CUTTING PLOTTER
FC8600-60/75/100/130/160
SERVICE MANUAL
FC8600-UM-251-07-9370

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FC8600-60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GRAPHTEC FC8600-60

Summary of Contents for GRAPHTEC FC8600-60

  • Page 1 CUTTING PLOTTER FC8600-60/75/100/130/160 SERVICE MANUAL FC8600-UM-251-07-9370...
  • Page 3 Parts number of Drive Pulley Assy was corrected. 9-10 14.8.27 Parts number of Center Covers were corrected. 14.8.27 Quantity of Push Roller Positioning Label S for the FC8600-60 and FC8600-75 were corrected. 9-14 14.8.27 The rank of labels were changed to C rank except I/F labels. 9-14 14.11.18...
  • Page 4 FC8600-UM-251-9370...

  • Page 5: Table Of Contents

    CONTENTS INTRODUCTION .................1-1 Main Specifications .......................1-1 1.2 External Dimensions ......................1-2 PARTS NAMES and FUNCTIONS ..........2-1 Parts Names and Functions ....................2-1 2.2 Assembling ..........................2-3 2.3 Attaching a Tool ........................2-8 2.4 Replacing the Cross-Cutter Unit ..................2-11 OPERATIONS ................3-1 Control Panel .........................
  • Page 6 6.2.4 How to Replace the Control Panel Board and the LCD ..............6-12 6.2.5 How to Replace the Pen Block ......................6-13 6.2.6 How to Replace the Y-belt ........................6-15 6.2.7 How to Replace the Pinch Roller Sensor ....................6-17 6.2.8 How to Replace the Y-relay Board.......................6-19 6.2.9 How to Replace the Cam Sensor ......................
  • Page 7 7.3.13 Adjusting the Spacing Between Pen 1 and Pen 2 (2-pen model) .............7-36 7.3.14 Adjusting the Tool 2 and the Cross Cutter Threshold (2-pen model) ..........7-40 Upgrading the System Firmware ..................7-42 TROUBLESHOOTING ............... 8-1 The Plotter is Turned On But Doesn’t Operate ..............8-1 8.2 Media Loading Operations ....................
  • Page 8 9.11 Media Stocker, Stand ................9-15 9.12 Basket ...........................9-16 9.13 Other Parts ...........................9-16 10 BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS ....10-1 10.1 Block Diagrams ........................10-1 10.2 Circuit Diagrams ......................... 10-2 10.2.1 Main Board (CPU)..........................10-2 10.2.2 Main Board (CONNECTOR) ......................... 10-3 10.2.3 Main Board (MOTOR DRIVER) ......................10-4 10.2.4 Main Board (FPGA) ..........................

  • Page 9: Introduction

    46 kg 54 kg 59 kg *1 When the optional basket and Graphtec-specified media are used. *2 HP-GL is a registered trademark of Hewlett-Packard Company. *3 The PPA32-TP12 pouncing pen cannot be used. *4 The CB15UA cutter blade and a reinforced backing sheet must be used when cutting high-intensity reflective film.

  • Page 10: External Dimensions

    INTRODUCTION External Dimensions 1162 FC8600-60: 1128 FC8600-75: 1278 FC8600-100: 1578 FC8600-130: 1878 FC8600-160: 2138 Units: mm Dimensional accuracy: ±5 mm FC8600-UM-251-9370...

  • Page 11: Parts Names And Functions

    PARTS NAMES and FUNCTIONS PARTS NAMES and FUNCTIONS Parts Names and Functions Front View Push roller Cross cutter unit Power switch Tool carriage Tool holder Grit roller position guide Push roller Cutting mat Control panel Cutting groove Rail Grit roller Media sensor Stand Pen station...
  • Page 12 PARTS NAMES and FUNCTIONS Rear View Push roller hold-down force switching lever AC line inlet Media stocker Stock rollers Media set lever Media lock USB interface RS-232C interface Network interface (Factory-installed option) Media set lever: �������������� Used to raise or lower the pinch rollers during the loading or unloading of media� Pinch roller hold-down force switching lever: ����������������������������������������...

  • Page 13: Assembling

    PARTS NAMES and FUNCTIONS Assembling Assemble the stand� Stand side bar x 2 Base assembly x 2 Center bar x 1 Allen wrench Socket head cap screw (for M5 screws) x 1 (M5) x 20 Media stocker x 2 Stock roller x 2 Front Loading and Rear Loading It is necessary to set the loading settings from the plotter control panel depending on the attachment direction�...
  • Page 14 PARTS NAMES and FUNCTIONS Assembly (1) Assemble the left and right stand sides� Fasten a base assembly to each of the stand side bars with four socket head cap screws using the Allen wrench� Socket head cap screw Base assembly Stand side bar Stand side bar (2) Loosely fasten the center bar to the left and right stand sides with four socket head cap screws (two on...
  • Page 15 PARTS NAMES and FUNCTIONS (4) Mount the plotter on the stand by inserting the positioning pins on the stand into the positioning holes on the underside of the plotter� Fasten with four socket head cap screws (two on each side), using the Allen wrench�...
  • Page 16 PARTS NAMES and FUNCTIONS Attaching the Basket The basket is attached directly to the plotter� The basket is made up of the following parts� Basket x 1, basket tubes (long) x 3, basket tubes (short) x 4, joints x 4, mounts x 2, socket cap head screws x 4, use Allen wrench to assemble the basket�...
  • Page 17 PARTS NAMES and FUNCTIONS (2) Insert 2 basket tubes (short) into the mount from the side without the cap� Assemble 2 sets as shown below� Basket tube (short) Mount (3) Connect the basket tubes (short) to the joints inserted on the basket tubes (long) at the end of the basket attached in step 1�...

  • Page 18: Attaching A Tool

    PARTS NAMES and FUNCTIONS Attaching a Tool Attach a tool (cutter pen, plotter pen) to the plotter� Attaching a Tool When mounting the tool in the tool holder, push the tool all the way into the holder until its flange contacts the upper part of the holder and then tighten the screw firmly.
  • Page 19 PARTS NAMES and FUNCTIONS Attaching a Pen to the Two-Pen Holder (Option) The two-pen holder is a factory-installed option, and cannot be retrofitted. (1) Loosen the pen holder screw� (2) While pushing the pen holder in the upward direction, push the pen all the way into the holder until its flange contacts the upper part of the holder.
  • Page 20 PARTS NAMES and FUNCTIONS Attaching a Plotting Pen to the Pen Station (1) Open the pen-hold mechanism on the pen station, and then attach a pen� (2) Make sure that the bracket of the pen station is engaged in the upper groove of the pen� (3) Close the pen-hold mechanism on the pen station to hold the pen in place�...

