Mounting Rail, Optional Attachment Method
►
Mount the mounting rail so that it lies flat against the four M5 mounting holes (highlighted in blue) or
►
Mount the mounting rail so that it lies flat against the four ø6.6 mounting holes (highlighted in blue).
Fig. 4.4: Dimensional Drawing of Mounting Rail, Optional Mounting Method
optoCONTROL 2700
250 (9.84)
250
185 (7.28)
185
4x ø6.6
4x ø6,6
4x M5
4x M5
ø11 6.4
ø11 6,4
ø9.5 4
ø9,5 4
140 (5.51)
140
Installation and Assembly
Seite 18
