Goodrive300-01A series VFD for air compressor
Function
Name
code
S4 terminal function
P05.04
selection
S5 terminal function
P05.05
selection
P05.06 Reserved
Input terminal polarity
P05.10
selection
P05.11 Digital filter time
S1 terminal switch-on
P05.14
S1 terminal switch-off
P05.15
S2 terminal switch-on
P05.16
6: Coast to stop
7: Fault reset
8: Running pause
9: External fault input
10–24: Reserved
25: PID control pause
26–39: Reserved
40: Zero out power consumption
41: Maintain power consumption
42: Air filter blockage signal
43: Oil filter blockage signal
44: Separator blockage signal
45: Precision splitter blockage signal
46: External fault 1 (motor overtemperature)
47: External fault 2
48: Reserved
49: Solenoid valve control signal
50: Cooling fan control signal of main motor
51–63: Reserved
This function code is used to set the input
terminal polarity.
When the bit is set to 0, input terminal polarity
is positive;
When the bit is set to 1, input terminal polarity
is negative.
BIT4
S5
Setting range: 0x000–0x1FF
0.000–1.000s
0.000–50.000s
delay
0.000–50.000s
delay
0.000–50.000s
delay
Description
BIT8 BIT7 BIT6
Reserved
BIT3 BIT2 BIT1
S4 S3 S2
-42-
Function code description
Default Modify
0
0
0x000
BIT5
BIT0
S1
0.200s
0.000s
0.000s
0.000s
◎
◎
◎
○
○
○
○
○
