Factory Five Racing Mk4 Roadster Assembly Manual page 7

Gauge Pod Installation ................................................................ 219
Ignition and Turn signal stalk ...................................................... 221
Trunk Aluminum .......................................................................... 222
Battery Mounting and Cable ........................................................ 225
Drivetrain Preparation ................................................................. 232
Aftermarket TKO 500 and TKO 600 prep ............................................ 232
99-04 Transmission mount ................................................................. 233
87-93 Alternate Drive Pulley ............................................................... 234
87-95 Oil Filter Relocator ................................................................... 236
96-04 A/C Eliminator Kit ..................................................................... 238
96-04 Oil Pan ..................................................................................... 242
Engine/Transmission Installation ................................................ 244
Transmission Mount .................................................................... 247
Driveshaft .................................................................................... 248
87-95 Oil Filter Relocator ............................................................ 250
Headers and J-pipes ................................................................... 251
Fuel Lines to engine .................................................................... 253
96-04 Connections ............................................................................. 253
96-04 Hydro-booster and Power Steering lines .......................... 254
Power Steering Oil Cooler (If applicable) .................................... 258
1996-1999 Version ............................................................................. 258
2000-2004 Version ............................................................................. 259
Clutch Cable ............................................................................... 261
Speedometer Sending Unit ......................................................... 262
Accelerator Cable........................................................................ 263
Fuel Injected application..................................................................... 264
Carbureted applications ..................................................................... 267
Intake hose and Air Filter ............................................................ 268
Mass air meter ............................................................................ 269
89-93 Mounting .................................................................................. 269
94-04 Mounting .................................................................................. 269
Fuel Vapor Canister .................................................................... 270
87-95 Mounting .................................................................................. 271
96-04 Mounting .................................................................................. 272
Cooling System ........................................................................... 272
87-93 Fan Mounting ........................................................................... 272
94-04 Mounting .................................................................................. 274
Radiator Mounting .............................................................................. 274
96-04 additional steps ........................................................................ 275
