the last step, it assigns a v3 user to this group, indicating that MD5 will be
used for authentication, provides the password "greenpeace" for
authentication, and the password "einstien" for encryption.
Console(config)#snmp-server view mib-2 1.3.6.1.2.1 included
Console(config)#snmp-server view 802.1d 1.3.6.1.2.1.17 included
Console(config)#snmp-server group r&d v3 auth mib-2 802.1d
Console(config)#snmp-server user steve group r&d v3 auth md5
greenpeace priv des56 einstien
Console(config)#
For a more detailed explanation on how to configure the switch for access
from SNMP v3 clients, refer to "Simple Network Management Protocol"
on page 5-63, or refer to the specific CLI commands for SNMP starting
on page 21-1.

Managing System Files

The switch's flash memory supports three types of system files that can be
managed by the CLI program, web interface, or SNMP. The switch's file
system allows files to be uploaded and downloaded, copied, deleted, and
set as a start-up file.
The three types of files are:
• Configuration — This file type stores system configuration
information and is created when configuration settings are saved.
Saved configuration files can be selected as a system start-up file or can
be uploaded via TFTP to a server for backup. The file named
"Factory_Default_Config.cfg" contains all the system default settings
and cannot be deleted from the system. If the system is booted with
the factory default settings, the master unit will also create a file named
"startup1.cfg" that contains system settings for stack initialization,
including information about the unit identifier, MAC address, and
installed module type for each unit the stack. The configuration
settings from the factory defaults configuration file are copied to this
file, which is then used to boot the stack. See "Saving or Restoring
