Data Format of RS422 Interface

Video Signal
Description Bit 7
Pixel 1 (14 bits)
Pixel n (14 bits)
Pixel 512 (14 bits)
Footer
Output value
Description Bit 7
Measured value
(32 bits)
Footer
12.16.3

Output values, data type and unit

Parameter Signal
MEASRATE Sample rate
TIMESTAMP Time stamp
COUNTER Measurement frame counter
STATE Status word
RAW Raw signal
(2048 x 16 bits)
RAW2D reduced 2D raw signal
(512 x 128 pixels * 1 bit
LIGHT Light-corrected signal
(2048 x 16 bits)
optoCONTROL 2700
Bit 6
1
0
1
0
1
0
0 0
Bit 6
1
1
1
0
0 0
0 0
Bit 5 Bit 4
D00 ... D06
D07 ... D13
D00 ... D06
D07 ... D13
D00 ... D06
D07 ... D13
0 0
Bit 5 Bit 4
D00 ... D06
D07 ... D13
D14 ... D20
D21 ... D27
0 0
0 0
Data type / Value range
unit32_t
2000 ... 100000
unit32_t
0 ... 2^32 - 1
unit32_t
0 ... 2^32 - 1
unit32_t
0 ... 2^32 - 1
0 ... 1023
0 ... 1
0 ... 1023
Bit 3 Bit 2
0 0
Bit 3 Bit 2
D28 ... D31
0 0
Scaling
10000 / value
value
Bit 0: Status switching output 3
Bit 1: Switching output 3 active
Bit 3: Encoder 1 track index status
Bit 4: Encoder status 1 track B
Bit 5: Encoder status 1 track A
Bit 7: Trigger
Bit 8: Status switching output 1
Bit 9: Switching output 1 active
Bit 10: Status switching output 2
Bit 11: Switching output 2 active
Bit 12: Sync/Trig active
Bit 13: Status Sync/Trig
Bit 14: Synchronization error
Bit 15: Triggered frame
Bit 24: Status LED
Bit 26: Ethernet link LED
Bit 27: Ethernet speed LED
value / 1024 * 100
View LSB as the first pixel of the im­
age
value / 1024 * 100
ASCII Communication
Bit 1 Bit 0
1 0
Bit 1 Bit 0
0 0
Unit
kHz
µs
%
Bright
pixel
%
