INVT Goodrive300-01A Series Operation Manual page 14

Goodrive300-01A series VFD for air compressor
Product model
GD300-01A-132G-2
GD300-01A-160G-2
GD300-01A-185G-2
AC 3PH 380V(-15%)–440V(+10%)
Product model
GD300-01A-7R5G-4
GD300-01A-011G-4
GD300-01A-015G-4
GD300-01A-018G-4
GD300-01A-022G-4
GD300-01A-030G-4
GD300-01A-037G-4
GD300-01A-045G-4
GD300-01A-055G-4
GD300-01A-075G-4
GD300-01A-090G-4
GD300-01A-110G-4
GD300-01A-132G-4
GD300-01A-160G-4
GD300-01A-185G-4
GD300-01A-200G-4
GD300-01A-220G-4
GD300-01A-250G-4
GD300-01A-280G-4
GD300-01A-315G-4
GD300-01A-350G-4
GD300-01A-400G-4
GD300-01A-500G-4
Note:
 Rated input current is the actually measured result under 380V input voltage; 7.5–11kW and
132–315kW are the actually measured results in cases where there is no DC reactor; 15–110kW
is the actually measured result in cases where there is DC reactor.
 Rated output current is defined as the output current under 380V output voltage.
Output power Input current
(kW)
132
160
185
Output power (kW)
7.5
11
15
18.5
22
30
37
45
55
75
90
110
132
160
185
200
220
250
280
315
350
400
500
Output current
(A) (A)
485 450
545 540
610 620
Input current (A)
25
32
32
37
44
58
72
87
106
140
170
202
265
310
345
385
430
485
545
610
625
715
890
-9-
Product overview
Installation dimension
description
Same as
GD300-01A-250G-4
Same as
GD300-01A-280G-4
Same as
GD300-01A-315G-4
Output current (A)
18.5
25
32
38
45
60
75
92
115
150
180
215
260
305
340
380
425
480
530
600
650
720
860
