INVT Goodrive300-01A Series Operation Manual page 104

Goodrive300-01A series VFD for air compressor
A.1 Keypad diagram
Digital display area
Increase/decrease key
Program/exit key
Short-cut multi-function key
A.2 External keypad installation dimensions
Simple keypad bracket
（ 61006-00911)
Appendix A Product dimension
Run key
88.0
57.1
54.3
82.0
Customer installation
dimensions
-99-
Product dimension
Function indicator
Unit indicator
Digital potentiometer
Confirmation key
Right shift key
Stop/fault reset key
