INVT Goodrive300-01A Series Operation Manual page 153

Goodrive300-01A series VFD for air compressor
Field
Protection level
Special function
Voltage type
B.3.1.3 Product specification
Category
Network status
detection
Device working
status indicator
Communication
Basic
functions
Remote update
Communication
interface
Parameter setup
Software watchdog Monitor system running status in real-time.
GPRS heartbeat
mechanism
communication
command
System Operating system Preemptive multi-tasking real-time kernel
Symbol Description
⑥
Protection level
Special function
⑦
(multiple letters
are supported)
⑧
Supply voltage
Name
Detect online status automatically and reconnect at offline.
Indicates the device working status by power and network
status indicators.
1: The network status indicator turns off every 800ms (flashes
slowly) if network is not registered.
2. The network status indicator turns off every 3s if network is
registered.
3. The network status indicator turns off every 300ms (flashes
quickly) if GPRS is connected.
IoT communication protocol;
PPP dial protocol;
protocol FTP transmission protocol;
Embedded TCP/UDP protocol.
Auto remote update on system programs via GPRS
Support RS232 commissioning output;
RS485 one-to-many front-end device collection;
GPRS wireless transmission.
Serial baudrate, data bit, stop bit and checkout bits of Modbus
device are configurable.
Monitor server connection in real-time.
GPRS
Enhance AT command set
0: IP00 (No housing);
1: IP20 (wall-mounted housing);
2: IP20 (rail-mounted housing);
6: IP65 (direct-insert housing).
G: With GPS
Standard configuration does not carry GPS
function, this bit is omitted
5: 4.5V–6V
Standard configuration voltage is 10–30V,
this bit is omitted.
Detailed instruction
-148-
External optional accessories
Content