  • Page 21: Replacing The Cross-Cutter Unit

    PARTS NAMES and FUNCTIONS Replacing the Cross-Cutter Unit Follow the procedure below to replace the cross-cutter unit that is used to cut the media after the plotting or cutting operation has been completed� (1) Check that the power switch is turned off (the “O“ side is pressed down)� Remove the screw holding the cross-cutter unit in place, and then remove the cross-cutter unit�...

  • Page 22: Operations

    OPERATIONS OPERATIONS Control Panel This section explains the function of lamps and keys on the control panel. USER1 lamp USER2 lamp [1] key [2] key CROSS CUT [MENU] key MENU lamp [STOP] key [ORIGIN] key [COPY] key Screen (LCD) [3] key [4] key [FAST] key POSITION...
  • Page 23 OPERATIONS Indicator Lamps MENU lamp ....Green lamp is lit while in MENU mode. USER 1, 2 lamp ....The lamp for selected user will lit. The lamp is lit when the user priority is set to “Key, Controller”. It will flash when it is set to “Key only”.

  • Page 24: Reading The Screen (Lcd)

    OPERATIONS Reading the Screen (LCD) Information reflecting the status will be displayed in the screen of the control panel. Name of the button and corresponding function is displayed on the screen when a function is allocated to the button on the control panel. Button name will be displayed in reverse when the button is enabled. Following items are displayed in the default screen.
  • Page 25 OPERATIONS Icon of the corresponding operation button is displayed in the screen to change the setting values. Increase or decrease the setting Select the setting by value using POSITION (pq) key. number keys (1, 2, 3, 4) or Select the change unit by [FAST] POSITION (pqtu) keys.
  • Page 26 OPERATIONS Menu tree Default Screen CONDITION Setting Screen 1/3 CONDITION Setting Screen 2/3 CONDITION Setting Screen 3/3 MENU Screen TOOLS SETTING Screen TOOLS SETTING Screen Continued TOOLS SETTING Screen 3/3 FC8600-UM-251-9370...
  • Page 27 OPERATIONS Default Screen (Continued) TOOLS SETTING Screen 2/3 MENU Screen TOOLS SETTING Screen ARMS SETTING Screen ARMS SETTING Screen ARMS SETTING Screen ARMS SETTING Screen Continued FC8600-UM-251-9370...
  • Page 28 OPERATIONS Default Screen (Continued) MENU Screen AREA PARAMETERS Screen 1/2 AREA PARAMETERS Screen 2/2 MEDIA SETTING Screen 1/3 MEDIA SETTING Screen 2/3 MEDIA SETTING Screen 3/3 INTERFACE Setting Screen 1/3 INTERFACE Setting Screen 2/3 INTERFACE Setting Screen 3/3 Continued FC8600-UM-251-9370...
  • Page 29 OPERATIONS Default Screen (Continued) MENU Screen ADVANCE Setting Screen 1/3 ADVANCE Setting Screen 2/3 ADVANCE Setting Screen 3/3 TEST Screen FC8600-UM-251-9370...

  • Page 30: Recommended Parts List

    792800707 LAN Board 692140322 Flexible Printed Cable, FFC707102 Control Panel 20P 692140330 Y Flexible Printed Cable, FPC707103, 60/75 – – – FC8600-60/75 692140340 Y Flexible Printed Cable, FPC707105 – – – – FC8600-100 692140350 Y Flexible Printed Cable, FPC707105 –...

  • Page 31: List Of Tools

    LIST OF TOOLS LIST OF TOOLS Tools Adjustment Item Tool 1 Pen force adjustment Cutter Pen Holder (CB09) Colex gauge (50,300,500 gf) 2 Distance adjustment Glass scale 3 Pen block height adjustment 10 mm height block 4 Firmware update PC, USB I/F cable 5 X-drive belt tension adjustment Push-pull gauge (2 kg) 6 Y-drive belt tension adjustment...

  • Page 33: Disassembly And Reassembly

    DISASSEMBLY AND REASSEMBLY DISASSEMBLY AND REASSEMBLY Exterior Parts 6.1.1 How to Replace the Right Side Cover How to detach the right side cover (1) Remove the four M4L6 binding head screws from the right side cover. (2) Detach the right side cover. Left side cover M4L6 binding head screw How to reinstall the right side cover...

  • Page 34: How To Replace The Left Side Cover

    DISASSEMBLY AND REASSEMBLY 6.1.2 How to Replace the Left Side Cover How to detach the left side cover (1) Remove the four M4L6 binding head screws from the left side cover. (2) Detach the left side cover. Right side cover M4L6 binding head screw How to reinstall the left side cover (1) Reattach the left cover in the reverse order in which it was detached.

  • Page 35: How To Replace The Control Panel Assembly

    DISASSEMBLY AND REASSEMBLY 6.1.3 How to Replace the Control Panel Assembly How to detach the control panel assembly (1) Detach the right side cover (see Subsection 6.1.1). (2) Remove the three M3L6 binding head screws holding the control panel assembly from the top of the center cover.

  • Page 36: How To Replace The Center Cover

    DISASSEMBLY AND REASSEMBLY 6.1.4 How to Replace the Center Cover How to detach the center cover (1) Detach the right side cover (see Subsection 6.1.1). (2) Detach the control panel assembly (see Subsection 6.1.3). (3) Remove the six M3L6 binding head screws holdong the center cover. M3L6 binding head screw Center cover (4) Detach the center cover.

  • Page 37: How To Replace The Front Guide

    How to Replace the Front Guide How to detach the front guide (1) Remove the four M3L6 binding head screws from the front guide for the FC8600-60/75. (Remove the five M3L6 binding head screws from the front guide for the FC8600-100.

  • Page 38: How To Replace The Rear Guide

    How to Replace the Rear Guide How to detach the rear guide (1) Remove the four M3L6 binding head screws from the rear guide for the FC8600-60/75. (Remove the five M3L6 binding head screws from the rear guide for the FC8600-100.

  • Page 39: How To Replace The Rear Writing Panel

    DISASSEMBLY AND REASSEMBLY 6.1.7 How to Replace the Rear Writing Panel How to detach the rear writing panel (1) Detach the rear guide (see Subsection 6.1.6). (2) Remove the M3L6 binding head screw from the top of the rear writing panel. (3) Remove the five M3L6 binding head screws from the rear of the rear writing panel for the FC8600- 60/75.

