INVT Goodrive300-01A Series Operation Manual page 65

Goodrive300-01A series VFD for air compressor
P13 group SM control
Function
Name
code
Pull-in current
P13.00
reduction coefficient
Initial magnetic pole
P13.01
detection mode
P13.02 Pull-in current 1
P13.03 Pull-in current 2
Switching frequency of
P13.04
pull-in current
High-frequency
P13.05 superposing frequency
(reserved)
High frequency
P13.06
superposing voltage
P13.08 Control parameter 1
P13.09 Control parameter 2
Maladjustment
P13.11
detection time
High-frequency
P13.12 compensation
coefficient
P14 group Serial communication
Function
Name
code
Local communication
P14.00
address
Communication baud
P14.01
rated setup
Description
0.0–100.0%
0: Do not detection
1: High frequency superposition (reserved)
2: Pulse superposition (reserved)
0.0%–100.0% rated motor current
0.0%–100.0% rated motor current
0.00Hz–P00.03 (max. frequency)
200Hz–1000Hz
0.0–300.0% of the rated motor voltage
0–FFFF
0–300.00
Adjust the responsiveness of the function
used to prevent maladjustment. Increase the
value of P13.11 if load inertia is too large,
however, the response speed will be impacted
if the value is increased.
Setting range: 0.0–10.0s
When the motor runs at rated speed, this
parameter is valid. If motor vibration occurs,
adjust this parameter properly.
Setting range: 0.0–100.0%
Description
1–247, 0 is broadcast address
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
-60-
Function code description
Default Modify
○
50.0%
◎
0
○
20.0%
○
10.0%
○
30.00Hz
◎
500Hz
◎
40.0%
○
0x120
○
5.00
○
0.5s
○
50.0%
Default Modify
○
2
○
4
