INVT Goodrive300-01A Series Operation Manual page 96

Goodrive300-01A series VFD for air compressor
Fault
Fault type
code
OL2 [12] VFD overload
[13] Phase loss on
SPI
input side
[14] Phase loss on
SPO
output side
[15] Overheat of
OH1
rectifier module
[16] Overheat of
OH2
inverter module
EF [17] External fault
[18] 485
CE
communication fault
[19] Current
ItE
detection fault
[20] Motor
tE
autotuning fault
Possible cause
transients

Acceleration is too fast.

The motor is restarted
during rotating.

The grid voltage is too low.

The load is too large.

Phase loss or fluctuation
occurs to input R, S and T.

Phase loss output occurs
to U, V and W (or serious
3PH imbalance occurs to
the load).

Air duct blocked or fan
damaged.

Ambient temperature is too
high.

Long-time overload
running.

S external fault input
terminal acts.

Baud rate is set improperly.

Communication line fault.

Communication address
error.

Communication suffers
strong interference.

Poor contact of controller
board connector.

Hall components are
damaged.

Amplifying circuit is
abnormal.

Motor capacity does not
match VFD capacity.
-91-
Fault information and troubleshooting
Solution

Increase acceleration time.

Restart the motor after stop.

Check grid voltage.

Adopt the VFD with a larger
power.

Select a proper motor.

Check input power.

Check installation wiring.

Check the output wiring.

Check the motor and cable.

Ventilate the air duct or
replace the fan.

Lower down the ambient
temperature.

Check external equipment
input.

Set proper baud rate.

Check the wiring of
communication interface.

Check the wiring of
communication interfaces.

Set correct communication
address.

Replace or change the
wiring to improve
anti-interference capacity.

Check the connector and
re-plug wires.

Replace the hall.

Replace the main control
board.

Change the VFD model.

Set motor type and
