you enter this command, you are provided feedback on the status of your request. file checksum sha1 file checksum sha1 user@host> file checksum sha1 /var/db/scripts/opscript.slax SHA1 (/var/db/scripts/commitscript.slax) = ba9e47120c7ce55cff29afd73eacd370e162c676 Copyright © 2010, Juniper Networks, Inc.
Page 823 727 Output Fields When you enter this command, you are provided feedback on the status of your request. file checksum sha-256 file checksum sha-256 user@host> file checksum sha-256 /var/db/scripts/commitscript.slax SHA256 (/var/db/scripts/commitscript.slax) = 94c2b061fb55399e15babd2529453815601a602b5c98e5c12ed929c9d343dd71 Copyright © 2010, Juniper Networks, Inc.
Page 824: File Compare
729 file compare files unified on page 729 file compare files unified ignore-white-space on page 730 Output Fields When you enter this command, you are provided feedback on the status of your request. Copyright © 2010, Juniper Networks, Inc.
Page 825 +++ /tmp/two Wed Dec 3 09:13:14 2003 @@ -97,8 +97,9 @@ user bill { full-name "Bill Smith"; class foo; # 'foo' is not defined full-name "Bill Smith"; uid 1089; class super-user; authentication { encrypted-passwordSECRET; Copyright © 2010, Juniper Networks, Inc.
Page 826 +++ /tmp/two Wed Dec 3 09:13:14 2003 ignore-white-space @@ -99,7 +99,7 @@ user bill { full-name "Bill Smith"; uid 1089; class foo; # 'foo' is not defined class super-user; authentication { encrypted-password <SECRET>; # SECRET-DATA Copyright © 2010, Juniper Networks, Inc.
Page 827: File Copy
The following sample command copies a text file from Routing Engine 1 on the the TX Matrix Plus switch-fabric chassis sfc0 to Routing Engine 1 on the line-card chassis lcc0 Router to a T1600 user@host> file copy sfc0-re1:/tmp/sample.txt lcc0-re1:/var/tmp Router Connected to the TX Matrix Plus Router) Copyright © 2010, Juniper Networks, Inc.
Page 828: File Delete
/var/tmp/snmpd.core user@host> file list /var/tmp dcd.core rpd.core file delete user@host> file list lcc0-re0:/var/tmp dcd.core (Routing Matrix) rpd.core snmpd.core user@host> file delete lcc0-re0:/var/tmp/snmpd.core user@host> file list /var/tmp dcd.core rpd.core Copyright © 2010, Juniper Networks, Inc.
Page 829: File List
(Routing Matrix) on page 734 Output Fields When you enter this command, you are provided feedback on the status of your request. file list file list user@host> file list /var/tmp dcd.core rpd.core snmpd.core Copyright © 2010, Juniper Networks, Inc.
Page 830 OS for EX Series Ethernet Switches, Release 10.3 file list (Routing user@host> file list lcc0-re0:var/tmp lcc0-re0: Matrix) -------------------------------------------------------------------------- /var/tmp/: .gdbinit .pccardd Test/ chassisd* chassisd.nathan* check_time* cores/ diagTestPrep* diagtest* diagtest.regress* do_switchovers* dump_test* err.manoj.log esw_clearstats* esw_counter* esw_debug* esw_debug_ge* esw_filt_test* esw_filter_tnp_addr* esw_getstats* esw_phy* esw_stats* Copyright © 2010, Juniper Networks, Inc.
Page 831: File Rename
, renames one of the files, and then displays the list of files again to reveal the newly named file. user@host> file list /var/tmp dcd.core rpd.core snmpd.core user@host> file rename /var/tmp/dcd.core /var/tmp/dcd.core.990413 user@host> file list /var/tmp dcd.core.990413 rpd.core snmpd.core Copyright © 2010, Juniper Networks, Inc.
Page 832 -------------------------------------------------------------------------- /var/tmp: .pccardd sartre.conf snmpd syslogd.core-tarball.0.tgz user@host> file rename lcc0-re0:/var/tmp/snmpd /var/tmp/snmpd.rr user@host> file list lcc0-re1:/var/tmp lcc0-re1: -------------------------------------------------------------------------- /var/tmp: .pccardd sartre.conf snmpd.rr syslogd.core-tarball.0.tgz Copyright © 2010, Juniper Networks, Inc.
Page 833: File Show
# hex dump of a block of memory # usage: dump address length define dump p $arg0, $arg1 set $ch = $arg0 set $j = 0 set $n = $arg1 while ($j < $n) Copyright © 2010, Juniper Networks, Inc.
Page 834 ® Complete Software Guide for Junos OS for EX Series Ethernet Switches, Release 10.3 #printf "%x %x ",&$ch[$j],$ch[$j] printf "%x ",$ch[$j] set $j = $j + 1 if (!($j % 16)) printf "\n" Copyright © 2010, Juniper Networks, Inc.
Page 835: Monitor List
Last changed Date and time at which the file was last modified. monitor list monitor list user@host> monitor list monitor start "vrrpd" (Last changed Dec 03:11:06 20) monitor start "cli-commands" (Last changed Nov 07:3) Copyright © 2010, Juniper Networks, Inc.
Page 836: Monitor Start
Jul 20 15:07:35 hang sshd[5845]: log: Connection from 204.69.248.180 port 912 Jul 20 15:07:37 hang sshd[5845]: log: RSA authentication for root accepted. Jul 20 15:07:37 hang sshd[5845]: log: ROOT LOGIN as 'root' from trip.jcmax.com Jul 20 15:07:37 hang sshd[5845]: log: Closing connection to 204.69.248.180 Copyright © 2010, Juniper Networks, Inc.
Page 837: Monitor Stop
739 Documentation monitor start on page 740 List of Sample Output monitor stop on page 741 Output Fields This command produces no output. monitor stop monitor stop user@host> monitor stop Copyright © 2010, Juniper Networks, Inc.
Page 838: Request System Configuration Rescue Delete
List of Sample Output request system configuration rescue delete on page 742 Output Fields This command produces no output. request system request system user@host> request system configuration rescue delete configuration rescue configuration rescue delete delete Copyright © 2010, Juniper Networks, Inc.
Page 839: Request System Configuration Rescue Save
List of Sample Output request system configuration rescue save on page 743 Output Fields This command produces no output. request system request system user@host> request system configuration rescue save configuration rescue configuration rescue save save Copyright © 2010, Juniper Networks, Inc.
Page 840: Request System Scripts Refresh-From Commit
744 request system scripts request system scripts user@switch> request system scripts refresh-from commit file config.txt url http://host1.juniper.net refresh-from commit refresh-from commit user@switch> file config.txt url file config.txt url http://host1.juniper.net http://host1.juniper.net Copyright © 2010, Juniper Networks, Inc.
Page 841: Request System Scripts Refresh-From Event
745 request system scripts request system scripts user@switch> request system scripts refresh-from event file config.txt url http://host1.juniper.net refresh-from event file refresh-from event file user@switch> config.txt url config.txt url http://host1.juniper.net http://host1.juniper.net Copyright © 2010, Juniper Networks, Inc.
Page 842: Request System Scripts Refresh-From Op
746 request system scripts request system scripts user@switch> request system scripts refresh-from op file config.txt url http://host1.juniper.net user@switch> refresh-from op file refresh-from op file config.txt url config.txt url http://host1.juniper.net http://host1.juniper.net Copyright © 2010, Juniper Networks, Inc.
Page 843: Show Chassis Alarms
(Alarms Active on a TX Matrix Router) on page 748 show chassis alarms (Backup Routing Engine) on page 749 show chassis alarms (Alarms Active on a TX Matrix Plus Router) on page 749 Copyright © 2010, Juniper Networks, Inc.
