6.3.10
Triggering for Data Acquisition
6.3.10.1
General
The acquisition and output of measured values by the sensor can be controlled using an external electrical trigger signal
or commands.
►
The triggering does not affect the preselected measuring rate.
►
The Sync/Trig inputs or multifunction inputs (TrigIn) are used as external trigger
►
Factory setting: No triggering, the sensor starts transmitting data immediately after being switched on.
►
The duration of the trigger signal pulse is at least 5 s.
Sync/Trig / TrigIn
Trigger type
Software
Encoder
optoCONTROL 2700
Level
Edge
inputs, see Chap.
High / Low
Trigger level
Trigger level
Falling edge / rising edge
Manual selection
Number of measured
values
Infinite
Number of measured
Manual selection
values
Infinite
Lower limit
Upper limit
Increment
Advanced Settings
4.3.4.
Value
Value
Value
Value
Value
