The plotter is now ready to receive data for cutting or plotting. If the interface or
command settings have not been made, make these settings before sending the
data. If the settings have been made, pen adjustment is performed. When the pen
adjustments have been made, the plotter is ready to start cutting. Send the cutting
or plotting data from the application software.
P re p ar i n g t o C u t: S e l e c t i n g t h e M e d i a T yp e
After the media is detected, the following screens are displayed in succession.
"ROTATE" OFF
"MIRROR" ON
CONDITION 1
READY
↓
CUT AREA
X=*****mm Y=*****mm
↓
Pen
12
20
4
