Goodrive300-01A series VFD for air compressor
B.1.5 Fault records
The fault record interface is used to display the fault and alarm information about current device
running. If an alarm is reported, alarm information is displayed. Fault records include VFD faults, air
compressor faults, real-time alarms, and historic alarms.
B.1.5.1 VFD fault interface
This interface displays fault information about the VFD. You can view the current fault and last five
faults.
03.17 16:02:35
Fault records
VFD fault
AirCompressor fault
Real-time alarm
Historical alarm
Return
Figure B-40 Fault record interface
03.17 16:02:35 VFD fault
Type of Current Fault
Type of Last Fault
nd
Type of 2 Last Fault
rd
Type of 3 Last Fault
th
Type of 4 Last Fault
th
Type of 5 Last Fault
Return
03.17 16:02:35
VFD fault
Type of Current Fault:
Current detection fault(ItE)
Return
Figure B-41 VFD fault interface
Home Select
000019
0000xx
0000xx
0000xx
0000xx
0000xx
Home Select
Home
