INVT Goodrive300-01A Series Operation Manual page 146

Goodrive300-01A series VFD for air compressor
B.2 TC070A touch screen
B.2.1 Specifications
Category
Hardware
category
Electrical
performance
Environment
requirement
Table B-4 Touch screen specifications
Item
Screen
Resolution
Color
Brightness
Backlight
LCD lifetime
Touch screen
CPU
Memory
RTC
Ethernet
USB port
Program download
method
Serial
communication port
Viewing angle of
LCD
(T/B/L/R)
Rated power
Rated voltage
Power supply
protection
Allowed power
outage
CE & RoHS
Working
temperature
Storage
temperature
UV resistance
7" 16:9 TFT LCD screen
800×480
24 bits
360 cd/m²
LED
50000 hours
4-wire industrial resistance touch screen
600MHz ARM Cortex-A8
128M Flash + 128M DDR3
Real-time clock (embedded)
None
1 USB Slave 2.0 port; 1 USB Host 2.0 port
USB Slave/U disk
COM1: RS232/RS485/RS422
COM2: RS485
COM3: RS232
50'/70'/70'/70'
< 10W
DC24V, allowable working range DC 9V–28V
Surge protection capability
< 5mS
Compliant with EN61000-6-2 and EN61000-6-4
Compliant with RoHS lightning surge ±1kV, group pulse
±2kV
Static contact 4kV, air discharge 8kV
0–50° C
-20–60° C
Disallowed to work under strong UV (such as direct
sunlight)
-141-
External optional accessories
Specifications
