Goodrive300-01A series VFD for air compressor
Function
Name
code
Running frequency at
P07.33
present fault
Ramp reference
P07.34 frequency at present
Output voltage at
P07.35
present fault
Output current at
P07.36
present fault
Bus voltage at present
P07.37
Max. temperature at
P07.38
present fault
Input terminal status at
P07.39
present fault
21: EEPROM operation fault (EEP)
22: PID feedback offline fault (PIDE)
23: Reserved
24: Running time reached (END)
25: Electronic overload (OL3)
26: Panel communication error (PCE)
27: Parameter upload error (UPE)
28: Parameter download error (DNE)
29–31: Reserved
32: To-ground short circuit fault 1 (ETH1)
33: To-ground short circuit fault 2 (ETH2)
34: Speed deviation fault (dEu)
35: Maladjustment fault (STo)
36: Underload fault (LL)
37: Reserved
38: Phase sequence fault (PSF)
39: 3PH current imbalance of the fan (SPOF)
40: Fan overload (OLF)
41: Encoder offline fault (ENC1O)
42: Encoder reverse fault (ENC1D)
43: Encoder Z pulse offline fault (ENC1Z)
44: Auxiliary pressure too low fault (L-AUP)
45: Handshake failure fault (HAnd)
fault
fault
Description
-49-
Function code description
Default Modify
●
0.00
●
0.00
●
0
●
0.0
●
0.0
●
0.0
●
0