Page 844: Table 129: Show Chassis Alarms Output Fields
2004-08-05 18:43:35 PDT Minor SIB 3 Not Online 2004-08-05 18:43:33 PDT Major SIB 2 Absent 2004-08-05 18:43:33 PDT Major SIB 1 Absent 2004-08-05 18:43:33 PDT Major SIB 0 Absent 2004-08-05 18:43:05 PDT Minor PEM 1 Absent Copyright © 2010, Juniper Networks, Inc.
Page 845 Check SIB 0 2009-05-06 17:33:51 PDT Major SIB_L - Fan Revision mismatch 2009-05-06 17:33:49 PDT Minor SIB 0 Fbr Bndls 2009-05-06 17:33:49 PDT Minor SIB 0 LOL 2009-05-06 17:31:58 PDT Minor PEM 1 Absent Copyright © 2010, Juniper Networks, Inc.
Page 846: Show Chassis Environment
For information about the remaining options, see the Related Topics. Required Privilege view Level Related show chassis environment cb Documentation show chassis environment cip show chassis environment fpc on page 766 show chassis environment fpm show chassis environment mcs show chassis environment pcg Copyright © 2010, Juniper Networks, Inc.
Page 847: Show Chassis Environment Routing-Engine
On some routers, this field indicates the status of one or more additional components. On the M160 router, includes (Connector Interface Panel). indicates the is present. Misc On the T640 router, includes (Switch Processor Mezzanine Board). indicates Misc SPMB the item is present. Copyright © 2010, Juniper Networks, Inc.
Page 848: Switches
35 degrees C / 95 degrees F Fans Left Fan 1 Spinning at normal speed Left Fan 2 Spinning at normal speed Left Fan 3 Spinning at normal speed Left Fan 4 Spinning at normal speed Misc Craft Interface Copyright © 2010, Juniper Networks, Inc.
Page 850 39 degrees C / 102 degrees F FEB 4 Intake 33 degrees C / 91 degrees F FEB 4 Exhaust A 39 degrees C / 102 degrees F FEB 4 Exhaust B 36 degrees C / 96 degrees F Copyright © 2010, Juniper Networks, Inc.
Page 851 43 degrees C / 109 degrees F FPM CMB 31 degrees C / 87 degrees F FPM Display 33 degrees C / 91 degrees F Fans Rear Bottom Blower Spinning at normal speed Rear Top Blower Spinning at normal speed Copyright © 2010, Juniper Networks, Inc.
Page 852 PEM 1 45 degrees C / 113 degrees F PEM 2 Absent PEM 3 Absent Routing Engine 0 39 degrees C / 102 degrees F Routing Engine 1 37 degrees C / 98 degrees F Copyright © 2010, Juniper Networks, Inc.
Page 855 Spinning at normal speed Bottom Right Rear fan Spinning at normal speed Rear Tray Top fan Spinning at normal speed Rear Tray Second fan Spinning at normal speed Rear Tray Middle fan Spinning at normal speed Copyright © 2010, Juniper Networks, Inc.
Page 857 Bottom Left Rear fan Spinning at normal speed Bottom Right Front fan OK Spinning at normal speed Bottom Right Middle fan OK Spinning at normal speed Bottom Right Rear fan Spinning at normal speed Copyright © 2010, Juniper Networks, Inc.
Page 858 49 degrees C / 120 degrees F FPM GBUS 27 degrees C / 80 degrees F FPM Display 30 degrees C / 86 degrees F Fans Top Left Front fan Spinning at normal speed Copyright © 2010, Juniper Networks, Inc.
Page 859 25 degrees C / 77 degrees F Fans Fan Tray 0 Fan 1 Spinning at normal speed Fan Tray 0 Fan 2 Spinning at normal speed Fan Tray 0 Fan 3 Spinning at normal speed Copyright © 2010, Juniper Networks, Inc.
Page 861 Rear Tray Fifth fan Spinning at normal speed Rear Tray Sixth fan Spinning at normal speed Rear Tray Seventh fan Spinning at normal speed Rear Tray Bottom fan Spinning at normal speed Misc SPMB 0 SPMB 1 Copyright © 2010, Juniper Networks, Inc.
Page 862 MX240 router—Replace with a value from through slot MX480 router—Replace slot with a value from through MX960 router—Replace with a value from through slot Other routers—Replace slot with a value from through EX Series switches: Copyright © 2010, Juniper Networks, Inc.
Page 863: Members
Temperature Top (M120 and M320 routers only) Temperature of the air flowing out of the chassis. Temperature Exhaust (T Series routers only) Temperature of the air flowing past the bottom of the FPC. Temperature Bottom Copyright © 2010, Juniper Networks, Inc.
Page 864: Switches
3.3 V bias 3296 mV 1.2 V Rocket IO 1205 mV 1.5 V Rocket IO 1501 mV I2C Slave Revision FPC 4 status: State Online Temperature Exhaust A 32 degrees C / 89 degrees F Copyright © 2010, Juniper Networks, Inc.
Page 865 27 degrees C / 80 degrees F Temperature Exhaust 37 degrees C / 98 degrees F Temperature MMB1 32 degrees C / 89 degrees F Power: 1.5 V 1504 mV 1.5 V * 1499 mV Copyright © 2010, Juniper Networks, Inc.
Page 866 FPC 2 status: State Online Temperature Intake 33 degrees C / 91 degrees F Temperature Exhaust A 41 degrees C / 105 degrees F Temperature Exhaust B 53 degrees C / 127 degrees F Copyright © 2010, Juniper Networks, Inc.
Page 869 25 degrees C / 77 degrees F Temperature MMB0 Absent Temperature MMB1 27 degrees C / 80 degrees F Power: 1.8 V 1813 mV 2.5 V 2504 mV 3.3 V 3338 mV 5.0 V 5037 mV Copyright © 2010, Juniper Networks, Inc.
Page 872: Configuration
Required Privilege view Level List of Sample Output show chassis environment routing-engine (Nonredundant) on page 777 show chassis environment routing-engine (Redundant) on page 777 show chassis environment routing-engine (TX Matrix Plus Router) on page 777 Copyright © 2010, Juniper Networks, Inc.
Page 873: Table 132: Show Chassis Environment Routing-Engine Output Fields
28 degrees C / 82 degrees F lcc0-re0: -------------------------------------------------------------------------- Routing Engine 0 status: State Online Master Temperature 30 degrees C / 86 degrees F Routing Engine 1 status: State Online Standby Temperature 29 degrees C / 84 degrees F Copyright © 2010, Juniper Networks, Inc.
Page 874: Switch
EX Series switches: EX3200 switches and EX4200 standalone switches—Replace fpc-slot with 0. EX4200 switches in a Virtual Chassis configuration—Replace with a fpc-slot value from 0 through 9 (switch’s member ID). Copyright © 2010, Juniper Networks, Inc.
Page 875 TX Matrix router. On a TX Matrix Plus router, display status information for a T1600 router (or line-card chassis) that is connected to the TX Matrix Plus router. Replace number with a value from through Required Privilege view Level Copyright © 2010, Juniper Networks, Inc.
Page 876: Table 133: Show Chassis Fpc Output Fields
Temperature of the air passing by the FPC, in degrees Celsius or in both Celsius all levels Temp (C) or and Fahrenheit. Temperature Total percentage of CPU being used by the FPC's processor. all levels Total CPU Utilization (%) Copyright © 2010, Juniper Networks, Inc.
Page 877 Slot State Online Online show chassis fpc (M20 user@host> show chassis fpc FPC status: Router) Temp CPU Utilization (%) Memory Utilization (%) Slot State Total Interrupt DRAM (MB) Heap Buffer Empty Online Online Empty Copyright © 2010, Juniper Networks, Inc.