  • Page 40: How To Replace The Front Writing Panel Assembly

    160.) (4) Loosen the five M3L6 binding head screws at the top of the front writing panel assembly for the FC8600-60/75. (Loosen the six M3L6 binding head screws at the top of the front writing panel assembly for the FC8600-100.

  • Page 41: Mechanical Parts

    DISASSEMBLY AND REASSEMBLY Mechanical Parts 6.2.1 How to Replace the Rear Media Sensor How to detach the rear media sensor (1) Detach the rear guide (see Subsection 6.1.6). (2) Remove the M3L10 binding head screw attaching the rear media sensor. (3) Disconnect the sensor from the connector.

  • Page 42: How To Replace The Front Media Sensor

    DISASSEMBLY AND REASSEMBLY 6.2.2 How to Replace the Front Media Sensor How to detach the front media sensor (1) Detach the front writing panel (see Subsection 6.1.8). (2) Remove the M3L6 binding head screw attaching the front media sensor bracket. M3L6 binding head screw Front media sensor bracket Front media sensor...

  • Page 43: How To Replace The Pinch Roller

    DISASSEMBLY AND REASSEMBLY 6.2.3 How to Replace the Pinch Roller How to detach the pinch roller (1) Detach the right side of the E-ring from the pinch roller shaft. E-ring Pinch roller shaft Pinch roller (2) Detach the pinch roller shaft from the pinch roller arm from the left side. (3) Detach the pinch roller.

  • Page 44: How To Replace The Control Panel Board And The Lcd

    DISASSEMBLY AND REASSEMBLY 6.2.4 How to Replace the Control Panel Board and the LCD How to detach the control panel board ant the LCD (1) Detach the control panel assembly (see Subsection 6.1.3). (2) Detach the control panel board from the control panel cover assembly. Release the hooks holding the control panel board, and then detach the control panel board from the control panel cover.

  • Page 45: How To Replace The Pen Block

    DISASSEMBLY AND REASSEMBLY 6.2.5 How to Replace the Pen Block How to detach the pen block (1) Detach the right side cover (see Subsection 6.1.1). (2) Detach the center cover (see Subsection 6.1.4). (3) Loosen the two M3L6 binding head screws attaching the pen block cover. M3L6 binding head screw (4) Detach the pen block cover.
  • Page 46 DISASSEMBLY AND REASSEMBLY How to reinstall the pen block (1) Attach the pen block to the Y-slider. (2) Fasten the two M4L6 binding head screws to attach the pen block so that there is a gap of 10 mm between the bottom of the pen block and the cutting mat. Perform a visual check to make sure that the pen block is not mounted at an angle.

  • Page 47: How To Replace The Y-Belt

    DISASSEMBLY AND REASSEMBLY 6.2.6 How to Replace the Y-belt How to detach the Y-belt (1) Detach the right and left side covers (see Subsection 6.1.1 and Subsection 6.1.2). (2) Detach the center cover (see Subsection 6.1.4). (3) Detach the pen block (see Subsection 6.2.5). (4) Loosen the two M3L35 binding head screws adjusting the Y-belt tension.
  • Page 48 DISASSEMBLY AND REASSEMBLY How to reinstall the Y-belt (1) Shave 2 to 3 mm off both ends of the Y-belt until the wire comes out as shown below. Y-belt Shave 2 to 3 mm off both ends of the Y-belt until the wire comes out. (2) Hang the Y-belt on both sides of the pulley.

  • Page 49: How To Replace The Pinch Roller Sensor

    DISASSEMBLY AND REASSEMBLY 6.2.7 How to Replace the Pinch Roller Sensor How to detach the pinch roller sensor (1) Detach the center cover (see Subsection 6.1.4). (2) Detach the pen block (see Subsection 6.2.5). (3) Disconnect the pinch roller flexible cable from the Y-relay board. (4) Remove the pinch roller flexible cable that is attached with double-sided adhesive tape to the Y-slider.
  • Page 50 DISASSEMBLY AND REASSEMBLY How to reinstall the pinch roller sensor (1) Attach the pinch roller bracket to the pinch roller sensor board. (2) Connect the pinch roller flexible cable to the pinch roller sensor board. (3) Attach the pinch roller sensor guard to the pinch roller sensor board bracket. (4) Attach the pinch roller bracket to the Y-slider.

  • Page 51: How To Replace The Y-Relay Board

    DISASSEMBLY AND REASSEMBLY 6.2.8 How to Replace the Y-relay Board How to detach the Y-relay board (1) Detach the center cover (see Subsection 6.1.4). (2) Remove the two plastic rivets attaching the flexible cable holding plate. Plastic rivet Flexible cable holding plate (3) Disconnect all the cables from the Y-relay board.

  • Page 52: How To Replace The Cam Sensor

    DISASSEMBLY AND REASSEMBLY 6.2.9 How to Replace the Cam Sensor How to detach the cam sensor (1) Detach the right side cover (see Subsection 6.1.1). (2) Disconnect the cable from the cam sensor. Cam sensor M3L6 binding head screw (3) Remove the M3L6 binding head screw attaching the cam sensor. How to reinstall the cam sensor (1) Reattach the cam sensor in the reverse order in which it was detached.

  • Page 53: How To Replace The Y-Motor

    DISASSEMBLY AND REASSEMBLY 6.2.10 How to Replace the Y-motor How to detach the Y-motor (1) Detach the right side cover (see Subsection 6.1.1). (2) Disconnect the Y-motor cables from connector J7 and J13 on the main board. (3) Loosen the two M3L4WP set screws to detach the Y-motor pulley. M3L6 binding head screw Y motor pulley Y motor...

  • Page 54: How To Replace The X-Motor

    DISASSEMBLY AND REASSEMBLY 6.2.11 How to Replace the X-motor How to detach the X-motor (1) Detach the right side cover (see Subsection 6.1.1). (2) Detach the main board (see Subsection 6.2.12). (3) Loosen the two M3L4WP set screws holding the X-motor pulley, then detach the X-motor pulley. M3L6 binding head screw M3L4WP set screw X motor pulley...

  • Page 55: How To Replace The Main Board

    DISASSEMBLY AND REASSEMBLY 6.2.12 How to Replace the Main Board How to detach the main board (1) Detach the right side cover (see Subsection 6.1.1). (2) Disconnect all the cables and flexible cables from their connectors on the main board. (3) Remove the four M3L6 binding head screws holding the main board to the chassis.

