Fig. 4.1: Connector assignment
i
Unnecessary connections must be fitted with protective caps in order to achieve the possible IP protec
tion class.
4.3.3
Connection options
Source
Cable/power supply
Receiver ODC2700
Empfänger ODC2700
Empfänger ODC2700
PS 2020
Fig. 4.2: Connection examples with the optoCONTROL 2700
optoCONTROL 2700
Light source
Interface
PCSC2700-x
SCD2700-3
IF2001/USB
IC2001/USB
IF2008/PCIE
Included in delivery
Terminal
IF2035-PROFINET
IF2030-EtherCAT
IF2035-EIP
Ethernet
USB
USB
PC
Sensor supply is done
Sensorversorgung erfolgt
Sensorversorgung erfolgt
by peripheral.
durch Peripheriegerät.
durch Peripheriegerät.
Installation and Assembly
SPS
Seite 22