Page 878 Temp CPU Utilization (%) Memory Utilization (%) (MX960 Router) Slot State Total Interrupt DRAM (MB) Heap Buffer Empty Empty Empty Online 1024 Empty Online 1024 Empty Empty Empty Empty Copyright © 2010, Juniper Networks, Inc.
Page 880 1x OC-192 SM SR2 PIC 2 Online 1x OC-192 SM SR1 PIC 3 Online 1x Tunnel Slot 1 Online FPC Type 2 PIC 0 Online 1x OC-48 SONET, SMSR PIC 1 Online 1x OC-48 SONET, SMSR Copyright © 2010, Juniper Networks, Inc.
Page 881 Online 1x OC-192 SONET XFP PIC 2 Online 1x OC-192 SM SR2 PIC 3 Online 10x 1GE(LAN), 1000 BASE lcc1-re0: -------------------------------------------------------------------------- Slot 4 Online FPC Type 4-ES PIC 0 Online 4x 10GE (LAN/WAN) XFP Copyright © 2010, Juniper Networks, Inc.
Page 882 Slot 7 Online FPC Type 3-ES PIC 0 Online 10x 1GE(LAN), 1000 BASE PIC 1 Online 1x OC-192 SONET XFP PIC 2 Online 1x OC-192 SM SR2 PIC 3 Online 10x 1GE(LAN), 1000 BASE Copyright © 2010, Juniper Networks, Inc.
Page 883 TX Matrix Plus router and its attached T1600 routers. clei-models —(All supported platforms, except EX2200, EX3200, EX4200, and EX4500 switches) (Optional) Display Common Language Equipment Identifier (CLEI) bar code and model number for orderable field-replaceable units (FRUs). Copyright © 2010, Juniper Networks, Inc.
Page 884 (MX960 Router with Bidirectional Optics) on page 804 show chassis hardware detail (MX960 Router) on page 805 show chassis hardware (T320 Router) on page 805 show chassis hardware (T640 Router) on page 806 Copyright © 2010, Juniper Networks, Inc.
Page 885: Ports
Serial number of the chassis component. The serial number of the backplane All levels Serial number is also the serial number of the router chassis. Use this serial number when you need to contact Juniper Networks Customer Support about the router chassis. Copyright © 2010, Juniper Networks, Inc.
Page 886: Switches
2x SHDSL (ATM) —G SHDSL PIM (2-port two-wire module or 1-port four-wire module) —TGM550 Telephony Gateway Module (Avaya VoIP Gateway 1x TGM550 Module with one console port, two analog LINE ports, and two analog TRUNK ports) Copyright © 2010, Juniper Networks, Inc.
Page 887 Hardware inventory: (J6350 Router) (J6350 Router) Item Version Part number Serial number Description Chassis JN1090E07ADB JSR6350 Midplane REV 03 710-014593 NP1265 System IO REV 01 710-016210 NN9950 JX350 System IO Crypto Module Crypto Acceleration Copyright © 2010, Juniper Networks, Inc.
Page 888 REV 01 740-011615 PAD5EER UNKNOWN Xcvr 2 REV 01 740-011614 PD94THU SFP-LX10 Xcvr 3 NON-JNPR PDC2E7A SFP-LX10 PIC 1 REV 03 750-023116 JT0203 4x CHSTM1 SDH CE SFP Xcvr 0 REV 01 740-012434 AGT063832PS SFP-SR Copyright © 2010, Juniper Networks, Inc.
Page 889 REV 01 710-001951 S/N AD5905 Internet Processor II SSRAM bank 0 REV 01 710-001385 S00480 2 Mbytes SSRAM bank 1 REV 01 710-001385 S00490 2 Mbytes SSRAM bank 2 REV 01 710-001385 S001:? 2 Mbytes Copyright © 2010, Juniper Networks, Inc.
Page 890 64 Mbytes PIC 0 REV 04 750-000613 S/N aa0343 1x OC-12 SONET, SMIR PIC 1 REV 04 750-000613 S/N AA0379 1x OC-12 SONET, SMIR PIC 2 REV 04 750-000613 S/N AA0377 1x OC-12 SONET, SMIR Copyright © 2010, Juniper Networks, Inc.
Page 891 750-002911 AN2286 4x F/E, 100 BASE-TX PIC 2 REV 01 750-002577 AP6345 4x OC-3 SONET, MM show chassis hardware user@host> show chassis hardware Hardware inventory: (M120 Router) Item Version Part number Serial number Description Copyright © 2010, Juniper Networks, Inc.
Page 892 REV 02 710-011410 CJ9221 M120 FPM CIP PEM 0 Rev 05 740-011936 RM28320 AC Power Entry Module PEM 1 Rev 05 740-011936 RM28321 AC Power Entry Module Routing Engine 0 REV 03 740-014080 1000642883 RE-A-1000 Copyright © 2010, Juniper Networks, Inc.
Page 893 FPC 1 REV 02 710-015908 M120-cFPC-1XGE-XFP FPC 3 PIC 0 REV 16 750-008155 PB-2GE-SFP-QPP PIC 1 REV 09 750-007745 PC-4OC3-SON-SMIR PIC 2 REV 16 750-008155 PB-2GE-SFP-QPP PIC 3 REV 07 750-011800 PB-8GE-TYPE2-SFP-IQ2 FPC 4 Copyright © 2010, Juniper Networks, Inc.
Page 894 REV 01 750-001323 P-TUNNEL PIC 1 REV 02 750-002987 PE-1OC12-SON-SMIR PIC 2 REV 04 750-001894 PB-1GE-SX PIC 3 REV 04 750-001896 PB-1OC12-SON-SMIR FPC 1 REV 02 710-010419 M320-FPC1 PIC 0 REV 04 750-001894 PB-1GE-SX Copyright © 2010, Juniper Networks, Inc.
Page 895 S/N AA9806 FPC Type 1 REV 02 710-001217 S/N AA9590 SSRAM REV 01 710-000077 S/N 302836 1 Mbyte SDRAM 0 REV 01 710-001196 S00141 32 Mbytes SDRAM 1 REV 01 710-001196 S0010; 32 Mbytes Copyright © 2010, Juniper Networks, Inc.
Page 896 FPC 7 REV 02 710-005017 CD9934 M320 FPC Type 2 SIB 0 REV 09 710-009184 JA6540 M320 SIB SIB 1 REV 09 710-009184 HV9511 M320 SIB SIB 2 REV 09 710-009184 HW2057 M320 SIB Copyright © 2010, Juniper Networks, Inc.
Page 897 Chassis MX80-48T Midplane REV 01 711-031603 KF9250 MX80-48T Routing Engine BUILTIN BUILTIN Routing Engine FEB 0 BUILTIN BUILTIN Forwarding Engine Board FPC 0 BUILTIN BUILTIN MPC BUILTIN MIC 0 BUILTIN BUILTIN 4x 10GE XFP Copyright © 2010, Juniper Networks, Inc.
Page 898 DPCE 40x 1GE R REV 06 710-013713 KD4078 DPC PMB PIC 0 BUILTIN BUILTIN 10x 1GE(LAN) Xcvr 0 REV 01 740-011613 P9F18ME SFP-SX PIC 1 BUILTIN BUILTIN 10x 1GE(LAN) PIC 2 BUILTIN BUILTIN 10x 1GE(LAN) Copyright © 2010, Juniper Networks, Inc.
Page 899 Rev 01 740-013682 000038 PS 1.7kW; 200-240VAC in Routing Engine 0 REV 00 740-015113 1000617944 RE-S-1300 CB 0 REV 05 710-013725 JK6947 MX960 Test SCB FPC 4 REV 01 710-013305 JM7617 MX960 Test DPC Copyright © 2010, Juniper Networks, Inc.