  • Page 56: How To Replace The Vacuum Fan

    DISASSEMBLY AND REASSEMBLY 6.2.13 How to Replace the Vacuum Fan How to detach the vacuum fan (1) Detach the front guide (see Subsection 6.1.5). (2) Disconnect the vacuum fan from the relay connector. Vacuum fan Relay connector (3) Use a long screwdriver to remove the two M3L35 binding head screws holding the vacuum fan as shown in the figure below.

  • Page 57: How To Replace The Drive Roller

    DISASSEMBLY AND REASSEMBLY 6.2.14 How to Replace the Drive Roller How to detach the drive roller (1) Detach the right and left side covers (see Subsection 6.1.1). (2) Detach the front guide and rear guide (see Subsection 6.1.5 and Subsection 6.1.6). (3) Detach the rear and front writing panels (see Subsection 6.1.7 and Subsection 6.1.8).
  • Page 58 DISASSEMBLY AND REASSEMBLY How to reinstall the drive roller (1) Reattach in the reverse order in which it was detached. (2) Spread a suitable quantity of Loctite 222 on the two M3L4WP set screws holding the X-drive pulley. (3) Perform the X-drive belt tension adjustment (see Subsection 7.2.3). (4) Spread a suitable quantity of the Shinetu silicon grease G501 on the X-motor pulley.

  • Page 59: How To Replace The Cutting Mat

    DISASSEMBLY AND REASSEMBLY 6.2.15 How to Replace the Cutting Mat How to detach the cutting mat (1) Peel off the cutting mat from the cutting mat base. How to reinstall the cutting mat (1) Clean the surface of the cutting mat base with alcohol where the cutting mat was attached. (2) Attach the new cutting mat to the cutting mat base.

  • Page 60: Home Dog Position

    DISASSEMBLY AND REASSEMBLY 6.2.16 Home Dog Position Home dog position Adjust the home dog position when you remove or replace the dog as shown below. If you have an error about the pinch roller position, confirm position of this dog. 115 mm Home position dog 6.2.17 Cross Cutter Dog Position...

  • Page 61: Adjustments

    ADJUSTMENT ADJUSTMENTS List of Items Requiring Readjustment If you replaced any of the units listed in the table below or altered their sensor positions, be sure to readjust the corresponding items. Auto Unit name Light Pinch roller X,Y Motor registration Main board Pen block X,Y motor Drive roller...

  • Page 62: Mechanical Adjustments

    (3) Move the Y-slider all the way to the right and pull the belt 20 mm towards the center using a force gauge. Adjust the Y-tension pulley adjustment screws evenly until the tension reads as follows: Specification of the Belt Tension Model Force gauge reading specification FC8600-60 700 g+50 FC8600-75 700 g+50 FC8600-100...

  • Page 63: Y-Drive Belt Tension Adjustment

    ADJUSTMENT 7.2.2 Y-Drive Belt Tension Adjustment How to adjust the Y-Drive belt tension (1) Detach the right side cover (see Subsection 6.1.1). (2) Loosen the four M3L6 binding head screws that hold the Y-motor. (3) Use the force gauge to pull the Y-drive motor pulley flange with a 2.25 kg force. (4) Tighten the four M3L6 binding head screws that hold the Y-motor. (5) Spread a suitable quantity of the Shinetu silicon grease G501 on the Y-motor pulley.

  • Page 64: X-Drive Belt Tension Adjustment

    ADJUSTMENT 7.2.3 X-Drive Belt Tension Adjustment How to adjust the X-Drive belt tension (1) Detach the right side cover (see Subsection 6.1.1). (2) Loosen the three M3L6 binding head screws that hold the X-motor. (3) Use the force gauge to push the X-drive motor pulley flange with a 800 g force as shown in the figure below. M3L6 binding head screw (4) Tighten the mounting screws that hold the X-motor.

  • Page 65: Pinch Roller Pressure Adjustment

    Hang the wire to the push roller shaft. (4) The push roller force should be 6.5 kg +-0.25 kg (5) Adjust the push roller force at locatin shown in the picture below. Adjusting position for each push rollers FC8600-60 FC8600-75 FC8600-100 FC8600-130...
  • Page 66 ADJUSTMENT How to adjust the right side and the left side push roller of push roller force (1) Move the pinch roller to the specified adjustment position. (2) Move the position for other push rollers from the grid roller which you are not going to adjust for the push rollers now.
  • Page 67 ADJUSTMENT (6) Spread the screw-lock-glue (1401B) to the adjustment screw after the push roller force was adjusted. (7) Tighten the screw (upper screw) holding the force adjustment bracket as shown in the picture below. Tighten this screw. (8) Set the push roller force lever to the lower position for the high force. (9) Loosen the screw (Lower screw) holding the bracket as shown in the picture below.
  • Page 68 ADJUSTMENT (11) Tighten the screw (Lower screw) holding the bracket as shown in the picture below. Tighten this screw. FC8600-UM-251-9370...
  • Page 69 ADJUSTMENT How to adjust the middle push roller of push roller force (1) Move the pinch roller to the specified adjustment position. (2) Move the position for other push rollers from the grid roller which you are not going to adjust for the push rollers now. The other push rollers should not be positioned on the grid roller. (3) Set the push roller force lever to the lower position for the high force.
  • Page 70 ADJUSTMENT (7) Tighten the screw (upper screw) holding the force adjustment bracket as shown in the picture below. Tighten this screw. (8) Set the push roller force lever to the upper position for the low force. (9) Loosen the screw (Lower screw) holding the bracket as shown in the picture below. Loosen this screw.
  • Page 71 ADJUSTMENT (10) Loosen the lower position adjustment screw, and then gently tighten the lower position adjustment screw until the screw hit to the inside of parts. Don’t tighten this screw strongly. Top part of the bracket will be bent if you tighten this screw strongly. Lower position adjustment screw (11) Confirm there is no gap between the top of tension and the bottom of tension bracket.
  • Page 72 ADJUSTMENT (13) Tighten the screw (Lower screw) holding the bracket as shown in the picture below. Tighten this screw. FC8600-UM-251-9370 7-12...

