5.
Laser Class
The gapCONTROL 2711 sensors operate with a semiconductor laser having a wavelength
of 658 nm (visible/red). The laser operation is indicated visually by the LED on the sensor.
Laser Class 2M
The gapCONTROL 2711 sensors with a maximum laser power up to 10 mW are classified
in Laser Class 2M (IIM). The following information labels are fitted to the sensor housing
(front and rear side).
i
If both information labels are hidden in the installed state, the user must ensure that
additional labels are fitted at the point of installation.
IEC 60825-1: 2008-05
65W
2
Hazard to the eye via laser radiation! Consciously close your eyes
or turn away if the laser radiation impinges on the eye.
Lasers of Class 2M are not subject to notification and a laser protection officer is not
required. Mark the laser area recognizable and everlasting.
Laser Class 3B
The gapCONTROL 2711 sensors with a maximum laser power up to 20 mW are classified
in Laser Class 3B (IIIB).
Injury to the eye or the skin via laser radiation! Consciously close
your eyes or turn away if the laser radiation impinges on the eye or
the skin.
Class 3B (IIIB) laser sensors are notifiable and a laser protection officer is required either.
During operation the laser area has to be restricted and marked. The following information
label should be fitted to the sensor housing (front and rear side):
Laser radiation
Avoid exposure to the beam
i
Class 3B Laser Product
Sensors of Laser Class 3B (IIIB)
IEC 60825-1: 2008-05
need an external key switch
P50 mW; =658 nm
to switch off the laser, see
Chap. "Laser switching".
Beam attenuator
The beam attenuator prevents access to all
laser and collateral radiation. The figures show
the sensor with closed and open beam attenu-
ator. The beam attenuator must be open during
measurement.
6.
Connections, LED Displays
laser on
state
1394/
Ethernet
1394/Ethernet
24 VDC
RS 422
RS 422
gapCONTROL 2711-x, top side
gapCONTROL 2711-x(001), rear
side
The sensors are available in two versions: Sockets on the top side or on the rear side.
LED displays
LED "laser on"
Green: Laser on
Note: The "status" LED flashes
green; long during active data
LED "state":
Green: Measurement
transmission and short for
Two-color LED
Green flashing: Data transmission
controller accesses.
(red / green)
Red flashing: Error code
The state LED indicates different error conditions by flashing. If no flashing occurs for
several seconds, no error has occurred.
Power supply (Power)
Pin
Range: 11 V – 30 V
Assignment connector "24 VDC"
no.
(Rated value 24 V)
Standard
DC;
Options 002, 003, 004, 005
Color PC2700;
maximum current
Color PC2700(002)
old version in ( )
500 mA
1
24 V+
white
(red)
24 V+
pink
1
2
Laser help
n.c.
LH+
gray
2
n.c.
3
3
Laser on/off
n.c.
Laser off+
yellow
4
Laser on/off
n.c.
Laser off-
green
View on solder pin
n.c.
side, male cable
connector, counting
5
Laser help
n.c.
LH-
brown
direction
(black
anticlockwise
6
24 V GND
brown
24 V GND
white
or blue)
The power supply is also possible using the FireWire connection cable, if the power sup-
ply needed is present in the PC with sufficient current intensity. When both voltages (1394
and power) are present, the higher voltage always takes over the supply of the sensor.
External laser switching
Series gapCONTROL 2711-x(002), gapCONTROL 2711-x(003), gapCONTROL 2711-
x(004) and gapCONTROL 2711-x(005) offer this function.
i
Sensors of Laser Class 3B (IIIB) need an external key switch to switch off the laser.
Use a serial key switch inside the control circuit to switch off the laser. You will find
details for the wiring in the instruction manual, Chap. 5.2.4.
RS422, Synchronization
24 VDC
Pin no.
Assignment connector "RS422"
RS422
General
9-pin Sub-D
1
2
1
RX1
CH1
2
2
/RX1
/CH1
3
5
GND1
5
3
TX2
CH2
9
View on solder
pin side, male
4
/TX2
/CH2
1
cable connector
6
GND2
5
The RS422 port can be used with either of the following configurations:
- RS422: Loading of programs and transmitting of measurement results (ASCII format).
- Synchronization/Triggering: Synchronization resp. triggering using switching signals.
Optional RS422 interface cable (SC2700-4,5RS422) from Micro-Epsilon, compatible to
1)
the RS422 to USB converter. All outputs or inputs are designed symmetrically. Internal
terminating resistors 120 Ohm.
7.
gapCONTROL 2711 with gapCONTROL Output Unit for Connection to an SPS
6
IEEE 1394
01 02
PHY
A
5
ISO
B
ASYN
24V 0V
4
I/O
+ +
01 02 03 04
- -
PE PE
OU Fieldbus Coupler
FireWire connection (1394), standard link to the PC
8-pin connector, ODU
Pin no. Assignment
1
GND_FireWire
2
TPA+
3
TPA-
4
Screen
5
TPB-
6
TPB+
The Pin numbers refer to
1
6
the gapCONTROL 2711
7
Screen
unit.
5
8
+24 V_FireWire
Micro-Epsilon recom-
3
4
mends the use of the
interface cable SC2700-
4.5 RS422 from the
optional accessories.
View on solder pin side ODU
The gapCONTROL 2711 sensor can also be supplied with operating voltage from the PC
on the 1394 connection socket. If its capacity is not sufficient, an appropriate voltage must
be connected to the 24 VDC socket.
Use the recommended FireWire connection cable.
A power supply via free cores in the FireWire connection cable is possible if these wires
are connected in the PC (Pin 1 to +8 ... 30 VDC, typically 12 VDC; Pin 2 to ground on the
FireWire connector).
Status voltage supply
- Power jumper contacts
13 14
Status
13 14
Status
- System
DO 1
DO 2
A
C
C
B
DO 8
D
D
DO 7
Data contacts
Data contacts
+
Ñ
A1 A2
System supply (OUT)
24 V
DO 1
DO 2
0 V
+
+
A3 A4
Supply via power
jumper contacts
DO 3
D0 4
24V
-
-
A5 A6
0 V
D0 6
DO 5
+
-
A7 A8
System supply (In)
24 V
DO 7
DO 8
0 V
750-626
Power jumper contacts
750-536
Power jumper contacts
OU-Filter
Digital output module
6-pin connector,
Connector "1394"
Pin no. Assignment
The Pin numbers refer to the
gapCONTROL 2711 unit.
2
GND_FireWire
Micro-Epsilon recommends
4
TPB+
using the FireWire con-
3
TPB-
nection cable SC2700-4.5
2
GND_FireWire
FireWire from the recom-
mended accessories.
5
TPA-
6
TPA+
2
GND_FireWire
1
+24 V_FireWire
View on solder pin side
FireWire
13 14
Function
A
A
C
C
Error
B
B
D
D
A1 A2
Data contacts
AO 1
AO 2
M M
0
V
0
V
A3 A4
AO 3
AO 4
M
M
0
V
0
V
750-555
Power jumper
750-600
contacts
Analog output module
Bustermination