Page 900 PIC 3 BUILTIN BUILTIN 10x 1GE(LAN) Xcvr 0 REV 01 740-017726 74S184H30341 SFP-LH Xcvr 1 REV 01 740-017726 4814061 SFP-LH Xcvr 5 REV 01 740-017726 6ZS184H31108 SFP-LH Xcvr 9 REV 01 740-021340 76E245X00486 SFP-1000BASE-BX10-U Copyright © 2010, Juniper Networks, Inc.
Page 901 REV 01 750-010618 CD9587 4x G/E SFP, 1000 BASE SFP 0 NON-JNPR P5A08QZ SFP-T SFP 1 REV 01 740-007326 P4Q133K SFP-SX SFP 2 REV 01 740-007326 P5809YY SFP-SX SFP 3 REV 01 740-007327 4C81704 SFP-LX Copyright © 2010, Juniper Networks, Inc.
Page 902 750-009567 HX4420 1x 10GE(LAN),XENPAK SFP 0 REV 01 740-012058 434TC124 XENPAK-LX4 FPC 5 REV 01 710-013553 JE4839 E2-FPC Type 1 REV 01 710-013569 JW9163 FPC CPU PIC 0 REV 01 750-009567 HX4419 1x 10GE(LAN),XENPAK Copyright © 2010, Juniper Networks, Inc.
Page 903 REV 04 710-002726 AX5633 Jedec Code: 0x7fb0 EEPROM Version: 0x01 P/N: 710-002726. S/N: S/N AX5633. Assembly ID: 0x0127 Assembly Version: 01.04 Date: 06-27-2001 Assembly Flags: 0x00 Version: REV 04..ID: Gibson Backplane Board Information Record: Copyright © 2010, Juniper Networks, Inc.
Page 904 REV 03 750-003336 HJ9954 4x OC-48 SONET, SMSR PIC 2 REV 01 750-004535 HC0235 1x OC-192 SM SR1 PIC 3 REV 07 750-007141 HX1699 10x 1GE(LAN), 1000 BASE SFP 0 REV 01 740-007326 2441042 SFP-SX Copyright © 2010, Juniper Networks, Inc.
Page 905 SPMB 1 REV 02 710-023321 DP0238 LCC Switch CPU SIB 0 REV 06 710-022594 DT8268 LCC SIB B Board REV 06 710-023185 DT5791 LCC SIB Mezz SIB 1 REV 06 710-022594 DT8261 LCC SIB Copyright © 2010, Juniper Networks, Inc.
Page 906 SIB F2S 1/2 REV 05 710-022603 DW7849 F2S SIB B Board REV 05 710-023787 DW7525 NEO PMB SIB F2S 1/4 REV 05 710-022603 DW7927 F2S SIB B Board REV 05 710-023787 DW7556 F2S SIB Mezz Copyright © 2010, Juniper Networks, Inc.
Page 907 750-017405 DP8794 4x 10GE (LAN/WAN) XFP Xcvr 0 REV 02 740-014289 C839XU0J8 XFP-10G-SR Xcvr 1 REV 02 740-014289 C839XU0K6 XFP-10G-SR Xcvr 2 REV 02 740-014289 C839XU0J7 XFP-10G-SR Xcvr 3 REV 02 740-014289 C839XU0KF XFP-10G-SR Copyright © 2010, Juniper Networks, Inc.
Page 908 FPM GBUS REV 10 710-002901 DS3450 T640 FPM Board FPM Display REV 01 710-021387 DS6430 T1600 FPM Display REV 06 710-002895 DS4239 T Series CIP PEM 0 Rev 08 740-017906 UD26649 Power Entry Module 3x80 Copyright © 2010, Juniper Networks, Inc.
Page 909 REV 08 710-022594 DW8043 LCC SIB B Board REV 08 710-023185 DW8193 LCC SIB Mezz Fan Tray 0 Front Top Fan Tray Fan Tray 1 Front Bottom Fan Tray Fan Tray 2 Rear Fan Tray Copyright © 2010, Juniper Networks, Inc.
Page 910 SIB F2S 2/4 REV 05 710-022603 DW7907 F2S SIB B Board REV 05 710-023787 DW7590 NEO PMB SIB F2S 2/6 REV 05 710-022603 DW7785 F2S SIB B Board REV 05 710-023787 DW7524 NEO PMB Copyright © 2010, Juniper Networks, Inc.
Page 912 REV 04 710-022603 SIB F2S 1/2 REV 05 710-022603 SIB F2S 1/4 REV 05 710-022603 SIB-TXP-F2S SIB F2S 1/6 REV 05 710-022603 SIB F2S 2/0 REV 05 710-022603 SIB F2S 2/2 REV 05 710-022603 Copyright © 2010, Juniper Networks, Inc.
Page 913 CIP 0 REV 01 710-023792 DR1437 TXP CIP CIP 1 REV 02 710-023792 DS4564 TXP CIP PEM 0 Rev 07 740-027463 UM26360 Power Entry Module Routing Engine 0 REV 01 740-026942 737A-1024 SFC RE Copyright © 2010, Juniper Networks, Inc.
Page 914 Disk 1 Routing Engine 1 REV 01 740-026942 737F-1024 LCC RE 3887 MB SMART CF 2008110500F9A8A8A8A8 Compact Flash 30533 MB SAMSUNG MCBQE32G8MPP-0V SY814A1076 Disk 1 CB 0 REV 05 710-022597 DV4264 LCC Control Board Copyright © 2010, Juniper Networks, Inc.
Page 915 SIB F2S 1/4 REV 05 710-022603 DW7927 SIB-TXP-F2S SIB F2S 1/6 REV 05 710-022603 DW7866 SIB F2S 2/0 REV 05 710-022603 DW7880 SIB F2S 2/2 REV 05 710-022603 DW7895 SIB F2S 2/4 REV 05 710-022603 DW7907 Copyright © 2010, Juniper Networks, Inc.
Page 916 CB 0 REV 06 710-022597 DW8523 CB-LCC CB 1 REV 06 710-022597 DW8528 CB-LCC FPC 4 REV 12 710-013037 DP8509 T1600-FPC4-ES PIC 0 REV 11 750-017405 DP8808 PD-4XGE-XFP PIC 1 REV 11 750-017405 DP7263 PD-4XGE-XFP Copyright © 2010, Juniper Networks, Inc.
Page 917 CB 1 REV 06 710-022597 DW8538 CB-LCC FPC 0 REV 14 710-013037 DS5345 T1600-FPC4-ES PIC 0 REV 13 750-017405 DS7641 PD-4XGE-XFP PIC 1 REV 13 750-017405 DS5479 PD-4XGE-XFP FPC 1 REV 14 710-013037 DS7338 T1600-FPC4-ES Copyright © 2010, Juniper Networks, Inc.
Page 918 4x 10GE(LAN) SFP+ PIC 2 BUILTIN BUILTIN 4x 10GE(LAN) SFP+ PIC 3 BUILTIN BUILTIN 4x 10GE(LAN) SFP+ Fan Tray 0 REV 05 740-014971 TP9990 Fan Tray Fan Tray 1 REV 05 740-014971 VS1709 Fan Tray Copyright © 2010, Juniper Networks, Inc.
Page 919 Chassis Status LEDs in an EX8200 Switch Output Fields Table 49 on page 282 lists the output fields for the command. Output show chassis led fields are listed in the approximate order in which they appear. Copyright © 2010, Juniper Networks, Inc.
Page 920: Chassis Configuration
State of the currently selected port parameter of the Status LED for the interface. The Status LED port parameters are: (ADM/SPD/DPX/POE) NOTE: EX4500 and EX8200 switches do not have the POE port parameter. —Administrative —Speed —Duplex —Power over Ethernet Copyright © 2010, Juniper Networks, Inc.
