B.1.4.2 Working environment interface
The working environment interface displays certain parameters about the running.
Parameter
Ready: indicates the device is not started and it does not encounter an alarm.
Only when the device is in standby state, the device can be started and the device
startup key is valid.
Run: indicates that the device is started and does not encounter an alarm.
Fault: indicates that the master VFD or fan VFD encounters a fault. The fault
Device status
alarm is cleared only after the fault is handled.
Emergency stop: indicates that the emergency stop key is pressed. It is cleared
only after the emergency stop key is reset.
Undervoltage: indicates that the master VFD bus voltage is too low. In this case,
you need to check the input power supply.
03.17 16:02:35
PMSM air compressor system
Software ver:V1.00
ConfigTB ver:V1.00
Figure B-7 Initial interface
03.17 16:02:35
Workspace
Output Freq
P17.01
Hz
Present Pressure
P19.11 Mpa
Present Temp
P19.12
Alarm
Accumulated Run Time
P19.16
h
Alarm
Figure B-8 Working environment
Enter
Device Status
Ready
0.00
0.00
25
Set Menu
0
Set Menu
Description