  • Page 73: Electrical Adjustments

    DIP Switch Settings The black circles indicate the position of each switch. Factory presets (Normal Mode) FC8600-60 FC8600-60 (2-Pen Model) 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 FC8600-75 FC8600-75 (2-Pen Model)
  • Page 74 ADJUSTMENT NOV-RAM Clear FC8600-60 1 2 3 4 5 6 7 8 FC8600-75 1 2 3 4 5 6 7 8 FC8600-100 1 2 3 4 5 6 7 8 FC8600-130 1 2 3 4 5 6 7 8 FC8600-160...

  • Page 75: Explanation Of The Values Of The Main Board Settings

    ADJUSTMENT 7.3.2 Explanation of the Values of the Main Board Settings (Default factory settings) The default factory settings are recorded in the location shown below. The default factory settings are recorded here. The contents of an example record are shown below. X= 0 X= 80 X= - Y= 4...

  • Page 76: Clearing The Non-Volatile Ram

    Input the adjustment values to the main board after you clear the Non-Volatile RAM. How to clear the Non-Volatile RAM. (1) Set SW1 to the NOV-RAM clear mode as shown below. FC8600-60 1 2 3 4 5 6 7 8 FC8600-75...
  • Page 77 ADJUSTMENT (6) Return the SW1 setting to the normal mode as shown below. FC8600-60 FC8600-60 (2-Pen Model) 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 FC8600-75 FC8600-75 (2-Pen Model) 1 2 3 4 5 6 7 8...

  • Page 78: How To Enter The Adjustment Menu

    ADJUSTMENT 7.3.4 How to Enter the Adjustment Menu (1) Turn on the power while pressing the FAST and ENTER keys. After turning on the power, press the FAST key and the ENTER key simultaneously within 2 seconds. (2) Load a sheet of paper in the plotter. (3) The plotter displays the menu shown below.
  • Page 79 ADJUSTMENT Adjustment Menu List Sensor & Key test. Pen pressure adjustment. Gain adjustment. (Not used.) Push roller number setting 1 and 2 pen position adjustment for the 2-pen model. Distance adjustment. 2-pen exchange adjustment for the 2-pen model. Registration mark sensor level adjustment. Registration mark sensor position adjustment.

  • Page 80: Adjusting The Pen Force

    ADJUSTMENT 7.3.5 Adjusting the Pen Force This adjustment will set the pen force. If you replace the main board, use the following procedure to input the recorded adjustment values. If you replace the moving coil and/or the pen block assembly, you must adjust the pen force using the following procedure.
  • Page 81 ADJUSTMENT (7) Adjust the 40g-pen force. If the measured value is within the specification range (40±4g) or if you have input the recorded value, press the ENTER key to store the setting. The next specified pen force appears. (8) Adjust the 120g-pen force. If the measured value is within the specification range (120±10g) or if you have input the recorded value, press the ENTER key to store the setting. The next specified pen force appears. (9) Adjust the 300g-pen force. If the measured value is within the specification range (300±20g) or if you have input the recorded value, press the ENTER key to store the setting. The next specified pen force appears. (10) Adjust the 400 g-pen force. If the measured value is within the specification range or if you have input the recorded value, press the ENTER key to store the setting. Note: When adjusting the pen force, it is important to do it quickly. Delaying the pen force adjustment changes the temperature of the actuator and causes artificially lower readings. When this happens the actual pen force may be higher than the specification. This is especially true for the upper pen force adjustment.

  • Page 82: Adjusting The Distance Accuracy

    ADJUSTMENT 7.3.6 Adjusting the Distance Accuracy This adjustment will set the distance accuracy. If you replace the main board, use the following procedure to input the recorded adjustment values. If you replace the drive roller, you must adjust the distance accuracy using the following procedure. How to adjust the distance accuracy (1) Enter the adjustment menu (see Section 7.3.4).
  • Page 83 ADJUSTMENT (10) Press the F1 key (DRAW PATTERN) to start to draw the adjustmen pattern. The plotter immediately plots the adjustment pattern, and the following menu appears. X=300 mm Y=300 mm Carriage moving direction (11) Remove the paper and measure the X -axis distance, Y-axis distance and the diagonal distance. If you have replaced the main board only, use the recorded values.
  • Page 84 ADJUSTMENT Press the left arrow key to display the menu shown below. (13) Press the F4 key to display the menu shown below if the Y-axis or Y-axis value is changed from the recorded values, and then input the value of the diagonal distance (XY=) which was measured. (14) Press the left arrow key to display the menu shown below.

  • Page 85: Adjusting The Registration Mark Sensor Sensitivity

    ADJUSTMENT 7.3.7 Adjusting the Registration Mark Sensor Sensitivity If you replace the main board, you need to adjust the sensitivity. How to adjust the registration mark sensor sensitivity (1) Enter the adjustment menu (see Section 7.3.4). (2) Load an A2 or larger size sheet of paper in the plotter. The paper color must be white, and it is recommended that high-quality paper made for ink-jet printers be used.

  • Page 86: Adjusting The Offset Of The Auto-Registration Mark Sensor

    ADJUSTMENT 7.3.8 Adjusting the Offset of the Auto-Registration Mark Sensor If you replace the Auto-registration mark sensor or the main board, you need to adjust the offset. How to adjust the auto-registration mark sensor (1) Enter the adjustment menu (see Section 7.3.4). (2) Load an A2 or larger size sheet of paper in the plotter.
  • Page 87 ADJUSTMENT (10) Press the F1 key to display the menu shown below. (11) Use the ARROW keys to move the pen to an open area to plot the adjustment pattern. (12) Use the ARROW keys to move the pen to an open area to plot the adjustment pattern. (13) Press the ENTER key to plot the adjustment pattern shown below.

  • Page 88: Adjusting The Cross Cutter Home Position

    ADJUSTMENT 7.3.9 Adjusting the Cross Cutter Home Position This adjustment will set the cross cutter home position value. If you replace the main board, use the following procedure to input the recorded adjustment values. How to adjust the cross cutter home position (1) Enter the adjustment menu (see Section 7.3.4).
  • Page 89 ADJUSTMENT (8) Adjust the gap to a value in the range of 0 mm to 0.2 mm. Press the UP or DOWN ARROW key to adjust the gap. Cross cutter release plate Cross cutter dog 0 to 0.2 mm (9) Press the left arrow key to display the menu shown below. (10) Press the F4 key to confirm the gap.