Page 921 Alarms LED: Off System LED: Green Master LED: Green Interface LED(ADM/SPD/DPX/POE) ------------------------------------- ge-0/0/0 ge-0/0/1 Full Duplex ge-0/0/2 Full Duplex ge-0/0/3 ge-0/0/4 ge-0/0/5 Full Duplex ge-0/0/6 Full Duplex ge-0/0/7 Full Duplex ge-0/0/8 Full Duplex ge-0/0/9 Full Duplex Copyright © 2010, Juniper Networks, Inc.
Page 922 Alarms LED: Red System LED: Green Master LED: Green Interface LED(ADM/SPD/DPX/POE) ------------------------------------- ge-0/0/0 ge-0/0/1 ge-0/0/2 ge-0/0/3 ge-0/0/4 ge-0/0/5 ge-0/0/6 ge-0/0/7 ge-0/0/8 ge-0/0/9 ge-0/0/10 ge-0/0/11 ge-0/0/12 ge-0/0/13 ge-0/0/14 ge-0/0/15 ge-0/0/16 ge-0/0/17 ge-0/0/18 ge-0/0/19 ge-0/0/20 ge-0/0/21 ge-0/0/22 ge-0/0/23 Copyright © 2010, Juniper Networks, Inc.
Page 923 —(TX Matrix and TX Matrix Plus routers only) (Optional) On a TX Matrix router, lcc number display the physical location of a specified T640 router (or line-card chassis) that is connected to a TX Matrix router. On a TX Matrix Plus router , display the physical Copyright © 2010, Juniper Networks, Inc.
Page 924: Table 136: Show Chassis Location Output Fields
T640 router. On a TX Matrix Plus router, the FPC slot number on a particular T1600 router. show chassis location show chassis location user@host> show chassis location country-code: US postal-code: 94404 Building: Building 2, Floor: 2 Copyright © 2010, Juniper Networks, Inc.
Page 925 Global FPC Local FPC fpc (TX Matrix Plus Router) show chassis location user@host> show chassis location interface by-slot fpc 2 lcc 1 Global FPC: 10 interface by-slot (TX Matrix Plus Router) Copyright © 2010, Juniper Networks, Inc.
Page 926 0 through 9 (switch’s member ID). EX8208 switches—Replace slot-number with a value from 0 through 7 (line card). EX8216 switches—Replace with a value from 0 through 15 (line slot-number card). Copyright © 2010, Juniper Networks, Inc.
Page 927: Table 137: Show Chassis Pic Output Fields
Status of the PIC. State is displayed only when a PIC is in the slot. State — PIC is online and running. Online —PIC is powered down. Offline PIC hardware version. PIC version How long the PIC has been online. Uptime Copyright © 2010, Juniper Networks, Inc.
Page 928 Type 10x 1GE(LAN), 1000 BASE ASIC type H chip State Online PIC version Uptime 1 day, 50 minutes, 58 seconds PIC Port Information: Port Cable Number Type GIGE 1000LX GIGE 1000LX Copyright © 2010, Juniper Networks, Inc.
Page 929 1 pic-slot 1 lcc 0 lcc0-re0: fpc-slot pic-slot lcc -------------------------------------------------------------------------- (TX Matrix Router) PIC fpc slot 1 pic slot 1 information: Type 4x OC-3 SONET, SMIR ASIC type D chip State Online Copyright © 2010, Juniper Networks, Inc.
Page 930 Type 4x CHOC3 SONET CE SFP CHOC3 SONET CE State Online SFP) PIC version CPU load average 1 percent Interrupt load average 0 percent Total DRAM size 128 MB Memory buffer utilization 99 percent Copyright © 2010, Juniper Networks, Inc.
Page 931 5 pic-slot 0 PIC fpc slot 5 pic slot 0 information: fpc-slot pic-slot (OTN) Type 1x10GE(LAN),OTN ASIC type H chip State Online PIC version Uptime 5 minutes, 50 seconds Copyright © 2010, Juniper Networks, Inc.
Page 932 —(Systems with multiple Routing Engines) (Optional) Display information for an slot individual Routing Engine. Replace with 0 or 1. slot Required Privilege view Level Related request chassis routing-engine master on page 240 Documentation Copyright © 2010, Juniper Networks, Inc.
Page 933: Table 138: Show Chassis Routing-Engine Output Fields
(Systems with multiple Routing Engines) Identification number of the Routing Engine in this slot. Serial ID Time at which the Routing Engine started running. Start time How long the Routing Engine has been running. Uptime Copyright © 2010, Juniper Networks, Inc.
Page 934 25 degrees C / 77 degrees F Router) DRAM 768 MB Memory utilization 21 percent CPU utilization: User 0 percent Background 0 percent Kernel 0 percent Interrupt 0 percent Idle 100 percent Model RE-2.0 Copyright © 2010, Juniper Networks, Inc.
Page 935 DRAM 768 MB Memory utilization 21 percent CPU utilization: User 0 percent Background 0 percent Kernel 0 percent Interrupt 0 percent Idle 100 percent Model RE-2.0 Serial ID 31000007349bf701 Start time 2003-12-04 09:42:17 PST Copyright © 2010, Juniper Networks, Inc.
Page 936 0 percent Kernel 0 percent Interrupt 0 percent Idle 100 percent Model RE-A-1000 Serial ID 1000621151 Start time 2006-10-31 17:10:04 PST Uptime 14 minutes, 30 seconds Last reboot reason Router rebooted after a normal shutdown Copyright © 2010, Juniper Networks, Inc.
Page 937 Interrupt 0 percent Idle 100 percent Model RE-S-2000 Serial ID 1000703522 Start time 2007-12-19 10:35:40 PST Uptime 16 days, 3 hours, 15 minutes, 23 seconds Last reboot reason Router rebooted after a normal shutdown Copyright © 2010, Juniper Networks, Inc.
Page 938 34 degrees C / 93 degrees F CPU temperature 33 degrees C / 91 degrees F DRAM 2048 MB Memory utilization 12 percent CPU utilization: User 0 percent Background 0 percent Kernel 2 percent Interrupt 0 percent Copyright © 2010, Juniper Networks, Inc.
Page 939 Router rebooted after a normal shutdown Load averages: 1 minute 5 minute 15 minute 0.01 0.01 show chassis user@host> show chassis routing-engine 0 lcc 0 lcc0-re0: routing-engine lcc (TX -------------------------------------------------------------------------------- Matrix Router) Routing Engine status: Copyright © 2010, Juniper Networks, Inc.
Page 940 Router rebooted after a normal shutdown. Load averages: 1 minute 5 minute 15 minute 0.00 0.00 0.00 Routing Engine status: Slot 1: Current state Backup Election priority Backup (default) Temperature 29 degrees C / 84 degrees F Copyright © 2010, Juniper Networks, Inc.
Page 941 Interrupt 0 percent Idle 100 percent Model RE-TXP-LCC Serial ID 737F-1024 Start time 2009-05-06 17:31:32 PDT Uptime 5 days, 3 hours, 54 minutes, 19 seconds Last reboot reason Router rebooted after a normal shutdown. Copyright © 2010, Juniper Networks, Inc.
Page 942 Last reboot reason Router rebooted after a normal shutdown. show chassis user@host> show chassis routing-engine bios sfc0-re0: routing-engine bios -------------------------------------------------------------------------- (TX Matrix Plus Routing Engine BIOS Version: V0.0.Z Router) lcc0-re0: -------------------------------------------------------------------------- Routing Engine BIOS Version: V0.0.N Copyright © 2010, Juniper Networks, Inc.
Page 943: Table 139: Show Chassis Temperature-Thresholds Output Fields
Routing Engines, FPCs, and FEBs. If per FRU per slot thresholds are not configured, the components about which information is displayed include the chassis and the Routing Engines. Copyright © 2010, Juniper Networks, Inc.
