Optional Accessories - MICRO-EPSILON optoCONTROL 2700 Operating Instructions Manual

11

Optional accessories

PC/SC2700-x
CE2700-1
PC/SC2700-3/IF2008
SCD2700-x
SCD2700-5 M12
SCA2700-x
IF2001/USB
IC2001/USB
IF2035-EtherCAT
IF2035-PROFINET
IF2035-EIP
PS2020
Minimum bending radius (permanently flexible) min. 7.5 x outer cable diameter
[11]
optoCONTROL 2700
Cable for power supply, RS422 and synchronization; one
side 12-pin socket M12, other side open ends; cable length x
= 3 m, 5 m, 10 m, 20 m
[11]
Transmitter-receiver extension cable, cable length 1 m
Interface and supply cable for connection to the IF2008/PCIE
interface card or the IF2004/USB 4-way converter; cable
length 3 m
[11]
Digital output cable for connection to an Ethernet/ EtherCAT
interface; with a 4-pin M12 male connector on one side and
an RJ45 male connector on the other; cable length x = 3 m,
5 m, 10 m, 20 m
Digital output cable, 5 m long, for connection to an Ethernet/
EtherCAT interface (with a 4-pin M12 round male connector
on both sides), drag chain-compatible
Cable for analog output, switching inputs and outputs; one
side 17-pin plug M12, other side open ends; cable length x =
3 m, 5 m, 10 m, 20 m
IF2001/USB single-channel RS422/USB converter
IC2001/USB single-channel RS422/USB converter cable
Interface module for connection to EtherCAT, PROFINET, or
EtherNet/IP of a Micro-Epsilon sensor with RS485 or RS422
interface; suitable for cable PC/SC2700-x, top-hat rail hous­
ing, incl. GSDML file for software integration into the PLC
Power supply unit for DIN rail mounting
Input 230 VAC, output 24 VDC/2.5 A
Optional accessories
Seite 78
