9-2
9.1 Using the Condition List Mode
CAUTION: The pen carriage starts moving as soon as the CONDITION PRINT function is
1
2
3
4
5
6
7
T E S T M O DE S A ND T RO U B L E S H O O T I N G : Us i n g t h e C o n d i t i o n L i s t M o d e
This function prints a list of the current plotter settings.
selected. Do not place your hands or other objects on any moving parts.
S
P
ETTING
ROCEDURE
Load paper larger than either ISO (A3) or Tabloid size (11" x 17") in the plotter,
and mount a plotting pen.
Press the MENU key.
Press the NEXT key until the following menu appears.
Press the F4 key (OPTION 2). The following menu appears.
Press the F4 key (TEST). The following menu appears.
Press the F2 key (CONDITION LIST). The following menu appears.
If a pen has not been mounted, mount a pen and then specify the conditions
for that pen. Press the F3 key to select DONE and start printing the
CONDITION LIST. If you do not wish to print the list, press the F4 key.
PEN UP/DOWN
BACKGROUND SETTINGS>
OPTION 1>
OPTION 2>
INITIAL DOWN FORCE>
DISTANCE ADJUST>
TEST>
CONDITION LIST>
SELF TEST>
DATA DUMP>
MOUNT THE PEN!
DONE>
CANCEL CONDITIONS>