Page 944 (TX Matrix Plus Fan speed Yellow alarm Red alarm Router) Item Normal High Normal Bad fan Normal Bad fan Chassis default Routing Engine 0 Routing Engine 1 SIB F13 0 SIB F13 1 SIB F13 3 Copyright © 2010, Juniper Networks, Inc.
Page 945 Item Normal High Normal Bad fan Normal Bad fan Chassis default Routing Engine 0 Routing Engine 1 FPC 4 FPC 6 FPC 7 SIB 0 SIB 1 SIB 2 SIB 3 SIB 4 lcc2-re0: Copyright © 2010, Juniper Networks, Inc.
Page 946 (TX Matrix Plus Fan speed Yellow alarm Red alarm Router) Item Normal High Normal Bad fan Normal Bad fan Chassis default Routing Engine 0 Routing Engine 1 SIB F13 0 SIB F13 1 SIB F13 3 Copyright © 2010, Juniper Networks, Inc.
Page 948: Show Log
1056301 Sep 30 10:50 rpd.5 -rw-r--r-- 1 root 1056350 Sep 30 07:04 rpd.6 -rw-r--r-- 1 root 1048876 Sep 30 03:21 rpd.7 -rw-rw-r-- 1 root 19656 Oct 1 19:37 wtmp show log filename user@host> show log rpd Copyright © 2010, Juniper Networks, Inc.
Page 949 1 18:53 - 18:58 (00:04) root mg1575 Wed Sep 30 18:39 - 18:41 (00:02) root ttyp2 jun.site.per Wed Sep 30 18:39 - 18:41 (00:02) alex ttyp1 192.168.1.2 Wed Sep 30 01:03 - 01:22 (00:19) Copyright © 2010, Juniper Networks, Inc.
Page 950 Required Privilege admin Level List of Sample Output show pfe next-hop on page 855 show pfe next-hop fpc (TX Matrix Router) on page 855 show pfe next-hop fpc (TX Matrix Plus Router) on page 855 Copyright © 2010, Juniper Networks, Inc.
Page 951 Next Hop Addr Protocol Encap ----- -------- ------------- --------------- ---------- ------------ ---- Mcast default IPv4 Bcast IPv4 Discard IPv4 MDiscard IPv4 Reject IPv4 Mcast default IPv6 Discard IPv6 MDiscard IPv6 Reject IPv6 Receive MPLS Discard MPLS Copyright © 2010, Juniper Networks, Inc.
Page 952 IPv4 Ethernet Receive ge-31/0/4.0 14.1.1.0 IPv4 Ethernet Local 14.1.1.1 IPv4 Resolve ge-31/0/4.0 IPv4 Ethernet Unicast ge-31/0/4.0 14.1.1.2 IPv4 Ethernet Unicast ge-15/0/3.0 14.2.1.2 IPv4 Ethernet Bcast ae1.0 IPv4 Ethernet Receive ae1.0 11.1.1.0 IPv4 Ethernet Copyright © 2010, Juniper Networks, Inc.
Page 953 Unicast ge-23/0/8.0 11.1.1.2 IPv4 Ethernet Unicast ge-7/0/9.0 11.1.1.2 IPv4 Ethernet Aggreg. ae1.0 MPLS Ethernet Unicast ge-23/0/8.0 MPLS Ethernet Unicast ge-7/0/9.0 MPLS Ethernet Aggreg. ae1.0 MPLS Ethernet Unicast ge-23/0/8.0 MPLS Ethernet Unicast ge-7/0/9.0 MPLS Ethernet Copyright © 2010, Juniper Networks, Inc.
Page 954 . For example, the following commands slot have the same result: user@host> show pfe route fpc 1 lcc 1 user@host> show pfe route fpc 9 —(Optional) Display Packet Forwarding Engine IPv6 routes. inet6 Copyright © 2010, Juniper Networks, Inc.
Page 955 224.0.0.1 Mcast 255.255.255.255 Bcast show pfe route iso user@host# show pfe route iso CLNS Route Table 0, CLNP.0, 0x0: Destination Type NH ID Interface ---------------------------------------- -------- ----- --------- default Reject 47.0005.80ff.f800.0000.0108.0001.0102.5508.2159/152 Local 49.0001.00a0.c96b.c491/72 Local Copyright © 2010, Juniper Networks, Inc.
Page 956 Default Slot 16 IPv4 Route Tables: Index Routes Size(b) -------- ---------- ---------- Default 2938 MPLS Route Tables: Index Routes Size(b) -------- ---------- ---------- Default IPV6 Route Tables: Index Routes Size(b) -------- ---------- ---------- Default Copyright © 2010, Juniper Networks, Inc.
Page 957 MPLS Route Tables: Index Routes Size(b) -------- ---------- ---------- Default IPv6 Route Tables: Index Routes Size(b) -------- ---------- ---------- Default 1305 1833 Slot 6 IPv4 Route Tables: Index Routes Size(b) -------- ---------- ---------- Default 2266 Copyright © 2010, Juniper Networks, Inc.
Page 958 Complete Software Guide for Junos OS for EX Series Ethernet Switches, Release 10.3 1371 1187 MPLS Route Tables: Index Routes Size(b) -------- ---------- ---------- Default IPv6 Route Tables: Index Routes Size(b) -------- ---------- ---------- Default 1305 1833 Copyright © 2010, Juniper Networks, Inc.
Page 959 Matrix Plus Router) -------------------------------------------------------------------------- Slot Type Slot State Uptime Present Online 2d 05:26 lcc0-re0: -------------------------------------------------------------------------- Slot Type Slot State Uptime GFPC Present Online 2d 05:25 GFPC Present Online 2d 05:25 Copyright © 2010, Juniper Networks, Inc.
Page 960 Complete Software Guide for Junos OS for EX Series Ethernet Switches, Release 10.3 show pfe terse sfc (TX user@host> show pfe terse sfc 0 sfc0-re0: Matrix Plus Router) -------------------------------------------------------------------------- Slot Type Slot State Uptime Present Online 2d 05:25 Copyright © 2010, Juniper Networks, Inc.
Page 961: Show System Alarms
2 alarms currently active Alarm time Class Description 2005-02-24 17:29:34 UTC Minor IPsec VPN tunneling usage requires a license 2005-02-24 17:29:34 UTC Minor Rescue configuration is not sent Copyright © 2010, Juniper Networks, Inc.
Page 962: Show System Audit
(or line-card chassis) that is connected to the TX Matrix Plus router. Replace with a value from through number —(EX4200 switches only) (Optional) Display file system MD5 hash and permissions local information on the local Virtual Chassis member. Copyright © 2010, Juniper Networks, Inc.
Page 963 \ md5digest=f414e06fea6bd646244b98e13d6e6226 .kernel.jkernel.backup \ mode=0744 size=1934552 time=944688902.0 \ md5digest=2c343cf0bd9fea8f04f78604feed7aa4 .profile uid=3 gid=7 mode=0644 nlink=2 size=173 time=939182975.0 \ md5digest=55a1e3c6c67789c9d3a1cce1ea39f670 COPYRIGHT uid=3 gid=7 mode=0444 size=3425 time=939182975.0 \ md5digest=7df8bc77dcee71382ea73eb0ec6a9243 boot.config mode=0644 size=3 time=945902618.0 \ Copyright © 2010, Juniper Networks, Inc.
