multiple MIB objects. To view the current SNMP filters, use the show snmp filter command from the
CLI Exec mode.
Foundry AP(config)#snmp-server filter trapfilter include .1.3.6.1.2.1.2.2.1
Foundry AP(config)#snmp-server filter trapfilter exclude .1.3.6.1.2.1.2.2.1.1.23
Foundry AP(config)#exit
Foundry AP#show snmp filter
Filter: trapfilter
Type: include
Subtree: iso.3.6.1.2.1.2.2.1
Type: exclude
Subtree: iso.3.6.1.2.1.2.2.1.1.23
=============================
Foundry AP#
snmp-server filter
This command configures SNMP v3 notification filters. Use the no form to delete an SNMP v3 filter
or remove a subtree from a filter.
Syntax
snmp-server filter <filter-id> <include | exclude> <subtree> [mask {mask}]
no snmp-server filter <filter-id> [subtree]
• filter-id - A user-defined name that identifies an SNMP v3 notification filter. (Maximum length:
32 characters)
• include - Defines a filter type that includes objects in the MIB subtree.
• exclude - Defines a filter type that excludes objects in the MIB subtree.
• subtree - The part of the MIB subtree that is to be filtered.
• mask - An optional hexadecimal value bit mask to define objects in the MIB subtree.
Default Setting
None
Command Mode
Global Configuration
Command Usage
• The access point allows up to 10 notification filters to be created. Each filter can be defined by
up to 20 MIB subtree ID entries.
• Use the command more than once with the same filter ID to build a filter that includes or
exculdes multiple MIB objects.
• The MIB subtree must be defined in the form ".1.2.3.4" and always start with a ".".
• The mask is a hexadecimal value with each bit masking the corresponding ID in the MIB
subtree. A "1" in the mask indicates an exact match and a "0" indicates a "wild card." For
example, a mask value of 0xFFBF provides a bit mask "1111 1111 1011 1111." If applied to the
subtree 1.3.6.1.2.1.2.2.1.1.23, the zero corresponds to the 10th subtree ID. When there are
more subtree IDs than bits in the mask, the mask is padded with ones.
