Client Security
Combination
802.1x WPA only
WPA Pre-Shared Key
only
Static and dynamic
(802.1x) WEP keys
Dynamic WEP and
802.1x WPA
Static and dynamic
(802.1x) WEP keys and
802.1x WPA
802.1x WPA2 only
WPA2 Pre-Shared Key
only
802.1x WPA-WPA2
Mixed Mode
WPA-WPA2 Mixed Mode
Pre-Shared Key
1. The configuration summary does not include the set up for MAC authentication (see page
18-2) or RADIUS server (see page 15-1).
December 2006
1
Configuration Summary
VAP interface settings:
Authentication: 802.1x
Set 802.1x key refresh and reauthentication rates
Encryption: WPA-TKIP
VAP interface settings:
Authentication: Pre-Shared Key
Encryption: WPA-TKIP
WPA Pre-shared Key Type: Hexadicmal or
Alphanumeric
Enter a WPA Pre-shared key
Enter 1 to 4 WEP keys
Select a WEP transmit key
VAP interface settings:
Authentication Type: 802.1x and User Shared Key
Set 802.1x key refresh and reauthentication rates
Encryption: WEP
VAP interface, Advanced settings:
Authentication Type: WPA
802.1x: Required
Set 802.1x key refresh and reauthentication rates
Data Encryption: Enable
WPA Configuration: Supported
Cipher Suite: WEP
Enter 1 to 4 WEP keys
Select a WEP transmit key
VAP interface, Advanced settings:
Authentication Type: WPA
802.1x: Required
Set 802.1x key refresh and reauthentication rates
Data Encryption: Enable
WPA Configuration: Supported
Cipher Suite: WEP
VAP interface settings:
Authentication: 802.1x
Set 802.1x key refresh and reauthentication rates
Encryption: WPA2-AES CCMP
VAP interface settings:
Authentication: Pre-Shared Key
Encryption: WPA2-AES CCMP
WPA Pre-shared Key Type: Hexadicmal or
Alphanumeric
Enter a WPA Pre-shared key
VAP interface settings:
Authentication: 802.1x
Set 802.1x key refresh and reauthentication rates
Encryption: WPA2-AES CCMP and AES-TKIP
Mixed Mode
VAP interface settings:
Authentication: Pre-Shared Key
Encryption: WPA2-AES CCMP and AES-TKIP
Mixed Mode
WPA Pre-shared Key Type: Hexadicmal or
Alphanumeric
Enter a WPA Pre-shared key
© 2006 Foundry Networks, Inc.
Wireless Security Configuration
MAC RADIUS
2 Server
Authentication
Local only Yes
Local only No
Local, RADIUS, Yes
or Disabled
Local or Disabled Yes
Local or Disabled Yes
Local or Disabled Yes
Local or Disabled No
Local or Disabled Yes
Local or Disabled No
21-3