  • Page 90: Adjusting The Offset Of The Light Pointer Position

    ADJUSTMENT 7.3.10 Adjusting the Offset of the Light Pointer Position If you replace the light pointer or the main board, you need to adjust the offset. How to adjust the offset of the light pointer position (1) Enter the adjustment menu (see Section 7.3.4). (2) Load an A2 or larger size sheet of paper in the plotter.
  • Page 91 ADJUSTMENT (10) Use the POSITION keys to move the pen to an open area to plot the adjustment pattern. (11) Press the ENTER key to plot the adjustment pattern shown below. (12) Move the light pointer to the center of the adjustment pattern using the POSITION keys. (13) Press the ENTER key to register the position.

  • Page 92: Confirming The 2-Pen Model (2-Pen Model)

    ADJUSTMENT 7.3.11 Confirming the 2-Pen Model (2-pen model) This setting will confirm that the plotter is a 2-pen model. If you replace the main board, use the following procedure to make the 2-pen model setting. (1) Load an A2 or larger size sheet of paper in the plotter. (2) Enter the adjustment menu (see Section 7.3.4). (3) Press the Up or Down position key until the menu shown below is displayed.
  • Page 93 ADJUSTMENT (8) Confirm the DIP-switch 7 of SW1 is OFF if the 2-pen system. FC8600-60 (2-Pen Model) 1 2 3 4 5 6 7 8 FC8600-75 (2-Pen Model) 1 2 3 4 5 6 7 8 FC8600-100 (2-Pen Model) 1 2 3 4 5 6 7 8 FC8600-130 (2-Pen Model) 1 2 3 4 5 6 7 8...

  • Page 94: Adjusting The Pen Exchange Y Direction Value (2-Pen Model)

    ADJUSTMENT 7.3.12 Adjusting the Pen Exchange Y Direction Value (2-pen model) This adjustment will set the pen exchange Y direction value. This value is used for the 2nd pen exchange. If you replace the main board, use the following procedure to input the recorded adjustment values. (1) Confirm that the DIP switch 7 of SW1 is OFF. (2-pen model mode) (2) Enter the adjustment menu (see Section 7.3.4).
  • Page 95 ADJUSTMENT (9) Press the ENTER key when the gap became to 1.1 mm. This gap should be 1.1 mm. (10) Mount a fiber tip pen in the 2nd pen station. (11) Press the F4 key to confirm that the pen exchanging is performed correctly. (12) If the pen exchanging is performed correctly, press the ENTER key to store the setting and complete the adjustment.

  • Page 96: Adjusting The Spacing Between Pen 1 And Pen 2 (2-Pen Model)

    ADJUSTMENT 7.3.13 Adjusting the Spacing Between Pen 1 and Pen 2 (2-pen model) This adjustment will set the spacing between pen 1 and pen 2. If you replace the main board, use the following procedure to input the recorded adjustment values. If you replace the pen block, you must adjust this value using the following procedure.
  • Page 97 ADJUSTMENT (10) Press the F1 key to display the menu shown below. (11) Press the F2 key to select the TOOL 1-2. (12) Press the ENTER key to display the menu shown below. (13) Press the F2 key to display the menu shown below. (14) Use the ARROW keys to move the pen to an open area to plot the adjustment pattern.
  • Page 98 ADJUSTMENT (16) When they have been plotted, the menu shown below is displayed. (17) Measure the offset between the pen 1 cross mark and the pen 2 lines. (18) Press the F3 key to display the menu shown below. (19) Set the X-offset value. Press the UP ARROW key or DOWN ARROW key to change the number based on the pen 1 cross mark.
  • Page 99 ADJUSTMENT (24) Press the F2 key. Verify that the plotted pen 1 cross mark is located at the center of the plotted pen 2 lines. (25) If the plotted cross marks are in the correct positions, press the ENTER key to store the setting and complete the adjustment.

  • Page 100: Adjusting The Tool 2 And The Cross Cutter Threshold (2-Pen Model)

    ADJUSTMENT 7.3.14 Adjusting the Tool 2 and the Cross Cutter Threshold (2-pen model) This adjustment will set the Cross Cutter Threashold between pen 2 and Cross Cutter. If you replace the main board, use the following procedure to input the adjustment values. If you replace the pen block, you must adjust this value using the following procedure.
  • Page 101 ADJUSTMENT Input the reading value +10 to the THRESHOLD value of TOOL2. Press the [2] key. Press the POSITION ( ) key to increase or decrease the value to set. For Example: Input the 185 (= 175+10) to the Tool 2 threshold if the reading height value is 175. (9) Confirm the setting and press the POSITION [ ] key (PREVIOUS).

  • Page 102: Upgrading The System Firmware

    ADJUSTMENT Upgrading the System Firmware To upgrade the system firmware you need to have the following files. In addition, you need to use a computer and USB cable. • FC8600_V***.X :FC8600 firmware • SEND.EXE :Utility to transfer files using Windows ® • OPS662 :USB Driver software for the FC8600 Preparation Install the USB Driver software to your computer before upgrading the system firmware. How to upgrade the system firmware (1) Connect the computer and the plotter via the USB interface. (2) Load a sheet of paper in the plotter.
  • Page 103 ADJUSTMENT FC8600-UM-251-9370 7-43...

  • Page 104: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING The Plotter is Turned On But Doesn’t Operate Symptom Verification item Solution Both USER1 and USER2 (1) Is the plotter being supplied with No ..Check that the power cord is lamp on the control panel power? securely connected to the plotter’s does not light.

  • Page 105: Cutting Operations

    TROUBLESHOOTING Symptom Verification item Solution The plotter can’t (1) Is there any dust on the front Yes ..Clean the front media sensor and recognize the X direction media sensor and the rear the rear media sensor. of the media size. media sensor? No ..Verify item (2).

  • Page 106: Error Messages

    TROUBLESHOOTING Error Messages 8.4.1 Hardware Error Messages Error Error Display Cause Verification item Solution code E01001 Main board is Replace the main board. defective. E01005 E01006 E01007 E01008 E01009 E01010 E01011 E01012 E01013 FC8600-UM-251-9370...
  • Page 107 TROUBLESHOOTING Error Error Display Cause Verification item Solution code E01014 X or Y motor is Replace the X or Y defective. motor. Or the main board is Or replace the main defective. board. E01015 E01017 Load on the motor Check the madia. Do not use heavy was too large.
  • Page 108 TROUBLESHOOTING Error Error Display Cause Verification item Solution code E01018 Cutting conditions do Cutting conditions. Lower the cutting not suit the cutting SPEED and/or the medium. cutting FORCE. Movement of the Is there anything Turn off the plotter, pen carriage is being blocking the Y slider? remove the obstacle, obstructed.

