10.
Incorrect disposal may cause harm to the environment.
11.
PS2020
CE1202-2
CE1202-5
SCD1202-2-RS232
SCD1202-5-RS232
SCD12xx-2-USB
SCA1202-2
SCA1202-5
ODC1202-L100
ODC1202-L200
ODC1202-L500
EK1100/CSP2008
EL3162/CSP2008
CSP2008
Further length are available on demand.
optoCONTROL 1202
Decommissioning, Disposal
Disconnect the power supply and output cable on the light source and receiver.
Dispose of the device, its components and accessories, as well as the packaging materials in compli-
ance with the applicable country-specific waste treatment and disposal regulations of the region of use.
Optional Accessories
Power supply (mounting on DIN-rail), output 24 VDC, input 240 VAC,
switchable for 110 VAC
Connection cable transmitter/receiver, length 2 m
Connection cable transmitter/receiver, length 5 m
Digital output cable for connection to an interface RS232, length 2 m
Digital output cable for connection to an interface RS232, length 5 m
Digital output cable incl. driver, length 2 m
Power supply and output cable, length 2 m
Power supply and output cable, length 5 m
Mounting rail for ODC1202, 400 mm; distance light source/receiver max. 100 mm
Mounting rail for ODC1202, 500 mm; distance light source/receiver max. 200 mm
Mounting rail for ODC1202, 800 mm; distance light source/receiver max. 500 mm
Bus terminal
Bus terminal; 2-channel analog input terminal
Universal controller for displacement sensors
Page 33
