MICRO-EPSILON optoCONTROL 2700 Operating Instructions Manual page 35

Fig. 5.2: Excerpt from Web Interface, Home Tab
For all presets, the averaging function can be customized for the measurement task by moving the
slider control.
In the signal quality section, you can switch between three basic settings (static, balanced, or dynamic). The reaction in
the chart and system configuration is immediately visible.
i If the sensor starts up with a set of user-specific measurement settings (a setup), the signal quality can­
not be changed.
i After parameterization, permanently save all settings in a parameter set so that they will be available
again the next time you switch on the sensor. To do this, use the
optoCONTROL 2700
You can select a preset in the tab
>
●
Home
You can select a setup in the tab
>
●
Home
●
Settings
measurement settings
A maximum of 8 setups can be permanently saved in the sensor.
Preset Averaging, measuring rate
Web edge Static
Balanced
Dynamic
Wire measure­ Static
ment
Balanced
Dynamic
Diameter Static
Balanced
Dynamic
Contour measure­ Static
ment
Balanced
Dynamic
Multi-segment Static
Balanced
Dynamic
Gap measurement Static
Balanced
Dynamic
Measurement configuration
Measurement configuration
in the menu
System settings > Load & Save
Moving with 8 values; 2.5 kHz
Moving with 8 values; 2.5 kHz
Moving with 8 values; 2.5 kHz
Moving with 128 values; 5 kHz
Moving with 64 values; 5 kHz
Median with 9 values; 5 kHz
Moving with 128 values; 2.5 kHz
Moving with 64 values; 2.5 kHz
Median with 9 values; 2.5 kHz
Moving with 128 values; 2.5 kHz
Moving with 64 values; 2.5 kHz
Median with 9 values; 2.5 kHz
No averaging; measuring rate 2 kHz
calculation function
Thickness
= center of segment 2 - center of segment 1
Thickness
Moving with 128 values; 2 kHz
Moving with 64 values; 2 kHz
Median with 9 values; 2 kHz
Signal quality
button.
Save settings
Operation
>
Saved
