Table 8-2 LACP Internal Configuration Information (Continued)
Field
Admin State,
Oper State
Description
Administrative or operational values of the actor's state
parameters:
• Expired – The actor's receive machine is in the expired state;
• Defaulted – The actor's receive machine is using defaulted
operational partner information, administratively
configured for the partner.
• Distributing – If false, distribution of outgoing frames on
this link is disabled; i.e., distribution is currently disabled and
is not expected to be enabled in the absence of
administrative changes or changes in received protocol
information.
• Collecting – Collection of incoming frames on this link is
enabled; i.e., collection is currently enabled and is not
expected to be disabled in the absence of administrative
changes or changes in received protocol information.
• Synchronization – The System considers this link to be
IN_SYNC; i.e., it has been allocated to the correct Link
Aggregation Group, the group has been associated with a
compatible Aggregator, and the identity of the Link
Aggregation Group is consistent with the System ID and
operational Key information transmitted.
• Aggregation – The system considers this link to be
aggregatable; i.e., a potential candidate for aggregation.
• Long timeout – Periodic transmission of LACPDUs uses a
slow transmission rate.
• LACP-Activity – Activity control value with regard to this
link. (0: Passive; 1: Active)