  • Page 109: Error Messages In Gp-Gl Command Mode

    (3) Has the correct No ..Set the correct model name model name. been set for the Configure your software plotter? application menu to permit Graphtec plotter control. Re-specify the software application’s interface conditions. E02004 The software The numeric Configure your software...

  • Page 110: Error Messages In Hp-Gl Emulation Mode

    (3) Has the correct No ..Set the correct model name model name. been set for the Configure your software plotter? application menu to permit Graphtec plotter control. Re-specify the software application’s interface conditions. E03002 A command was Execute the Configure your software...
  • Page 111 TROUBLESHOOTING Error Error Display Cause Verification item Solution code E03006 The data being input Execute coordinates exceeds the capacity within the cutting area. of the plotter’s E03007 Coordinates of Adjust the buffer size. command specified out of cutting area. E03010 Other output Check the program.

  • Page 112: Error Messages On Arms

    TROUBLESHOOTING 8.4.4 Error Messages on ARMS Error Error Display Cause Solution code E04001 Tilt to adjust with AXIS Reload the media. ALIGNMENT is too large. E04003 Failed to adjust the sensor This media cannot be used. level. E04004 It is over the setting range of Reset to smaller value.
  • Page 113 TROUBLESHOOTING Error Error Display Cause Solution code E04013 It has exceeded detection area Check the media. Check the print while detecting the registration position of the registration mark. mark. E04014 E04015 E04016 E04017 E04018 Media set lever was lowered. Reload the media and try again. E04019 There was cancel operation by Redo the process.
  • Page 114 TROUBLESHOOTING Error Error Display Cause Solution code E04024 Registration mark was not Redo the sensor level adjustment. detected. Change the color of the registration mark. Check the media. E04025 Check the print position of the registration mark. FC8600-UM-251-9370 8-11...

  • Page 115: Other Error Messages

    TROUBLESHOOTING 8.4.5 Other Error Messages Error Error Display Cause Verification item Solution code E05001 Data larger than the Perform normal cutting buffer size cannot be not using the copy copied. mode. E05002 There is no data to Perform normal cutting copy.

  • Page 116: Warning Messages

    TROUBLESHOOTING 8.4.6 Warning Messages Error Error Display Cause Solution code W06001 Cross cut function cannot be Use roll media. used for sheet media. W06002 Cross cut function cannot be Load the media from the rear. used because the media is loaded from the front.

  • Page 117: Service Mode

    TROUBLESHOOTING Service mode 8.5.1 Sensor Test Mode & Panel Switch Test Mode This mode checks the sensor status and the control panel switch status. If there is a bad sensor you will observe one of the symptoms in the table below. Please check the relevant sensor(s).
  • Page 118 TROUBLESHOOTING (11) When testing is completed, turn off the power to the plotter. FC8600-UM-251-9370 8-15...

  • Page 119: Printing The Setting Of The Plotter

    TROUBLESHOOTING 8.5.2 Printing the Setting of the Plotter Condition setting list can be printed when you need to check the current setting of the plotter. Operation (1) Set a paper larger than A3 size. (2) Set the pen tool to the tool carriage and select the condition where the pen tool is set. (3) Press the [MENU] key to display the menu below.

  • Page 120: Printing The Test Pattern

    TROUBLESHOOTING 8.5.3 Printing the Test Pattern Print a self-test pattern to check the operation of the plotter. Operation (1) Set a paper larger than A3 size. (2) Set the pen tool to the tool carriage and select the condition where the pen tool is set. (3) Press the [MENU] key to display the menu below.

  • Page 121: Confirm The Cutting Data

    TROUBLESHOOTING 8.5.4 Confirm the Cutting Data Output of the dump list of the cutting data received by the plotter is possible. It is used to check if the transmission of cutting data is performed correctly. Operation (1) Set a media larger than A4 size. (2) Set the pen tool to the tool carriage and select the condition where the pen tool is set.

  • Page 122: Self Diagnostic Test

    TROUBLESHOOTING 8.5.5 Self Diagnostic Test Operation status can be tested by self diagnostic test by operating the sensors and switches following the instruction on the screen. Operation (1) Confirm that the power is turned off. (2) Turn the power on without loading the media. (3) Press the [MENU] key to display the menu below.

  • Page 123: Parts List

    Outer Casing Part No. Description Q’ty Remarks Rank 621404011 Right Side Cover 621404001 Left Side Cover 621632150 Center Cover 60 FC8600-60 621632250 Center Cover 75 FC8600-75/ 621632350 Center Cover 100 FC8600-100 621632450 Center Cover 130 FC8600-130 621632550 Center Cover 160...
  • Page 124 PARTS LIST Outer Casing FC8600-UM-251-9370...

  • Page 125: Control Panel

    PARTS LIST Control Panel Part No. Description Q’ty Remarks Rank 621632010 Cover, Control Panel, 86 621400062 Control Panel Sheet 621632020 Key Top, Cursor 86 621632050 Key Top, Function 86 621632030 Key Top, Right 86 621632040 Key Top, Left 86 792800790 Control Panel Board 86 682140133 LCD, JMS12864-15ABAYD...

  • Page 126: Pen Block

    PARTS LIST Pen Block Part No. Description Q’ty Remarks Rank 792219702 Pen Holder Assy 4200 For 2-pen model 621403032 Cutter Pen Holder 621353010 Thumb Screw L10 621403000 Pen Arm These parts are part of pen 621263230 Slide Shaft block assembly, replace 682126520 Moving Coil with Yoke (PM1306) 617363351...
  • Page 127 PARTS LIST Pen Block Pen Holder for 2-pen Model Pen Station for 2-pen Model FC8600-UM-251-9370...

  • Page 128: Registration Mark Sensor Assy

    PARTS LIST Registration Mark Sensor Assy Part No. Description Q’ty Remarks Rank 621403200 Spring, Cover Down 621263340 Spring, RMS Up Core, Solenoide 500052472 Solenoide 621263312 Bracket, RMS sensor 792800704 Registration Mark Sensor Board 621263331 Paper Hold Down B 621263322 Paper Hold Down A Registration Mark Sensor Assy FC8600-UM-251-9370...

  • Page 129: Cross Cutter

    PARTS LIST Cross Cutter Part No. Description Q’ty Remarks Rank 621403110 Bracket, Cross Cutter 621263453 Shaft, Cross Cutter 621263460 Latch, TL-294 621403120 Arm, Catch 621403100 Cross Cutter Base 380265331 Spring, E-533 621353010 Thumb Screw, L10 CT01H Cross Cutter Blade, Standard Type Consumption goods CT02U Cross Cutter Blade, High durability Type...

