Attachment to Mounting Rail

The sensor unit – comprising the light source, receiver, and mounting rail – is preassembled.
The mounting rail ensures that the components are correctly aligned with one another.
Messebene 22 Measurement
plane 22 (.87)
+0,04 +0.04
ø4D7 ø4D7 E E
+0.03 +0,03
6x
6x
8,10 13 8.10 13
57
57
(2.24)
11 (.43)
11
Fig. 4.2: Dimensional Drawing of Light Source and Receiver with Mounting Rail, Dimensions Stated in mm
i The mounting rail must be attached without bending or twisting it.
A horizontal measurement setup is preferable because it results in less soiling of the optical windows.
Mounting Rail, Standard Attachment Method
► Ideally, you should mount the mounting rail so that it lies flat against the four M5 mounting holes (highlighted in
blue).
Fig. 4.3: Dimensional Drawing of Mounting Rail, Standard Mounting Method
optoCONTROL 2700
Measuring distance 150 (5.91)
Messabstand 150
250 (9.84) 250
185 (7.28) 185
80 80 (3.15)
40 40
(1.57)
4x ø6,6 4x ø6.6 4x M5 4x M5
ø11 6.4 ø11 6,4 ø9,5 4 ø9.5 4
140 (5.51)
140
280 (11.0) 280
532 (20.9)
532
(658,5) 658.5 (25.9)
490 490 (19.3)
383.5 (15.1)
383,5
80 80 (3.15)
40 40
(1.57)
140 (5.51)
140
280 (11.0) 280
4x M5 4x M5
ø8 4 ø8 4
+0.04
+0,04
ø4D7 ø4D7
+0.03
+0,03
60 (2.36)
60
4x M5 4x M5
ø8 4 ø8 4
