Configuring An Ipv6 General Network Prefix - SMC Networks TigerStack II SMC8848M Management Manual

B M
ASIC ANAGEMENT
CLI – This example configures an IPv6 gateway, specifies the
management interface, configures a global unicast address, and then sets
the MTU.
Console#config
Console(config)ipv6 default-gateway 2009:DB9:2229::240
Console(config)#ipv6 general-prefix rd 2009:DB9:2229::/48
Console(config)#interface vlan 1
Console(config-if)#ipv6 address rd 7279::79/64
Console(config-if)#ipv6 mtu 1280
Console(config-if)#ipv6 enable
Console(config-if)#end
Console#show ipv6 default-gateway
ipv6 default gateway:
Console#show ipv6 interface
Vlan 1 is up
IPv6 is enable.
Link-local address:
FE80::200:E8FF:FE90:0/64
Global unicast address(es):
2009:DB9:2229::79, subnet is 2009:DB9:2229:0::/64
Joined group address(es):
FF01::1/16
FF02::1/16
FF02::1:FF00:79/104
FF02::1:FF90:0/104
MTU is 1280 bytes.
ND DAD is enabled, number of DAD attempts: 1.
ND retransmit interval is 1000 milliseconds
Console#show ipv6 mtu
MTU
1400
1280
Console#

Configuring an IPv6 General Network Prefix

The IPv6 General Prefix page is used to configure general prefixes that are
subsequently used on the IPv6 Configuration web page (see page 4-13) to
specify the network address portion of an interface address.
Command Usage
• Prefixes may contain zero-value fields or end in zeros.
• A general prefix holds a short prefix that indicates the high-order bits
used in the network portion of the address. Longer, more specific,
prefixes can be based on the general prefix to specify any number of
4-22
T
ASKS
2009:DB9:2229::240
Since Destination Address
00:04:21 5000:1::3
00:04:50 FE80::203:A0FF:FED6:141D
36-24
36-12
24-2
36-14
36-26
36-10
36-25
36-22
36-27
