6.2.3.2
Interpolation
Interpolation increases the resolution of an encoder. The counter reading is incremented or decremented with each inter
polated pulse edge.
A
B
1
Fig. 6.1: Encoder Signal Pulse Image, Single Resolution, Add Up (Left), Decrease (Right)
A
B
1
2
Fig. 6.2: Encoder Signal Pulse Image, Single Resolution, Add Up (Left), Decrease (Right)
A
B
1
2
3
4
Fig. 6.3: Encoder Signal Pulse Image, Quadruple Resolution, Add Up (Left), Decrease (Right)
6.2.3.3
Effect of Reference Track
effect. The encoder counter keeps on counting; the resetting takes place when the sensor/controller is switched on
No
or when the
Set to value
Set to value once for
reached. The applicable mark is the first one after sensor/controller switch-on.
marks. Sets the encoder counter to the start value in the case of all marks.
Set for all
A
B
Ref
Fig. 6.4: Reference Signal of an Encoder
6.2.3.4
Set to Value
This function sets the encoders to this value
every time the controller is switched on,
●
with the Set to value button.
●
The start value must be less than the maximum value and is max. 4,294,967,294 (2^32-2).
6.2.3.5
Reset Reference Marker
Resets the reference marker detection.
optoCONTROL 2700
2
3
4
5
6
7
8
button is pressed.
mark. Sets the encoder counter to the defined value when the first reference marker is
34
33
34
33
32
34
33
32
31
30
29
31
28
27
Advanced Settings
