Foundry IronPoint 200 User Guide
Default
No MAC addresses configured.
Command Mode
Global Configuration
Command Usage
• Up to 10 MAC address entries can be configured in the QoS MAC address table.
• Frames received with a MAC address not configured in the table are assigned to the default
priority level (zero).
qos ether-type
This command builds a table of Ethernet protocol types mapped to 802.1p priority levels. Use the no
form to remove an Ethernet type entry from the table.
Syntax
qos ether-type <type> <priority>
no qos ether-type <type>
• type - The Ethernet protocol type specified in hexadecimal format. (Range: 0000 - FFFF)
• priority - The 802.1p priority level assigned to the Ethernet protocol type. (Range: 0 - 7, where
7 is the highest priority)
Default
No Ethernet protocol types configured.
Command Mode
Global Configuration
Command Usage
• Up to 10 Ethernet type entries can be configured in the table.
• Frames received of an Ethernet type not configured in the table are assigned to the default
priority level (zero).

show qos

This command shows the current QoS configuration.
Command Mode
Exec

Using the Web Management Interface

From the main menu, click QoS. To configure the access point to support QoS, select a QoS mode
from the drop-down menu and, if appropriate, configure Ethernet types or MAC addresses in the
classification tables. Click Apply.