Page 964 /set type=file uid=0 gid=0 mode=0700 nlink=1 flags=none type=dir mode=0755 nlink=2 size=512 time=1089843059.0 type=link size=28 time=1090266270.0 \ link=/packages/mnt/jbase/bin/test type=link size=27 time=1090266270.0 \ link=/packages/mnt/jbase/bin/cat chmod type=link size=29 time=1090266270.0 \ link=/packages/mnt/jbase/bin/chmod type=link size=26 time=1090266270.0 \ link=/packages/mnt/jbase/bin/cp type=link size=27 time=1090266270.0 \ link=/packages/mnt/jbase/bin/csh Copyright © 2010, Juniper Networks, Inc.
Page 965 # ./bin # ./boot /set type=file uid=0 gid=0 mode=0444 nlink=1 flags=none boot type=dir mode=0555 nlink=3 size=512 time=1095069935.0 boot0 size=512 time=1094978286.0 \ md5digest=6f780822dd4ae482a20462b66e542cca boot1 mode=0555 size=512 time=1094978294.0 \ md5digest=8d112b09df342cd0b60fdb9bdcde8e07 boot2 mode=0555 size=7680 time=1094978294.0 \ md5digest=28eb58c4068c6b85717e1484f9e028e4 Copyright © 2010, Juniper Networks, Inc.
Page 966 \ link=/packages/mnt/jbase/bin/cat chflags type=link size=31 time=1242346941.0 \ link=/packages/mnt/jbase/bin/chflags chmod type=link size=29 time=1242346941.0 \ link=/packages/mnt/jbase/bin/chmod type=link size=26 time=1242346941.0 \ link=/packages/mnt/jbase/bin/cp type=link size=27 time=1242346941.0 \ link=/packages/mnt/jbase/bin/csh date type=link size=28 time=1242346941.0 \ link=/packages/mnt/jbase/bin/date Copyright © 2010, Juniper Networks, Inc.
Page 967 \ link=/packages/mnt/jbase/bin/sh sleep type=link size=29 time=1242346942.0 \ link=/packages/mnt/jbase/bin/sleep stty type=link size=28 time=1242346942.0 \ link=/packages/mnt/jbase/bin/stty sync type=link size=28 time=1242346942.0 \ link=/packages/mnt/jbase/bin/sync tcsh type=link size=27 time=1242346941.0 \ link=/packages/mnt/jbase/bin/csh test type=link size=28 time=1242346942.0 \ link=/packages/mnt/jbase/bin/test # ./bin Copyright © 2010, Juniper Networks, Inc.
Page 968: Show System Buffers
—(EX4200 switches only) (Optional) Show buffer statistics for the local Virtual local Chassis member. member member-id —(EX4200 switches only) (Optional) Show buffer statistics for the specified member of the Virtual Chassis configuration. Replace with a member-id value from 0 through 9. Copyright © 2010, Juniper Networks, Inc.
Page 969 (TX Matrix Plus Router) on page 875 Output Fields Table 140 on page 874 describes the output fields for the command. show system buffers Output fields are listed in the approximate order in which they appear. Copyright © 2010, Juniper Networks, Inc.
Page 970: Table 140: Show System Buffers Output Fields
384 mbufs allocated to fxp data 784/944 mbuf clusters in use 1994 Kbytes allocated to network (83% in use) 0 requests for memory denied 0 requests for memory delayed 0 calls to protocol drain routines Copyright © 2010, Juniper Networks, Inc.
Page 971 0 calls to protocol drain routines lcc0-re0: -------------------------------------------------------------------------- 772/2558/3330 mbufs in use (current/cache/total) 772/598/1370/30000 mbuf clusters in use (current/cache/total/max) 768/512 mbuf+clusters out of packet secondary zone in use (current/cache) 0/0/0/0 4k (page size) jumbo clusters in use (current/cache/total/max) Copyright © 2010, Juniper Networks, Inc.
Page 972 0/0/0 requests for mbufs denied (mbufs/clusters/mbuf+clusters) 0/0/0 requests for jumbo clusters denied (4k/9k/16k) 0/4/1024 sfbufs in use (current/peak/max) 0 requests for sfbufs denied 0 requests for sfbufs delayed 0 requests for I/O initiated by sendfile Copyright © 2010, Juniper Networks, Inc.
Page 973: Show System Connections
T640 routers (or line-card chassis) connected to the TX Matrix router. On a TX Matrix Plus router, display system connection activity for all T1600 routers (or line-card chassis) connected to the TX Matrix Plus router Copyright © 2010, Juniper Networks, Inc.
Page 974 (TX Matrix Plus Router) on page 887 Output Fields Table 141 on page 879 describes the output fields for the show system connections command. Output fields are listed in the approximate order in which they appear. Copyright © 2010, Juniper Networks, Inc.
Page 975: Table 141: Show System Connections Output Fields
*.79 LISTEN tcp 00 *.1023 LISTEN tcp 00 *.111 LISTEN udp00192.168.4.16.1634 208.197.169.249.2049 udp00192.168.4.16.1627 208.197.169.254.2049 udp00192.168.4.16.1371 208.197.169.195.2049 udp00*.* udp00*.9999 udp00 *.161 udp00192.168.4.16.1039 192.168.4.16.1023 udp00192.168.4.16.1038 192.168.4.16.1023 udp 00 192.168.4.16.1037 192.168.4.16.1023 udp00192.168.4.16.1036 192.168.4.16.1023 udp00*.1022 udp00*.1023 udp00*.111 udp00*.* Copyright © 2010, Juniper Networks, Inc.
Page 976 192.168.66.130.23 ESTABLISHED tcp4 192.168.66.131.2496 192.168.66.130.23 ESTABLISHED tcp4 *.3221 LISTEN tcp4 *.23 LISTEN tcp4 *.22 LISTEN tcp4 *.514 LISTEN tcp4 *.513 LISTEN tcp4 *.21 LISTEN tcp4 *.79 LISTEN tcp4 *.6234 LISTEN udp4 *.514 udp4 *.6333 Copyright © 2010, Juniper Networks, Inc.
Page 977 *.38 __juniper_private1__ LISTEN tcp4 *.3221 default LISTEN show system user@host> show system connections sfc0-re0: connections (TX Matrix -------------------------------------------------------------------------- Plus Router) Active Internet connections (including servers) Proto Recv-Q Send-Q Local Address Foreign Address (state) Copyright © 2010, Juniper Networks, Inc.
Page 978 *.6152 LISTEN tcp4 *.32003 LISTEN tcp4 *.33009 LISTEN tcp4 *.3221 LISTEN tcp4 *.23 LISTEN tcp4 *.22 LISTEN tcp4 *.514 LISTEN tcp4 *.513 LISTEN tcp4 *.21 LISTEN tcp4 *.79 LISTEN tcp4 *.514 LISTEN tcp4 *.513 Copyright © 2010, Juniper Networks, Inc.
Page 979 LISTEN tcp4 *.3221 LISTEN tcp4 *.23 LISTEN tcp4 *.22 LISTEN tcp4 *.514 LISTEN tcp4 *.513 LISTEN tcp4 *.21 LISTEN tcp4 *.79 LISTEN tcp4 *.514 LISTEN tcp4 *.513 LISTEN udp46 *.514 udp4 *.514 udp46 *.59924 Copyright © 2010, Juniper Networks, Inc.
Page 980 *.161 udp4 *.6333 lcc2-re0: -------------------------------------------------------------------------- Active Internet connections (including servers) Proto Recv-Q Send-Q Local Address Foreign Address (state) tcp4 *.6234 LISTEN tcp4 *.7000 LISTEN tcp4 *.9000 LISTEN tcp4 *.33009 LISTEN tcp4 *.3221 LISTEN Copyright © 2010, Juniper Networks, Inc.
