Figure 6-2 Authentication Server Settings - SMC Networks TigerStack II SMC8848M Management Manual

U A
SER UTHENTICATION
Web – Click Security, Authentication Settings. To configure local or
remote authentication preferences, specify the authentication sequence
(i.e., one to three methods), fill in the parameters for RADIUS or
TACACS+ authentication if selected, and click Apply.
CLI – Specify all the required parameters to enable logon authentication.
Console(config)#authentication login radius
Console(config)#radius-server port 181
Console(config)#radius-server key green
Console(config)#radius-server retransmit 5
Console(config)#radius-server timeout 10
Console(config)#radius-server 1 host 192.168.1.25
Console(config)#exit
Console#show radius-server
Remote RADIUS server configuration:
Global settings:
Communication key with RADIUS server: *****
Server port number:
Retransmit times:
Request timeout:
6-6

Figure 6-2 Authentication Server Settings

181
5
10
