Example
The following example shows how to display information for VLAN 1:
Console#show vlan id 1
VLAN ID:
Type:
Name:
Status:
Ports/Port Channels:
Console#

Configuring Private VLANs

Private VLANs provide port-based security and isolation between ports
within the assigned VLAN. This section describes commands used to
configure private VlANs.
Command

pvlan

show pvlan
pvlan
This command enables or configures a private VLAN. Use the no form to
disable the private VLAN.
Syntax
pvlan [up-link interface-list down-link interface-list]
no pvlan
• up-link – Specifies an uplink interface.
• down-link – Specifies a downlink interface.
Default Setting
No private VLANs are defined.
1
Static
DefaultVlan
Active
Eth1/ 1(S) Eth1/ 2(S) Eth1/ 3(S) Eth1/ 4(S) Eth1/ 5(S)
Eth1/ 6(S) Eth1/ 7(S) Eth1/ 8(S) Eth1/ 9(S) Eth1/10(S)
Eth1/11(S) Eth1/12(S) Eth1/13(S) Eth1/14(S) Eth1/15(S)
Eth1/16(S) Eth1/17(S) Eth1/18(S) Eth1/19(S) Eth1/20(S)
Eth1/21(S) Eth1/22(S) Eth1/23(S) Eth1/24(S)

Table 30-6 Private VLAN Commands

Function
Enables and configured private
VLANS
Displays the configured private
VLANS
C P
ONFIGURING
VLAN
RIVATE
Mode Page
GC 30-17
PE 30-18
30-17
S
