INVT Goodrive300-01A Series Operation Manual page 83

Goodrive300-01A series VFD for air compressor
Function
Name
code
Input power phase
P19.22
sequence state
State of phase
P19.23 sequence detection flat
P21 group Power-frequency fan protection
Function
Name
code
P21.00 Rated fan current
Current transformation
P21.01
ratio of the fan
Current imbalance
P21.03
coefficient
Calibration coefficient
P21.04 of A phase current of
the fan
Calibration coefficient
P21.05 of B phase current of
the fan
If the VFD enables phase sequence detection
and input phase loss hardware protection,
corresponding fault will be reported when
negative sequence and any phase loss
occurs; otherwise, fault will not be reported.
0: Positive sequence
1: Negative sequence
2: R phase loss
3: S phase loss
4: T phase loss
0: Normal, indicating the flat cable is plugged
in properly
1: Abnormal, indicating the flat cable is not
cable
plugged in
0.0–40.0A
This function code is related to current
detection and overload protection function of
power-frequency fan.
Set to 0 will disable this function.
1.0–4000.0
1.00–3.00
Among the current of three phases of the fan,
if the ratio between max. current and min.
current is larger than P21.03, the VFD
displays fan current imbalance fault.
0.0–150.0%
Actual current=display current*current
calibration coefficient
Note: When restoring to default values, this
value will stay in currently set value.
Description
Description
-78-
Function code description
Default Modify
●
0
●
0
Default Modify
○
0.0A
200
(≤15kW);
○
1000
(≥18.5k
W)
○
3.0
○
100.0%
○
100.0%
