12.10.11

List of Edge Filter Signals

META_EDGEFILTER1SIGNAL
META_EDGEFILTER2SIGNAL
Lists all the available signals that can be selected for the EDGEFILTER1SIGNAL and EDGEFILTER2SIGNAL com­
mands.
12.10.12

Switching the LED On and Off

LED OFF | ON
Switches the LED on or off.
12.11

Edit measured value

12.11.1

Tilt Correction

TILTCORRECTION [ON|OFF]
Switches tilt correction on (ON) or off (OFF).
12.11.2

Calculation, Computing Module, Averaging

COMP [<id>]
COMP <id> MEDIAN <signal> <median data count>
COMP <id> MOVING <signal> <moving data count>
COMP <id> RECURSIVE <signal> <recursive data count>
COMP <id> CALC <factor1> <signal> <factor2> <signal> <offset> <name>
COMP <id> THICKNESS <signal> <signal> <name>
COMP <id> COPY <signal> <name>
COMP <id> NONE
The COMP command can be used to display, create, adjust, or delete individual settings for data processing and calcula­
tion processes. The MEDIAN, MOVING, and RECURSIVE averaging functions affect the <signal> output signal.
Value Meaning
id 1 ... 10
signal A measurement data signal (see META_COMP)
median data count 3|5|7|9
moving data count 2|4|8|16|32|64|128|256|512|1024|2048|4096
recursive data count 2 .. 32767
factor 1 -32768.0 .. 32767.0 (unit mm)
factor 2 -32768.0 .. 32767.0 (unit mm)
offset -2147.0 .. 2147.0 (unit mm)
name The name of the new signal. Names must have at least 2 characters and can contain a maximum of 5. The
following characters are permitted: a-zA-Z0-9_. Each name must begin with a letter of the alphabet: a-zA-Z.
Some names are not allowed, e.g., STATISTIC, MASTER, NONE, ALL.
List of predefined functions:
MEDIAN: Sorts the last <median data count> values and outputs the middle value. Useful, for example, for eliminating
●
spikes.
MOVING: Outputs an average of the last <moving data count> values.
●
