Goodrive300-01A series VFD for air compressor
Function
code
Auxiliary pressure
P15.07
low protection point
P15.08 Dynamic password
Handshake
P15.09
password
P15.10 Handshake timeout
P15.11 Handshake state
Pressure decimal
P15.12
P17 group Status viewing
Function
Name
code
P17.00 Setting frequency
P17.01 Output frequency
Ramps reference
P17.02
frequency
P17.03 Output voltage
P17.04 Output current
P17.05 Motor speed
P17.06 Torque current
P17.07 Excitation current
Name
0.00–20.00MPa
When the auxiliary pressure protection is
enabled (P18.39=1), if the auxiliary pressure is
less than the value set in P15.07, the auxiliary
pressure too low fault is reported.
Note: When the compressor is in the sleeping
state, the auxiliary pressure too low fault is not
judged.
0–9999
Note: The dynamic password is automatically
refreshed every power-on/every 8 hours/every
time a new P15.09 value is written.
0–9999
Note: Handshake password (P15.09) is used to
open or close the handshake protocol.
0–65535s
Note: If the handshake is still not successful
after the time set in P15.10 is reached, the
HAnd fault is reported, and no fault is reported
when P15.10 is set to 0.
0–1
0: The handshake function is disabled.
1: The handshake function is enabled.
0–1
0: Two decimal places
places
1: Three decimal places
0.00Hz–P00.03
0.00Hz–P00.03
0.00Hz–P00.03
0–1200V
0.0–3000.0A
0–65535RPM
-3000.0–3000.0A
-3000.0–3000.0A
Description
Description
-63-
Function code description
Default Modify
○
0.00
●
0000
◎
0000
○
20s
●
0
○
0
Default Modify
●
0.00Hz
●
0.00Hz
●
0.00Hz
●
0V
●
0.0A
●
0 RPM
●
0.0A
●
0.0A
