SMC Networks SMC8848M Specifications

Enterprise Switch
OVERVIEW
SMC Networks' TigerStack II 10/100/1000 Switches are the newest in a
series of "Next Generation" high performance stackable switches that
deliver high scalability, wire-speed Gigabit performance, high availability,
10 Gigabit Ethernet uplinks, and redundant power options. These switches
are the first to include both IPv4 and IPv6 Management options enabling
future proofed flexibility and maintainability.
The TigerStack II 10/100/1000 SMC8824M/SMC8848M stacks up to 8
units in a stack, providing up to 384 Gigabit ports. A stack can
be created with either of the 24 or 48 port switches, providing
unprecedented flexibility. It provides up to 48 built-in copper Gigabit ports,
including (4) Combo SFP ports supporting either copper links or SFP
adapters for easy, flexible connection to fiber-based Gigabit media and a
switching capacity of up to 176Gbps. The 2 10G module slots on the rear of
the switch provide support for XFP 10G connections. These provide high
bandwidth connections to the core of a network and are in additon to the
2 stacking connectors giving high capacity connections to the other units
in the stack.
FEATURES
High-port density and migration protection in a small footprint
Advanced Management Support
Layer 3 support via RIPv1/2 and Static routing
QoS
VLAN with GVRP and 802.1v
IGMP Snooping
MultiLink Trunking with LACP
Comprehensive security support
Redundant Power Supply
www.smc.com
SMC8824M / SMC8848M
TigerStack II 1000 Stackable 24/48 10/100/1000
Managed Layer 2 Switch with 2 x 10G Uplink slots
The SMC8824M/SMC8848M switches feature a variety of network
management options for both IPv4 and IPv6: console CLI, telnet, web,
SNMPv1/v2/v3, RMON, TFTP, Port Mirroring, BootP, and DHCP. It also
supports a variety of advanced traffic management options including:
802.1x, Bandwidth Control, Broadcast Storm Control, and support for IGMP
Snooping v1/v2.
The SMC8824M/SMC8848M supports Layer 3 and Layer 2 networks by
providing RIP v1,v2 and static routing to allow extra flexibility for your ethernet
network and a comprehensive L2/L4 feature set. The L2/L4 feature set
includes QoS/Cos, VLAN, and security features. It supports 8 priority
queues for 802.1p/ToS/DiffServ, with classification and marking based on
MAC SA/DA, IP SA/DA, and/or TCP/UDP. Security features include: 802.1x
(Port Authentication), port security, and Access Control Lists (ACL) based
on MAC address, IP address, and/or TCP/UDP port numbers. It also
provides extensive support for GVRP, 802.1q, and a flexible VLAN
implementation including port, tagged and protocol based VLANs. The
SMC8824M/SMC8848M is the latest example ofSMC's continued
commitment to our channel partners and customers to be the industry
leader in cost-effective, reliable, high performance, feature-rich switches.
BENEFITS
Supports 24 or 48*10/100/1000Mbps including 2 stacking ports
and 2 optional 10G uplink slots in a 1RU chassis
Introduces IPv6 Management support to enhance the standard
IPv4 management interfaces.
Allows Layer 3 edge networks to be implemented without the need
for a hardware upgrade
Support eight levels of priority, with weighted fair queuing and
L2/3/4 IP precedence--ensures smooth transmission of mission
critical data
Support VLANs based on frame tags or ports, plus support for
automatic GVRP LAN registration spanning tree per VLAN--pro-
vides maximum security and bandwidth efficiency
Only allows IP Multicast traffic transmission to the registered
members, resulting bandwidth savings--reduce IP multicast traffic
and increase LAN performance
Can group links between switches to provide higher
bandwidth of up to 16Gbps
Currently supports RADIUS, IEEE802.1x, SSH, SSL,TACACS+, ACL
Provides backup power in case of power failure
Unmanaged
Smart
Managed
Enterprise
