6.4

Signal Processing

6.4.1

Tilt Correction

The sensor detects tilted targets. The two-dimensional video signal is used to compensate for the resulting measuring
errors.
Empfänger
Receiver
EMR
MBE
MBA
SMR
Fig. 6.8: Measurement Chart for Targets Titled Counterclockwise (Left) and Clockwise (Right)
EMR
MBE
MBE
EMR
MBA
SMR
SMR
MBA
Receiver
Empfänger
Fig. 6.16: Correct: Edges of Target Parallel with Light Curtain (Left), Incorrect Measurement Result due to Rotated Target
(Right)
Upon delivery of the sensor, tilt correction is deactivated (off) by default.
Tilt correction is possible with the following presets:
and
multi-segment,
Activating Tilt Correction
Switch to the tab
Settings > Signal processing > Tilt correction
The tilt correction function can handle a tilt angle of up to ±45° affecting the target.
optoCONTROL 2700
Angle A
Correction
Korrektur
possible
möglich
Correction
Korrektur
not possible
nicht möglich
Receiver
Empfänger
measurement. Tilt correction is likewise possible in setups based on these.
gap
Empfänger
Receiver
EMR
MBE
SMR
MBA
wire measurement, diameter, contour measurement,
Advanced Settings
Angle A
Correction
Korrektur
possible
möglich
and select On.
