Navigating the Settings Submenu

Keypad button presses are shown as
selections are shown as
This submenu allows you to select:
Measure, System Lock,
Parameters.

Selecting the Units of Measure

If your cabinet is equipped with an airflow sensor,
the units of measure can be set for
minute) or M/S (meters per second). Select the
appropriate units of measure, then [OK/Mute].

Activating the Security Lock

The Security Lock "locks" the keypad to prevent
unauthorized use of the cabinet. To enable / disable
select Protected / Unprotected, then [OK/MUTE].
When enabled, the keypad is locked immediately
after the blower is turned off. The security lock is
deactivated by holding
blower is not turned on within 5 minutes of unlocking,
the keypad will relock. The feature remains enabled
until it is disabled in this screen.

Setting the USB Output Rate

This menu option selects the rate that cabinet status
data is exported out of the mini USB port on the side
of the top electrical box. Data can output at a rate of
once per second, once per 10
seconds, or once per 60
appropriate selection, then [OK/MUTE].
[BLUE WITH
green italics.
Units of
Data Output, or UV
Units of Measure
System Lock
Data Output
FT/MIN
[DOWN] for three seconds. If
seconds, once per 30
seconds. Make the
48
BRACKETS]. Menu screen
(feet per
METRIC (M/S)
IMPERIAL (FT/MIN)
1 / SECOND
1 / 10 SECONDS
1 / 30 SECONDS
1 / 60 SECONDS
Figure 6-15
UV Parameters
Figure 6-16
Figure 6-17
PASSWORD
Figure 6-18
OUTPUT DATA