  • Page 130: Main Frame

    X Drive Roller Shaft 130 FC8600-130 621292011 X Drive Roller Shaft 160 FC8600-160 682132431 Motor, UGJMEE-A7JGR34 X Motor, FC8600-100/130/160 682126201 Motor, DMN37HE-003 X Motor, FC8600-60/75 561080004 Media Sensor, PS-117ED1 621260011 Pillow Block FC8600-60/FC8600-75 621260011 Pillow Block FC8600-100 621260011 Pillow Block...
  • Page 131 PARTS LIST Main Frame FC8600-UM-251-9370...

  • Page 132: Y Rail

    Y Drive Adjustment Plate 792800705 Cam Sensor Board, FC80 621260202 Y Home Dog 621400390 Cam Lever 621400380 Cam Lever Cap 621400400 Cam Shaft, 60 FC8600-60 621410400 Cam Shaft, 75 FC8600-75 621420400 Cam Shaft, 100 FC8600-100 621430310 Cam Shaft, 130 FC8600-130 621440310...
  • Page 133 PARTS LIST Part No. Description Q’ty Remarks Rank 692140330 Y Flexible Cable, FPC707103 FC8600-60/75 692140340 Y Flexible Cable, FPC707104 FC8600-100 692140350 Y Flexible Cable, FPC707105 FC8600-130 692140361 Y Flexible Cable, FPC707106 FC8600-160 621271250 Flexible Cable Reinforcement Strip Plate 100 FC8600-100...

  • Page 134: Y Slider

    PARTS LIST Y Slider Part No. Description Q’ty Remarks Rank 621173160 Pinch Roller Sensor Guard 792800703 Pinch Roller Sensor Board 621173150 Pinch Roller Sensor Bracket B 095013010 Slider Roller, BB13 621403300 Y Slider 621183410 Roller Tension Plate L 392330200 Spacer C320 For FC8600-130,160 only 792800702 Pen Relay Board...

  • Page 135: Wiring Harness

    Cable, CA707110 (Fan to Main Board) FC8600-100 692140110 Cable, CA707111 (Fan to Main Board) FC8600-130/160 692140011 Cable, CA707101A (Power Supply Switch to Main Board) FC8600-60/75 692140021 Cable, CA707102A (Power Supply Switch to Main Board) FC8600-100 692140031 Cable, CA707103A (Power Supply Switch to Main Board) FC8600-130...

  • Page 136: Labels

    Q’ty Remarks Rank 621404590 Emblem GRAPHTEC FC8600 621404450 Caution Label 621404460 Pinch Roller Pressure Label 621634060 Caution Label 86 621634160 Model Label FC8600-60 FC8600-60 621634260 Model Label FC8600-75 FC8600-75 621634360 Model Label FC8600-100 FC8600-100 621634460 Model Label FC8600-130 FC8600-130 621634560...

  • Page 137: Media Stocker, Stand

    Part No. Description Q’ty Remarks Rank 621269215 Right Media Stocker Bracket 621269225 Left Media Stocker Bracket 621400140 Center Bar 60 FC8600-60 621410140 Center Bar 75 FC8600-75 621420140 Center Bar 100 FC8600-100 621430140 Center Bar 130 FC8600-130 621440290 Center Bar 160...

  • Page 138: Basket

    PARTS LIST 9.12 Basket Part No. Description Q’ty Remarks Rank 772140920 Basket Assy, PG0039 FC8600-60 772141990 Basket Assy, PG0040 FC8600-75 772142990 Basket Assy, PG0041 FC8600-100 772143990 Basket Assy, PG0042 FC8600-130 772144990 Basket Assy, PG0043 FC8600-160 9.13 Other Parts Standard Accessories Part No.
  • Page 139 10 BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS 10 BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS 10.1 Block Diagrams FH12A-26S-0.5SH RESZ 20FMN-STRK-A 20FMZ-BT KEY0 KEY0 KEY1 KEY1 KEY2 KEY2 KEY3 KEY3 KEY4 KEY4 KEY5 KEY5 VOUT KEY6 KEY6 CAP3+ KEY7 KEY7 CAP1- CAP1+ HOLDZ HOLDZ CAP2+ MENUZ...

  • Page 140: Block Diagrams And Circuit Diagrams

    10 BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS 10.2 Circuit Diagrams 10.2.1 Main Board (CPU) FC8600-UM-251-9370 10-2...

  • Page 141: Main Board (Connector)

    10 BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS 10.2.2 Main Board (CONNECTOR) FC8600-UM-251-9370 10-3...

  • Page 142: Main Board (Motor Driver)

    10 BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS 10.2.3 Main Board (MOTOR DRIVER) FC8600-UM-251-9370 10-4...

  • Page 143: Main Board (Fpga)

    10 BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS 10.2.4 Main Board (FPGA) FC8600-UM-251-9370 10-5...

  • Page 144: Main Board (I/F)

    10 BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS 10.2.5 Main Board (I/F) FC8600-UM-251-9370 10-6...

  • Page 145: Main Board (Memory)

    10 BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS 10.2.6 Main Board (MEMORY) FC8600-UM-251-9370 10-7...

  • Page 146: Main Board (Power)

    10 BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS 10.2.7 Main Board (Power) FC8600-UM-251-9370 10-8...

  • Page 147: Lan Board

    10 BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS 10.2.8 LAN Board FC8600-UM-251-9370 10-9...

  • Page 148: Light Pointer

    10 BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS 10.2.9 Light Pointer FC8600-UM-251-9370 10-10...

  • Page 149: Pen Relay Board

    10 BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS 10.2.10 Pen Relay Board FC8600-UM-251-9370 10-11...

  • Page 150: Pinch Roller Sensor Board

    10 BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS 10.2.11 Pinch Roller Sensor Board 10.2.12 RMS Board RMS SENSOR BOARD FC8600-UM-251-9370 10-12...

  • Page 151: Control Panel Board

    10 BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS 10.2.13 Control Panel Board FC8600-UM-251-9370 10-13...

  • Page 152: Cam Sensor Board

    10 BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS 10.2.14 Cam Sensor Board FC8600-UM-251-9370 10-14...

This manual is also suitable for:

Fc8600-75Fc8600-100Fc8600-130Fc8600-160

Table of Contents

Save PDF
