6.2 Setting AUTO PRE FEED

When the AUTO PRE-FEED function is set to "ON," the loaded media is
automatically fed forward and backward by the preset length when data is
received. This operation leaves traces of the grit rollers on the media and prevents
it from slipping during a cutting or plotting operation. Similarly, if roll media is
used, the media is automatically pulled out by the plotter.
This setting can be made at the INITIAL MENU screen, or at the FUNCTION 2
menu screen.
M
1
2
3
4
5
6
7
8
9
AKING THE SETTING AT THE
Lower the media set lever. The following menu appears.
Press the F4 key (INITIAL MENU). The following INITIAL MENU screen
appears.
Press the F2 key (AUTO PRE FEED). The following menu appears.
The asterisk "*" indicates the currently selected setting. Press the F3 key
(ENABLED) to select AUTO PRE FEED. Press the F4 key (DISABLED) if you
do not wish to use the AUTO PRE FEED function.
Press the ENTER key to register your settings.
If ON was selected, the following FEED LENGTH setting menu appears.
Use the ( ) POSITION keys to increase or decrease the value within the
range of 1 to 50 (m).
Press the ENTER key to register your settings.
Press the NEXT key to return to Step 1 and load the media.
A DV AN C E D F U N C T I O N S A ND O P E R A T I O NS : S e t t i n g A UT O P R E F E E D
INITIAL MENU
SCREEN
LOAD MEDIA!
INITIAL MENU>
AUTO REG. MARK>
AUTO PRE FEED>
INITIAL FEED SPEED>
INTERFACE>
AUTO PRE FEED
ENABLED
DISABLED*
AUTO PRE FEED
FEED LENGTH = 1 m
6-3