Page 981 192.168.178.11.23 192.168.69.199.51255 ESTABLISHED tcp4 192.168.178.11.23 172.24.26.227.42860 ESTABLISHED tcp4 162.0.0.4.32012 162.0.0.5.58935 ESTABLISHED tcp4 *.32012 LISTEN tcp4 *.33007 LISTEN tcp4 1432 162.0.0.4.6161 162.0.0.5.62026 ESTABLISHED tcp4 *.33005 LISTEN tcp4 162.0.0.4.9000 162.0.0.4.51611 FIN_WAIT_2 tcp4 162.0.0.4.51611 162.0.0.4.9000 CLOSE_WAIT Copyright © 2010, Juniper Networks, Inc.
Page 982 *.123 udp46 *.514 udp4 *.514 udp46 *.50895 udp4 *.50794 udp4 *.31342 udp46 *.161 udp4 *.161 udp4 *.31340 udp4 *.31340 udp46 *.49152 udp46 *.4784 udp46 *.3784 udp4 *.49152 udp4 *.4784 udp4 *.3784 udp4 *.6333 Copyright © 2010, Juniper Networks, Inc.
Page 983 *.6152 __juniper_private1__ LISTEN tcp4 *.32003 __juniper_private2__ LISTEN tcp4 *.33009 __juniper_private2__ LISTEN tcp4 *.3221 default LISTEN tcp4 *.23 default LISTEN tcp4 *.22 default LISTEN tcp4 *.514 default LISTEN tcp4 *.513 default LISTEN tcp4 *.21 Copyright © 2010, Juniper Networks, Inc.
Page 984 *.4784 default udp4 *.3784 default udp4 *.6333 __juniper_private1__ default default default lcc0-re0: -------------------------------------------------------------------------- Active Internet connections (including servers) (including routing-instances) Proto Recv-Q Send-Q Local Address Foreign Address Routing Instance (state) tcp4 *.7000 __juniper_private1__ LISTEN Copyright © 2010, Juniper Networks, Inc.
Page 985 Proto Recv-Q Send-Q Local Address Foreign Address Routing Instance (state) tcp4 *.7000 __juniper_private1__ LISTEN tcp4 *.6234 __juniper_private1__ LISTEN tcp4 *.9000 __juniper_private1__ LISTEN tcp4 *.3221 default LISTEN tcp4 *.23 default LISTEN tcp4 *.22 default LISTEN tcp4 *.514 Copyright © 2010, Juniper Networks, Inc.
Page 986 LISTEN tcp4 *.23 default LISTEN tcp4 *.22 default LISTEN tcp4 *.514 default LISTEN tcp4 *.513 default LISTEN tcp4 *.21 default LISTEN tcp4 *.79 default LISTEN tcp4 *.514 __juniper_private1__ LISTEN tcp4 *.513 __juniper_private1__ LISTEN Copyright © 2010, Juniper Networks, Inc.
Page 987 LISTEN tcp4 *.79 default LISTEN tcp4 *.514 __juniper_private1__ LISTEN tcp4 *.513 __juniper_private1__ LISTEN udp46 *.514 default udp4 *.514 default udp46 *.62103 default udp4 *.59924 default udp4 *.31342 __juniper_private1__ udp46 *.161 default udp4 *.161 Copyright © 2010, Juniper Networks, Inc.
Page 989: Show System Core-Dumps
Matrix router, display core dump files for all T640 routers (or line-card chassis) or a specific T640 router connected to the TX Matrix router. On a TX Matrix Plus router, display logging information about all T1600 routers (or line-card chassis) or a specific Copyright © 2010, Juniper Networks, Inc.
Page 990: Table 142: Show System Core-Dumps Output Fields
Links Number of links to the file. Owner Name of the file owner. Name of the group with file access. Group File size in bytes. File size Last file modification date and time. Modified Copyright © 2010, Juniper Networks, Inc.
Page 991 -------------------------------------------------------------------------- /var/crash/kernel.*: No such file or directory /tftpboot/corefiles/*core*: No such file or directory /var/crash/cores: total 8 /var/tmp/cores: total 12 lcc1-re0: -------------------------------------------------------------------------- /var/crash/kernel.*: No such file or directory /tftpboot/corefiles/*core*: No such file or directory /var/crash/cores: Copyright © 2010, Juniper Networks, Inc.
Page 992 427277312 May 7 04:47 core-LCC2-STFPC4.core.0.090507.0447 -rw-r--r-- 1 root wheel 419609600 May 7 04:47 core-LCC2-STFPC5.core.0.090507.0447 -rw-r--r-- 1 root wheel 432356352 May 7 04:47 core-LCC2-STFPC6.core.0.090507.0447 /var/tmp/cores: total 2568 -rw-r--r-- 1 root field 1290240 May 14 14:26 ksyncd_1540.core.0.090514.1426 Copyright © 2010, Juniper Networks, Inc.
Page 993: Show System Directory-Usage
T640 router that is connected to the TX Matrix router. On a TX Matrix Plus router, display directory information for a specific T1600 router that is connected to the TX Matrix Plus router. Replace number with a value from through Copyright © 2010, Juniper Networks, Inc.
Page 994 Output fields are listed in the approximate order in which they appear. Table 143: show system directory-usage Output Fields Field Name Field Description Number of bytes used by files in a directory. bytes directory-name Name of the directory. Copyright © 2010, Juniper Networks, Inc.
Page 995 /var/tmp/instmp.6fqHf3/packages /var/tmp/instmp.mljECe 4.6M /var/tmp/instmp.mljECe/packages show system user@host> show system directory-usage /var/tmp sfc 0 sfc0-re0: directory-usage sfc -------------------------------------------------------------------------- (TX Matrix Plus /var/tmp Router) /var/tmp/gres-tp /var/tmp/sec-download 2.0K /var/tmp/sec-download/sub-download 2.0K /var/tmp/vi.recover 2.0K /var/tmp/install 795M /var/tmp/cores 766K /var/tmp/pr440594 Copyright © 2010, Juniper Networks, Inc.
Page 996: Show System Processes
T1600 routers (or line-card chassis) connected to the TX Matrix Plus router. —(EX4200 switches only) (Optional) Display standard system process all-members information for all members of the Virtual Chassis configuration. Copyright © 2010, Juniper Networks, Inc.
Page 997 (TX Matrix Plus Router) on page 906 show system processes sfc (TX Matrix Plus Router) on page 913 show system processes lcc wide (TX Matrix Plus Routing Matrix) on page 916 Copyright © 2010, Juniper Networks, Inc.
Page 998: Table 144: Show System Processes Output Fields
—The process requested first-in, first-out (FIFO) page replacement. —The process is a session leader. —The process is temporarily suspended. —The process is swapped out. —The process is being traced or debugged. User identifier. detail Copyright © 2010, Juniper Networks, Inc.
Page 999 STAT TIME COMMAND processes processes 0:00.70 (swapper) 0:00.35 /sbin/init -- 0:00.00 (pagedaemon) 0:00.00 (vmdaemon) 0:42.37 (update) 0:00.00 (if_jnx) 0:14.66 syslogd -s 0:00.01 portmap 0:02.70 cron 0:02.24 /usr/local/sbin/sshd (sshd1) 0:03.80 /sbin/watchdog -t180 0:00.03 /usr/sbin/tnetd -N Copyright © 2010, Juniper Networks, Inc.
Page 1000 Mem: 25M Active, 3968K Inact, 19M Wired, 8346K Buf, 202M Free Swap: 528M Total, 64K Used, 528M Free PID USERNAME PRI NICE SIZE RES STATE TIME WCPU CPU COMMAND 544 root 604K 768K RUN 0:00 0.00% 0.00% top Copyright © 2010, Juniper Networks, Inc.

Juniper JUNOS OS 10.3 - SOFTWARE Manual

Quick Links

Chapters

Troubleshooting

Related Manuals for Juniper JUNOS OS 10.3 - SOFTWARE

Summary of Contents for Juniper JUNOS OS 10.3 - SOFTWARE
