INVT Goodrive300-01A Series Operation Manual page 53

Goodrive300-01A series VFD for air compressor
Function
Name
code
High bit of power
P07.15 consumption of the
Low bit of power
P07.16 consumption of the
P07.17 VFD model
P07.18 Rated VFD power
P07.19 Rated VFD voltage
P07.20 Rated VFD current
P07.21 Factory barcode 1
P07.22 Factory barcode 2
P07.23 Factory barcode 3
P07.24 Factory barcode 4
P07.25 Factory barcode 5
P07.26 Factory barcode 6
P07.27 Type of present fault 0: No fault
P07.28 Type of the last fault
Type of the last but one
P07.29
Type of the last but two
P07.30
Type of the last but
P07.31
three fault
Type of the last but
P07.32
four fault
0–65535 kWh (*1000)
VFD
0.0–999.9 kWh
VFD
0: G type
1: P type
0.4–3000.0kW
50–1200V
0.1–6000.0A
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
1: Inverter unit U phase protection (OUt1)
2: Inverter unit V phase protection (OUt2)
3: Inverter unit W phase protection (OUt3)
fault
4: Overcurrent at acceleration (OC1)
5: Overcurrent at deceleration (OC2)
fault
6: Overcurrent at constant speed (OC3)
7: Overvoltage at acceleration (OV1)
8: Overvoltage at deceleration (OV2)
9: Overvoltage at constant speed (OV3)
10: Bus undervoltage fault (UV)
11: Motor overload (OL1)
12: VFD overload (OL2)
13: Phase loss on input side (SPI)
14: Phase loss on output side (SPO)
15: Rectifier module overheat (OH1)
16: Inverter module overheat (OH2)
17: External fault (EF)
18: 485 communication fault (CE)
19: Current detection fault (ItE)
20: Motor autotuning fault (tE)
Description
-48-
Function code description
Default Modify
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
