6.3.2

Measuring program

Initial setup on booting (sensor startup): A favorite setting can be selected from the setups for automatic activation on
sensor startup. If no favorite has been identified from the setups, the sensor starts with the most recently saved settings/
setup or the sensor activates the web edge preset.
Preset Active
Tilt correction
Strip edge No
Wire measure­
ment
Diameter Yes
Contour measure­
ment
Multi-segment Yes
Gap measurement Yes
Fig. 6.1: Overview of factory settings for the presets and their measuring program
Selecting preset or setup
► Switch to the
Home
measurement task.
Here you can adapt a measuring program.
Measuring pro­ Search direction Standard
gram
Falling edge Sensor searches for a light-dark transition,
start is SMR
Rising edge Sensor searches for a dark-light transition,
start is SMR
Diameter Sensor searches for the first light-dark and the
last dark-light transition, start is SMR
Gap Sensor searches for the first dark-light and the
next light-dark transition, start is SMR
Segment Sensor searches for all dark-light and light-
dark transitions, start is SMR
Fig. 6.2: Edge assignment for the measuring programs
Don't forget to save!
► Save individual adjustments to the measurement programs in a
optoCONTROL 2700
Measuring program
Falling edge
Diameter
Segment
Gap
>
Measurement configuration
Search direction
Standard
tab and select a preset or individual setup suitable for the
Search direction Reverse
Sensor searches for a light-dark transition,
start is EMR
Sensor searches for a dark-light transition,
start is EMR
Sensor searches for the first light-dark and the
last dark-light transition, start is EMR
Sensor searches for the first dark-light and the
next light-dark transition, start is EMR
Sensor searches for all dark-light and light-
dark transitions, start is EMR
setup, see Chap.
Advanced Settings
Measurement direc­
tion
Standard
6.7.2.
Seite 43
