Menu Keys

CONDITIONS key: ...Press CONDITIONS to change the pen conditions shown on
HOLD key: ...............Press HOLD to temporarily suspend cutting or plotting. While
MENU key: ..............Press MENU to access the MENU mode. When this key is
COPY key: ...............Press COPY to repeat the cutting operation defined by the
HOME/VIEW key: .....Press HOME/VIEW to move the pen carriage to the standby
NEXT key: ...............When the FC7000 is in MENU mode, press NEXT to move to
TEST key: ...............Press TEST to run a cutting test to check whether the cur-
AXIS/R.M.S. key: .....Press AXIS/R.M.S. to initiate automatic reading of the regis-
ORIGIN key: ............Press ORIGIN to move the origin point. To reset the FC7000,
ENTER key: .............Press ENTER to register your setting after setting a function.
the FC7000 display panel.
the cutting or plotting operation is suspended, the media set
lever can be lowered to enable skewed media to be reset if
necessary.
pressed, the MENU mode is accessed and the green LED
lights. Press it again to cancel MENU mode. The green LED
goes out. Use this key to set the various menu functions. If
data is received after the MENU key has been pressed, that
data is temporarily stored in the plotter's buffer.
data in the plotter's buffer.
position. Press it again to move the pen carriage to the origin
point. Press it one more time to return the pen carriage to its
former position.
the next menu page.
rently-selected cutting conditions are compatible with the
media loaded.
tration marks. If Off has been selected for the registration
mark mode, this key is used to perform axis alignment.
press ORIGIN and ENTER together when the initial MENU
mode screen is displayed.
To reset the FC7000, press ENTER and ORIGIN together
when the INITIAL MENU mode screen is displayed. The cut-
ting area can also be displayed by pressing the ENTER key
in Ready status.
P re p a r i n g t o C u t : C o n tr o l P a n e l
3 - 3
