Q
S
UALITY OF
ERVICE
set
This command services IP traffic by setting a CoS, DSCP, or IP
Precedence value in a matching packet (as specified by the match
command on page 32-4). Use the no form to remove the traffic
classification.
Syntax
[no] set {cos new-cos | ip dscp new-dscp | ip precedence new-precedence
| ipv6 dscp new-dscp}
• new-cos - New Class of Service (CoS) value. (Range: 0-7)
• new-dscp - New Differentiated Service Code Point (DSCP) value.
(Range: 0-63)
• new-precedence - New IP Precedence value. (Range: 0-7)
Default Setting
None
Command Mode
Policy Map Class Configuration
Example
This example creates a policy called "rd_policy," uses the class command
to specify the previously defined "rd_class," uses the set command to
classify the service that incoming packets will receive, and then uses the
police command to limit the average bandwidth to 100,000 Kbps, the
burst rate to 1522 bytes, and configure the response to drop any violating
packets.
Console(config)#policy-map rd_policy
Console(config-pmap)#class rd_class
Console(config-pmap-c)#set ip dscp 3
Console(config-pmap-c)#police 100000 1522 exceed-action drop
Console(config-pmap-c)#
32-8
C
OMMANDS
