Goodrive300-01A series VFD for air compressor
B.4 Fan control protector
B.4.1 Model instruction
Field Symbol
①
Category
②
Model
Protection
③
current
Note: Only model MCP120-1000 is available for the MCP120 series.
B.4.2 Rated specifications
Product model
MCP100-015
MCP100-1000
MCP120-1000
B.4.3 Terminal description
Terminal
Category
sign
POWER R, S, T
MOTOR U, V, W
Power
supply
MCP100 - 015
①
Description
Product series
Type of current
feedback
Current class
Figure B-69 Pictures of fan protection controller
Rated current (A)
Name
3PH AC input
3PH AC output
24V power
24V
supply
②
③
MCP: Fan protection controller
100: Basic (digital feedback)
120: Enhanced (current analog feedback)
015: Rated current is 1.5A
1000: Rated current is 10A
1.5
10
10
Power frequency input, connected to the grid
Power frequency output, connected to the
motor
Provide 24V power supply to the fan control
protector
-152-
External optional accessories
Content
Type of current feedback
Digital feedback
Digital feedback
Current analog feedback
Terminal function
