2.6

Technical Data

Model
Measurement area
Min. target size
Distance light source - receiver
Measuring distance target - receiver
Sampling rate
[1]
Measuring rate
[2]
Exposure time
[3]
Resolution
[4]
Linearity
[5] [6]
Repeatability
[5]
Light source
Laser class
Permissible ambient light
Supply voltage
Max. current consumption
Signal input
Digital interface
[7]
Analog Output
Switching output
Digital output
Connection
Installation
Temperature range
[8]
Shock (DIN EN 60068-2-27)
Vibration (DIN EN 60068-2-6)
Protection class (DIN EN 60529)
Material
Weight
Measuring programs
Number of measurements taken per second
[1]
Number of measured values that are output at the sensor interface
[2]
With video averaging switched on = 3 x 8.5 µs exposures per measurement
[3]
At the digital interface
[4]
The specified data apply to a constant room temperature of 20°C, after a warm-up time of 30 min | 95% confidence interval for
[5]
diameter measurement when averaging 1024 over a period of 5 minutes in a temperature-stabilized environment
Measured with 2 mm testing pin at a measurement distance of 150 mm in measuring field 1 (Z=±2.5 mm). In measuring field 2 (Z=
[6]
±10 mm) linearity ≤ 3 µm - 95% confidence interval
EtherCAT, PROFINET and EtherNet/IP: Connection either via interface module (see accessories) or as a sensor option
[7]
Relative humidity % 5 ... 95 (non-condensing)
[8]
optoCONTROL 2700
3x inputs optionally for encoder, zero point, reset, trigger; light on/off (can be
Ethernet, RS422 (up to 2 MBaud) EtherCAT, EtherNet/IP, PROFINET
0 ... 10 VDC / 4 ... 20 mA (16 bit, freely scalable within the measuring range)
3 outputs, optionally for errors and 2x limit values, not electrically separated 24V
logic (HTL), high level depends on operating voltage Switchable TTL level
Light source integrated cable 0.8 m, with 8-pin M8 socket for power supply
Receiver 8-pin M12 plug for light source supply, 12-pin M12 socket for power supply and
signals, 4-pin M12x1 socket for Ethernet 17-pin M12 plug for analog sync inputs
Storage
Operation
Light source
Receiver
Mounting rail
Diameter / gap / segment measurement / edge measurement with rising or falling
edge / search and measurement direction / additional detection of edge positions
ODC 2700-40
40 mm
0.3 mm
300 mm
150 (±10) mm
15.0 kHz
5.0 kHz
8.5 µs
10 nm
≤ 1 µm
≤ 0.1 µm
LED turquoise 508 nm (blue-green)
no laser, LED according to DIN EN 62471 risk group 0
30,000 lx indirect; 5000 lx direct irradiation
11 ... 30 VDC
≤ 1 A
switched off via menu)
Synchronization
(trigger/encoder)
integrated mounting rail with mounting holes
-20 ... +70 °C
0 ... +50 °C
15 g / 6 ms in XY axis, 100 shocks each
2 g / 20 ... 500 Hz in XY axis, 10 cycles each
IP67
Aluminum housing
approx. 500 g
approx. 1400 g
approx. 1000 g
and center axes
